Common scenarios in VCL - Varnish Summit CPH 2016

Slides for my "Common scenarios in VCL" talk at the 2016 Varnish Summit in Copenhagen. See http://info.varnish-software.com/copenhagen-summit-2016 for more information

Transcript

1. Common
   scenarios
   in VCL
   By Thijs Feryn


   View Slide

2. Hi, I’m Thijs


   View Slide

3. I’m
   @ThijsFeryn
   on Twitter


   View Slide

4. I’m an
   Evangelist
   At


   View Slide

5. I’m a
   at
   board member


   View Slide

6. 149 th
   talk


   View Slide

7. This is my first
   time
   in København


   View Slide

8. Slow websites suck


   View Slide

9. Varnish


   View Slide

10. Better end-user experience


    View Slide

11. Easy peasy
    right?


    View Slide

12. Not
    really


    View Slide

13. There are rules


    View Slide

14. ✓Only GET & HEAD
    ✓No authorization headers
    ✓No cookies
    ✓No set-cookies
    ✓Valid cache-control/expires
    headers
    When does Varnish
    cache? Some rules …


    View Slide

15. It’s all
    about
    state


    View Slide

16. Lots of
    developers
    don’t follow
    those rules


    View Slide

17. Cookies
    everywhere


    View Slide

18. Cache-control quoi?


    View Slide

19. Out of the box
    These are the main reasons
    why Varnish will not work


    View Slide

20. Write VCL


    View Slide

21. Varnish
    Configuration
    Language


    View Slide

22. Programming
    the
    Varnish
    behaviour


    View Slide

23. Varnish flow


    View Slide

24. View Slide

25. Hooks


    View Slide

26. VCL
    Recv
    VCL
    Hash
    VCL
    Miss
    VCL
    Hit
    VCL
    Backend
    Response
    VCL
    Deliver
    VCL
    Purge
    VCL
    Error
    VCL
    Pipe
    VCL
    Pass
    VCL
    Synth
    VCL
    Backend
    Error


    View Slide

27. ✓vcl_recv: receive request
    ✓vcl_hash: compose cache key
    ✓vcl_miss: not found in cache
    ✓vcl_hit: found in cache
    ✓vcl_pass: don’t store in cache
    ✓vcl_pipe: bypass cache
    ✓vcl_backend_fetch: connect to
    backend
    ✓vcl_backend_response: response
    from backend
    ✓vcl_backend_error: backend fetch
    failed


    View Slide

28. ✓vcl_purge: after successful purge
    ✓vcl_synth: send synthetic output
    ✓vcl_deliver: return data to client
    ✓vcl_init: initialize VMODs
    ✓vcl_fini: discard VMODs


    View Slide

29. vcl 4.0;
    backend default {
    .host = "127.0.0.1";
    .port = "8080";
    }
    Minimal VCL


    View Slide

30. vcl 4.0;
    backend default {
    .host = "127.0.0.1";
    .port = "80";
    .max_connections = 300;
    .first_byte_timeout = 300s;
    .connect_timeout = 5s;
    .between_bytes_timeout = 2s;
    }
    More backend work


    View Slide

31. vcl 4.0;
    backend default {
    .host = "127.0.0.1";
    .port = "80";
    .max_connections = 300;
    .first_byte_timeout = 300s;
    .connect_timeout = 5s;
    .between_bytes_timeout = 2s;
    .probe = {
    .url = "/";
    .interval = 5s;
    .timeout = 1s;
    .window = 5;
    .threshold = 3;
    }
    }
    Even more backend work


    View Slide

32. vcl 4.0;
    backend default {
    .host = "127.0.0.1";
    .port = "80";
    .max_connections = 300;
    .first_byte_timeout = 300s;
    .connect_timeout = 5s;
    .between_bytes_timeout = 2s;
    .probe = {
    .request =
    "HEAD / HTTP/1.1"
    "Host: localhost"
    "Connection: close"
    "User-Agent: Varnish Health Probe";
    .interval = 5s;
    .timeout = 1s;
    .window = 5;
    .threshold = 3;
    }
    }
    Even more backend work


    View Slide

33. Load balancing


    View Slide

34. vcl 4.0;
    import directors;
    backend server1 {
    .host = “1.2.3.4”;
    .port = "80";
    .max_connections = 300;
    .first_byte_timeout = 300s;
    .connect_timeout = 5s;
    .between_bytes_timeout = 2s;
    .probe = {
    .request =
    "HEAD / HTTP/1.1"
    "Host: localhost"
    "Connection: close"
    "User-Agent: Varnish Health Probe";
    .interval = 5s;
    .timeout = 1s;
    .window = 5;
    .threshold = 3;
    }
    }
    Loadbalancing: server 1


    View Slide

35. backend server2 {
    .host = “1.2.3.5”;
    .port = "80";
    .max_connections = 300;
    .first_byte_timeout = 300s;
    .connect_timeout = 5s;
    .between_bytes_timeout = 2s;
    .probe = {
    .request =
    "HEAD / HTTP/1.1"
    "Host: localhost"
    "Connection: close"
    "User-Agent: Varnish Health Probe";
    .interval = 5s;
    .timeout = 1s;
    .window = 5;
    .threshold = 3;
    }
    }
    Loadbalancing: server 2


    View Slide

36. sub vcl_init {
    new vdir = directors.round_robin();
    vdir.add_backend(server1);
    vdir.add_backend(server2);
    }
    sub vcl_recv {
    set req.backend_hint = vdir.backend();
    }
    Loadbalancing: round robin


    View Slide

37. sub vcl_init {
    new vdir = directors.random();
    vdir.add_backend(server1,2);
    vdir.add_backend(server2,3);
    }
    sub vcl_recv {
    set req.backend_hint = vdir.backend();
    }
    Loadbalancing: random


    View Slide

38. sub vcl_init {
    new vdir = directors.fallback();
    vdir.add_backend(server1);
    vdir.add_backend(server2);
    }
    sub vcl_recv {
    set req.backend_hint = vdir.backend();
    }
    Loadbalancing: fallback


    View Slide

39. sub vcl_init {
    new vdir = directors.hash();
    vdir.add_backend(server1);
    vdir.add_backend(server2);
    }
    sub vcl_recv {
    set req.backend_hint = vdir.backend(req.url);
    }
    Loadbalancing: URL hash


    View Slide

40. sub vcl_init {
    new vdir = directors.hash();
    vdir.add_backend(server1);
    vdir.add_backend(server2);
    }
    sub vcl_recv {
    set req.backend_hint = vdir.backend(client.identity);
    }
    Loadbalancing: IP hash


    View Slide

41. sub vcl_recv {
    if(req.url ~ “^/products”) {
    set req.backend_hint = server1;
    } else {
    set req.backend_hint = server2;
    }
    }
    Conditional loadbalacning


    View Slide

42. Normalize


    View Slide

43. vcl 4.0;
    import std;
    sub vcl_recv {
    set req.http.Host = regsub(req.http.Host, ":[0-9]+", "");
    set req.url = std.querysort(req.url);
    if (req.url ~ "\#") {
    set req.url = regsub(req.url, "\#.*$", "");
    }
    if (req.url ~ "\?$") {
    set req.url = regsub(req.url, "\?$", "");
    }
    if (req.restarts == 0) {
    if (req.http.Accept-Encoding) {
    if (req.http.User-Agent ~ "MSIE 6") {
    unset req.http.Accept-Encoding;
    } elsif (req.http.Accept-Encoding ~ "gzip") {
    set req.http.Accept-Encoding = "gzip";
    } elsif (req.http.Accept-Encoding ~ "deflate") {
    set req.http.Accept-Encoding = "deflate";
    } else {
    unset req.http.Accept-Encoding;
    }
    }
    }
    }
    Normalize


    View Slide

44. Static assets


    View Slide

45. vcl 4.0;
    sub vcl_recv {
    if (req.url ~ "^[^?]*\.(7z|avi|bmp|bz2|css|csv|doc|docx|eot|flac|
    flv|gif|gz|ico|jpeg|jpg|js|less|mka|mkv|mov|mp3|mp4|mpeg|mpg|odt|otf|
    ogg|ogm|opus|pdf|png|ppt|pptx|rar|rtf|svg|svgz|swf|tar|tbz|tgz|ttf|
    txt|txz|wav|webm|webp|woff|woff2|xls|xlsx|xml|xz|zip)(\?.*)?$") {
    unset req.http.Cookie;
    return (hash);
    }
    }
    sub vcl_backend_response {
    if (bereq.url ~ "^[^?]*\.(7z|avi|bmp|bz2|css|csv|doc|docx|eot|flac|
    flv|gif|gz|ico|jpeg|jpg|js|less|mka|mkv|mov|mp3|mp4|mpeg|mpg|odt|otf|
    ogg|ogm|opus|pdf|png|ppt|pptx|rar|rtf|svg|svgz|swf|tar|tbz|tgz|ttf|
    txt|txz|wav|webm|webp|woff|woff2|xls|xlsx|xml|xz|zip)(\?.*)?$") {
    unset beresp.http.set-cookie;
    }
    if (bereq.url ~ "^[^?]*\.(7z|avi|bz2|flac|flv|gz|mka|mkv|mov|mp3|mp4|
    mpeg|mpg|ogg|ogm|opus|rar|tar|tgz|tbz|txz|wav|webm|xz|zip)(\?.*)?$") {
    unset beresp.http.set-cookie;
    set beresp.do_stream = true;
    set beresp.do_gzip = false;
    }
    }
    Cache static assets


    View Slide

46. Do you really
    want to cache
    static assets?


    View Slide

47. Nginx or
    Apache can
    be fast
    enough for
    that


    View Slide

48. vcl 4.0;
    import std;
    sub vcl_recv {
    if (req.url ~ "^[^?]*\.(7z|avi|bmp|bz2|css|csv|doc|docx|eot|flac|
    flv|gif|gz|ico|jpeg|jpg|js|less|mka|mkv|mov|mp3|mp4|mpeg|mpg|odt|otf|
    ogg|ogm|opus|pdf|png|ppt|pptx|rar|rtf|svg|svgz|swf|tar|tbz|tgz|ttf|
    txt|txz|wav|webm|webp|woff|woff2|xls|xlsx|xml|xz|zip)(\?.*)?$") {
    unset req.http.Cookie;
    return (pass);
    }
    }
    Don’t cache static assets


    View Slide

49. URL whitelist/blacklist


    View Slide

50. sub vcl_recv {
    if (req.url ~ "^/status\.php$" ||
    req.url ~ "^/update\.php$" ||
    req.url ~ "^/admin$" ||
    req.url ~ "^/admin/.*$" ||
    req.url ~ "^/user$" ||
    req.url ~ "^/user/.*$" ||
    req.url ~ "^/flag/.*$" ||
    req.url ~ "^.*/ajax/.*$" ||
    req.url ~ "^.*/ahah/.*$") {
    return (pass);
    }
    }
    URL blacklist


    View Slide

51. sub vcl_recv {
    if (req.url ~ "^/products/?"
    return (hash);
    }
    }
    URL whitelist


    View Slide

52. Those damn
    cookies again!


    View Slide

53. vcl 4.0;
    sub vcl_recv {
    set req.http.Cookie = regsuball(req.http.Cookie, "has_js=[^;]+(; )?", "");
    set req.http.Cookie = regsuball(req.http.Cookie, "__utm.=[^;]+(; )?", "");
    set req.http.Cookie = regsuball(req.http.Cookie, "_ga=[^;]+(; )?", "");
    set req.http.Cookie = regsuball(req.http.Cookie, "_gat=[^;]+(; )?", "");
    set req.http.Cookie = regsuball(req.http.Cookie, "utmctr=[^;]+(; )?", "");
    set req.http.Cookie = regsuball(req.http.Cookie, "utmcmd.=[^;]+(; )?", "");
    set req.http.Cookie = regsuball(req.http.Cookie, "utmccn.=[^;]+(; )?", "");
    set req.http.Cookie = regsuball(req.http.Cookie, "__gads=[^;]+(; )?", "");
    set req.http.Cookie = regsuball(req.http.Cookie, "__qc.=[^;]+(; )?", "");
    set req.http.Cookie = regsuball(req.http.Cookie, "__atuv.=[^;]+(; )?", "");
    set req.http.Cookie = regsuball(req.http.Cookie, "^;\s*", "");
    if (req.http.cookie ~ "^\s*$") {
    unset req.http.cookie;
    }
    }
    Remove tracking cookies


    View Slide

54. vcl 4.0;
    sub vcl_recv {
    if (req.http.Cookie) {
    set req.http.Cookie = ";" + req.http.Cookie;
    set req.http.Cookie = regsuball(req.http.Cookie, "; +", ";");
    set req.http.Cookie = regsuball(req.http.Cookie, ";(PHPSESSID)=", "; \1=");
    set req.http.Cookie = regsuball(req.http.Cookie, ";[^ ][^;]*", "");
    set req.http.Cookie = regsuball(req.http.Cookie, "^[; ]+|[; ]+$", "");
    if (req.http.cookie ~ "^\s*$") {
    unset req.http.cookie;
    }
    }
    }
    Only keep session cookie


    View Slide

55. sub vcl_recv {
    if (req.http.Cookie) {
    set req.http.Cookie = ";" + req.http.Cookie;
    set req.http.Cookie = regsuball(req.http.Cookie, "; +", ";");
    set req.http.Cookie = regsuball(req.http.Cookie, ";(language)=", "; \1=");
    set req.http.Cookie = regsuball(req.http.Cookie, ";[^ ][^;]*", "");
    set req.http.Cookie = regsuball(req.http.Cookie, "^[; ]+|[; ]+$", "");
    if (req.http.cookie ~ "^\s*$") {
    unset req.http.cookie;
    return(pass);
    }
    return(hash);
    }
    }
    sub vcl_hash {
    hash_data(regsub( req.http.Cookie, "^.*language=([^;]*);*.*$", "\1" ));
    }
    Language cookie cache variation


    View Slide

56. Alternative
    language
    cache
    variation


    View Slide

57. sub vcl_hash {
    hash_data(req.http.Accept-Language);
    }
    Language cookie cache variation
    Or just send a
    “Vary:Accept-Language”
    header


    View Slide

58. sub vcl_hash {
    hash_data(req.http.Cookie);
    }
    Hash all cookies


    View Slide

59. Edge Side Includes


    View Slide

60. sub vcl_recv {
    set req.http.Surrogate-Capability = "key=ESI/1.0";
    }
    sub vcl_backend_response {
    if (beresp.http.Surrogate-Control ~ "ESI/1.0") {
    unset beresp.http.Surrogate-Control;
    set beresp.do_esi = true;
    }
    }
    Edge Side Includes


    View Slide

61. header("Cache-Control: public,must-revalidate,s-maxage=10");
    echo "Date in the ESI tag: ".date('Y-m-d H:i:s').'
    ';
    header("Cache-Control: no-store");
    header(“Surrogate-Control: content='ESI/1.0'");
    echo ''.PHP_EOL;
    echo "Date in the main page: ".date('Y-m-d H:i:s').'
    ';
    Main page
    ESI frame:
    esi.php
    Cached for
    10 seconds
    Not cached


    View Slide

62. ESI_xmlerror No ESI processing, first char
    not 'Expects HTML/
    XML tags


    View Slide

63. -p feature=+esi_disable_xml_check
    Add as
    startup option


    View Slide

64. Control
    Time
    To
    Live


    View Slide

65. sub vcl_backend_response {
    set beresp.ttl = 3h;
    }
    Control Time To Live


    View Slide

66. sub vcl_backend_response {
    if (beresp.ttl <= 0s || beresp.http.Set-Cookie ||
    beresp.http.Vary == "*") {
    set beresp.ttl = 120s;
    set beresp.uncacheable = true;
    return (deliver);
    }
    }
    Control Time To Live


    View Slide

67. Debugging


    View Slide

68. sub vcl_deliver {
    if (obj.hits > 0) {
    set resp.http.X-Cache = "HIT";
    } else {
    set resp.http.X-Cache = "MISS";
    }
    }
    Debugging


    View Slide

69. Anonymize


    View Slide

70. sub vcl_deliver {
    unset resp.http.X-Powered-By;
    unset resp.http.Server;
    unset resp.http.X-Drupal-Cache;
    unset resp.http.X-Varnish;
    unset resp.http.Via;
    unset resp.http.Link;
    unset resp.http.X-Generator;
    }
    Anonymize


    View Slide

71. Purging


    View Slide

72. acl purge {
    "localhost";
    "127.0.0.1";
    "::1";
    }
    sub vcl_recv {
    if (req.method == "PURGE") {
    if (!client.ip ~ purge) {
    return (synth(405, “Not allowed.”));
    }
    return (purge);
    }
    }
    Purging


    View Slide

73. acl purge {
    "localhost";
    "127.0.0.1";
    "::1";
    }
    sub vcl_backend_response {
    set beresp.http.x-url = bereq.url;
    set beresp.http.x-host = bereq.http.host;
    }
    sub vcl_deliver {
    unset resp.http.x-url;
    unset resp.http.x-host;
    }
    sub vcl_recv {
    if (req.method == "PURGE") {
    if (!client.ip ~ purge) {
    return (synth(405, "Not allowed"));
    }
    if(req.http.x-purge-regex) {
    ban("obj.http.x-host == " + req.http.host + " && obj.http.x-url ~ " +
    req.http.x-purge-regex);
    } else {
    ban("obj.http.x-host == " + req.http.host + " && obj.http.x-url == " +
    req.url);
    }
    return (synth(200, "Purged"));
    }
    }
    Banning


    View Slide

74. Banning
    curl -XPURGE -H "x-purge-regex:/products"
    "http://example.com"
    curl -XPURGE "http://example.com/products"


    View Slide

75. Grace mode


    View Slide

76. sub vcl_backend_response {
    set beresp.grace = 6h;
    }
    Grace mode


    View Slide

77. Cheers, hope
    this helps!


    View Slide

78. View Slide
