Elixir hot-reloading & MIDI events generation

Lightning talk at ElixirConfEU 2017. Demonstrates how to use Elixir "hot-reloading" feature, together with MIDI events generation.

Video: https://www.youtube.com/watch?v=_VgcUatTilU&feature=youtu.be&t=2m2s
Repo: https://github.com/thbar/demo-elixir-reloading-music

Transcript

1. ELIXIR HOT-RELOADING & MIDI NOTES GENERATION
   https://github.com/thbar/demo-elixir-reloading-music


   View Slide

2. HOW TO IMPLEMENT A VERY SIMPLE ELIXIR
   CODE HOT-RELOADING EXAMPLE?


   View Slide

3. HOW TO MAKE IT INTERESTING?


   View Slide

4. LIVE SOUND EVENTS GENERATION !


   View Slide

5. HOW TO GENERATE ONE NOTE?


   View Slide

6. RENOISE (MUSIC PRODUCTION SYSTEM)


   View Slide

7. PORTMIDI (C LIBRARY)


   View Slide

8. ELIXIR BINDINGS FOR PORTMIDI


   View Slide

9. # Start a process for MIDI event queue
   {:ok, pid} = PortMidi.open(:output, "Renoise MIDI-In")
   note = 48 # C-4
   velocity = 127
   # Send "NOTE ON"
   PortMidi.write(pid, {0x90, note, velocity})
   # Send "NOTE OFF"
   PortMidi.write(pid, {0x80, note})


   View Slide

10. HOW TO BUILD A MUSIC LOOP?


    View Slide

11. ▸ GenServer
    ▸ Process.send_after(xxx)


    View Slide

12. defmodule MidiPlayer do
    use GenServer
    def start_link do
    {:ok, device} = PortMidi.open(:output, "Renoise MIDI-In")
    tick_period = 50
    Process.send_after(:midi, {:tick}, tick_period)
    GenServer.start_link(__MODULE__, %{
    current_tick: -1,
    device: device,
    tick_period: tick_period
    }, name: :midi)
    end
    # SNIP
    end


    View Slide

13. defmodule MidiPlayer do
    def handle_info({:tick}, state) do
    Process.send_after(:midi, {:tick}, state.tick_period)
    current_tick = Map.fetch!(state, :current_tick) + 1
    show_visual_feedback(current_tick)
    play_notes(state.device, current_tick)
    {:noreply, %{state | current_tick: current_tick}}
    end
    end


    View Slide

14. def play_notes(device, current_tick) do
    notes = [0x54, 0x57, 0x5B, 0x60]
    delay = 4
    if rem(current_tick, delay) == 0 do
    index = rem(div(current_tick, delay), Enum.count(notes))
    note = Enum.at(notes, index)
    PortMidi.write(device, {0x90, note, volume})
    Process.send_after(:midi, {:note_off, note}, 50 * 2)
    end
    end


    View Slide

15. I CAN HAZ RELOADING?
    Code.eval_file("music.exs")


    View Slide

16. HOW TO REACT TO FILE CHANGE?
    defmodule Monitor do
    use ExFSWatch,
    dirs: ["music.exs"],
    listener_extra_args: "--latency=0.0"
    def callback(_file_path, _events) do
    Code.eval_file("music.exs")
    end
    end
    Monitor.start


    View Slide

17. AHA MOMENT
    GenServer reloading keeps the state across reloads.
    => We can keep the "current music tick" between reloads.


    View Slide

18. +-----------------+ +------------------------+
    | (reloable) code | + | preserved state (tick) |
    +-----------------+ +------------------------+
    | |
    \ /
    +---------------------+ +----------+ +---------+
    | ex-portmidi process | -> | portmidi | -> | renoise |
    +---------------------+ +----------+ +---------+


    View Slide

19. DEMO
    Youtube Link


    View Slide
