sort-hash-pgconfus-2017

 sort-hash-pgconfus-2017

Video: https://www.youtube.com/watch?v=aic_9KNwKn0

PostgreSQL 9.5 and 9.6 significantly improved upon the performance of both hash joins, and sort operations. Sorts are often used as input to GroupAggregate nodes and merge joins. While both approaches have various strengths and weaknesses, and are essential components of the PostgreSQL executor, their relative importance has somewhat shifted over the years. This happened due to trends in CPU and storage performance characteristics, and various improvements that gradually made their way into Postgres.

Capabilities expected to be part of PostgreSQL 10 may further complicate this picture; parallel hash join and parallel sort add another dimension that must be considered. This may force us to further revise the "Sort vs. Hash" analysis in the coming years.

In this talk, I'll discuss:

* Why merge joins may be faster than hash joins for particular cases, and vice-versa. (Nested-loop joins will be briefly discussed.)

* Improvements that have been made in both areas, and improvements that are tentatively scheduled for the next Postgres release.

* How to conceptualize both approaches, to understand why the optimizer may prefer one or the other of the two general approaches in practice.

* A historical perspective: the waxing and waning of sort merge join since the 1970s.

Peter Geoghegan

March 29, 2017
Tweet

More Decks by Peter Geoghegan

Other Decks in Technology

Transcript

  1. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Sort vs. Hash: A Duality PGConf US — March

    29, 2017 Peter Geoghegan (Twitter: @petervgeoghegan) PMS COOL GRAY 11 BLACK
  2. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Presentation Overview 1. Preamble on Nested Loop Join Why

    it’s very different to hash based or sort based algorithms. 2. Duality of Sort-Merge Join and Hash Join Introduction to both algorithms. 3. The introduction and popularization of Hash Join Why hash joins became popular in late 1980s/early 1990s. 4. Parallelism, memory bandwidth, and the future New era, same old pressures. 5. Duality between Sorting and Hashing revisited Central idea of the presentation, in summary. 2
  3. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Image generated using experimental Graphiz Postgres B-Tree visualization tool

    — Heikki Linnakangas Preamble — what makes Nested Loop Join special among join algorithms 1 L 11 61 61 61 31 33 32 2 L 11 61 61 61 31 36 35 4 L 11 61 61 61 31 39 38 5 L 11 61 61 61 32 33 31 3 6 L 11 61 61 61 32 36 34 7 L 11 61 61 61 32 39 37 8 L 11 61 61 61 33 33 30 9 L 11 61 61 61 33 36 33 10 L 11 61 61 61 33 39 36 11 L 11 61 61 61 34 32 39 12 L 11 61 61 61 34 36 32 13 L 11 61 61 61 34 39 35 14 L 0f 61 61 61 35 32 38 15 L 11 61 61 61 35 36 30 16 L 11 61 61 61 35 39 33 17 L 11 61 61 61 36 32 36 18 L 11 61 61 61 36 35 39 19 L 11 61 61 61 36 39 32 20 L 11 61 61 61 37 32 35 21 L 11 61 61 61 37 35 38 22 L 11 61 61 61 37 39 31 23 L 11 61 61 61 38 32 34 24 L 11 61 61 61 38 35 37 25 L 11 61 61 61 38 39 30 26 L 11 61 61 61 39 32 33 27 L 11 61 61 61 39 35 36 28 L 11 61 61 61 39 38 39 29 L 3 1 61 35 32 38 15 L 11 61 61 61 35 36 30 16 L 11 61 61 61 35 39 33 17 L
  4. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Image generated using experimental Graphiz Postgres B-Tree visualization tool

    — Heikki Linnakangas Preamble — what makes Nested Loop Join special among join algorithms 1 L 11 61 61 61 31 33 32 2 L 11 61 61 61 31 36 35 4 L 11 61 61 61 31 39 38 5 L 11 61 61 61 32 33 31 3 6 L 11 61 61 61 32 36 34 7 L 11 61 61 61 32 39 37 8 L 11 61 61 61 33 33 30 9 L 11 61 61 61 33 36 33 10 L 11 61 61 61 33 39 36 11 L 11 61 61 61 34 32 39 12 L 11 61 61 61 34 36 32 13 L 11 61 61 61 34 39 35 14 L 0f 61 61 61 35 32 38 15 L 11 61 61 61 35 36 30 16 L 11 61 61 61 35 39 33 17 L 11 61 61 61 36 32 36 18 L 11 61 61 61 36 35 39 19 L 11 61 61 61 36 39 32 20 L 11 61 61 61 37 32 35 21 L 11 61 61 61 37 35 38 22 L 11 61 61 61 37 39 31 23 L 11 61 61 61 38 32 34 24 L 11 61 61 61 38 35 37 25 L 11 61 61 61 38 39 30 26 L 11 61 61 61 39 32 33 27 L 11 61 61 61 39 35 36 28 L 11 61 61 61 39 38 39 29 L 3 1 61 35 32 38 15 L 11 61 61 61 35 36 30 16 L 11 61 61 61 35 39 33 17 L
  5. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Image generated using experimental Graphiz Postgres B-Tree visualization tool

    — Heikki Linnakangas Preamble — what makes Nested Loop Join special among join algorithms 1 L 11 61 61 61 31 33 32 2 L 11 61 61 61 31 36 35 4 L 11 61 61 61 31 39 38 5 L 11 61 61 61 32 33 31 3 6 L 11 61 61 61 32 36 34 7 L 11 61 61 61 32 39 37 8 L 11 61 61 61 33 33 30 9 L 11 61 61 61 33 36 33 10 L 11 61 61 61 33 39 36 11 L 11 61 61 61 34 32 39 12 L 11 61 61 61 34 36 32 13 L 11 61 61 61 34 39 35 14 L 0f 61 61 61 35 32 38 15 L 11 61 61 61 35 36 30 16 L 11 61 61 61 35 39 33 17 L 11 61 61 61 36 32 36 18 L 11 61 61 61 36 35 39 19 L 11 61 61 61 36 39 32 20 L 11 61 61 61 37 32 35 21 L 11 61 61 61 37 35 38 22 L 11 61 61 61 37 39 31 23 L 11 61 61 61 38 32 34 24 L 11 61 61 61 38 35 37 25 L 11 61 61 61 38 39 30 26 L 11 61 61 61 39 32 33 27 L 11 61 61 61 39 35 36 28 L 11 61 61 61 39 38 39 29 L 3 1 61 35 32 38 15 L 11 61 61 61 35 36 30 16 L 11 61 61 61 35 39 33 17 L
  6. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Nested Loop Join Only join algorithm usable in principle

    to execute any join that you can express with SQL. Often index scans on both sides of join. Or, another nestloop join on outer side of top-level nestloop join. Output from inner side “plugged into” outer side. Often very fast — “lookup based”. 6
  7. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 sales id customer coupon_id 2958 Condor 85495282 183 Condor

    43957257 785257 Condor 23583853 coupons id valid_until ??? ??? Join output id customer coupon_id valid_until 2958 Condor ??? ???
  8. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 sales id customer coupon_id 2958 Condor 85495282 183 Condor

    43957257 785257 Condor 23583853 coupons id valid_until ??? ??? 1 L 11 61 61 61 31 33 32 2 L 11 61 61 61 31 36 35 4 L 11 61 61 61 31 39 38 5 L 11 61 61 61 32 33 31 3 6 L 11 61 61 61 32 36 34 7 L 11 61 61 61 32 39 37 8 L 11 61 61 61 33 33 30 9 L 11 61 61 61 33 36 33 10 L 11 61 61 61 33 39 36 11 L 11 61 61 61 34 32 39 12 L 11 61 61 61 34 36 32 13 L 11 61 61 61 34 39 35 14 L 0f 61 61 61 35 32 38 15 L 11 61 61 61 35 36 30 16 L 11 61 61 61 35 39 33 17 L 11 61 61 61 36 32 36 18 L 11 61 61 61 36 35 39 19 L 11 61 61 61 36 39 32 20 L 11 61 61 61 37 32 35 21 L 11 61 61 61 37 35 38 22 L 11 61 61 Join output id customer coupon_id valid_until 2958 Condor ??? ???
  9. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 sales id customer coupon_id 2958 Condor 85495282 183 Condor

    43957257 785257 Condor 23583853 coupons id valid_until ??? ??? 1 L 11 61 61 61 31 33 32 2 L 11 61 61 61 31 36 35 4 L 11 61 61 61 31 39 38 5 L 11 61 61 61 32 33 31 3 6 L 11 61 61 61 32 36 34 7 L 11 61 61 61 32 39 37 8 L 11 61 61 61 33 33 30 9 L 11 61 61 61 33 36 33 10 L 11 61 61 61 33 39 36 11 L 11 61 61 61 34 32 39 12 L 11 61 61 61 34 36 32 13 L 11 61 61 61 34 39 35 14 L 0f 61 61 61 35 32 38 15 L 11 61 61 61 35 36 30 16 L 11 61 61 61 35 39 33 17 L 11 61 61 61 36 32 36 18 L 11 61 61 61 36 35 39 19 L 11 61 61 61 36 39 32 20 L 11 61 61 61 37 32 35 21 L 11 61 61 61 37 35 38 22 L 11 61 61 Join output id customer coupon_id valid_until 2958 Condor ??? ???
  10. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 sales id customer coupon_id 2958 Condor 85495282 183 Condor

    43957257 785257 Condor 23583853 coupons id valid_until ??? ??? 1 L 11 61 61 61 31 33 32 2 L 11 61 61 61 31 36 35 4 L 11 61 61 61 31 39 38 5 L 11 61 61 61 32 33 31 3 6 L 11 61 61 61 32 36 34 7 L 11 61 61 61 32 39 37 8 L 11 61 61 61 33 33 30 9 L 11 61 61 61 33 36 33 10 L 11 61 61 61 33 39 36 11 L 11 61 61 61 34 32 39 12 L 11 61 61 61 34 36 32 13 L 11 61 61 61 34 39 35 14 L 0f 61 61 61 35 32 38 15 L 11 61 61 61 35 36 30 16 L 11 61 61 61 35 39 33 17 L 11 61 61 61 36 32 36 18 L 11 61 61 61 36 35 39 19 L 11 61 61 61 36 39 32 20 L 11 61 61 61 37 32 35 21 L 11 61 61 61 37 35 38 22 L 11 61 61 Join output id customer coupon_id valid_until 2958 Condor ??? ???
  11. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 sales id customer coupon_id 2958 Condor 85495282 183 Condor

    43957257 785257 Condor 23583853 coupons id valid_until 85495282 2017-05-20 1 L 11 61 61 61 31 33 32 2 L 11 61 61 61 31 36 35 4 L 11 61 61 61 31 39 38 5 L 11 61 61 61 32 33 31 3 6 L 11 61 61 61 32 36 34 7 L 11 61 61 61 32 39 37 8 L 11 61 61 61 33 33 30 9 L 11 61 61 61 33 36 33 10 L 11 61 61 61 33 39 36 11 L 11 61 61 61 34 32 39 12 L 11 61 61 61 34 36 32 13 L 11 61 61 61 34 39 35 14 L 0f 61 61 61 35 32 38 15 L 11 61 61 61 35 36 30 16 L 11 61 61 61 35 39 33 17 L 11 61 61 61 36 32 36 18 L 11 61 61 61 36 35 39 19 L 11 61 61 61 36 39 32 20 L 11 61 61 61 37 32 35 21 L 11 61 61 61 37 35 38 22 L 11 61 61 Join output id customer coupon_id valid_until 2958 Condor ??? ???
  12. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 sales id customer coupon_id 2958 Condor 85495282 183 Condor

    43957257 785257 Condor 23583853 coupons id valid_until 85495282 2017-05-20 1 L 11 61 61 61 31 33 32 2 L 11 61 61 61 31 36 35 4 L 11 61 61 61 31 39 38 5 L 11 61 61 61 32 33 31 3 6 L 11 61 61 61 32 36 34 7 L 11 61 61 61 32 39 37 8 L 11 61 61 61 33 33 30 9 L 11 61 61 61 33 36 33 10 L 11 61 61 61 33 39 36 11 L 11 61 61 61 34 32 39 12 L 11 61 61 61 34 36 32 13 L 11 61 61 61 34 39 35 14 L 0f 61 61 61 35 32 38 15 L 11 61 61 61 35 36 30 16 L 11 61 61 61 35 39 33 17 L 11 61 61 61 36 32 36 18 L 11 61 61 61 36 35 39 19 L 11 61 61 61 36 39 32 20 L 11 61 61 61 37 32 35 21 L 11 61 61 61 37 35 38 22 L 11 61 61 Join output id customer coupon_id valid_until 2958 Condor 85495282 2017-05-20
  13. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 sales id customer coupon_id 2958 Condor 85495282 183 Condor

    43957257 785257 Condor 23583853 1 L 11 61 61 61 31 33 32 2 L 11 61 61 61 31 36 35 4 L 11 61 61 61 31 39 38 5 L 11 61 61 61 32 33 31 3 6 L 11 61 61 61 32 36 34 7 L 11 61 61 61 32 39 37 8 L 11 61 61 61 33 33 30 9 L 11 61 61 61 33 36 33 10 L 11 61 61 61 33 39 36 11 L 11 61 61 61 34 32 39 12 L 11 61 61 61 34 36 32 13 L 11 61 61 61 34 39 35 14 L 0f 61 61 61 35 32 38 15 L 11 61 61 61 35 36 30 16 L 11 61 61 61 35 39 33 17 L 11 61 61 61 36 32 36 18 L 11 61 61 61 36 35 39 19 L 11 61 61 61 36 39 32 20 L 11 61 61 61 37 32 35 21 L 11 61 61 61 37 35 38 22 L 11 61 61 Join output id customer coupon_id valid_until 2958 Condor 85495282 2017-05-20 coupons id valid_until ??? ???
  14. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 sales id customer coupon_id 2958 Condor 85495282 183 Condor

    43957257 785257 Condor 23583853 1 L 11 61 61 61 31 33 32 2 L 11 61 61 61 31 36 35 4 L 11 61 61 61 31 39 38 5 L 11 61 61 61 32 33 31 3 6 L 11 61 61 61 32 36 34 7 L 11 61 61 61 32 39 37 8 L 11 61 61 61 33 33 30 9 L 11 61 61 61 33 36 33 10 L 11 61 61 61 33 39 36 11 L 11 61 61 61 34 32 39 12 L 11 61 61 61 34 36 32 13 L 11 61 61 61 34 39 35 14 L 0f 61 61 61 35 32 38 15 L 11 61 61 61 35 36 30 16 L 11 61 61 61 35 39 33 17 L 11 61 61 61 36 32 36 18 L 11 61 61 61 36 35 39 19 L 11 61 61 61 36 39 32 20 L 11 61 61 61 37 32 35 21 L 11 61 61 61 37 35 38 22 L 11 61 61 Join output id customer coupon_id valid_until 2958 Condor 85495282 2017-05-20 183 Condor ??? ??? coupons id valid_until ??? ???
  15. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 sales id customer coupon_id 2958 Condor 85495282 183 Condor

    43957257 785257 Condor 23583853 1 L 11 61 61 61 31 33 32 2 L 11 61 61 61 31 36 35 4 L 11 61 61 61 31 39 38 5 L 11 61 61 61 32 33 31 3 6 L 11 61 61 61 32 36 34 7 L 11 61 61 61 32 39 37 8 L 11 61 61 61 33 33 30 9 L 11 61 61 61 33 36 33 10 L 11 61 61 61 33 39 36 11 L 11 61 61 61 34 32 39 12 L 11 61 61 61 34 36 32 13 L 11 61 61 61 34 39 35 14 L 0f 61 61 61 35 32 38 15 L 11 61 61 61 35 36 30 16 L 11 61 61 61 35 39 33 17 L 11 61 61 61 36 32 36 18 L 11 61 61 61 36 35 39 19 L 11 61 61 61 36 39 32 20 L 11 61 61 61 37 32 35 21 L 11 61 61 61 37 35 38 22 L 11 61 61 coupons id valid_until ??? ??? Join output id customer coupon_id valid_until 2958 Condor 85495282 2017-05-20 183 Condor ??? ???
  16. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 sales id customer coupon_id 2958 Condor 85495282 183 Condor

    43957257 785257 Condor 23583853 1 L 11 61 61 61 31 33 32 2 L 11 61 61 61 31 36 35 4 L 11 61 61 61 31 39 38 5 L 11 61 61 61 32 33 31 3 6 L 11 61 61 61 32 36 34 7 L 11 61 61 61 32 39 37 8 L 11 61 61 61 33 33 30 9 L 11 61 61 61 33 36 33 10 L 11 61 61 61 33 39 36 11 L 11 61 61 61 34 32 39 12 L 11 61 61 61 34 36 32 13 L 11 61 61 61 34 39 35 14 L 0f 61 61 61 35 32 38 15 L 11 61 61 61 35 36 30 16 L 11 61 61 61 35 39 33 17 L 11 61 61 61 36 32 36 18 L 11 61 61 61 36 35 39 19 L 11 61 61 61 36 39 32 20 L 11 61 61 61 37 32 35 21 L 11 61 61 61 37 35 38 22 L 11 61 61 coupons id valid_until ??? ??? Join output id customer coupon_id valid_until 2958 Condor 85495282 2017-05-20 183 Condor ??? ???
  17. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 sales id customer coupon_id 2958 Condor 85495282 183 Condor

    43957257 785257 Condor 23583853 1 L 11 61 61 61 31 33 32 2 L 11 61 61 61 31 36 35 4 L 11 61 61 61 31 39 38 5 L 11 61 61 61 32 33 31 3 6 L 11 61 61 61 32 36 34 7 L 11 61 61 61 32 39 37 8 L 11 61 61 61 33 33 30 9 L 11 61 61 61 33 36 33 10 L 11 61 61 61 33 39 36 11 L 11 61 61 61 34 32 39 12 L 11 61 61 61 34 36 32 13 L 11 61 61 61 34 39 35 14 L 0f 61 61 61 35 32 38 15 L 11 61 61 61 35 36 30 16 L 11 61 61 61 35 39 33 17 L 11 61 61 61 36 32 36 18 L 11 61 61 61 36 35 39 19 L 11 61 61 61 36 39 32 20 L 11 61 61 61 37 32 35 21 L 11 61 61 61 37 35 38 22 L 11 61 61 coupons id valid_until ??? ??? Join output id customer coupon_id valid_until 2958 Condor 85495282 2017-05-20 183 Condor ??? ???
  18. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 sales id customer coupon_id 2958 Condor 85495282 183 Condor

    43957257 785257 Condor 23583853 1 L 11 61 61 61 31 33 32 2 L 11 61 61 61 31 36 35 4 L 11 61 61 61 31 39 38 5 L 11 61 61 61 32 33 31 3 6 L 11 61 61 61 32 36 34 7 L 11 61 61 61 32 39 37 8 L 11 61 61 61 33 33 30 9 L 11 61 61 61 33 36 33 10 L 11 61 61 61 33 39 36 11 L 11 61 61 61 34 32 39 12 L 11 61 61 61 34 36 32 13 L 11 61 61 61 34 39 35 14 L 0f 61 61 61 35 32 38 15 L 11 61 61 61 35 36 30 16 L 11 61 61 61 35 39 33 17 L 11 61 61 61 36 32 36 18 L 11 61 61 61 36 35 39 19 L 11 61 61 61 36 39 32 20 L 11 61 61 61 37 32 35 21 L 11 61 61 61 37 35 38 22 L 11 61 61 coupons id valid_until 43957257 2018-01-01 Join output id customer coupon_id valid_until 2958 Condor 85495282 2017-05-20 183 Condor ??? ???
  19. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 sales id customer coupon_id 2958 Condor 85495282 183 Condor

    43957257 785257 Condor 23583853 1 L 11 61 61 61 31 33 32 2 L 11 61 61 61 31 36 35 4 L 11 61 61 61 31 39 38 5 L 11 61 61 61 32 33 31 3 6 L 11 61 61 61 32 36 34 7 L 11 61 61 61 32 39 37 8 L 11 61 61 61 33 33 30 9 L 11 61 61 61 33 36 33 10 L 11 61 61 61 33 39 36 11 L 11 61 61 61 34 32 39 12 L 11 61 61 61 34 36 32 13 L 11 61 61 61 34 39 35 14 L 0f 61 61 61 35 32 38 15 L 11 61 61 61 35 36 30 16 L 11 61 61 61 35 39 33 17 L 11 61 61 61 36 32 36 18 L 11 61 61 61 36 35 39 19 L 11 61 61 61 36 39 32 20 L 11 61 61 61 37 32 35 21 L 11 61 61 61 37 35 38 22 L 11 61 61 Join output id customer coupon_id valid_until 2958 Condor 85495282 2017-05-20 183 Condor 43957257 2018-01-01 coupons id valid_until 43957257 2018-01-01
  20. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Nested Loop Join in action -- Column values are

    “plugged in” here: EXPLAIN SELECT * FROM tenk1 t1, tenk2 t2 WHERE t1.unique1 < 10 AND t1.unique2 = t2.unique2; QUERY PLAN -------------------------------------------------------------------------------------- Nested Loop (cost=4.65..118.62 rows=10 width=488) -> Bitmap Heap Scan on tenk1 t1 (cost=4.36..39.47 rows=10 width=244) Recheck Cond: (unique1 < 10) -> Bitmap Index Scan on tenk1_unique1 (cost=0.00..4.36 rows=10 width=0) Index Cond: (unique1 < 10) -> Index Scan using tenk2_unique2 on tenk2 t2 (cost=0.29..7.91 rows=1 width=244) Index Cond: (unique2 = t1.unique2) [1] PostgreSQL documentation: EXPLAIN Basics (basic discussion of different join algorithms)
  21. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Nested Loop Join in action -- Column values are

    “plugged in” here: EXPLAIN SELECT * FROM tenk1 t1, tenk2 t2 WHERE t1.unique1 < 10 AND t1.unique2 = t2.unique2; QUERY PLAN -------------------------------------------------------------------------------------- Nested Loop (cost=4.65..118.62 rows=10 width=488) -> Bitmap Heap Scan on tenk1 t1 (cost=4.36..39.47 rows=10 width=244) Recheck Cond: (unique1 < 10) -> Bitmap Index Scan on tenk1_unique1 (cost=0.00..4.36 rows=10 width=0) Index Cond: (unique1 < 10) -> Index Scan using tenk2_unique2 on tenk2 t2 (cost=0.29..7.91 rows=1 width=244) Index Cond: (unique2 = t1.unique2) [1] PostgreSQL documentation: EXPLAIN Basics (basic discussion of different join algorithms) 39.47 + (7.91 * 10 rows) = 118.57 (~118.62)
  22. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Low latency OLTP queries Great OLTP performance is possible

    because nested loop joins fed by index scans (or another nested loop join) can scale wonderfully well. Nothing scales as well as selective index scans. Decent optimizer important too, to get the join ordering right consistently. Sort-merge join and Hash Join are not really “in competition” with nested loop Join — only each other. 23
  23. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 “The cost of this type of query plan [nested

    loop join heavy plans] grows linearly with the number of records involved, which might very well mean that the cost is effectively independent of the database size…the cost of index look-ups in traditional B-tree indexes grows logarithmically with the database size…” [1] Modern B-Tree techniques, 5.9 Nested Queries and Nested Iteration — Goetz Graefe, Modern B-Tree techniques [1]
  24. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 “…The key to interactive response times, both in online

    transaction processing (OLTP) and in online analytical processing (OLAP), is to ensure that query results are fetched, not searched and computed…In relational database systems, fetching query results directly means index searches. If a result requires records from multiple indexes, index nested loops join or, more generally, nested iteration are the algorithms of choice.” [1] Modern B-Tree techniques, 5.9 Nested Queries and Nested Iteration — Goetz Graefe, Modern B-Tree techniques [1]
  25. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Presentation Overview 1. Preamble on Nested Loop Join Why

    it’s very different to hash based or sort based algorithms. 2. Duality of Sort-Merge Join and Hash Join Introduction to both algorithms. 3. The introduction and popularization of Hash Join Why hash joins became popular in late 1980s/early 1990s. 4. Parallelism, memory bandwidth, and the future New era, same old pressures. 5. Duality between Sorting and Hashing revisited Central idea of the presentation, in summary. 26
  26. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Duality — The symmetric relationship between Hash Join and

    Sort-Merge Join Cube frame with Octahedron dual inside Octahedron frame with Cube dual inside Query Evaluation Techniques for Large Databases — Goetz Graefe (ACM Computing Surveys,Vol. 25, No. 2, June 1993)
  27. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Hash Joins First, build a hash table of smaller

    relation. Hash table consists of join attribute as hash key for each row, alongside row itself. Build hash table by scanning smaller table/input. Scan larger table, joining rows from smaller relation by performing lookups in hash table. Only supports equi-joins — joins with simple equality condition in predicate. 28
  28. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Hash Joins (cont.) Works particularly well when one input

    is smaller, such as a lookup table. Or, moderately large subset of table (e.g., hash table built by reading from bitmap index scan). High join selectivity works well (e.g., uncorrelated join attributes). Hash table can spill “batches” to disk when insufficient main memory available. 29
  29. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Hash Join in action -- Hash table built first,

    by scanning ~100 rows in tenk1 table where “unique1 < 100”: EXPLAIN SELECT * FROM tenk1 t1, tenk2 t2 WHERE t1.unique1 < 100 AND t1.unique2 = t2.unique2; QUERY PLAN ------------------------------------------------------------------------------------------ Hash Join (cost=230.47..713.98 rows=101 width=488) Hash Cond: (t2.unique2 = t1.unique2) -> Seq Scan on tenk2 t2 (cost=0.00..445.00 rows=10000 width=244) -> Hash (cost=229.20..229.20 rows=101 width=244) -> Bitmap Heap Scan on tenk1 t1 (cost=5.07..229.20 rows=101 width=244) Recheck Cond: (unique1 < 100) -> Bitmap Index Scan on tenk1_unique1 (cost=0.00..5.04 rows=101 width=0) Index Cond: (unique1 < 100) [1] PostgreSQL documentation: EXPLAIN Basics (basic discussion of different join algorithms)
  30. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Hash Join in action -- Hash table built first,

    by scanning ~100 rows in tenk1 table where “unique1 < 100”: EXPLAIN SELECT * FROM tenk1 t1, tenk2 t2 WHERE t1.unique1 < 100 AND t1.unique2 = t2.unique2; QUERY PLAN ------------------------------------------------------------------------------------------ Hash Join (cost=230.47..713.98 rows=101 width=488) Hash Cond: (t2.unique2 = t1.unique2) -> Seq Scan on tenk2 t2 (cost=0.00..445.00 rows=10000 width=244) -> Hash (cost=229.20..229.20 rows=101 width=244) -> Bitmap Heap Scan on tenk1 t1 (cost=5.07..229.20 rows=101 width=244) Recheck Cond: (unique1 < 100) -> Bitmap Index Scan on tenk1_unique1 (cost=0.00..5.04 rows=101 width=0) Index Cond: (unique1 < 100) [1] PostgreSQL documentation: EXPLAIN Basics (basic discussion of different join algorithms) Naturally, would-be nested loop join plan’s cost exceeds 713.98 (extrapolate from similar “WHERE t1.unique1 < 10” plan): ~39.47 + (7.91 * 100 rows) = 830.47 (approx.)
  31. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Merge Joins Sorted input to Merge Join node on

    both sides of join. Actual sort node typically appears for at least one side of join. Often both sides. Input might instead come from an index scan. B- Trees “materialize” sort order of columns that are indexed. Sorts can, in general, spill to disk if there is much data to sort. 32
  32. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 conferences conf_id conf_name city_id 23 Systems We Love 4

    12 Surge 10 13 PGConf.US 9 24 pgCon 3 17 Postgres Vision 4 16 pgConf SV 4 431 ACM SIGMOD 4 2 Strangeloop 7 44 All Your Base 282 15 VLDB2016 18 94 IEEE ICDE 48 25 Velocity 32 59 Percona Live 17 cities city_id city_name 171 Dublin 2 Beijing 1 Johannesburg 10 Baltimore 44 San Mateo 3 Ottawa 9 New York 282 London 4 San Francisco
  33. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 conferences conf_id conf_name city_id 24 pgCon 3 23 Systems

    We Love 4 17 Postgres Vision 4 16 pgConf SV 4 431 ACM SIGMOD 4 2 Strangeloop 7 13 PGConf.US 9 12 Surge 10 59 Percona Live 17 15 VLDB2016 18 25 Velocity 32 94 IEEE ICDE 48 44 All Your Base 282 cities city_id city_name 171 Dublin 2 Beijing 1 Johannesburg 10 Baltimore 44 San Mateo 3 Ottawa 9 New York 282 London 4 San Francisco
  34. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 conferences conf_id conf_name city_id 24 pgCon 3 23 Systems

    We Love 4 17 Postgres Vision 4 16 pgConf SV 4 431 ACM SIGMOD 4 2 Strangeloop 7 13 PGConf.US 9 12 Surge 10 59 Percona Live 17 15 VLDB2016 18 25 Velocity 32 94 IEEE ICDE 48 44 All Your Base 282 cities city_id city_name 1 Johannesburg 2 Beijing 3 Ottawa 4 San Francisco 9 New York 10 Baltimore 44 San Mateo 171 Dublin 282 London
  35. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Join output conf_id conf_name city_id city_name conferences conf_id conf_name

    city_id 24 pgCon 3 23 Systems We Love 4 17 Postgres Vision 4 16 pgConf SV 4 431 ACM SIGMOD 4 2 Strangeloop 7 13 PGConf.US 9 12 Surge 10 59 Percona Live 17 15 VLDB2016 18 25 Velocity 32 94 IEEE ICDE 48 44 All Your Base 282 cities city_id city_name 1 Johannesburg 2 Beijing 3 Ottawa 4 San Francisco 9 New York 10 Baltimore 44 San Mateo 171 Dublin 282 London
  36. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Join output conf_id conf_name city_id city_name conferences conf_id conf_name

    city_id 24 pgCon 3 23 Systems We Love 4 17 Postgres Vision 4 16 pgConf SV 4 431 ACM SIGMOD 4 2 Strangeloop 7 13 PGConf.US 9 12 Surge 10 59 Percona Live 17 15 VLDB2016 18 25 Velocity 32 94 IEEE ICDE 48 44 All Your Base 282 cities city_id city_name 1 Johannesburg 2 Beijing 3 Ottawa 4 San Francisco 9 New York 10 Baltimore 44 San Mateo 171 Dublin 282 London
  37. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Join output conf_id conf_name city_id city_name conferences conf_id conf_name

    city_id 24 pgCon 3 23 Systems We Love 4 17 Postgres Vision 4 16 pgConf SV 4 431 ACM SIGMOD 4 2 Strangeloop 7 13 PGConf.US 9 12 Surge 10 59 Percona Live 17 15 VLDB2016 18 25 Velocity 32 94 IEEE ICDE 48 44 All Your Base 282 cities city_id city_name 1 Johannesburg 2 Beijing 3 Ottawa 4 San Francisco 9 New York 10 Baltimore 44 San Mateo 171 Dublin 282 London
  38. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Join output conf_id conf_name city_id city_name conferences conf_id conf_name

    city_id 24 pgCon 3 23 Systems We Love 4 17 Postgres Vision 4 16 pgConf SV 4 431 ACM SIGMOD 4 2 Strangeloop 7 13 PGConf.US 9 12 Surge 10 59 Percona Live 17 15 VLDB2016 18 25 Velocity 32 94 IEEE ICDE 48 44 All Your Base 282 cities city_id city_name 1 Johannesburg 2 Beijing 3 Ottawa 4 San Francisco 9 New York 10 Baltimore 44 San Mateo 171 Dublin 282 London
  39. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Join output conf_id conf_name city_id city_name 24 pgCon 3

    Ottawa conferences conf_id conf_name city_id 24 pgCon 3 23 Systems We Love 4 17 Postgres Vision 4 16 pgConf SV 4 431 ACM SIGMOD 4 2 Strangeloop 7 13 PGConf.US 9 12 Surge 10 59 Percona Live 17 15 VLDB2016 18 25 Velocity 32 94 IEEE ICDE 48 44 All Your Base 282 cities city_id city_name 1 Johannesburg 2 Beijing 3 Ottawa 4 San Francisco 9 New York 10 Baltimore 44 San Mateo 171 Dublin 282 London
  40. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Join output conf_id conf_name city_id city_name 24 pgCon 3

    Ottawa conferences conf_id conf_name city_id 24 pgCon 3 23 Systems We Love 4 17 Postgres Vision 4 16 pgConf SV 4 431 ACM SIGMOD 4 2 Strangeloop 7 13 PGConf.US 9 12 Surge 10 59 Percona Live 17 15 VLDB2016 18 25 Velocity 32 94 IEEE ICDE 48 44 All Your Base 282 cities city_id city_name 1 Johannesburg 2 Beijing 3 Ottawa 4 San Francisco 9 New York 10 Baltimore 44 San Mateo 171 Dublin 282 London
  41. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Join output conf_id conf_name city_id city_name 24 pgCon 3

    Ottawa conferences conf_id conf_name city_id 24 pgCon 3 23 Systems We Love 4 17 Postgres Vision 4 16 pgConf SV 4 431 ACM SIGMOD 4 2 Strangeloop 7 13 PGConf.US 9 12 Surge 10 59 Percona Live 17 15 VLDB2016 18 25 Velocity 32 94 IEEE ICDE 48 44 All Your Base 282 cities city_id city_name 1 Johannesburg 2 Beijing 3 Ottawa 4 San Francisco 9 New York 10 Baltimore 44 San Mateo 171 Dublin 282 London
  42. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Join output conf_id conf_name city_id city_name 24 pgCon 3

    Ottawa 23 Systems We Love 4 San Francisco conferences conf_id conf_name city_id 24 pgCon 3 23 Systems We Love 4 17 Postgres Vision 4 16 pgConf SV 4 431 ACM SIGMOD 4 2 Strangeloop 7 13 PGConf.US 9 12 Surge 10 59 Percona Live 17 15 VLDB2016 18 25 Velocity 32 94 IEEE ICDE 48 44 All Your Base 282 cities city_id city_name 1 Johannesburg 2 Beijing 3 Ottawa 4 San Francisco 9 New York 10 Baltimore 44 San Mateo 171 Dublin 282 London
  43. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Merge Joins (cont.) More flexible than hash joins in

    some ways — not limited to equi-joins. Can also be interval-based, for example. Sorts can, in general, spill to disk if there is much data to sort. 44
  44. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Merge Join in action -- N.B.: t2 is from

    one table, not tench table. -- -- Tuples “sucked up” from each side, in sorted order: EXPLAIN SELECT * FROM tenk1 t1, onek t2 WHERE t1.unique1 < 100 AND t1.unique2 = t2.unique2; QUERY PLAN ------------------------------------------------------------------------------------------ Merge Join (cost=198.11..268.19 rows=10 width=488) Merge Cond: (t1.unique2 = t2.unique2) -> Index Scan using tenk1_unique2 on tenk1 t1 (cost=0.29..656.28 rows=101 width=244) Filter: (unique1 < 100) -> Sort (cost=197.83..200.33 rows=1000 width=244) Sort Key: t2.unique2 -> Seq Scan on onek t2 (cost=0.00..148.00 rows=1000 width=244) [1] PostgreSQL documentation: EXPLAIN Basics (basic discussion of different join algorithms)
  45. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Presentation Overview 1. Preamble on Nested Loop Join Why

    it’s very different to hash based or sort based algorithms. 2. Duality of Sort-Merge Join and Hash Join Introduction to both algorithms. 3. The introduction and popularization of Hash Join Why hash joins became popular in late 1980s/early 1990s. 4. Parallelism, memory bandwidth, and the future New era, same old pressures. 5. Duality between Sorting and Hashing revisited Central idea of the presentation, in summary. 46
  46. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Replacement Selection: Merge Scheduling ❖ Knuth dedicated a special

    pull-out section of his book to various orders in which to merge runs ❖ Each of these is a different strategy with different advantages and disadvantages ❖ Some depend on being able to read tapes backwards or have an operator change tapes ❖ They all assume you have a small fixed number of tape drives Prehistory: Merge Scheduling, and early importance of Sort-merge join
  47. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 ❖ Knuth dedicated a special pull-out section of his

    book to various orders in which to merge runs ❖ Each of these is a different strategy with different advantages and disadvantages ❖ Some depend on being able to read tapes backwards or have an operator change tapes ❖ They all assume you have a small fixed number of tape drives “Readers will benefit most from this material by transplanting themselves temporarily into the mindset of the 1970s. Let us therefore pretend that we still live in that bygone era.” — Donald Knuth, The Art of Computer Programming: Volume 3: Sorting and Searching (2nd Edition,1998)
  48. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 ❖ Knuth dedicated a special pull-out section of his

    book to various orders in which to merge runs ❖ Each of these is a different strategy with different advantages and disadvantages ❖ Some depend on being able to read tapes backwards or have an operator change tapes ❖ They all assume you have a small fixed number of tape drives • Limited number of tape drives — use of actual magnetic tape decks assumed! • These days, we still almost always do one merge pass. Polyphase techniques of minimal practical value, since in practice we should be able to fit at least one record from each run in memory, for heap that merges (to produce final sorted output). • Every time main memory size doubles, our capacity to have an external sort complete with only one pass quadruples. • Capacity doubled many times since early 1970s! • External sorting often necessary, even still — data sizes have grown, too.
  49. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Trends in hardware make hash join compelling Introduction of

    hash joins in major systems in late 1980s and early 1990s can, to a large degree, be explained as response to trends in CPU architecture. In particular, the huge increase in main memory sizes. 64-bit architectures become available in high end commodity servers. “Hybrid” hash joins have plausible spill mechanism. It now matters far less that there is no such thing as “polyphase hashing”. Sort-merge join loses a significant advantage. 51
  50. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Additions to speed up hash joins in PostgreSQL 9.6

    + 10 Cleverer management of memory, to avoid cache misses during merging — use of “memory chunks”. In Postgres 10, “Robin Hood hashing” open addressing scheme added to replace hash chaining. Parallel hash join proposed for Postgres 10. 52
  51. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Advancements in CPU architecture help sorting, too 64-bit processors

    become fairly mainstream for server workloads in early 1990s. Memory bandwidth and memory latency bottleneck. CPU caches added to hide latency. 53
  52. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Figure 2. Replacement-selection sort vs. QuickSort °.. .... ~.~_~.~

    .~o,.%°~o,. The tournament tree of replacement-selection sort at left has bad cache behavior, unless the entire tournament fits in cache. The diagram at left shows the memory references as a winner is removed, and a new element is added to the tournament. Each traversal of the tree has many cache misses at the leaves of the tree. By contrast, the QuickSort diagrammed on the right fits entirely in the on-board cache, and partially in the on-chip cache. [1] AlphaSort: A Cache-Sensitive Parallel External Sort — Nyberg, Barclay, Cvetanovic, Gray, and Lomet (VLDB Journal Volume 4, 1995)
  53. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Advancements in CPU architecture help sorting, too Using memory

    capacity as efficiently as possible no longer first concern. Rather, CPU cache efficiency becomes first concern. Forget elegance! Focus on cache misses, and to a lesser extent instruction count and branch prediction. 55 [1] AlphaSort: A Cache-Sensitive Parallel External Sort — Nyberg, Barclay, Cvetanovic, Gray, and Lomet (VLDB Journal Volume 4, 1995)
  54. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Figure 1. How far away is the data? l

    109 Tape/Optical ~ ° . m ~ ~ a cn Robot 10 6 Disk O C .E I-- 100 Memory ~, 10 On Board C ..... ~ This Campus Eo 2 On Chip Cache ]his Room O 1 Registers ~ y My Head 2,000 Years i 2 Years .g 1.5hr ~ Z 10 min 1 min A whimsical analogy between computer time and human time, as seen from San Francisco. The scale on the left shows the number of processor cycles needed to get to various levels of the memory hierarchy (measured in 5 ns. processor clock ticks). The scale on the right is a more human scale, showing time based in human units (minutes). Suppose that AlphaSort paid no attention to the cache, and that it randomly [1] AlphaSort: A Cache-Sensitive Parallel External Sort — Nyberg, Barclay, Cvetanovic, Gray, and Lomet (VLDB Journal Volume 4, 1995)
  55. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Additions to speed up sorting in PostgreSQL 9.5, 9.6

    “Abbreviated keys” — avoids “pointer chasing”. Use quicksort for external sort operations. Multiple quicksorted runs are merged to produce final output Careful memory management — maximizes locality Avoids CPU cache misses by making memory access to sorted runs sequential. 57
  56. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Additions to speed up sorting in future PostgreSQL version

    Parallel CREATE INDEX Approach is not based on partitioning, which may be better for parallel query Significant research needed on partitioning for parallel query Discussion on this patch has stalled “Unique joins” 58
  57. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Presentation Overview 1. Preamble on Nested Loop Join Why

    it’s very different to hash based or sort based algorithms. 2. Duality of Sort-Merge Join and Hash Join Introduction to both algorithms. 3. The introduction and popularization of Hash Join Why hash joins became popular in late 1980s/early 1990s. 4. Parallelism, memory bandwidth, and the future New era, same old pressures. 5. Duality between Sorting and Hashing revisited Central idea of the presentation, in summary. 59
  58. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Multicore era problems Main memory scaling (scaling of memory

    size) has benefitted database system performance immensely over the past few decades. More of a transformative technology than any other. Now seems to have stalled, due to problems related to power management [1]. 61 [1] Memory Scaling: A Systems Architecture Perspective
  59. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Multicore era problems (cont.) Core count now growing faster

    than main memory sizes, and CPUs are faster than ever, but total memory bandwidth a huge bottleneck. “Like driving a Ferrari in New York City”. Available memory bandwidth per core actually seems to be decreasing in absolute terms! [1] 62 [1] Memory Scaling: A Systems Architecture Perspective
  60. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Parallel query & parallel join Decrease in memory bandwidth

    per core makes parallel join more important than ever. To avoid regressing performance across CPU microarchitecture generations. To make use of all available memory/cache bandwidth. (Not merely to get more “compute bandwidth”, which is usually not pressing concern.) CPU vendors and research community have some ideas, and plenty of incentive, but future is unclear. 63
  61. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Hash vs. Sort — Merge Join resurgence? Trend towards

    less memory bandwidth per core favors Sort-merge Join. [1] “Bandwidth-oblivious sort” can gain memory bandwidth at an acceptable cost in compute bandwidth. TLB unfriendly access also a problem for Hash Join. Fewer cacheline accesses inherently necessary (highly tuned implementations of both). 64 [1] Sort vs. Hash Revisited: Fast Join Implementation on Modern Multi-Core CPUs
  62. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Hash vs. Sort — Merge Join resurgence? (cont.) SIMD

    (instruction-level parallelism) No great way to exploit SIMD for hashing. Bitonic sort can exploit SIMD well [1], though. 256- bit SIMD register CPUs now commercially available. Bitonic sort not readily adaptable to complicated requirements for RDBMSs. Also, careful tuning required. Well written Quicksort really hard to beat [2]. 65 [1] Multi-Core, Main-Memory Joins: Sort vs. Hash Revisited [2] Quicksort Is Optimal — Robert Sedgewick, Jon Bentley
  63. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Presentation Overview 1. Preamble on Nested Loop Join Why

    it’s very different to hash based or sort based algorithms. 2. Duality of Sort-Merge Join and Hash Join Introduction to both algorithms. 3. The introduction and popularization of Hash Join Why hash joins became popular in late 1980s/early 1990s. 4. Parallelism, memory bandwidth, and the future New era, same old pressures. 5. Duality between Sorting and Hashing revisited Central idea of the presentation, in summary. 66
  64. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Icosahedron frame with Dodecahedron dual inside Dodecahedron frame with

    Icosahedron dual inside Query Evaluation Techniques for Large Databases — Goetz Graefe (ACM Computing Surveys,Vol. 25, No. 2, June 1993) Duality between Sorting and Hashing revisited
  65. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Duality between Sorting and Hashing revisited: Symmetry Query Evaluation

    Techniques for Large Databases — Goetz Graefe (ACM Computing Surveys,Vol. 25, No. 2, June 1993) Sort: Physical Division Logical Combination Hash: Logical Division Physical Combination
  66. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Merge Join: Characteristics Locality, locality, locality. External sorts degrade

    slowly and steadily as less memory is available — cost function is nice and smooth. High cardinality sort keys work well. Works best with low selectivity join qualifications. With final on-the-fly merge step, first output record can be returned before the sort fully finishes (external sorts only). 69
  67. https://speakerdeck.com/peterg/sort-hash-pgconfus-2017 Hash Join: Characteristics Hash Join works best with low

    cardinality attribute joined from smaller table. Highly selective join qualifications work best. Doesn’t do well when very memory constrained; cost function looks like a step function when hash table not entirely in-memory. Optimizer will use incorrect selectivity estimates at times. When that happens, hash join may be worse off. 70
