Interactive visual analytics using Sencha Charts by Vitaly Kravchenko

Charts and graphs are core to any enterprise grade analytics application. With Ext JS 5, Sencha Charts (formerly a part of Sencha Touch) provide advanced charting capabilities with interactive features for both desktop and mobile devices. The session walks through all the Do's and Don'ts of using Sencha Charts, how to add interactions, and how to migrate from old Ext JS Charts package to Sencha Charts. You will also learn about the fundamentals of sprites to customize the rendering of various charts elements.

Transcript

1. View Slide

2. Interactive visual analytics
   using Sencha Charts
   Vitaly Kravchenko
   SenchaCon 2015 - April 9, 2015


   View Slide

3. Vitaly Kravchenko
   Graphics Engineer, Sencha


   View Slide

4. Ext Core


   View Slide

5. Charts and Draw packages
   are shared by both toolkits
   Classic Modern


   View Slide

6. View Slide

7. View Slide

8. items: {

   xtype: 'cartesian',



   series: {

   type: 'bar3d'

   },



   axes: [{

   type: 'numeric3d',

   position: 'left'

   }, {

   type: 'category3d',

   position: 'bottom'

   }]

   }
   3D Bar


   View Slide

9. 3D Pie
   series: {

   type: 'pie3d'

   }


   View Slide

10. View Slide

11. View Slide

12. Challenge


    View Slide

13. View Slide

14. View Slide

15. View Slide

16. View Slide

17. View Slide

18. View Slide

19. Data


    View Slide

20. {label: 'year', span: 100},
    // Northeast region

    {label: 'CT', span: 100, y2007: 0.2, ..., y2012: -0.6, state: 'Connecticut'},

    {label: 'DE', span: 100, y2007: 0.0, ..., y2012: -0.3, state: 'Delaware'},

    ...



    {label: '', span: 20},


    // Southeast region

    {label: 'AL', span: 100, y2007: -0.1, ..., y2012: -1.4, state: 'Alabama'},

    {label: 'DC', span: 100, y2007: -0.2, ..., y2012: -1.1, state: 'District of Columbia’},
    ...


    View Slide

21. items: [

    {

    xtype: 'polar',



    store: {

    type: 'unemployment'

    },



    series: [{


    type: ‘pie',


    angleField: 'span',



    donut: 93



    }]

    }

    ]


    View Slide

22. View Slide

23. layout: 'absolute',

    width: 990,



    items: [

    {

    xtype: 'polar',



    width: '100%',

    height: 1375,


    insetPadding: '400 0 125 0’,
    . . .
    400
    0
    0
    125


    View Slide

24. Adding infographic content


    View Slide

25. HTML vs Sprites


    View Slide

26. sprites: [

    {

    type: 'rect',

    x: 50,

    y: 40,

    width: 890,

    height: 100,

    fillStyle: 'rgb(77, 77, 77)'

    },

    {

    type: 'text',

    text: 'Changes in U.S. Unemployment',

    font: 'bold 54px Charter',

    fillStyle: 'white',

    x: 70,

    y: 120

    }


    View Slide

27. Labels?


    View Slide

28. series: {

    type: 'pie',

    . . .


    label: {

    field: ‘label',


    display: ‘inside',


    fillStyle: ‘white',


    fontSize: 13,
    fontWeight: ‘bold',

    fontFamily: 'Tahoma'

    }

    }


    View Slide

29. View Slide

30. series: {

    type: 'pie',

    angleField: ‘span',
    ...,



    label: {

    field: ‘label',
    ...,



    renderer: 'onLabelRender2012'

    },
    renderer: 'onSliceRender2012'



    }


    View Slide

31. onLabelRender2012: function (text, sprite, config, data, index) {

    if (text === 'year') {

    return {

    text: '2012',

    font: 'bold 16px sans-serif'

    };

    }

    }


    View Slide

32. onSliceRender2012: function (sprite, config, data, index) {

    var record = data.store.getAt(index),

    label = record.get('label'),

    unemployment = record.get('y2012'),

    style = {};



    if (label === '') {

    style.fillStyle = 'none';

    style.strokeStyle = 'none';

    } else if (label === 'year') {

    style.fillStyle = ‘#444';

    } else {

    style.fillStyle = this.getStateColor(unemployment);

    }

    return style;

    }


    View Slide

33. View Slide

34. series: [{

    type: 'pie',

    angleField: 'span',



    donut: 93

    }, {

    type: 'pie',

    angleField: 'span',



    radiusFactor: 93,

    donut: 86

    }, {

    type: 'pie',

    angleField: 'span',



    radiusFactor: 86,

    donut: 79,

    }, {
    . . .


    View Slide

35. View Slide

36. Interactions


    View Slide

37. highlight: true
    highlightCfg: {

    margin: 20

    }
    highlight: {

    fillStyle: 'yellow'

    }
    highlight: {

    fillStyle: ‘yellow',
    margin: 0

    }
    highlightCfg: {

    fllStyle: 'yellow'

    }


    View Slide

38. Performance Optimization


    View Slide

39. {

    xtype: 'polar',



    interactions: ['itemhighlight'],



    series: [

    {

    type: 'pie',

    angleField: 'span',



    donut: 57,



    subStyle: {

    fillStyle: 'none',

    strokeStyle: 'none'

    },



    highlightCfg: {

    fillStyle: 'rgba(0,0,0,0.2)'

    },
    . . .


    View Slide

40. Adding cartesian chart


    View Slide

41. {

    xtype: 'cartesian',



    width: 350,

    height: 250,



    x: 300,

    y: 700,



    series: {

    type: 'bar',



    xField: 'year',

    yField: 'percent',



    renderer: 'onBarRender'

    }
    }


    View Slide

42. listeners: {

    itemhighlight: 'onItemHighlight'

    }


    View Slide

43. var storeData = [

    {year: '2007', percent: recordData.y2007},

    {year: '2008', percent: recordData.y2008},

    {year: '2009', percent: recordData.y2009},

    {year: '2010', percent: recordData.y2010},

    {year: '2011', percent: recordData.y2011},

    {year: '2012', percent: recordData.y2012}

    ];
    onItemHighlight: function (chart, item) {



    var recordData = item.record.data;
    this.lookupReference('cartesian').getStore().setData(storeData);


    View Slide

44. View Slide

45. Draw package


    View Slide

46. Main features
    ✦ Allows to create arbitrary graphics
    ✦ Renderer agnostic
    ✦ Sprite based


    View Slide

47. Ext.draw.Container
    Ext.draw.Surface
    Ext.draw.Surface
    Ext.draw.Surface
    Sprite Sprite
    Sprite


    View Slide

48. Surface management
    Ext.draw.Container
    config: {

    resizeHandler: null
    }
    drawContainer.renderFrame();
    defaultResizeHandler: function (size) {

    this.getItems().each(function (surface) {

    surface.setRect([0, 0, size.width, size.height]);

    });

    }


    View Slide

49. Ext.chart.AbstractChart
    series surface
    performLayout();
    bottom axis surface x
    left axis surface
    y


    View Slide

50. Surface creation
    drawContainer.getSurface(id);


    View Slide

51. Engines
    engine: 'Ext.draw.engine.Canvas'
    engine: 'Ext.draw.engine.SVG'


    View Slide

52. Draw Surface
    Ext.draw.Surface
    Ext.draw.engine.Canvas Ext.draw.engine.Svg
    Canvas VML SVG
    Ext.draw.engine.SvgContext
    Native Canvas 2D context Ext.draw.engine.excanvas
    Ext.Widget Ext.Component
    CLASSIC MODERN


    View Slide

53. Surface methods
    surface.renderFrame();
    add(config/sprite);
    remove(sprite/id);
    get(id);
    clear();
    surface.renderSprite(sprite);
    sprite.render(ctx);


    View Slide

54. Performant Flexible Extensible
    General Purpose
    Themeable
    Bi-directional
    Renderer Agnostic
    Mobile / Touch Cross-toolkit


    View Slide

55. Credits: http://goo.gl/5ywnzO
    Twitter: @vitalyx
    Thank you!
    Example code: https://github.com/yay/SenchaCon2015
