Vault @ Continuous Lifecycle 2016

Transcript

1. Vault Mittwoch, 16. November Simon Kölsch
2. Storing Credentials [..] String username = “foo” String password = “bar” [..]
3. Storing Credentials Environment config.json Application [..] { username = “foo” password = “bar” } [..] Maybe Encryption
4. The Problems > Who has access to secrets? > How to revoke/update secrets? > How to lease secrets? > How to not make a difference between a user and an application?
5. The Solution > Put the secrets into a secure store > Create an API > Change secrets after use > Create temporary credentials > Log every access to the store
6. DIY? > Writing secure software is hard > Writing security software is even harder > If your application needs HA, your infrastructure needs also HA > Writing HA security software is much much harder
7. Why Vault? > This talk is about Vault > It is not the only secret store, but a nice one > Checkout Keywhiz as an alternative:
 https://square.github.io/keywhiz/ > Check your requirements!
8. Vault Overview Vault Service HTTP API Storage Backend
9. Vault Overview Vault Service HTTP API CLI Storage Backend Clients Client Library Monitoring
10. CC0, https://www.pexels.com/photo/24h-always-open-neon-neon-signs-18947
11. Vault HA Setup Storage Backend Storage Backend Vault Service HTTP API CLI Vault Service HTTP API Standby Storage Backend Active Clients Client Library Monitoring
12. How to Interact? > CLI > RESTful API > Client Libraries > Go > Ruby > Java, Node, PHP, Python, Scala, C#, Ansible, …
13. Initialize your Vault Public Domain, https://commons.wikimedia.org/wiki/File%3ASAS_Container.png
14. Initialize your Vault > Define key shares (-key-shares=5) > Define shares needed for unlocking
 (-key-threshold=3) > Initialize > Unseal
15. λ ~ vault init -key-shares=5 -key-threshold=3
 Unseal Key 1: pNVHTqoTwVeONEVLfHyrLjH+bD3+Q1WS1ixbI/vI9HUB Unseal Key 2: hsoNYsxhuEay8J71R3BZoIEsnIjGdg6cYNIFK6/XROwC Unseal Key 3: UnQ+yyIOgOmoOpKGjTc1+1odwpSFPbhZ+LGgCwwD9iED Unseal Key 4: iAf662hnv16Q0O0VrJTjUwkgPRqSeXypBhmN6DNqrWkE Unseal Key 5: XLnJQoYIh/GKGuFmZtOPCNIRYwbRMspsnnooyJC+H6QF Initial Root Token: 25d5513b-70b2-2ced-488f-7e3d718d1115 Vault initialized with 5 keys and a key threshold of 3.
 Please securely distribute the above keys.
 When the Vault is re-sealed, restarted, or stopped, you must provide at least 3 of these keys to unseal it again. Vault does not store the master key.
 Without at least 3 keys, your Vault will remain permanently sealed.
16. λ ~ vault unseal Key (will be hidden): pNVHTqoTwVeONEVLfHyrLjH+bD3+Q1WS1ixbI/vI9HUB Sealed: true Key Shares: 5 Key Threshold: 3 Unseal Progress: 1


17. λ ~ vault unseal Key (will be hidden): pNVHTqoTwVeONEVLfHyrLjH+bD3+Q1WS1ixbI/vI9HUB Sealed: true Key Shares: 5 Key Threshold: 3 Unseal Progress: 1
 [..]
 λ ~ vault unseal Key (will be hidden): UnQ+yyIOgOmoOpKGjTc1+1odwpSFPbhZ+LGgCwwD9iED Sealed: false Key Shares: 5 Key Threshold: 3 Unseal Progress: 0
18. “Data Model” JSON Meta Data Secret ACL CC0, https://www.pexels.com/photo/dawn-nature-tree-romania-56875
19. Storing a Secret
20. λ ~ vault auth 25d5513b-70b2-2ced-488f-7e3d718d1115 Successfully authenticated! You are now logged in. token: 25d5513b-70b2-2ced-488f-7e3d718d1115 token_duration: 0 token_policies: [root]




21. λ ~ vault auth 25d5513b-70b2-2ced-488f-7e3d718d1115 Successfully authenticated! You are now logged in. token: 25d5513b-70b2-2ced-488f-7e3d718d1115 token_duration: 0 token_policies: [root]
 λ ~ vault write secret/somePath user=foo password=bar Success! Data written to: secret/somePath



22. λ ~ vault auth 25d5513b-70b2-2ced-488f-7e3d718d1115 Successfully authenticated! You are now logged in. token: 25d5513b-70b2-2ced-488f-7e3d718d1115 token_duration: 0 token_policies: [root]
 λ ~ vault write secret/somePath user=foo password=bar Success! Data written to: secret/somePath

 λ ~ echo -n '{"user":"foo", "password":"bar"}'|
 vault write secret/someOtherPath -
 Success! Data written to: secret/someOtherPath

23. Reading a Secret
24. λ ~ vault read secret/somePath Key Value --- ----- refresh_interval 768h0m0s password bar user foo

25. λ ~ vault read secret/somePath Key Value --- ----- refresh_interval 768h0m0s password bar user foo
 λ ~ vault read -format=json secret/somePath { "request_id": "f1f65da9-42d5-273e-50e9-9a3c55b479d4", "lease_id": "", "lease_duration": 2764800, "renewable": false, "data": { "password": "bar", "user": "foo" }, "warnings": null }
26. λ ~ curl -s
 -H “X-Vault-Token:25d55-[..]–2ced-d1115”
 http://localhost:8200/v1/secret/somePath |
 jq .data.user
 “foo"
27. More Secret Backends > Database Backends > SSH




28. Host SSH vault-ssh- helper PAM *.so Vault pam_exec.so - Username - IP Address
29. More Secret Backends > Database Backends > SSH > Transit > PKI (X.509 Certificates)

30. Vault Root CA Store HTTP API CSR Certificate Root Certificate Intermediate Certificate Service
31. More Secret Backends > Database Backends > SSH > Transit > PKI (X.509 Certificates) > Others
32. > Consul * > etcd > Zookeeper > DynamoDB > Azure and S3 Storage Backends > MySQL > PostgreSQL > Filesystem * > (In Memory *) = High Availability * Officially Supported
33. Auth Backends > Token > Username & Password > App Role / App ID > MFA > AWS EC2 > Github > LDAP > TLS Client Cert
34. Auditing > Audit Backends > Syslog > File > Full requests / responses are logged > Sensitive data is hashed with a salt > Beware of blocking!
35. Enterprise Features > The usual 24/7 support contract > (HSM integration) > Web UI / Dashboard
36. Simon Kölsch | @simkoelsch simon.koelsch@innoq.com innoQ Deutschland GmbH Krischerstr. 100 40789 Monheim am Rhein Germany Phone: +49 2173 3366-0 innoQ Schweiz GmbH Gewerbestr. 11 CH-6330 Cham Switzerland Phone: +41 41 743 0116 www.innoq.com Ohlauer Straße 43 10999 Berlin Germany Phone: +49 2173 3366-0 Robert-Bosch-Straße 7 64293 Darmstadt Germany Phone: +49 2173 3366-0 Radlkoferstraße 2 D-81373 München Germany Telefon +49 (0) 89 741185-270 Thank you! Questions?
    Comments?
