Automated Android CI, how hard can it be? by Nicolas Fränkel

Transcript

1. AUTOMATED ANDROID CONTINUOUS INTEGRATION: HOW HARD CAN IT BE? @NICOLAS_FRANKEL
2. ME, MYSELF AND I @nicolas_frankel #springboot 2 Ø  Backend Java Developer •  As consultant
3. HYBRIS, AN SAP COMPANY 3 @nicolas_frankel #springboot
4. THE EXISTING ORGANIZATION SoIware Factory Mobile Dev Team
5. THE REAL ORGANIZATION SoIware Factory Mobile Dev Team
6. THE EXISTING SITUATION
7. SOFTWARE INSTALL AUTOMATION
8. SOFTWARE INSTALL AUTOMATION
9. JENKINS JOB CONFIGURATION Ø  No central registry • Stored in XML • In each job’s folder
10. WHAT WE DID Ø Analyzed the config of an exisXng job Ø Divided it into snippets Ø Created Puppet template for each Ø Assembled and filled in snippets through classes
11. WHAT WE DID Ø CreaXon of a Jenkins DSL in Puppet
12. WHY FAIL? Ø Time-consuming Ø Error-prone Ø Fragile • ImplementaGon details Ø ReinvenXng the wheel
13. ALTERNATIVES Ø Jenkins Job Builder • Part of OpenStack • DSL that calls Jenkins API •  YAML configuraGon
14. SOFTWARE INSTALL AUTOMATION
15. DEPENDENCIES
16. THE CHALLENGE
17. ISSUES 1.  Gradle Wrapper 2.  Robolectric 3.  Android pla_orms/extra/ add-ons
18. JENKINS GRADLE PLUGIN
19. GRADLE ISSUE Ø ./gradlew xxx
20. GRADLE WRAPPER Ø Made of: • A JAR • A property Ø Downloads the required version from the Internet
21. GRADLE-WRAPPER.PROPERTIES distributionUrl= https\://services.gradle.org/distributions/ gradle-2.3-bin.zip
22. THE ROOT ISSUE Ø The proxy…
23. REQUIREMENT Ø ArXfactory Ø Nexus Ø Simple Web Server?
24. UPDATED GRADLE-WRAPPER.PROPERTIES distributionUrl= https\://intranet.mydomain.org/org/gradle/ gradle-2.3-bin.zip
25. GRADLE ISSUE Ø ./gradlew xxx
26. ROBOLECTRIC ISSUE Ø ./gradlew test
27. AN ERROR!? Error:Could not HEAD 'http:// repo1.maven.org/maven2/org/robolectric/ robolectric-gradle-plugin/0.12.0/ robolectric-gradle-plugin-0.12.0.jar'. Received status code 407 from server: AuthorizedOnly
28. GRADLE.PROPERTIES systemProp.http.proxyHost=mydomain.org systemProp.http.proxyPort=8080 systemProp.http.proxyUser=user systemProp.http.proxyPassword=password
29. WTF!?... SAME ERROR
30. Y U ROBOLECTRIC? public class RobolectricTestRunner { protected DependencyResolver getJarResolver() { if (dependencyResolver == null) { if (Boolean.getBoolean("robolectric.offline")) { String dependencyDir = System.getProperty( "robolectric.dependency.dir", "."); dependencyResolver = new LocalDependencyResolver( new File(dependencyDir)); } else { File cacheDir = new File(new File( System.getProperty("java.io.tmpdir")), "robolectric"); if (cacheDir.exists() || cacheDir.mkdir()) { Logger.info( "Dependency cache location: %s", cacheDir.getAbsolutePath()); dependencyResolver = new CachedDependencyResolver( new MavenDependencyResolver(), cacheDir, 60 * 60 * 24 * 1000); } else { dependencyResolver = new MavenDependencyResolver(); } } } }
31. Y U ROBOLECTRIC? <?xml version="1.0" encoding="UTF-8"?> <project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/maven-v4_0_0.xsd"> <modelVersion>4.0.0</modelVersion> <parent> <groupId>org.robolectric</groupId> <artifactId>robolectric-parent</artifactId> <version>3.1-SNAPSHOT</version> </parent> <artifactId>robolectric</artifactId> <dependencies> ... <dependency> <groupId>org.apache.maven</groupId> <artifactId>maven-ant-tasks</artifactId> <version>2.1.3</version> <exclusions> <exclusion> <groupId>*</groupId> <artifactId>*</artifactId> </exclusion> </exclusions> </dependency> </dependencies> </project>
32. Y U ROBOLECTRIC? “Robolectric downloads a version of Android at runXme that's built specifically for running tests. Each API level is ~40mb, so producing a single jar file that includes everything would be prohibiXve. All of the arXfacts are available on maven central under the coordinates: org.robolectric:android-all. You can grab the API levels from maven central and use them with offline mode.” hlps://groups.google.com/forum/#!topic/robolectric/ nJgHtdbkpi8
33. Y U ROBOLECTRIC? Ø Uses a custom class loader Ø Either: • Download dependencies beforehand • Override method • Pass through proxy K
34. YOUR OWN TEST RUNNER @Override protected DependencyResolver getJarResolver() { if (this.dependencyResolver == null) { if (Boolean.getBoolean("robolectric.offline")) { String cacheDir = System.getProperty( "robolectric.dependency.dir", "."); this.dependencyResolver = new LocalDependencyResolver( new File(cacheDir)); } else { this.dependencyResolver = new MyResolver(); } } return this.dependencyResolver; }
35. YOUR OWN RESOLVER public class MyResolver extends MavenDependencyResolver { @Override protected void configureMaven( DependenciesTask task) { RemoteRepository remoteRepository = new RemoteRepository(); remoteRepository.setId("My Maven repo"); remoteRepository.setUrl(BuildConfig.NEXUS_URL); task.addConfiguredRemoteRepository( remoteRepository); } }
36. ROBOLECTRIC ISSUE Ø ./gradlew test
37. ANDROID SDK ISSUE Ø android update sdk
38. ANDROID SDK ISSUE Ø android update sdk -u Non interacXve mode
39. 2 ISSUES Ø Set the proxy Ø Accept license agreements
40. ANDROID SDK --HELP Action "update sdk": Updates the SDK by suggesting new platforms to install if available. Options: -f --force : Forces replacement of a package or its parts, even if something has been modified. -n --dry-mode : Simulates the update but does not download or install anything. --proxy-host: HTTP/HTTPS proxy host (overrides settings if defined) -s --no-https : Uses HTTP instead of HTTPS (the default) for downloads. -t --filter : A filter that limits the update to the specified types of packages in the form of a comma-separated list of [platform, system-image, tool, platform-tool, doc, sample, source]. This also accepts the identifiers returned by 'list sdk --extended'. -u --no-ui : Updates from command-line (does not display the GUI) --proxy-port: HTTP/HTTPS proxy port (overrides settings if defined) -p --obsolete : Deprecated. Please use --all instead. -a --all : Includes all packages (such as obsolete and non-dependent ones.)
41. WTF?!!? Ø Accepts proxy parameters Ø But no authenXcaXon…
42. SOLUTIONS (THANKS GOOGLE FOR NOTHING) Ø Environments variables Ø Specific credenXal file Ø Local proxy L
43. A WORKING SOLUTION: EXPECT Ø Linux binary Ø Originally for tesXng purpose Ø Script input in regard to output
44. (VERY) SIMPLE EXPECT SCRIPT #!/usr/bin/expect eval spawn jot -r 1 0 1 expect { "0" { puts "zero" } "1" { puts "one" } }
45. THE “REAL” SCRIPT #!/bin/bash expect -d -c ' log_file /var/log/update-android.log set timeout -1 spawn <%= @android_sdk_dir %>/tools/android -v update sdk -a -u -f --proxy-host\ <%= @proxy_host %> --proxy-port <%= @proxy_port %> -t <%= @joined_packages %> while {1} { expect { "Login:" { send "<%= @proxy_user %>\r" } "Password:" { send "<%= @proxy_password %>\r" } "Workstation:" { send "\r" } "Domain:" { send "\r" } -re ".*\[y\/n\]:" { send "y\r" } } }' Handles the proxy Handles license agreements
46. ANDROID SDK ISSUE Ø android update sdk -u
47. ANDROID CONTINUOUS INTEGRATION? Ø Not mature • Lags behind “standard” Java Ø So Xme-consuming… • But possible!
48. Q&A @nicolas_frankel 48 hlp://blog.frankel.ch/ @nicolas_frankel hlp://frankel.in/
