  1. Multi-Cluster Kubernetes
    Past, present,future?
    Cloud Native Day
    Sept 14, 2022
    Tim Hockin
    @thockin

    View full-size slide

  2. “That Networking Guy”

    View full-size slide

  3. “That Networking Guy”
    “He Who Takes Too Long to Review”

    View full-size slide

  4. “That Networking Guy”
    “He Who Takes Too Long to Review”
    “Mister NO”

    View full-size slide

  5. “That Networking Guy”
    “He Who Takes Too Long to Review”
    “Mister NO”
    “The person who approved my PR”

    View full-size slide

  6. Most of the Kubernetes concept is rooted
    in the cluster abstraction.
    • Nodes are in a single cluster
    • Scheduling is considered per-cluster
    • Clusters have their own network configs
    • Service discovery is per-cluster
    • Volumes and LBs are tied to cluster
    • Each cluster is its own ID provider
    • Each cluster does its own authn and authz
    In the beginning...clusters

    View full-size slide

  7. Why so many clusters?

    View full-size slide

  8. Location
    • Latency: Run apps as close to the
    customer as possible
    • Jurisdiction: Required to keep
    user-data in the country
    • Data gravity: Large amounts of data
    already exists and would cost too
    much to move
    Why so many clusters?

    View full-size slide

  9. Reliability
    • Infrastructure diversity: A provider
    outage does not kill the whole app
    • Blast radius: Unplanned problems
    have bounded impact
    • Upgrades: Do one part at a time, or
    even avoid in-place upgrades
    • Scale: App is too big for one cluster
    Why so many clusters?

    View full-size slide

  10. Isolation
    • Environment: Dev, test, prod
    • Performance: Apps should not
    impact each other
    • Security: Sensitive data, untrusted
    code, or very-high-value services
    • Organization: Different management
    • Cost: Teams get their own bills
    Why so many clusters?

    View full-size slide

  11. • Started before 1.0!
    • Goal: federate the k8s APIs
    • Goal: API compatible with k8s
    • Runs a “control-plane” cluster
    • Adds a “cluster” API resource
    • Adds cross-cluster controllers
    Kubefed aka “Übernetes”

    View full-size slide

  12. • A control-plane cluster brings
    its own problems
    • Needed API changes vs. k8s
    • Not all k8s resources make
    sense to federate
    • Lack of awareness of
    infrastructure
    Problems

    View full-size slide

  13. • A kubernetes-style API for
    listing clusters
    • Enable building multi-cluster
    controllers without defining or
    implementing them ourselves
    • Human- and machine-friendly
    • Enable Single-Pane-Of-Glass UX
    ClusterRegistry

    View full-size slide

  14. • Too small and precise:
    demands kubernetes API
    machinery
    • No lifecycle management, just
    listing
    • Too abstract: lacking details
    Problems

    View full-size slide

  15. • Evolution from v1: but less
    “everything all at once”
    • Only specific types are federated
    • API leaves room for placement
    and overrides
    • Many of v1’s problems persist
    • Proposed to be archived
    Kubefed v2
    v2

    View full-size slide

  16. 1) Cluster / fleet / platform admins
    ● Care about clusters
    ● Care about governance
    ● Care about TCO
    2) Application operators
    ● Shouldn’t care about clusters
    ● Care about functionality
    ● Care about UX
    Who are we solving for?

    View full-size slide

  17. Specific problems

    View full-size slide

  18. Cluster B
    Cluster A
    Services: Between clusters

    View full-size slide

  19. Cluster C
    Cluster A
    Services: Between clusters
    Cluster B

    View full-size slide

  20. Cluster C
    Cluster A
    Services: Between clusters
    Cluster B

    View full-size slide

  21. Cluster B
    Cluster A
    Ingress

    View full-size slide

  22. Cluster B
    Governance & Policy
    Cluster A

    View full-size slide

  23. Cluster B
    Single Pane Of Glass
    Cluster A

    View full-size slide

  24. Cluster Migration / Upgrades
    Cluster A (v1.x)

    View full-size slide

  25. Cluster Migration / Upgrades
    Cluster B (v1.y)
    Cluster A (v1.x)

    View full-size slide

  26. Cluster Migration / Upgrades
    Cluster B (v1.y)
    Cluster A (v1.x)

    View full-size slide

  27. Cluster Migration / Upgrades
    Cluster B (v1.y)

    View full-size slide

  28. Cluster Migration / Upgrades
    Cluster B (v1.y)

    View full-size slide

  29. Cluster B
    Lifecycle / CD
    Cluster A Cluster C

    View full-size slide

  30. Tenancy
    Cluster A
    ₣€$
    Cluster B
    ₣€$
    Cluster C
    ₣€$

    View full-size slide

  31. Workloads
    Cluster C
    Cluster A Cluster B

    View full-size slide

  32. Can we generalize?

    View full-size slide

  33. clusterset
    Commit
    member
    cluster
    member
    cluster
    Source of truth
    raw payload
    Target selection
    Payload specialization per target
    Payload delivery
    member
    cluster
    Might be a git repository, a
    k8s API, a kcp instance, or
    other.
    Might be label selectors, a
    list of cluster names, or
    other.
    Might be push or pull.
    Might have policies applied
    (e.g. rate limits).
    Might be unilateral or
    reconciled bi-directionally.
    Might be templates, helm,
    kustomize, or other.
    Cluster registry
    Might be individual
    resources or some form of
    “package”.
    Target sequencing Might be none or highly
    orchestrated or something
    in-between.
    NB: Arbitrary processing can occur
    at various stages
    E.g “package” expansion could be:
    ● before commit
    ● at payload specialization
    ● at payload delivery

    View full-size slide

  34. Cluster B
    Cluster A
    Multi-cluster Services

    View full-size slide

  35. apiVersion: v1
    kind: Service
    metadata:
    name: my-svc
    spec:
    selector:
    app: my-svc
    type: ClusterIP
    clusterIP: 10.9.3.76
    ports:
    - port: 80
    protocol:TCP
    Multi-cluster Services
    apiVersion: v1
    kind: Endpoints
    metadata:
    name: my-svc
    subsets:
    - addresses:
    - ip: 10.123.1.18
    - ip: 10.123.12.8
    - ip: 10.123.1.11
    ports:
    - port: 8000
    protocol:TCP

    View full-size slide

  36. apiVersion: v1
    kind: Service
    metadata:
    name: my-svc
    spec:
    selector:
    app: my-svc
    type: ClusterIP
    clusterIP: 10.9.3.76
    ports:
    - port: 80
    protocol:TCP
    Multi-cluster Services
    apiVersion: discovery.k8s.io/v1
    kind: EndpointSlice
    metadata:
    generateName: my-svc-
    labels:
    .../managed-by:
    .../service-name: my-svc
    endpoints:
    - addresses:
    - 10.123.1.18
    - 10.123.12.9
    - 10.123.1.11
    ports:
    - port: 8000
    protocol: TCP

    View full-size slide

  37. Cluster B
    Cluster A
    Multi-cluster Services

    View full-size slide

  38. apiVersion: v1
    kind: Service
    metadata:
    name: my-svc
    spec:
    selector:
    app: my-svc
    type: ClusterIP
    clusterIP: 10.9.3.76
    ports:
    - port: 80
    protocol:TCP
    Multi-cluster Services
    apiVersion: .../v1alpha1
    kind: ServiceExport
    metadata:
    name: my-svc

    View full-size slide

  39. Wait, Clusterset?

    View full-size slide

  40. Cluster B
    Cluster A
    Multi-cluster Services

    View full-size slide

  41. Clusterset
    Cluster B
    Cluster A
    Multi-cluster Services

    View full-size slide

  42. Clusterset
    Cluster B
    Cluster A
    Multi-cluster Services

    View full-size slide

  43. Wait, Sameness?

    View full-size slide

  44. Clusterset
    Cluster B
    Cluster A
    Multi-cluster Services

    View full-size slide

  45. Cluster B
    Cluster A
    Multi-cluster Ingress

    View full-size slide

  46. Clusterset
    Cluster B
    Cluster A
    Multi-cluster Ingress

    View full-size slide

  47. Clusterset
    Cluster B
    Cluster A
    Multi-cluster Ingress Gateway

    View full-size slide

  48. MC NetworkPolicy
    ● Conspicuously absent in upstream
    MC AdminNetworkPolicy
    ● Capturing tenancy more fully
    MC Scheduling
    ● Pick the best cluster for my workload
    MC Stateful apps
    ● Move/share disks between clusters
    ● DR, active-passive, or active-active
    Future projects (?)
