  1. The Future of Open Networking and OpenStack
    Phil Huang 黃秉鈞
    [email protected] / [email protected]
    ONF CORD Ambassador / Edgecore Networks Solution Engineer
    National Taichung University of Science and Technology, Taichung, Taiwan August 14, 2017

    View Slide

  2. 黃秉鈞 Phil Huang
    • ONF Ambassador Member
    • Edgecore Solution Engineer
    § ONF Projects Support
    § BigSwitch / CumulusLinux / Pica8
    • SDNDS-TW Co-Founder
    2
    Ref: https://www.linkedin.com/in/phil-huang-09b09895/ ONF: Open Networking Foundation

    View Slide

  3. SDN & NFV
    3
    Where Are We Now?
    Disaggregated Network
    Monolithic Systems
    You disaggregate to get choice; you aggregate to get efficiencies

    View Slide

  4. 4

    View Slide

  5. Partner
    The Ecosystem of ONF – 200+ Members Strong
    Vibrant Operator Led Consortium Positioned for Success
    Innovator 110+
    Volunteer
    Volunteers
    Collaborator
    Operators (7) Vendors (10)
    70+
    100s
    ONF (& Stanford) Guru Parulkar
    Network Operators
    AT&T Andre Fuetsch – CTO
    Google Urs Hölzle – SVP
    NTT Comm Dai Kashiwa – Director
    Comcast Rob Howald– VP
    Verizon Srini Kalapala – VP
    China Unicom Shao Guanglu - SVP
    Research & Vendor Community
    Nick McKeown Stanford
    Fabian Schneider NEC
    New ONF Board
    Including 14 Operators:
    Argela/Turk Telecom Microsoft
    China Mobile Swisscom
    SK Telecom Telecom Italia
    ECI Telecom Telefonica
    Facebook TELUS
    Globe Telecom Vodafone
    Goldman Sachs Yahoo

    View Slide

  6. Network Virtualization: Overlay and Underlay
    Unified Network Infrastructure
    6

    View Slide

  7. Underlay and Overlay Network Infrastructure
    7
    Underlay
    Overlay
    Tenant N
    vSwitch vRouter
    Tenant N
    vSwitch
    vRouter

    View Slide

  8. SONA: Data Center Network Virtualization
    Simplified Overlay Network Architecture
    8
    Ref: https://wiki.onosproject.org/display/ONOS/SONA:+DC+Network+Virtualization

    View Slide

  9. SONA Objective
    • Optimized tenant network virtualization service for DC
    • Based on ONOS which provides
    § OpenStack Neutron ML2 driver
    § L3 service plugin
    • Provisioning an isolated virtual tenant network
    § Use VXLAN based L2 tunneling with Open vSwitch as a network
    hypervisor
    § Use BGP provides horizontal scalability of gateway node
    9

    View Slide

  10. SONA Architecture
    10
    VXLAN

    View Slide

  11. Trellis
    CORD Network Infrastructure
    11
    Ref: https://wiki.opencord.org/display/CORD/Trellis%3A+CORD+Network+Infrastructure

    View Slide

  12. What is Trellis?
    12
    Datacenter Leaf-Spine
    Fabric Underlay
    Virtual Network
    Overlay
    Unified SDN Control
    Of Underlay & Overlay
    ONOS
    Controller Cluster &
    Apps
    Trellis is the enabling Network Infrastructure for CORD
    Trellis Provides Common control over underlay & overlay networks, including
    1. Service Composition for Tenant Networks
    2. Distributed Virtual Routing
    3. Optimized Delivery of Multicast Traffic Streams
    CORD: Central Office Re-architected as a Datacenter

    View Slide

  13. Underlay Fabric – Open Hardware
    13
    White Box SDN Switch
    Edgecore AS6712-32x
    Spine Switch
    32 x 40G ports downlink to leaf switches
    40G QSFP+/DAC
    GE
    mgmt.
    AS6712-32x
    White Box SDN Switch
    Edgecore AS6712-32x
    Leaf Switch
    24 x 40G ports downlink to servers
    and vOLT
    8 x 40G ports uplink to different spine switches
    ECMP across all uplink ports
    GE
    mgmt.
    AS6712-32x

    View Slide

  14. Metro
    Router
    White Box White Box
    White Box
    White Box
    White Box White Box White Box White Box
    White Box White Box White Box
    White Box
    White Box
    White Box
    Open Source
    SDN-based
    Bare-metal
    White Box
    White Box
    R,E,M-
    Access
    Trellis Architecture
    14
    ONOS Controller Cluster
    vRouter
    Control
    XOS (Orchestrator)
    vSG
    VNF
    VNF VNF
    VNF
    vSG VNF
    VNF
    VNF
    VNF
    vSG VNF
    VNF VNF
    VNF
    OVS OVS OVS OVS OVS
    Residential Mobile Enterprise
    Underlay
    Control
    Underlay
    Overlay
    Control
    Overlay
    vOLT
    Control

    View Slide

  15. Virtual Network Overlay
    15
    OVS
    OVS
    OVS
    OVS
    OVS
    OVS
    OVS
    OVS
    OVS
    Service VNFs & vNets
    Non-overlapping addresses
    Service B
    Virtual Network
    Tenant Green
    Virtual Network
    Overlapping address space
    Connectivity isolation
    VMs/Containers
    Service Y
    Virtual Network
    Tenant Blue
    Virtual Network
    Services can dynamically
    grow or shrink
    VXLAN Overlay VXLAN Overlay
    VXLAN
    Overlay
    Single VXLAN
    port in OVS

    View Slide

  16. Trellis Summary
    • Underlay Fabric
    § L2/L3 spine-leaf fabric – Bare-metal hardware + open source software
    § SDN control plane – No distributed protocols
    § Modern ASIC data plane – 1.28 Tbps switching bandwidth for each switch
    • Virtual Network Overlay
    § Designed for NFV – ChainedVNFs using with best principles of cloud
    § Overlay Control – XOS and VTN implement service graph
    § OVS + VXLAN Data Plane
    • Unified SDN Control
    § Common Control – Opportunity for optimized service delivery
    16

    View Slide

  17. Show Case
    Leaf and Spine Traffic Engineering using Segment Routing and ONOS
    17

    View Slide

  18. Leaf-Spine Traffic Engineering
    18
    Ref: http://blog.sflow.com/2015/06/leaf-and-spine-traffic-engineering.html

    View Slide

  19. 19

    View Slide

  20. ONOS Community
    Open and Community-Driven.
    20

    View Slide

  21. 21

    View Slide

  22. 22

    View Slide

  23. ONOS Brigades
    • Build and Package Infrastructure
    • Deployments
    • Dynamic configuration
    • gRPC
    • GUI
    • Lion (Localization/Internationalization)
    23
    Ref: https://wiki.onosproject.org/display/ONOS/SONA:+DC+Network+Virtualization
    • Orchestration
    • P4
    • Security &
    performance analysis
    • Teaching
    • Virtualization

    View Slide

  24. Join us !!!!
    24

    View Slide

  25. Thank you!
    www.opennetworking.org

    View Slide
