Reactive Programming

Reactive Programming

Presentation held at the Parallel Conference in Karlsruhe, Germany, on May 6, 2014. Apart from the slides, the presentation featured a demo of RxJava, highlighting its strengths and some of its current limitations.

Patrick Peschlow

May 06, 2014
Tweet

More Decks by Patrick Peschlow

Other Decks in Technology

Transcript

  1. codecentric AG
    Patrick Peschlow
    Reactive Programming

    View Slide

  2. codecentric AG
    The Challenge
    Users

    View Slide

  3. codecentric AG
    The Challenge
    Users don’t like to wait

    View Slide

  4. codecentric AG
    The Challenge
    Users don’t wait

    View Slide

  5. codecentric AG
    The Challenge
    Many users don’t wait

    View Slide

  6. codecentric AG
    The Challenge
    Many many users don’t wait

    View Slide

  7. codecentric AG
    The Challenge
    Today’s applications don’t cope

    View Slide

  8. codecentric AG
    So we need a Manifesto

    View Slide

  9. codecentric AG
    Reactive Traits
    From: http://www.reactivemanifesto.org

    View Slide

  10. codecentric AG
    Event-driven Trait
    − Asynchronous
    − Synchronous APIs tightly couple client and service (often block)
    − Asynchronous means the client can decide if and where to block
    !
    − Non-blocking
    − Blocking APIs may require large numbers of threads (often coupled to users)
    − Wastes CPU resources (context switches, scheduling)
    − Non-blocking frees threads to do new work
    − Define worker thread pools based on resources
    !
    − Share nothing
    !
    − Loose coupling
    Based on: Roland Kuhn, Jamie Allen. „Reactive Design Patterns“. Manning. Chapter 1 preview.

    View Slide

  11. codecentric AG
    Example Time Scale of System Latencies
    From: Brendan Gregg. „Systems Performance: Enterprise and the Cloud“. Prentice Hall, 2013

    View Slide

  12. codecentric AG
    Futures and Promises
    − Future: A reference to an asynchronously computed value
    !
    − Promise: A future with additional features
    − May be completed in various ways (e.g., by a setter)
    − Enables composition (one promise completes another)
    !
    − (Functional) Reactive Programming
    − Futures and promises taking to the extreme

    View Slide

  13. codecentric AG
    Futures and Promises
    Demo

    View Slide

  14. codecentric AG
    RxJava
    Reactive Extensions for the JVM

    A library for composing

    asynchronous and event-based programs
    using observable sequences
    for the Java VM
    From: http://github.com/Netflix/RxJava

    View Slide

  15. codecentric AG
    Observable
    single items multiple items
    synchronous T  getData() Iterable  getData()
    asynchronous Future  getData() Observable  getData()
    From: http://github.com/Netflix/RxJava/wiki

    View Slide

  16. codecentric AG
    Observable
    From: http://github.com/Netflix/RxJava/wiki
    Iterable (pull) Observable (push)
    T  next() onNext(T)
    throws Exception onError(Exception)
    returns onCompleted()

    View Slide

  17. codecentric AG
    Transformations on Observables
    From: http://netflix.github.io/RxJava/javadoc/rx/Observable.html

    View Slide

  18. codecentric AG
    RxJava
    Demo

    View Slide

  19. codecentric AG
    Transformations on Observables
    From: http://netflix.github.io/RxJava/javadoc/rx/Observable.html

    View Slide

  20. codecentric AG
    Transformations on Observables
    From: http://netflix.github.io/RxJava/javadoc/rx/Observable.html

    View Slide

  21. codecentric AG
    Transformations on Observables
    From: http://netflix.github.io/RxJava/javadoc/rx/Observable.html

    View Slide

  22. codecentric AG
    Transformations on Observables
    From: http://netflix.github.io/RxJava/javadoc/rx/Observable.html

    View Slide

  23. codecentric AG
    Transformations on Observables
    From: http://netflix.github.io/RxJava/javadoc/rx/Observable.html

    View Slide

  24. codecentric AG
    Transformations on Observables
    From: http://netflix.github.io/RxJava/javadoc/rx/Observable.html

    View Slide

  25. codecentric AG
    Transformations on Observables
    From: http://netflix.github.io/RxJava/javadoc/rx/Observable.html

    View Slide

  26. codecentric AG
    Transformations on Observables
    From: http://netflix.github.io/RxJava/javadoc/rx/Observable.html

    View Slide

  27. codecentric AG
    Transformations on Observables
    From: http://netflix.github.io/RxJava/javadoc/rx/Observable.html

    View Slide

  28. codecentric AG
    Transformations on Observables
    From: http://netflix.github.io/RxJava/javadoc/rx/Observable.html

    View Slide

  29. codecentric AG
    Benefits of Observables
    − Life cycle of client and service are decoupled
    !
    − Service API keeps control over its implementation
    !
    − Client decides how its subscription should behave (e.g., timeouts)
    !
    − Note: The „client“ may be another service having its own clients
    − Not necessarily a human or a browser

    View Slide

  30. codecentric AG
    Back Pressure
    − An eager producer can overflow its consumer(s)
    − Due to inversion of control when going from sync to async
    !
    − Consumers need a mechanism for „back pressure“
    − Tell the producer how much data you can handle
    − Similar to, e.g., receiver window in TCP
    From: http://www.reactive-streams.org

    View Slide

  31. codecentric AG
    So are we Reactive yet?
    From: http://www.reactivemanifesto.org

    View Slide

  32. codecentric AG
    Responsive Trait
    − Goal: Achieve bounded latency
    !
    − Parallelize tasks within services
    !
    − Choose algorithms with small variance in execution time
    − Predictable execution time for some target percentile
    !
    − Use explicit and bounded queues
    !
    − Use circuit breakers that monitor target metrics and react on violation
    − fail-fast and reject, return partial results, or delegate to another service
    − e.g., for input queues, reject requests when the queue is full
    Based on: Roland Kuhn, Jamie Allen. „Reactive Design Patterns“. Manning. Chapter 1 preview.

    View Slide

  33. codecentric AG
    Resilient Trait
    − Goal: Service stays available even in the presence of unexpected failures
    − software, hardware, human
    !
    − Distribute the system
    !
    − Use bulkheading
    !
    !
    !
    !
    − Let supervisors handle failure
    − separate failure handling from the actual business logic of the service
    Based on: Roland Kuhn, Jamie Allen. „Reactive Design Patterns“. Manning. Chapter 1 preview.
    From: http://www.reactivemanifesto.org

    View Slide

  34. codecentric AG
    Scalable Trait
    − Goal: Scale up (and down) based on load
    !
    − Distribute requests to various instances of the services
    !
    − The more stateless services, the better
    !
    − Measure load at run time and react accordingly
    − But: No reason to forego capacity planning
    Based on: Roland Kuhn, Jamie Allen. „Reactive Design Patterns“. Manning. Chapter 1 preview.

    View Slide

  35. codecentric AG
    What about Actors?
    − Seem to fulfill the reactive traits much better than reactive programming does
    − Asynchronous, non-blocking, and event-driven by definition
    − Supervisors and „let it crash“
    − Distributed
    − Easily scalable
    !
    − But maybe too „heavyweight“ for some problems within services
    − Often, stateless actors don’t suffice or get highly complex
    !
    − Promising approach: Combine actors and reactive programming
    − Actors for the backbone and cluster „infrastructure“
    − Reactive Programming inside the nodes

    View Slide

  36. codecentric AG
    Conclusion
    − Clear need for reactive applications
    !
    − Well addressed by the actor model and reactive programming approaches
    !
    − Building reactive applications requires different thinking
    !
    − Helped by various reactive frameworks, in particular on the JVM
    !
    − Brings up the topic of essential complexity vs. incidental complexity

    View Slide

  37. codecentric AG
    Frameworks
    − Reactive Extensions (Rx)

    http://rx.codeplex.com
    !
    − RxJava

    http://github.com/Netflix/RxJava
    !
    − Akka

    http://akka.io
    !
    − Vert.x

    http://vertx.io
    !
    − Reactor

    https://github.com/reactor/reactor

    View Slide

  38. codecentric AG
    Resources
    − Reactive Manifesto

    http://www.reactivemanifesto.org
    !
    − Reactive Streams

    http://www.reactive-streams.org
    !
    − Conference „React 2014“

    http://reactconf.com

    http://www.youtube.com/user/reactconf
    !
    − Online course on Reactive Programming

    http://www.coursera.org/course/reactive
    !
    − Roland Kuhn, Jamie Allen. „Reactive Design Patterns“. Manning. Currently in writing.
    !
    − Michael Nygard. „Release It!“. Pragmatic Bookshelf. 2007.

    View Slide

  39. codecentric AG
    Questions?
    Dr. rer. nat. Patrick Peschlow

    codecentric AG

    Merscheider Straße 1

    42699 Solingen


    tel +49 (0) 212.23 36 28 54

    fax +49 (0) 212.23 36 28 79

    [email protected]

    www.codecentric.de

    View Slide

  40. codecentric AG
    Bonus: What does this mean for my (Big) Data?
    − If reactive applications focus so much on availability, what about consistency
    − CAP suggests you need to choose between C and A
    !
    − But: Even with CAP you can have C and A most of the time
    − You just need to have a reliable strategy for detecting and handling partitions
    − http://www.infoq.com/articles/cap-twelve-years-later-how-the-rules-have-changed
    !
    − Note: There is also a „Reactive Programming“ in the context of databases
    − http://www.espressologic.com/reactive-programming-database-logic/
    − Don’t confuse it with the „Functional Reactive Programming“ we have seen

    View Slide
