MicroFrontends - A Strive for fully Verticalized Systems

µCon London 2019 (London, Uk)

https://skillsmatter.com/conferences/11982-con-london-2019-the-conference-on-microservices-ddd-and-software-architecture

video: https://skillsmatter.com/skillscasts/13498-micro-frontends-a-strive-for-fully-verticalized-systems#video

Transcript

1. @duffleit leitner.io Micro Frontends a Strive for Fully Verticalized Systems µCon London 2019 @duffleit leitner.io
2. @duffleit leitner.io David Leitner Senacor Technologies
3. @duffleit leitner.io “the idea of micro frontends is to extend the concept of micro services to the frontend world.”
4. @duffleit leitner.io Secret 1: That's fine in 80 % of the cases. SPA API Gateway Microservice Microservice Microservice DB DB DB
5. @duffleit leitner.io Monolith API Gateway SPA DB Secret 2: That's also fine in 80 % of the cases.
6. @duffleit leitner.io Microservice API Gateway SPA Microservice Microservice DB DB DB
7. @duffleit leitner.io Sam Newman “microservices are small and focused on one thing to be autonomous.”
8. @duffleit leitner.io Why autonomous? ✔ Independent Deployments ✔ Distinct Operations ✔ Technology Agnostic ✔ Model around Business Domains ✔ Small Interface Surface ✔ Parallel development
9. @duffleit leitner.io Microservice API Gateway SPA Microservice Microservice DB DB DB ❌ Independent Deployments ❌ Distinct Operations ❌ Technology Agnostic ❌ Small Interface Surface ❌ Parallel development Frontend Monolith
10. @duffleit leitner.io Microservice API Gateway SPA Microservice Microservice DB DB DB SPA API Gateway Micro Frontends
11. @duffleit leitner.io μService Ordering μService DB μService μService DB DB Catalogue Profile μService DB DB Hyperlink Hyperlink
12. @duffleit leitner.io ✔ Independent Deployments ✔ Distinct Operations ✔ Technology Agnostic ✔ Small Interface Surface ✔ Model around Business Domains ✔ Parallel development Based on the assumption to have fully verticalized systems. μService Ordering μService DB μService μService DB DB Catalogue Profile μService DB DB Hyperlink Hyperlink Approach 1: Hyperlink Connected Applications
13. @duffleit leitner.io μService Ordering μService DB μService μService DB DB Catalogue Profile μService DB DB Hyperlink Hyperlink Dashboard Hyperlink μService DB ⛔ Overfetching ⛔ Overrequesting Approach 1: Hyperlink Connected Applications
14. @duffleit leitner.io Approach 1: Hyperlink Connected Applications with Backend for Frontends μService Ordering μService DB μService μService DB DB Catalogue Profile μService DB DB Hyperlink Hyperlink Dashboard Hyperlink μService DB BFF Service BFF Service BFF Service BFF Service https://samnewman.io/patterns/architectural/bff/ Presentation Process Flow Domain Logic Data Presentation Process Flow Domain Logic Data
15. @duffleit leitner.io Approach 1: Hyperlink Connected Applications with GraphQL μService Ordering μService DB μService μService DB DB Catalogue Profile μService DB DB Hyperlink Hyperlink Dashboard Hyperlink μService DB GraphQL Presentation Process Flow Domain Logic Data
16. @duffleit leitner.io The more coarse-grained you can go, the more coarse-grained you should go. Or: Think big.
17. @duffleit leitner.io But,
18. @duffleit leitner.io Hyperlink Integration breaks your SPA.
19. @duffleit leitner.io
20. @duffleit leitner.io μService Ordering μService DB μService μService DB DB Catalogue Profile μService DB DB Hyperlink Hyperlink Dashboard Hyperlink μService DB View Aggregation Layer Horizontal Layer Ripple Effect
21. @duffleit leitner.io Dashboard Profile Profile μService DB Catalogue μService DB Catalogue Ordering Ordering μService DB Dashboard μService DB
22. @duffleit leitner.io Dashboard Profile Catalogue Ordering Ordering Catalogue Hyperlink Hyperlink Dashboard How to slice? One “Micro Frontend” per page. 2...n Micro Frontends per page.
23. @duffleit leitner.io How to integrate them?
24. @duffleit leitner.io Repository Build & Deploy Server Browser Composed Application Micro Frontend Build Time Integration Server Side Integration Runtime Integration
25. @duffleit leitner.io Repository Build & Deploy Server Browser Mono Repo package.json Composed Application Micro Frontend Build Time Integration MonoRepo ✔ Allows extensive code sharing and reuse. ✔ Simplifies Dependency Management. Angular Workspaces
26. @duffleit leitner.io Repository Build & Deploy Server Browser Composed Application Micro Frontend Build Time Integration ❌ Independent Deployments ❌ Distinct Operations ❌ Technology Agnostic ✔ Small Interface Surface ✔ Model around Business Domains ✔ Parallel development
27. @duffleit leitner.io Repository Build & Deploy Server Browser Composed Application Micro Frontend Server Side Integration Project Mosaic
28. @duffleit leitner.io Based on the concept of Server Side Includes or Edge Side Includes ⛔ JS and CSS global scoped ⛔ Round-Trips are needed
29. @duffleit leitner.io Tailor is a Layout Server header fragment μService account fragment μService catalogue fragment μService maps your request to a template checkout-template.html ... dashboard.template.html profile-template.html
30. @duffleit leitner.io supports Javascript-Isolation init(fragment-dom){ ... } How about account fragment μService html script styles 1...n
31. @duffleit leitner.io supports Javascript-Isolation account fragment μService html script styles 1...n init(fragment-dom){ ... } isolate CSS: naming-convention like BEM
32. @duffleit leitner.io Repository Build & Deploy Server Browser Composed Application Micro Frontend Server Side Integration ✔ Independent Deployments ✔ Distinct Operations ✔ Technology Agnostic ✔ Small Interface Surface ✔ Model around Business Domains ✔ Parallel development
33. @duffleit leitner.io Repository Build & Deploy Server Browser Composed Application Micro Frontend Runtime Integration Aggregating UI Routing, Templates, Lazy Loading
34. @duffleit leitner.io the aggregation is done on a single point. Aggregating UI
35. @duffleit leitner.io the aggregation and configuration is done on a single point. Aggregating UI
36. @duffleit leitner.io the aggregation and configuration is done on a single point. immutablewebapps.org index.html https://12factor.net/
37. @duffleit leitner.io Repository Build & Deploy Server Browser Composed Application Micro Frontend ✔ Independent Deployments ✔ Distinct Operations ✔ Technology Agnostic ✔ Small Interface Surface ✔ Model around Business Domains ✔ Parallel development Runtime Integration
38. @duffleit leitner.io Ok, which one to use?
39. @duffleit leitner.io Server Browser Server Side Integration Runtime Integration Request Response Model Interactions between different Verticals are done on the Backend. Longliving App State in the frontend & verticals need to interact with each other.
40. @duffleit leitner.io Cool, anything that can go wrong?
41. @duffleit leitner.io UI/UX Consistency Shared State Resilience Tracing/Analytics Offline-First ...
42. @duffleit leitner.io 1 Micro-Frontend per Page Hyperlink Integration n Micro-Frontends per Page Buildtime Integration Serverside Integration Runtime Integration
43. @duffleit leitner.io
44. @duffleit leitner.io Micro Frontends in a nutshell Integration and Slicing Is your application big?* Frontend Monolith no Are UI/Domain Parts strongly independent? yes Applications integrated with Hyperlinks yes Server Side Integration no Are Server-Roundtrips a problem? no Runtime Integration yes * an application is big enough to justify using micro frontends, if slight UI/UX differences between the two most unrelated subpages are acceptable.
45. @duffleit leitner.io Mix and Match Landing Shop Ordering hyperlink hyperlink <!–- SSIs --> <!--#include … --> <!--#include … --> APP SHELL Header Footer
46. @duffleit leitner.io Micro-Frontends are Distributed Systems. The Final Secret:
47. @duffleit leitner.io Everything that can go wrong will go wrong. The Final Secret: Murphy’s law
48. @duffleit leitner.io Think of starting with a monolithic first approach.
49. @duffleit leitner.io by: twitter.com/swardley
50. @duffleit leitner.io David Leitner Non-Hype-Train-Activist @duffleit
