  1. Google Cloud Platform
    Kubernetes: A very brief
    explanation of ports
    Tim Hockin
    Senior Staff Software Engineer
    @thockin

    View Slide

  2. Google Cloud Platform
    cluster
    pod.spec.ports[*].containerPort
    ● declares the existence of a port on a pod
    ● can be assigned a name or hostPort
    ● informational, not required
    node node node
    pod
    3306
    pod
    8080
    pod
    8080
    pod
    80

    View Slide

  3. Google Cloud Platform
    cluster
    pod.spec.ports[*].hostPort
    ● maps a specific port on a single node’s IP to a containerPort
    ● only one per-port per-node
    ● should be your LAST RESORT - if the pod moves, the ip:port changes
    node node node
    pod
    3306
    pod
    8080
    pod
    8080
    pod
    80
    80 80 80

    View Slide

  4. Google Cloud Platform
    cluster
    service.spec.ports[*].port
    ● the virtual port on the service VIP
    ● service clients use this
    ● stable ip:port - does not change when pods move
    node node node
    pod
    3306
    pod
    8080
    pod
    80
    pod
    8080
    pod
    8080
    service
    8080

    View Slide

  5. Google Cloud Platform
    cluster
    service.spec.ports[*].targetPort
    ● maps a service port to backend containerPorts
    node node node
    pod
    3306
    pod
    8080
    pod
    80
    pod
    8080
    pod
    8080
    service
    80

    View Slide

  6. Google Cloud Platform
    cluster
    service.spec.ports[*].targetPort
    ● maps a service port to backend containerPorts
    ● can target a containerPort by number or name
    node node node
    pod
    mysql
    pod
    http
    pod
    http
    pod
    http
    pod
    http
    service
    80

    View Slide

  7. Google Cloud Platform
    service.spec.ports[*].nodePort
    ● maps a port on every node to a service port
    ● ports are allocated, random
    ● useful to interface with load-balancers that only understand nodes
    cluster
    node node node
    pod pod pod
    31234 31234
    3306 8080 8080
    31234
    pod
    3306
    pod
    8080

    View Slide

  8. Google Cloud Platform
    service.spec.ports[*].nodePort (OnlyLocal)
    ● annotation:
    service.beta.kubernetes.io/external-traffic=OnlyLocal
    ● changes how backends are chosen
    cluster
    node node node
    pod pod pod
    31234 31234
    3306 8080 8080
    31234
    pod
    3306
    pod
    8080

    View Slide
