Sentinel - The First Home Security Robot Powered by Android Things

Sentinel - The First Home Security Robot Powered by Android Things

Hackster Project: https://hackster.io/oscarsalguero/sentinel-8234b3
Presented at Google New York with the NYC-GDG.
July 10th 2017.
Periscope Video: https://www.pscp.tv/w/1YqKDwNlrMaxV

Oscar Salguero

July 10, 2017
Tweet

More Decks by Oscar Salguero

Other Decks in Technology

Transcript

  1. Sentinel (A Work In Progress) The First Home Security Robot

    Powered by Android Things™ https://www.hackster.io/oscarsalguero/sentinel-8234b3 Oscar Salguero @OscarSalguero
  2. Agenda • Motivation • Hardware • Software • Valuable Tips

    • Demo • Roadmap
  3. Motivation

  4. • Expensive • Monthly Fees • Gotta have one on

    each room • Hackable • Complicated Setup • Can’t See Anything Without Dynamic DNS • OEM and Third Party Apps are Unreliable Home Security Cameras Suck
  5. • Don’t Talk To Other Smart Home or IoT Hardware

    • Use Email • Send You Unrelevant Push Notifications • No Face Recognition! • No Image Classification! Home Security Solutions are Dumb
  6. • Dogs move from room to room or go outside

    • Yeah!… Cats kinda move around too. • Throw Fido a ball, or scare your Cat! ;P • You just want to stalk your pets • Want to keep an eye on the kids • Want to see if some delivery arrived Where Is My Pet and What is He/She Doing?
  7. Hardware

  8. Rover 5 Platform https://www.pololu.com/product/1535

  9. Raspberry Pi 3, & SD Card with Android Things ™

    https://www.adafruit.com/product/3292
  10. Rasperry Pi Camera Module v2 https://www.adafruit.com/product/3099

  11. Adafruit Motor Hat & Servo Hat https://www.adafruit.com/product/2348 and https://www.adafruit.com/product/2327

  12. Other Stuff • Pan/Tilt Bracket (https://www.sparkfun.com /products/10335) • 3D Printed

    Camera Mount • Expansion Plates • Cables, wires • Standoffs, nuts, screws, etc. • Power Bank (Battery Pack)
  13. Software

  14. Android All The Things • Android Studio 3.0 • Android

    Phone • Android Things ™ • Antonio Zugaldia’s Android Robocar Project (PWM and Motor Hat Java Library) http://androidrobocar.com
  15. Companion Android App • See your pet from anywhere! •

    Remote Control • Image History
  16. Firebase & Google Cloud Galore

  17. Valuable Tips

  18. Valuable Tips • Draw, sketch or diagram your idea first

    • Write down a list of desirable features • Research about the technologies such as APIs, protocols, etc. you’ll need to achieve the desired features • Write down a list of parts and materials • Research about the parts and materials before purchasing them; pros/cons matter
  19. Valuable Tips • Learn about circuits, voltages, current, etc... BEFOREHAND!

    • Be mindful about power requirements • Run and analyze google sample code (GitHub) • Ask questions (forums, Stack Overflow… the Interwebz) • Watch how it done (YouTube) • Try not to burn your fingers when soldering the headers (Ouch, it hurts!)
  20. Roadmap • Face Detection And Tracking (Google Mobile Vision) •

    Face Recognition (TF) • Real Time Image Classification (TF) • Movement Detection • “Smart” Push Notifications (Firebase) • Pan/Tilt Bracket controlled with right joystick on the 8Bitdo NES 30 Pro controller • Voice Control • Autonomous Patrolling • Find Your Pet
  21. Demo

  22. Questions? This presentation is available at: https://goo.gl/Jjwr8F

  23. Thank You! Oscar Salguero @OscarSalguero

  24. Sentinel Will Be Back to GDG NYC on 08/07! The

    First Home Security Robot Powered by Android Things™ https://www.hackster.io/oscarsalguero/sentinel-8234b3 Oscar Salguero @OscarSalguero
