Kiba ETL v2 - RubyKaigi 2018

Kiba 2 - Past, present & future of data processing with Ruby.

Kiba ETL (http://www.kiba-etl.org) is a lightweight, generic data processing framework for Ruby, initially released in 2015 & now in v2.

In this talk, I highlight why Kiba was created, how it is used for low-maintenance data preparation and processing in the enterprise, why and how the version 2 (leveraging Ruby's Enumerator) brings a massive improvement in authoring reusable & composable data processing components, and why I'm optimistic about the future of data processing with Ruby.

Transcript

1. ᇌ KIBA ETL
   Past, present & future of
   data processing with Ruby
   RubyKaigi 2018 - Thibaut Barrère (France), independent consultant
   thibaut.barrere@gmail.com / twitter.com/thibaut_barrere


   View Slide

2. KIBA ETL?
   lightweight, generic
   data processing framework
   for Ruby
   initially released in 2015 & now at v2.


   View Slide

3. Kiba == Fang (scrunch your data)


   View Slide

4. EXTRACT
   TRANSFORM
   LOAD
   (see http://thibautbarrere.com)


   View Slide

5. View Slide

6. Back in time
   Why was Kiba ETL created?


   View Slide

7. 2006
   ❤ activewarehouse-etl
   Thanks Anthony Eden! (now founder at DNSimple)


   View Slide

8. source :in, {
   :file => 'extracted/crm-changes.csv',
   :parser => :delimited,
   :skip_lines => 1
   }, [:first_name, :last_name]
   after_read :ensure_fields_presence, { :fields => fields }
   transform(:id_partenaire) { |n,v,r| some_computation }
   destination :out, {
   :file => output_file,
   :include_headers => true,
   :separator => ";"
   }


   View Slide

9. transform(:email_provider) do |name, value, row|
   row.fetch(:email).downcase.split('@').last
   end
   transform :email_provider, :default,
   :default_value => 'Unknown'
   before_write do |r|
   r[:email_provider] =~ /Hotmail/ ? nil : r
   end


   View Slide

10. before_write do |r|
    position, status = geocode_with_redis_cache(row)
    row[:geocoding_status] = status
    row[:latitude] = position.latitude
    row[:longitude] = position.longitude
    row
    end


    View Slide

11. $ etl my_etl_script.etl


    View Slide

12. Use cases 2006-2012
    Extract CSV data from a ($$$) CRM
    Import to MySQL (low-cost Business Intelligence)
    Geocode & export to "nearby search" Rails app
    IBAN validation & export to COBOL back-end
    More details available in RuLu 2012 talk1
    1 See Youtube video & SpeakerDeck slides


    View Slide

13. 2011 Took over maintenance


    View Slide

14. ETL::Parser::Parser: SaxParser, FixedWidthParser, NokogiriXmlParser, XmlParser, ExcelParser,
    CsvParser
    ETL::Processor::Processor: FtpUploaderProcessor, FtpDownloaderProcessor, EscapeCsvProcessor,
    ZipFileProcessor, SftpDownloaderProcessor, SftpUploaderProcessor,
    ImapattachmentDownloaderProcessor, EncodeProcessor, TruncateProcessor, BulkImportProcessor,
    Pop3attachmentDownloaderProcessor
    ETL::Processor::RowProcessor: BlockProcessor, EnsureFieldsPresenceProcessor,
    DatabaseJoinProcessor, RequireNonBlankProcessor, CopyFieldProcessor, SequenceProcessor,
    PrintRowProcessor, SurrogateKeyProcessor, FilterRowProcessor, CheckExistProcessor,
    HierarchyExploderProcessor, CheckUniqueProcessor, RenameProcessor
    ETL::Transform: StringToDateTimeTransform, DateToStringTransform, HierarchyLookupTransform,
    SplitFieldsTransform, DecodeTransform, StringToTimeTransform, Sha1Transform, TypeTransform,
    OrdinalizeTransform, BlockTransform, StringToDateTransform, Md5Transform, CalculationTransform,
    TrimTransform, ForeignKeyLookupTransform
    Source: ModelSource, DatabaseSource, FileSource
    Destination: CsvDestination, ExcelDestination, YamlDestination, DatabaseDestination,
    InsertUpdateDatabaseDestination, UpdateDatabaseDestination, FileDestination


    View Slide

15. module ETL #:nodoc:
    module Parser #:nodoc:
    # Parses CSV files
    class CsvParser < ETL::Parser::Parser
    # Initialize the parser
    # * source: The Source object
    # * options: Hash of options for the parser, defaults to an empty hash
    def initialize(source, options={})
    super
    configure
    end
    attr_reader :validate_rows
    def get_fields_names(file)
    File.open(file) do |input|
    fields = CSV.parse(input.readline, options).first
    new_fields = []
    fields.each_with_index do |field,index|
    # compute the index of occurrence of this specific occurrence of the field (usually, will be 1)
    occurrence_index = fields[0..index].find_all { |e| e == field }.size
    number_of_occurrences = fields.find_all { |e| e == field }.size
    new_field = field + (number_of_occurrences > 1 ? "_#{occurrence_index}" : "")
    new_fields << Field.new(new_field.to_sym)
    end
    return new_fields
    end
    end
    # Returns each row.
    def each
    Dir.glob(file).each do |file|
    ETL::Engine.logger.debug "parsing #{file}"
    if fields.length == 0
    ETL::Engine.logger.debug "no columns specified so reading names from first line of #{file}"
    @fields = get_fields_names(file)
    end
    line = 0
    lines_skipped = 0
    CSV.foreach(file, options) do |raw_row|
    if lines_skipped < source.skip_lines
    ETL::Engine.logger.debug "skipping line"
    lines_skipped += 1
    next
    end
    line += 1
    row = {}
    validate_row(raw_row, line, file) if self.validate_rows
    raw_row.each_with_index do |value, index|
    f = fields[index]
    row[f.name] = value
    end
    yield row
    end
    end
    end
    # Get an array of defined fields
    def fields
    @fields ||= []
    end
    private
    def validate_row(row, line, file)
    ETL::Engine.logger.debug "validating line #{line} in file #{file}"
    if row.length != fields.length
    raise_with_info( MismatchError,
    "The number of columns from the source (#{row.length}) does not match the number of columns in the definition (#{fields.length})",
    line, file
    )
    end
    end
    def configure
    @validate_rows = if source.configuration.has_key?(:validate_rows)
    source.configuration[:validate_rows]
    else
    true
    end
    source.definition.each do |options|
    case options
    when Symbol
    fields << Field.new(options)
    when Hash
    fields << Field.new(options[:name])
    else
    raise DefinitionError, "Each field definition must either be a symbol or a hash"
    end
    end
    end
    class Field #:nodoc:
    attr_reader :name
    def initialize(name)
    @name = name
    end
    end
    end
    end
    end


    View Slide

16. Photo Credit: National Fire Protection Association


    View Slide

17. 2013 - Maintenance stopped
    Too many features
    Yet, features lacking flexibility
    Custom components complicated to implement
    Costly to maintain (code + CI)


    View Slide

18. But I still have data processing needs!
    source
    transform
    transform
    transform
    destination
    and that row-based DSL syntax is really great for maintenance


    View Slide

19. 2008 TinyTL (a tiny ETL)
    Clean-room implementation
    Minimalistic (113 lines total)
    2 small production apps


    View Slide

20. 2015 Kiba ETL v0.5.0
    Lightweight.
    Flexible (write your own components)
    Simple assumptions (PORO)
    Standalone (no ActiveRecord dependency)
    Strong focus on documentation & articles
    Easy to "keep alive" as a maintainer


    View Slide

21. 5 keywords only
    pre_process
    source
    transform
    destination
    post_process


    View Slide

22. source CSVSource,
    filename: 'data/extract.csv',
    csv_options: {
    col_sep: ';',
    encoding: 'ISO-8859-1:UTF-8'
    }
    transform MyLookup, config: { xxx }
    transform do |row|
    {
    siren: row.fetch('SIREN'),
    libapen: row.fetch('LIBAPEN')
    }
    end
    destination CSVDestination,
    filename: 'data/output.csv'


    View Slide

23. Source
    def initialize(*args)
    def each (yields N rows)


    View Slide

24. class CSVSource
    def initialize(options)
    @filename = options.fetch(:filename)
    @csv_options = options.fetch(:csv_options)
    end
    def each
    CSV.foreach(@filename, @csv_options) do |row|
    yield(row)
    end
    end
    end


    View Slide

25. Transform (as class)
    def initialize(*args)
    def process(row) (returns 1 or 0 row)
    Transform (as block)
    transform { |row| xxx } (returns 1 or 0 row)


    View Slide

26. Destination
    def initialize(*args)
    def write(row) (writes 1 row)
    def close


    View Slide

27. class CSVDestination
    def initialize(filename:, csv_options: {}, headers:)
    @filename = filename
    @csv_options = csv_options
    @headers = headers
    end
    def write(row)
    @csv ||= CSV.open(filename, 'wb', csv_options)
    @headers ||= row.keys
    @headers_written ||= (csv << headers ; true)
    csv << row.fetch_values(*@headers)
    end
    def close
    @csv&.close
    end
    end


    View Slide

28. 2015-2018
    Numerous production uses
    Almost no core changes to Kiba
    Components easy to author & maintain
    "Long Term Support" of gem possible as solo dev


    View Slide

29. Sustainable project evolution


    View Slide

30. #1 Micro-batches
    < 50k rows per job
    Very near realtime sync


    View Slide

31. View Slide

32. Push mode


    View Slide

33. Pull mode (with push notify)


    View Slide

34. Don't shell out from HTTP or Sidekiq
    ❌ ❌ ❌
    def perform
    system("kiba my-import-job.etl")
    end
    ❌ ❌ ❌


    View Slide

35. Use the Programmatic API (e.g call from Sidekiq2)
    class PartnersUploadProcessorWorker
    include Sidekiq::Worker
    def perform(options)
    job = Kiba.parse do
    source CSVSource, filename: options.fetch('filename')
    transform ...
    transform ...
    transform ...
    destination SQLUpsert, connection: SEQUEL_DB, table: xxx
    end
    Kiba.run(job)
    end
    end
    2 Kiba ETL Wiki: Considerations for running Kiba jobs programmatically


    View Slide

36. Extract the job declaration
    module ETL
    module SyncPartners
    module_function
    def setup(source_file, sequel_connection, logger)
    Kiba.parse do
    source
    transform
    transform
    transform
    destination
    end
    end
    end
    end


    View Slide

37. #2 Multistep batch processing
    (enterprise data aggregation)
    N different ERP systems (1 per SaaS client)
    Different extraction methods
    Different input formats (fields & data)
    Target: a single, common schema


    View Slide

38. View Slide

39. View Slide

40. Keep things simple (cron + bash)
    #!/usr/bin/env bash
    set -e
    bundle exec kiba common/s3_downloader.etl
    bundle exec kiba client_acme/extractor.etl
    bundle exec kiba client_acme/transformer.etl
    bundle exec kiba common/api_uploader.etl
    bundle exec kiba common/cleaner.etl


    View Slide

41. View Slide

42. Amazon S3 = inbox
    Email from ERP (CSV/XLSX) -> Amazon SES -> S3
    ERP -> SFTP export -> S3
    Capybara -> XLSX download from ERP -> S3


    View Slide

43. Pre-extraction from S3 to local file system
    Generic local download step (Kiba script)
    Move from /unprocessed to /processed
    S3 lifecycle rules to ensure data removal
    config = {
    aws_region: ENV.fetch('ACME_CORP_AWS_REGION'),
    aws_bucket: ENV.fetch('ACME_CORP_AWS_BUCKET'),
    aws_kms_key_id: ENV.fetch('ACME_CORP_AWS_KMS_KEY_ID')
    }
    source ETL::S3::ListObjects, config
    transform ETL::S3::Downloader


    View Slide

44. Amazon S3 = message passing
    between machines (scalability!)


    View Slide

45. Keep things DRY & enforce re-use
    Sources, transforms, destinations
    "Meta-transforms"
    Steps (whole Kiba scripts)


    View Slide

46. Actual components re-use between pipelines
    module DSLExtensions
    module DefaultValue
    def default_value(field, default_value)
    transform do |row|
    value = row.fetch(field)
    row.merge(field => value.blank? ? default_value : value)
    end
    end
    end
    end
    extend DSLExtensions::DefaultValue
    default_value :some_field, 'Unknown'


    View Slide

47. More actual components re-use between pipelines
    AddTimestamps
    DefaultValue
    EnforceValuesChoice
    RenameField
    HashLookup
    RaiseOnBlanks
    RemapBoolean
    (more...)


    View Slide

48. #3 Automation of internal tasks


    View Slide

49. View Slide

50. View Slide

51. View Slide

52. source ETL::Sources::HTTPPaginatingFetcher,
    base_url: bank_base_url,
    headers: { Authorization: bank_auth }
    assert_equal :content_type, 'application/json'
    transform { |r| r.fetch(:body) }
    transform { |r| JSON.parse(r) }
    transform { |r| r.fetch('transactions') }
    transform Kiba::Common::Transforms::EnumerableExploder
    assert_equal 'currency', 'EUR'
    # SNIP
    destination Kiba::Pro::Destinations::SQLUpsert,
    database: ENV.fetch('DATABASE_URL'),
    unique_key: :fit_id,
    table: :bank_transactions


    View Slide

53. source ETL::Sources::OFXSource,
    dir_pattern: "files/*.ofx"
    transform do |row|
    {
    fit_id: row.fit_id,
    memo: row.memo,
    name: row.name,
    posted_at: row.posted_at.to_date,
    amount: row.amount
    }
    end
    destination Kiba::Pro::Destinations::SQLUpsert,
    database: ENV.fetch('DATABASE_URL'),
    unique_key: :fit_id,
    table: :bank_transactions


    View Slide

54. Source = PDF files


    View Slide

55. PDF download & transform
    pre_process do
    system!("wget -A pdf ... https://vat-site.com")
    end
    source Kiba::Common::Enumerable, -> { Dir["downloads/*.pdf"] }
    transform { |r| { filename: r } }
    transform PDFToText, :filename_key => :filename
    # SNIP - extraction, verification
    destination CSVDestination, file: 'vat_rates.csv'


    View Slide

56. class PDFToText
    def initialize(filename_key, content_key, pdftotext_args)
    @filename = filename_key
    @content = content_key
    @pdftotext_args = pdftotext_args
    end
    def process(row)
    cmd = "pdftotext #{@pdftotext_args} #{row[@filename]} -"
    output = system_with_output!(cmd)
    row[@content] = output
    row
    end
    end


    View Slide

57. #4 Big rewrites & data migrations


    View Slide

58. View Slide

59. View Slide

60. Use MiniTest & Sequel for "data screens"
    class Screens < ETL::BaseTest
    def test_well_known_record
    amount = db[:orders].where(id: 12456).amount_with_vat
    assert_equal 100.27, amount
    end
    def test_counts
    count = db[:orders].count
    assert_in_delta(230_000, count, 10_000)
    end
    def test_states
    states = db[:orders].distinct.select('state')
    assert_equal ['complete', 'pending'], states
    end
    end


    View Slide

61. Key takeaways from data migrations
    Use "Bulk insert" (Kiba Pro, Sequel, ...)
    Use deterministic ids & reset sequence
    Bypass ActiveRecord validations
    validate_uniqueness_of :email, unless: -> { @etl_running }
    Work on a data subset for iteration
    Measure & optimize continuously
    Use screens to test specific & global data


    View Slide

62. Why Kiba v2?
    mostly a drop-in replacement


    View Slide

63. class XMLSource
    def initialize(...)
    @dir_pattern = dir_pattern
    end
    def each
    Dir[@dir_pattern].sort.each do |file|
    doc = Nokogiri::XML(IO.binread(file))
    doc.search('/invoices/invoice').each do |item|
    yield(item)
    end
    end
    end
    end


    View Slide

64. class CSVSource
    def initialize(...)
    @dir_pattern = dir_pattern
    end
    def each
    Dir[@dir_pattern].sort.each do |file|
    CSV.foreach(file, csv_options) do |row|
    yield(row)
    end
    end
    end
    end


    View Slide

65. Kiba v2 "StreamingRunner"
    def transform_stream(stream, t)
    Enumerator.new do |y|
    stream.each do |input_row|
    returned_row = t.process(input_row) do |yielded_row|
    y << yielded_row
    end
    y << returned_row if returned_row
    end
    end
    end
    ❤ Ruby's Enumerator


    View Slide

66. v2 transforms can yield N rows, not just sources
    More components re-use + more composition
    class EnumerableExploder
    def process(row)
    row.each { |item| yield(item) }
    nil
    end
    end
    source DirectoryLister, dir_pattern: '*.csv'
    transform XMLReader
    transform XMLSearcher, selector: '/invoices/invoice'
    transform EnumerableExploder


    View Slide

67. Happy with current data processing toolkit
    Kiba (core, OSS)
    Kiba Common (extra generic components, OSS)
    Kiba Pro (fast SQL, S3, profilers...)
    Tons of gems for pretty much any format


    View Slide

68. More performance available soon
    TruffleRuby
    Ruby 2.6.0
    JIT improvements
    GIL & Guilds


    View Slide

69. Ruby ETL performance trend4
    4 https://github.com/thbar/kiba-ruby-benchmarks


    View Slide

70. Data + Ruby = ❤
    Great asset for data enterprise glue
    Efficient code reuse between data pipelines
    Components can be tested quite easily (PORO)
    Wealth of libraries to tap into
    Raw speed (single threaded) good & improving
    Concurrency story will improve too!


    View Slide
