1. Tony Arcieri · Oxidize Global · July 18th, 2020
   Embedded cryptography in Rust
   RustCrypto + Veriform


   View Slide

2. Hello!
   I’m Tony Arcieri
   • @bascule

   • tarcieri


   View Slide

3. @iqlusioninc


   View Slide

4. A quick plug
   How iqlusion is using RustCrypto
   • USB Armory mkII

   https://github.com/iqlusioninc/usbarmory.rs

   • Armistice: RTIC-based Hardware Security Module

   https://github.com/iqlusioninc/armistice


   View Slide

5. Back in 2014…


   View Slide

6. View Slide

7. Pure Rust Crypto
   WARNING: Proceed with caution!


   View Slide

8. Is Rust a good
   language for crypto?
   Timing side-channels
   Is it possible to generate
   constant-time assembly
   from Rust source code?
   Towards a Rust
   common crypto library


   View Slide

9. Conclusion
   Two-pronged approach
   1. Wrap mainstream crypto libs

   2. Experimental pure Rust crypto
   Final thoughts
   • Rust has immense potential for cryptography but
   we must tread carefully
   • Rust code without any branches isn’t necessarily
   constant time. Beware LLVM!
   • Stick with wrappers to mainstream crypto
   libraries until pure Rust crypto is more mature


   View Slide

10. 2020
    Two-pronged approach to Rust Cryptography
    • Libraries which wrap high-quality non-Rust crypto implementations:

    • ring
    • sodiumoxide (wrapper for libsodium/NaCl)
    • secp256k1-rs

    • Pure Rust cryptography:

    • RustCrypto

    • Dalek libraries (e.g. curve25519-dalek)

    • fiat-rust



    View Slide

11. What is RustCrypto?


    View Slide

12. ⚠



    View Slide

13. rust-crypto


    View Slide

14. RustCrypto
    https://github.com/RustCrypto
    “2.0”


    View Slide

15. View Slide

16. RustCrypto
    Project information
    • Home: https://github.com/RustCrypto

    • Started in 2016

    • Leads:

    • Artyom Pavlov (@newpavlov)

    • Myself (@tarcieri)

    • ~12 additional active contributors

    • ~100 crates


    View Slide

17. RustCrypto
    You might already be using one of these crates:
    • aes
    • blake2
    • digest
    • hmac
    • sha2


    View Slide

18. Rethinking `rust-crypto`
    Multi-crate architecture
    2016


    View Slide

19. RustCrypto
    Goals and Architectural Principles
    • Pure Rust as a baseline

    • #![no_std] as a baseline

    • Portable implementations which work on all targets

    • Optional assembly is allowed (off-by-default / opt-in only)

    • Multi-crate architecture: crate-per-trait / crate-per-algorithm

    • Trait-based architecture: trait per algorithm family, anyone can implement


    View Slide

20. Exploring RustCrypto
    The `cryptography` crate
    https://docs.rs/cryptography


    View Slide

21. Exploring RustCrypto
    A quick tour


    View Slide

22. Authenticated Encryption
    https://github.com/RustCrypto/AEADs
    • Traits: `aead` crate
    • Algorithm crates:

    • aes-gcm
    • aes-gcm-siv and aes-siv
    • ccm and aes-ccm
    • chacha20poly1305
    • xsalsa20poly1305
    • …and more!
    ✅
    ✅


    View Slide

23. https://research.nccgroup.com/tag/rust/


    View Slide

24. Block Ciphers
    https://github.com/RustCrypto/block-ciphers
    • Traits: `block-cipher` crate
    • Algorithm crates:

    • aes
    • des (DES + 3DES)

    • …and more!
    ⚠


    View Slide

25. Hashes (a.k.a. digest algorithms)
    https://github.com/RustCrypto/hashes
    • Traits: `digest` crate
    • Algorithm crates:

    • blake2
    • ripemd160
    • sha2 (SHA-256, SHA-384, SHA-512)

    • …and more!


    View Slide

26. Message Authentication Codes (MACs)
    https://github.com/RustCrypto/MACs
    • Traits: `crypto-mac` crate
    • Algorithm crates:

    • cmac
    • hmac
    • pmac
    • …and more!


    View Slide

27. Stream Ciphers
    https://github.com/RustCrypto/stream-ciphers
    • Traits: `stream-cipher` crate
    • Algorithm crates:

    • ctr (aes-ctr)
    • chacha20
    • salsa20

    • …and more!
    ⚠


    View Slide

28. Public Key Cryptography
    • Elliptic Curve Cryptography (ECC)

    https://github.com/RustCrypto/elliptic-curve

    • Traits: `elliptic-curve` crate

    • Curve crates: `k256` (secp256k1), `p256`, `p384`, `p512`

    • RSA: `rsa` crate

    https://github.com/RustCrypto/RSA

    • no_std + alloc support coming soon! (see RustCrypto/RSA#22)

    • Digital Signatures

    https://github.com/RustCrypto/signatures

    • Traits: `signature` crate

    • Algorithm crates: `ecdsa`, `ed25519` (now used by `ed25519-dalek`)


    View Slide

29. Embedded highlights
    Optimizing RustCrypto for embedded targets


    View Slide

30. #![no_std]


    View Slide

31. Tier-1 targets:
    ARM Cortex-A + Cortex-M
    WARNING: other targets may NOT be constant time! ⚠


    View Slide

32. Hardware accelerators
    RustCrypto traits as a “crypto HAL”
    https://github.com/RustCrypto/traits/


    View Slide

33. View Slide

34. View Slide

35. Generic composition with
    BlockCipher
    Example from `aes-gcm` crate


    View Slide

36. View Slide

37. AES-GCM
    32-bit (targeting Cortex-M) optimizations


    View Slide

38. “Doesn’t AES-GCM perform poorly on
    embedded platforms?”


    View Slide

39. What if people have just been
    implementing it badly?


    View Slide

40. BearSSL: SSL for all Things
    Thomas Pornin
    BSides Edinburgh, April 7th, 2017


    View Slide

41. View Slide

42. View Slide

43. View Slide

44. View Slide

45. View Slide

46. View Slide

47. Lightweight symmetric cryptography
    ChaCha + Poly1305 authenticated encryption using reduced rounds


    View Slide

48. Too Much Crypto
    Jean-Philippe Aumasson
    Teserakt AG, Switzerland
    Abstract. We show that many symmetric cryptography primitives would not be less
    safe with significantly fewer rounds. To support this claim, we review the cryptanalysis
    progress in the last 20 years, examine the reasons behind the current number of rounds,
    and analyze the risk of doing fewer rounds. Advocating a rational and scientific
    approach to round numbers selection, we propose revised number of rounds for AES,
    BLAKE2, ChaCha, and SHA-3, which o↵er more consistent security margins across
    primitives and make them much faster, without increasing the security risk.
    1 Introduction 2
    2 Security bits 2
    3 A history of attacks 3
    3.1 AES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3


    View Slide

49. Salsa20 ChaCha20
    Quarter-round functions


    View Slide

50. Salsa20 + Poly1305
    Stream cipher Universal hash (MAC)
    Universal hash (MAC)
    ChaCha20 + Poly1305
    Stream cipher
    Authenticated encryption algorithms


    View Slide

51. “Why 20 rounds?”


    View Slide

52. Communication Theory of Secrecy Systems
    By C. E. SHANNON
    1 INTRODUCTION AND SUMMARY
    The problems of cryptography and secrecy systems furnish an interesting ap-
    plication of communication theory1. In this paper a theory of secrecy systems
    is developed. The approach is on a theoretical level and is intended to com-
    plement the treatment found in standard works on cryptography2. There, a
    detailed study is made of the many standard types of codes and ciphers, and
    of the ways of breaking them. We will be more concerned with the general
    mathematical structure and properties of secrecy systems.
    The treatment is limited in certain ways. First, there are three general
    types of secrecy system: (1) concealment systems, including such methods
    as invisible ink, concealing a message in an innocent text, or in a fake cov-
    ering cryptogram, or other methods in which the existence of the message
    is concealed from the enemy; (2) privacy systems, for example speech in-
    version, in which special equipment is required to recover the message; (3)
    “true” secrecy systems where the meaning of the message is concealed by
    cipher, code, etc., although its existence is not hidden, and the enemy is as-
    1949


    View Slide

53. produced by variation in M should divide the key space into a number of
    subsets of comparable probability, with the statistic specifying the one in
    which the correct key lies. The statistic should give us sizeable informa-
    tion about the key, not a tiny fraction of a bit.
    4. The information it gives must be simple and usable. Thus the subsets in
    which the statistic locates the key must be of a simple nature in the key
    space.
    Frequency count for simple substitution is an example of a very good
    statistic.
    Two methods (other than recourse to ideal systems) suggest themselves
    for frustrating a statistical analysis. These we may call the methods of diffu-
    sion and confusion. In the method of diffusion the statistical structure of M
    which leads to its redundancy is “dissipated” into long range statistics—i.e.,
    708
    “Diffusion” (Shannon 1949)


    View Slide

54. ChaCha20 vs Salsa20
    Algorithmic improvements
    • ChaCha20 improves per-round diffusion

    • ChaCha20 improves performance

    • Salsa20 has reduced round variants:

    • Salsa20/8

    • Salsa20/12


    View Slide

55. New Features of Latin Dances:
    Analysis of Salsa, ChaCha, and Rumba
    Jean-Philippe Aumasson1, Simon Fischer1, Shahram Khazaei2,
    Willi Meier1, and Christian Rechberger3
    1 FHNW, Windisch, Switzerland
    2 EPFL, Lausanne, Switzerland
    3 IAIK, Graz, Austria
    Abstract. The stream cipher Salsa20 was introduced by Bernstein in 2005 as a can-
    didate in the eSTREAM project, accompanied by the reduced versions Salsa20/8 and
    Salsa20/12. ChaCha is a variant of Salsa20 aiming at bringing better diffusion for sim-
    ilar performance. Variants of Salsa20 with up to 7 rounds (instead of 20) have been
    broken by differential cryptanalysis, while ChaCha has not been analyzed yet. We in-
    troduce a novel method for differential cryptanalysis of Salsa20 and ChaCha, inspired
    by correlation attacks and related to the notion of neutral bits. This is the first appli-
    cation of neutral bits in stream cipher cryptanalysis. It allows us to break the 256-bit
    version of Salsa20/8, to bring faster attacks on the 7-round variant, and to break 6- and
    7-round ChaCha. In a second part, we analyze the compression function Rumba, built
    as the XOR of four Salsa20 instances and returning a 512-bit output. We find collision
    and preimage attacks for two simplified variants, then we discuss differential attacks
    on the original version, and exploit a high-probability differential to reduce complexity
    of collision search from 2256 to 279 for 3-round Rumba. To prove the correctness of our
    approach we provide examples of collisions and near-collisions on simplified versions.
    1 Introduction
    Salsa20 [5] is a stream cipher introduced by Bernstein in 2005 as a candidate
    in the eSTREAM project [12], that has been selected in April 2007 for the
    third and ultimate phase of the competition. Three independent cryptanalyses
    were published [11,13,16], reporting key-recovery attacks for reduced versions
    with up to 7 rounds, while Salsa20 has a total of 20 rounds. Bernstein also
    2007
    Too Much Crypto
    Jean-Philippe Aumasson
    Teserakt AG, Switzerland
    Abstract. We show that many symmetric cryptography primitives would not be less
    safe with significantly fewer rounds. To support this claim, we review the cryptanalysis
    progress in the last 20 years, examine the reasons behind the current number of rounds,
    and analyze the risk of doing fewer rounds. Advocating a rational and scientific
    approach to round numbers selection, we propose revised number of rounds for AES,
    BLAKE2, ChaCha, and SHA-3, which o↵er more consistent security margins across
    primitives and make them much faster, without increasing the security risk.
    1 Introduction 2
    2 Security bits 2
    3 A history of attacks 3
    3.1 AES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
    3.2 BLAKE2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
    3.3 ChaCha . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
    3.4 SHA-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
    4 The meaning of attacks 5
    4.1 Attacks as negative results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
    4.2 Attacks on paper vs. in reality . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
    4.3 Attacks and risk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
    4.3.1 Perfection is imperfection . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
    4.3.2 Cryptographic numerology . . . . . . . . . . . . . . . . . . . . . . . . . . 8
    2019


    View Slide

56. and present attacks on ChaCha up to 7 rounds. The 128-bit versions are also
    investigated. In a second part, we first show collision and preimage attacks for
    simplified versions of Rumba, then we present a differential analysis of the orig-
    inal version using the methods of linearization and neutral bits: our main result
    is a collision attack for 3-round Rumba running in about 279 trials (compared
    to 2256 with a birthday attack). We also give examples of near-collisions over
    three and four rounds.
    Table 1. Complexity of the best attacks known, with success probability 1/2.
    Salsa20/7 Salsa20/8 ChaCha6 ChaCha7 Rumba3
    Before 2190 2255 2255 2255 2256
    Now 2151 2251 2139 2248 279
    Road Map. We first recall the definitions of Salsa20, ChaCha, and Rumba in
    §2, then §3 describes our attacks on Salsa20 and ChaCha, and §4 presents our
    cryptanalysis of Rumba. The appendices give the sets of constant values, and
    some parameters necessary to reproduce our attacks.
    “New Features of Latin Dances” (Aumasson et al 2007)


    View Slide

57. Ask 10 cryptographers and you’ll get 10 di↵erent predictions (for di↵erent definitions of “quan-
    tum computer”), plus cryptographers are usually not the better informed on this question, due
    to their limited knowledge of quantum physics and engineering, and their natural incentive to
    exaggerate the risk. The past scientific and technological progress, as well as the current pace
    of research and engineering, do not support a prediction of a quantum computer able (say) to
    run Grover on AES anytime soon, or so we believe.
    Dismissing the risk as negligible is however as easy as it is to naively apply the precautionary
    principle—for every complex question there is an answer that is clear, simple, and wrong, to
    quote H.L. Mencken. Anyway, the number of rounds would not matter much would AES be
    Groverable, the answer to that question is therefore not important in choosing a number of
    rounds.
    5.3 How many rounds?
    Our goal is to propose numbers of rounds for which we have strong confidence that the algorithm
    will never be wounded, let alone broken, using the terminology defined in §4.4. Based on the
    previous research and our cryptanalysis experience, in particular as related to these algorithm,
    we propose the following:
    • AES: 9 rounds instead of 10 for AES-128, 10 instead of 12 for AES-192, 11 instead of 14
    for AES-256, yielding respectively a 1.1⇥, 1.2⇥, and 1.3⇥ speed-up.
    13A third one might be Shor’s exponential speed-up, but it won’t apply to symmetric primitives as they rarely
    rely on Shorable problems—an exception is the VSH hash function [25].
    13
    • BLAKE2: 8 rounds instead of 12 for BLAKE2b, 7 rounds instead of 10 for BLAKE2s
    (we’ll call these versions BLAKE2bf and BLAKE2sf), yielding respectively a 1.5⇥ and
    1.4⇥ speed-up.
    • ChaCha: 8 rounds instead of 20 (that is, ChaCha8), yielding a 2.5⇥ speed-up.
    • SHA-3: 10 rounds instead of 24 (we’ll call this version KitTen, inspired by Keccak family
    member KangarooTwelve), yielding a 2.4⇥ speed-up.
    These suggested numbers of rounds are probably imperfect choices in terms of consistency, yet
    the security margins of these four families of algorithms are more consistent with these new
    rounds numbers than with their original ones. Note that AES’ initial security margin was the
    thinnest of all, not because it’s the older design, but because of the initial not-overconservative
    choice of rounds vs. best known attack. AES is thus the primitive for which we propose the
    smallest change.
    “Too Much Crypto” (Aumasson 2019)


    View Slide

58. ChaCha20 is overkill
    12 rounds provides equivalent security margin to Salsa20
    8 rounds beats best known attack at 256-bit security level


    View Slide

59. View Slide

60. View Slide

61. Elliptic Curve Cryptography
    https://github.com/RustCrypto/elliptic-curves


    View Slide

62. Elliptic Curve Cryptography
    RustCrypto Project Highlights
    • “Legacy” elliptic curves (Weierstrass curves: NIST, secp256k1)

    • Modern formulas (complete formulas using projective coordinates)

    • Optimizing for correctness first (performance second)

    • Constant-time implementations based on the subtle crate

    • No usages of lookup tables (yet) - small code size


    View Slide

63. Elliptic curve cryptography
    RustCrypto implementation status
    Crate Curve Definitions
    32-bit
    arithmetic
    64-bit
    arithmetic
    ECDH ECDSA
    k256
    secp256k1
    (Bitcoin, etc)
    ✅ ✅ ✅ ✅
    p256 NIST P-256 ✅ ✅ ✅
    p384 NIST P-384 ✅ ⛔ ⛔ ⛔ ⛔
    p521 NIST P-521 ⛔ ⛔ ⛔ ⛔ ⛔


    View Slide

64. Elliptic Curve Cryptography
    Embedded highlights
    • Targeting embedded ECDH + ECDSA use cases

    • ECDH usable today; ECDSA expected in August

    • Embedded security plans:

    • Sidechannel resistance (DPA) via random blinding

    • RNG failures mitigated via RFC 6979 (deterministic ECDSA)

    • Fault attacks mitigated via additional randomess

    (draft-mattsson-cfrg-det-sigs-with-noise)


    View Slide

65. Veriform
    Embedded-friendly cryptographically verifiable serialization format
    https://github.com/iqlusioninc/veriform


    View Slide

66. Problem: crypto is half the battle
    Secure systems must combine crypto with authenticated messages


    View Slide

67. The Most Dangerous Code in the World:
    Validating SSL Certificates in Non-Browser Software
    Martin Georgiev
    The University of Texas
    at Austin
    Subodh Iyengar
    Stanford University
    Suman Jana
    The University of Texas
    at Austin
    Rishita Anubhai
    Stanford University
    Dan Boneh
    Stanford University
    Vitaly Shmatikov
    The University of Texas
    at Austin
    ABSTRACT
    SSL (Secure Sockets Layer) is the de facto standard for secure In-
    ternet communications. Security of SSL connections against an
    active network attacker depends on correctly validating public-key
    certificates presented when the connection is established.
    We demonstrate that SSL certificate validation is completely bro-
    ken in many security-critical applications and libraries. Vulnerable
    software includes Amazon’s EC2 Java library and all cloud clients
    based on it; Amazon’s and PayPal’s merchant SDKs responsible
    for transmitting payment details from e-commerce sites to payment
    gateways; integrated shopping carts such as osCommerce, ZenCart,
    Ubercart, and PrestaShop; AdMob code used by mobile websites;
    Chase mobile banking and several other Android apps and libraries;
    Java Web-services middleware—including Apache Axis, Axis 2,
    Codehaus XFire, and Pusher library for Android—and all applica-
    tions employing this middleware. Any SSL connection from any of
    these programs is insecure against a man-in-the-middle attack.
    The root causes of these vulnerabilities are badly designed APIs
    of SSL implementations (such as JSSE, OpenSSL, and GnuTLS)
    and data-transport libraries (such as cURL) which present devel-
    opers with a confusing array of settings and options. We analyze
    perils and pitfalls of SSL certificate validation in software based on
    these APIs and present our recommendations.
    Categories and Subject Descriptors
    C.2.0 [Computer-Communication Networks]: General—Secu-
    rity and protection; K.4.4 [Computers and Society]: Electronic
    Commerce—Security
    cations. The main purpose of SSL is to provide end-to-end security
    against an active, man-in-the-middle attacker. Even if the network
    is completely compromised—DNS is poisoned, access points and
    routers are controlled by the adversary, etc.—SSL is intended to
    guarantee confidentiality, authenticity, and integrity for communi-
    cations between the client and the server.
    Authenticating the server is a critical part of SSL connection es-
    tablishment.1 This authentication takes place during the SSL hand-
    shake, when the server presents its public-key certificate. In order
    for the SSL connection to be secure, the client must carefully verify
    that the certificate has been issued by a valid certificate authority,
    has not expired (or been revoked), the name(s) listed in the certifi-
    cate match(es) the name of the domain that the client is connecting
    to, and perform several other checks [14, 15].
    SSL implementations in Web browsers are constantly evolving
    through “penetrate-and-patch” testing, and many SSL-related vul-
    nerabilities in browsers have been repaired over the years. SSL,
    however, is also widely used in non-browser software whenever
    secure Internet connections are needed. For example, SSL is used
    for (1) remotely administering cloud-based virtual infrastructure
    and sending local data to cloud-based storage, (2) transmitting cus-
    tomers’ payment details from e-commerce servers to payment pro-
    cessors such as PayPal and Amazon, (3) logging instant messenger
    clients into online services, and (4) authenticating servers to mobile
    applications on Android and iOS.
    These programs usually do not implement SSL themselves. In-
    stead, they rely on SSL libraries such as OpenSSL, GnuTLS, JSSE,
    CryptoAPI, etc., as well as higher-level data-transport libraries,
    such as cURL, Apache HttpClient, and urllib, that act as wrappers
    around SSL libraries. In software based on Web services, there is
    an additional layer of abstraction introduced by Web-services mid-


    View Slide

68. Veriform
    Design highlights
    • Canonical “TLV” encoding (inspired by both ASN.1 DER/OER and Protobufs)

    • “Heapless” #![no_std] implementation

    • Structured hashing: automatically computes digests for all parts of a message

    • Extensible: supports unknown fields and critical fields

    • Proc macro-derived encoders and decoders


    View Slide

69. Armistice example


    View Slide

70. Veriform
    Use case examples
    • Certificates (code signing)

    • RPC serialization

    • Cryptographic audit logs


    View Slide

71. Thanks for watching!


    View Slide

72. Links
    • Twitter: @bascule

    • GitHub: tarcieri

    • RustCrypto: https://github.com/RustCrypto

    • Veriform: https://github.com/iqlusioninc/veriform


    View Slide
