Elixir, MIDI & LiveView (CodeElixir London 2019)

In this talk, I demonstrate the use of Elixir, Phoenix LiveView with SVG and hot-code reloading to achieve live music coding.

Live demo at https://twitter.com/unnawut/status/1151939962855677952

Transcript

1. Elixir, MIDI
   & LiveView
   @thibaut_barrere - I create data pipelines with Ruby & Elixir


   View Slide

2. Code-based music
   production?
   infiniWIP (TM)


   View Slide

3. Previous episode
   https://github.com/thbar/demo-elixir-reloading-music


   View Slide

4. Detect when I save a code file
   def init(args) do
   {:ok, watcher_pid} = FileSystem.start_link(args)
   FileSystem.subscribe(watcher_pid)
   def handle_info({:file_event, watcher_pid, {path, events}}, state) do do
   IO.puts "The file at #{path} has changed!"
   {:noreply, state}
   end


   View Slide

5. Re-evaluate it at runtime (hot reloading)
   def handle_info({:file_event, watcher_pid, {path, events}}, state) do do
   Code.eval_file(path)
   {:noreply, state}
   end


   View Slide

6. AHA MOMENT
   GenServer reloading keeps the state across reloads.
   => We can keep the "current music position/tick"
   between reloads.
   defmodule Artist do
   use GenServer
   def handle_info(:tick, state) do
   Process.send_after(self(), :tick, @tick_period)


   View Slide

7. MIDI


   View Slide

8. Note On
   {0x90 + channel, note, velocity}
   Note Off
   {0x80 + channel, note, release_velocity}


   View Slide

9. Keyboard / Piano / Synthetizers
   photo by Clavia


   View Slide

10. MIDI controllers
    photo by Novation


    View Slide

11. Virtual Instruments (on computer)


    View Slide

12. Virtual Instruments (on iOS)
    photo by Korg


    View Slide

13. Lightning = Inter-Device Audio & MIDI (IDAM)
    photo by Apple


    View Slide

14. Elixir
    Code / DRY
    Refactoring Music
    Augmented Human (theory, scales)
    Soft realtime


    View Slide

15. brew install portmidi


    View Slide

16. View Slide

17. # Start a process for MIDI event queue
    {:ok, pid} = PortMidi.open(:output, "Kontakt Virtual Input")
    note = 48 # C-4
    velocity = 127
    # Send "NOTE ON"
    PortMidi.write(pid, {0x90, note, velocity})
    # Send "NOTE OFF"
    PortMidi.write(pid, {0x80, note})


    View Slide

18. View Slide

19. Phoenix LiveView


    Time is


    HTML? ✔


    View Slide

20. Phoenix LiveView





    SVG? ✔


    View Slide

21. Phoenix LiveView


    # white notes


    # black notes




    View Slide

22. View Slide

23. View Slide

24. def note_on({channel, note, velocity}, device, portmidi \\ PortMidi) do
    Phoenix.PubSub.broadcast(Widgets.PubSub, "notes", {:note_on, note})
    :ok = portmidi.write(device, {0x90 + channel, note, velocity})
    end


    View Slide

25. View Slide

26. Live Demo
    https://twitter.com/unnawut/status/1151939962855677952


    View Slide
