as a new graduate in April 2020 I was assigned to the team which widely managed the networks, databases, web servers, etc. in operation in ZOZOTOWN and was in charge of hybrid construction and operation using on- premise and cloud services Currently, I am leading projects in the SRE domain of front-end replacement projects Technology Division SRE Department ZOZO SRE Section
the load test for the New Year's sales in ZOZOTOWN Load test to be performed in December 2022 Load test in December 2021 implementing various improvements
Characteristics of the Load Test - New Year's sale on January 1, 2020 - Load Test in December 2020 - Load Test in December 2021 - Load Test in December 2022 - Summary
Characteristics of the Load Test - New Year's sale on January 1, 2020 - Load Test in December 2020 - Load Test in December 2021 - Load Test in December 2022 - Summary
we had performed unit load tests in each micro service, we had never performed a load test for the New Year's sale through the Web servers and API servers accessed by users until December 2020. The reason why we had not performed such a load test is that both Web servers and API servers were on-premise environments and the production environments had to be used for such a test.
to sale in accordance with user access line to identify and improve the possible bottlenecks in advance 2. Evacuation training for quick collaboration with parties concerned in the event of trouble
Characteristics of the Load Test - New Year's sale on January 1, 2020 - Load Test in December 2020 - Load Test in December 2021 - Load Test in December 2022 - Summary
- Perform a load test with low traffic late at night For on-premise environments, we repeated scale-up and scale-down along with the growth of ZOZOTOWN. Currently, it is too costly to prepare infrastructure environments equivalent to production environments for load tests.
Characteristics of the Load Test - New Year's sale on January 1, 2020 - Load Test in December 2020 - Load Test in December 2021 - Load Test in December 2022 - Summary
Server SQL Server iOS・Android Data Center Cloud DC extension using VMWare Cloud on AWS Browser Transfer the on- premise stored procedure to API SQL Server Read Only Goods Service Stored Procedure Stored Procedure Stored Procedure Replication
health of ZOZOTOWN from a medium- to long-term perspective ⎯ Service availability as an item to measure availability ⎯ Occupancy rate within a certain time (1 day) ⎯ (1 - Total number of Errors/Total number of Requests) × 100 ⎯ Service availability below 99.9% less than 3 days per month ⎯ Check the graphs that com up after this to see if they are below 99.9% every hour SLO Measurement
Characteristics of the Load Test - New Year's sale on January 1, 2020 - Load Test in December 2020 - Load Test in December 2021 - Load Test in December 2022 - Summary
and support ⎯ Planning of the schedule ⎯ Creation of scenarios ⎯ Determination of the target value ⎯ Execution of the load test ⎯ Infrastructure resource estimate ⎯ Infrastructure resource reinforcement ⎯ Resource monitoring on the test day ⎯ Cooperation for creation of scenarios Team in charge of the load test Breakdown of the teams ⎯ Backend (2 teams) ⎯ SRE (3 teams) ⎯ DB (1 team)
the persons in charge ⎯ Consideration of the schedule and target value by the persons in charge of the load test ⎯ Kick-off with the parties concerned and request for cooperation ⎯ Preparation of the load test execution environment ⎯ Creation of scenarios ⎯ Correction of scenarios ⎯ Execution of the load test October 2020
consecutive days (one backup day) ⎯ Two inconsecutive days (one backup day) ⎯ Consider whether to use the backup day based on the result of the test ⎯ Determine within the four days including the backup days ⎯ 0:00 AM to 2:00 AM Preparation by each team ⎯ Apply the scenario several times from 2:00 AM to 5:00 AM ⎯ Test backup/cleanup from 5:00 AM to 6:00 AM ⎯ Reflect on the test from 6:00 AM to 7:00 AM Load test schedule
using the voice chat of Discord on the day of the test because some members came to the office but others didn’t due to the coronavirus disaster The team in charge of the load test recorded the result Utilization of Discord
Mall was twice higher in the preceding event, we applied twice larger traffic for the New Year's sale on January 1, 2021 than that on January 1, 2020 ⎯ Traffic was difficult to expect partly due to the coronavirus catastrophe Determination method
Server SQL Server Data Center AWS Browser Session API Gateway Stored Procedure Stored Procedure Stored Procedure ID Authentication Service Replication iOS・Android Goods Service Search Service Akamai DCC extension using VMWare Cloud on AWS Via Akamai Change in the access destination of API Shift to a micro service Offload of Session information
information using Splunk ⎯ Access ratio of each function ⎯ Instantaneous maximum value of Request/Sec ⎯ Collectively get samples of Query Parameter ⎯ Create 80 or more patterns of scenarios by web/app ⎯ Recreate the access just after the start of the New Year's Sale ⎯ Create a dashboard for analysis in Splunk ⎯ Each team had to cooperate with each other to create correct scenarios because we could not grasp the actual execution method of each function from the access logs Creation of scenarios
details ⎯ Sale product details ⎯ View favorites ⎯ Sale LP ⎯ Login ⎯ Related to HOME ⎯ Announcement ⎯ Product details ⎯ Search ⎯ Measurement account information ⎯ Favorite product information ⎯ Product ranking ⎯ Product inventory ⎯ Brand list ⎯ Login ⎯ Addition of favorites Examples of Web scenarios Examples of app scenarios
⎯ 48,000 Request/Sec because the target value of traffic is twice as high ⎯ AM2:00 ~ 0.50 times the Request/Sec of January 1, 2020 Scenario execution time 5 min ⎯ AM2:30 ~ 1.0 times the Request/Sec of January 1, 2020 Scenario execution time 5 min ⎯ AM3:00 ~ 1.25 times the Request/Sec of January 1, 2020 Scenario execution time 5 min ⎯ AM3:30 ~ 1.5 times the Request/Sec of January 1, 2020 Scenario execution time 5 min ⎯ AM4:00 ~ 1.75 times the Request/Sec of January 1, 2020 Scenario execution time 5 min ⎯ AM4:30 ~ 2.0 times the Request/Sec of January 1, 2020 Scenario execution time 5 min Determination of Request/Sec
and second load tests Number of servers in the third load test ⎯ On-premise/VMWare Cloud on AWS: Web 180 API 343 ⎯ On-premise/VMWare Cloud on AWS: Web 427 API 940 Number of servers in January 1, 2020 ⎯ On-premise/VMWare Cloud on AWS: Web 307 API 820 Number of servers in January 1, 2021 ⎯ On-premise/VMWare Cloud on AWS: Web 452 API 812 More than double
Some potential bottleneck was found, an only the same number of Requests/Sec could be executed while the target value was double. There were some errors in scenarios, etc. which even developers had not recognized, so we felt changes in ZOZOTOWN. Second test Restart with 0.5 times higher loads because scenarios were partially modified. As for web, resources are used up with the same loads with the number of servers obtained by trial calculation. Only the app endured two times higher loads, but there remained agita factors in the result of web, so we redid the test. Third test Final test Web: Endures 1.25 times higher loads à Issue that the target value of loads could not applied fully App: Endured two times higher loads
event of trouble ⎯ Identification of bottlenecks in each team ⎯ Reduction of the contents-cut amount ⎯ Guideline for how much loads the current resources can endure ⎯ We could share the recognition of what each team should do in the event of an error Realize a load test under an environment equivalent to sale in accordance with user access line to identify and improve the possible bottlenecks in advance Summary of the Load Test in December 2020
was a physically demanding task due to night shift within a short period of time ⎯ Improvement in the accuracy of the load test execution tool ⎯ Execution of scenarios of addition of products to the cart and payment ⎯ Reinforcement of collaboration by departments whose collaboration was insufficient ⎯ Performed the test on a day with many coupons Required improvements pointed out in KPT Summary of the Load Test in December 2020
Characteristics of the Load Test - New Year's sale on January 1, 2020 - Load Test in December 2020 - Load Test in December 2021 - Load Test in December 2022 - Summary
and support ⎯ Planning of the schedule ⎯ Creation of scenarios ⎯ Determination of the target value ⎯ Execution of the load test ⎯ Infrastructure resource estimate ⎯ Infrastructure resource reinforcement ⎯ Resource monitoring on the test day ⎯ Cooperation for creation of scenarios Team in charge of the load test Breakdown of the teams ⎯ Back end (7 teams) ⎯ SRE (3 teams) ⎯ MLOps (1 team) ⎯ DB (1 team)
in charge of the load test ⎯ Consideration of the schedule and target value by the persons in charge of the load test ⎯ Kick-off with the parties concerned and request for cooperation ⎯ Preparation of the load test execution environment ⎯ Creation of scenarios ⎯ Execution of the load test ⎯ Correction of scenarios ⎯ Execution of the load test October 2021
the schedule considering the number of coupons ⎯ Two days with many coupons (including one backup day) ⎯ Two inconsecutive days for the execution of the load test ⎯ Determine within the four days including the backup days ⎯ 0:00 AM to 2:00 AM Preparation by each team ⎯ Apply the scenario several times from 2:00 AM to 5:00 AM ⎯ Clean up from 5:00 AM to 6:00 AM ⎯ Reflect on the test from 6:00 AM to 7:00 AM, Determination of Next Action Load test schedule
Meet on the day of the test After the load test, prepare a common material in which all teams enter the result of the load test and reflect on the load test immediately for quick determination of the next action Utilization of Google Meet
growth rate ⎯ We analyzed the growth rate from the traffic and the numbers of UUs and PVs on January 1, 2021 and assumed the traffic of the New Year's sales on January 1, 2022 to be 1.6 times larger than on January 1, 2021 Determination method
Center AWS Browser Session API Gateway Stored Procedure ID Authentication Service iOS・Android Goods Service Search Service Akamai Lift to EC2 Akamai Replication Payment service BFF (Aggregation) SQL Server Stored Procedure SQL Server Stored Procedure IIS(API) Replacement of the HOME side Replacement of the payment function Phase1 Introduction of Akamai
information using Splunk ⎯ Access ratio of each function ⎯ Instantaneous maximum value of Request/Sec ⎯ Collectively get samples of Query Parameter ⎯ Create 80 or more patterns of scenarios by web/app ⎯ Recreate the access just after the start of the New Year's Sale ⎯ Create a dashboard for analysis in Splunk ⎯ Addition of scenarios of the payment function ⎯ Preparation of text accounts and test product numbers ⎯ Divide scenarios (payment, login, and main) Creation of scenarios
details ⎯ Sale product details ⎯ View favorites ⎯ Sale LP ⎯ Login ⎯ Addition of products to the cart ⎯ Order ⎯ Related to HOME ⎯ Announcement ⎯ Product details ⎯ Search ⎯ Favorite product information ⎯ Product ranking ⎯ Product inventory ⎯ Brand list ⎯ Login ⎯ Addition of favorites ⎯ New HOME side ⎯ Addition of products to the cart Examples of Web scenarios Examples of app scenarios
⎯ 46,080 Request/Sec because the target value of traffic is 1.6 times as high ⎯ AM2:00 ~ 0.25 times the Request/Sec of January 1, 2021 Scenario execution time 5 min ⎯ AM2:30 ~ 0.75 times the Request/Sec of January 1, 2021 Scenario execution time 5 min ⎯ AM3:00 ~ 1.0 times the Request/Sec of January 1, 2021 Scenario execution time 5 min ⎯ AM3:30 ~ 1.25 times the Request/Sec of January 1, 2021 Scenario execution time 5 min ⎯ AM4:00 ~ 1.4 times the Request/Sec of January 1, 2021 Scenario execution time 5 min ⎯ AM4:30 ~ 1.6 times the Request/Sec of January 1, 2021 Scenario execution time 5 min Determination of Request/Sec
EC2 ⎯ Preparation takes 40 hours ⎯ Upper limit of the procurable stock quantity ⎯ Occurrence of connection timeout due to overcommitment of CPU ⎯ Some parts had to be set manually ⎯ Preparation takes 4 hours ⎯ It is easy to secure resources in advance thanks to preliminary negotiations with AWS ⎯ The initial setting, the monitoring setting, etc. become easier ⎯ Automation of the operation Issue of VMWare Cloud on AWS Host startup Construction Execution in the production environment 40 hours à 4 hours
load test Number of servers in the second and third load tests ⎯ On-premise/VMWare Cloud on AWS: Web 452 API 812 ⎯ On-premise/EC2: Web 480 API 1018 (EC 900) Number of servers in January 1, 2021 ⎯ On-premise/EC2: Web 480 API 1020 (EC 820) Number of servers in January 1, 2021 ⎯ On-premise/EC2: Web 588 API 1160 (EC 1160) Number of servers in the second load test ⎯ On-premise/EC2: Web 468 API 1160 (EC 1160) Enable to operate API servers only in EC2
We could execute only the same number of Requests/Sec due to mistakes in the first couple of scenario In addition, partly because we had never tried a scenario of the payment function, more loads than expected were applied. Second test Both web and the app endured 1.25 times higher loads. Depletion of resources did not occur. We decided to use the backup day because unusual loads were applied to some parts of micro services due to a defect in the scenario. Third test Changed the loads in the scenario of the payment function to the same loads because the loads were too high. Both web BOEUIFBQQFOEVSFEUJNFT IJHIFSMPBET 1FSGPSNFEUIFUFTUPOUIFMBTUEBZUPWFSJGZUIFUISPUUMJOH PGUIFQBZNFOUGVODUJPO Fourth test Final test Web: Endured 1.6 times higher loads App: Endured 1.6 times higher loads We could apply the target value of loads
for quick collaboration with parties concerned in the event of trouble ⎯ Detection of IP depletion problems of EKS ⎯ Performance measures by cutting contents in effective points ⎯ It was a good rehearsal for remote communication ⎯ We could share the recognition of what each team should do in the event of an error Realize a load test under an environment equivalent to sale in accordance with user access line to identify and improve the possible bottlenecks in advance
in the accuracy of scenarios ⎯ Creation of an architecture diagram which shows the procedure from access to web/app to micro services ⎯ Construction of an environment where preliminary tests are easy to perform ⎯ Thorough management of the schedule on the day of the test ⎯ Creation of a dashboard and console which participants should see Required improvements pointed out in KPT
Characteristics of the Load Test - New Year's sale on January 1, 2020 - Load Test in December 2020 - Load Test in December 2021 - Load Test in December 2022 - Summary
as a working group ⎯ Planning of the schedule ⎯ Creation of scenarios ⎯ Determination of the target value ⎯ Execution of the load test ⎯ Infrastructure resource estimate ⎯ Infrastructure resource reinforcement ⎯ Resource monitoring on the test day ⎯ Cooperation for creation of scenarios Team in charge of the load test Breakdown of the teams ⎯ Backend (7 teams) ⎯ SRE (3 teams) ⎯ MLOps (1 team) ⎯ DB (1 team)
⎯ Consideration of the schedule and target value by the persons in charge of the load test ⎯ Kick-off with the parties concerned and request for cooperation ⎯ Preparation of the load test execution environment ⎯ Creation of scenarios ⎯ Correction of scenarios ⎯ Execution of the load test ⎯ Execution of the load test October 2022 End of September 2022 ⎯ Determination of the chief of the working group
the schedule considering the number of coupons ⎯ Two days with many coupons (including one backup day) ⎯ Two inconsecutive days for the execution of the load test ⎯ Determine within the four days including the backup days ⎯ Apply the scenario several times from 2:00 AM to 5:00 AM ⎯ Clean up from 5:00 AM to 6:00 AM ⎯ Reflect on the test on the day from 6:00 AM to 6:30 AM, Determination of Next Action Load test schedule
traffic and the numbers of UUs and PVs on January 1, 2022 and found no significant change, so we assumed the traffic of the New Year's sales on January 1, 2023 to be 1.6 times larger than on January 1, 2022 ⎯ Analyze the latency during the New Year sale and considered the target latency for each scenario Determination method
Center AWS Browser Session API Gateway Stored Procedure ID Authentication Service iOS・Android Goods Service Search Service Akamai Akamai Replication Payment service BFF (Aggregation) SQL Server SQL Server IIS(API) Front-end Replacement Phase1 Web Gateway Stored Procedure Stored Procedure Web Front
information using Splunk ⎯ Access ratio of each function ⎯ Instantaneous maximum value of Request/Sec ⎯ Collectively get samples of Query Parameter ⎯ Create 80 or more patterns of scenarios by web/app ⎯ Additional scenarios for Front End Replacement Phase 1 ⎯ Access scenario for hot item ⎯ Access number scenario assuming rush when crossing the day Creation of scenarios
details ⎯ Sale product details ⎯ View favorites ⎯ Sale LP ⎯ Login ⎯ Addition of products to the cart ⎯ Order ⎯ Related to HOME ⎯ Announcement ⎯ Product details ⎯ Search ⎯ Favorite product information ⎯ Product ranking ⎯ Product inventory ⎯ Brand list ⎯ Login ⎯ Addition of favorites ⎯ New HOME side ⎯ Addition of products to the cart Examples of Web scenarios Examples of app scenarios
⎯ 46,080 Request/Sec because the target value of traffic is 1.6 times as high ⎯ AM2:00 ~ 0.25 times the Request/Sec of January 1, 2021 Scenario execution time 5 min AM2:30 ~ 0.5 times the Request/Sec of January 1, 2021 Scenario execution time 5 min ⎯ AM3:00 ~ 1.0 times the Request/Sec of January 1, 2021 Scenario execution time 5 min ⎯ AM3:30 ~ 1.3 times the Request/Sec of January 1, 2021 Scenario execution time 5 min ⎯ AM4:00 ~ 1.6 times the Request/Sec of January 1, 2021 Scenario execution time 5 min ⎯ AM4:30 ~ reserve Determination of Request/Sec
Characteristics of the Load Test - New Year's sale on January 1, 2020 - Load Test in 2020 - Load Test in 2021 - Results of January 1, 2021 and January 1, 2022 - Load Test in December 2022 - Summary
Year's sales safely so that users can use ZOZOTOWN comfortably - Creation of scenarios in accordance with changes in ZOZOTOWN - Set an appropriate target value to realize the loads of the New Year's sale - Resource reinforcement enough to cover the loads of the New Year's sale - Identification of bottlenecks through the load test - Preliminary communication assuming the New Year's sale
