Testing a constraint-based layout of UIView iOS Test Night #11
Shin Yamamoto @scenee #ios_test_night
今日は.. • AutoLayout(constraint-based)のレイアウトテスト • 前提と手法 • UIViewにフォーカス ◦ UIViewControllerは割愛しますが、ほぼ同じ
なぜUIViewレイアウトを テストしたいのか?
XCTestでレイアウトを ユニットテストしたいから
XCTestでレイアウトをユニットテストしたい • OSSのメンテンスなどで必要に QAで時間が溶ける!
XCTestでレイアウトをユニットテストしたい • OSSのメンテンスなどで必要に QAで時間が溶ける! • 安心して追加変更、デグレ防止
XCTestでレイアウトをユニットテストしたい • OSSのメンテンスなどで必要に QAで時間が溶ける! • 安心して追加変更、デグレ防止 • 素早い開発フィードバックループ Design Develop
Unit testing
どうしたらレイアウトを ユニットテストできるか?
SnapshotTesting with Jest
SnapshotTesting with Jest • 画面に描画する • Reactツリーを出力 • 比較 •
差分検出
ポイントは...
レンダラーを信頼する
レンダラーが あるレイアウトを期待通り描画する と仮定すること!
コントロールできない領域を テスト対象から除外する
UIKitのレンダラーを信頼する • あるレイアウト結果が、期待通りに描画されると想定 • レイアウト結果とは ◦ UIViewの各プロパティ値(frameなど) ◦ View hierarchy(Layer
tree) ◦ など
もう少し詳しく説明します
High Performance Auto Layout: https://developer.apple.com/videos/play/wwdc2018/220
High Performance Auto Layout: https://developer.apple.com/videos/play/wwdc2018/220 Layout pass Update pass Display
pass
High Performance Auto Layout: https://developer.apple.com/videos/play/wwdc2018/220 draw(_:) layoutSubviews(_:) updateConstraints(_:)
High Performance Auto Layout: https://developer.apple.com/videos/play/wwdc2018/220 draw(_:)はテストしない layoutSubviews(_:) updateConstraints(_:)
何が嬉しいのか?
レイアウトのパラメーター化 • レイアウトを各パラメーターの集合として処理 • 各パラメーターの変化をXCTestで評価
Pros • 気軽にViewのテストが書ける • Viewの振る舞いをテストで記述・保存 ◦ i.e. リグレッションテストが簡単に • Viewをテスト駆動で開発・リファクタ
◦ i.e. frame-based layoutからの移行が楽に
Cons • 描画結果が想定と異なるケースがある
この前提の上で...
早速テストを書いてみましょう! コード例ではわかりやすさのため使ってませんが、 swift-snaphost-testing が便利 https://github.com/pointfreeco/swift-snapshot-testing
MyView .containerView top bottom left right
MyView .containerView top bottom left right
レイアウト更新をテスト
レイアウト更新をテスト
レイアウト更新をテスト
レイアウト更新をテスト
❌ Failed: frame値が.zero
レイアウト更新をテスト
レイアウト更新をテスト
✅ Passed: frameが期待通り更新
なぜ?
Layout passを手動実行している
Layout passを手動実行している setNeedsLayoutはLayout passをlayoutIfNeededで実行するために
Mysteries of Auto Layout, Part 2: https://developer.apple.com/videos/play/wwdc2015/219
1. 制約の変更 2. setNeedsLayout() + layoutIfNeeded() 3. frameを評価 XCTestでのレイアウトテスト方法
• Intrinsic Content Sizeに応じたテスト可 • Unsatisfiable constraintsエラーもコンソールに出力 補足
簡単ですね! あくまで導入です!でも導入が大事。
✅ Passed: UIWindow + MainRunLoop ✏ Frameworkでは、Host Application追加不要
まとめ: XCTestでレイアウトテストをするには? • UIKitのレンダラーを信頼する • レイアウトをパラメーター化して評価 • レイアウト更新するにはLayout passを手動実行
References ◦ https://jestjs.io/docs/en/snapshot-testing Snapshot Testing · Jest ◦ https://github.com/pointfreeco/swift-snapshot-testing swift-snapshot-testing
◦ https://developer.apple.com/videos/play/wwdc2015/219 Mysteries of Auto Layout, Part 2 ◦ https://developer.apple.com/videos/play/wwdc2018/220 High Performance Auto Layout ◦ http://tech.gc.com/demystifying-ios-layout/ Demystifying iOS Layout
Happy Testing 質問があればぜひ懇親会で話かけてください
