Auto Layouters Anonymous

I gave this talk at the March 18, 2014, CocoaHeadsNL meeting.

In an attempt to mediate a resolution of the troubled relationship that many members of our community have with Auto Layout, I talked about my experience with Auto Layout, the basics of Auto Layout and some of the more advanced stuff.

There were quite some movies in the presentation, which don't translate well to pdf. Sorry about that.

Thanks to my colleagues at Touchwonders (Dick, Tim, Lars, Jonah & Christian) and Chris Eidhof for providing feedback to an earlier version of this talk.

Transcript

2. Auto Layouters Anonymous The 1st annual CocoaHeadsNL meeting of the Thomas Visser, @thomvis88 ALA
3. “I have never tried Auto Layout”
4. “I have no idea what Auto Layout is”
5. “I tried using Auto Layout and hated it”
6. “I tried using Auto Layout, hated it, tried it again and now love it.”
7. “I tried using Auto Layout, hated it, tried it again, loved it, used it for absolutely everything, that didn’t work out too well and now I try to use it where it makes sense.”
8. Technology Trigger http://www.gartner.com/technology/research/methodologies/hype-cycle.jsp Peak of Inflated Expectations Through of Disillusionment Slope of Enlightenment Plateau of Productivity Me
10. Springs & Struts (0,0) 133 100
11. Springs & Struts
12. Auto Layout >= 0 >= 0 == 8 == 8
13. Past Springs & Struts
14. Auto Layout Future
15. Auto Layout • Uniform layout description for multiple orientations & UI idioms • Declarative UI definition • More flexible UI for easier localisation • Bi-directional UI support • Fun
19. _horizontalSpacingConstraints = [NSLayoutConstraint constraintsWithVisualFormat:@"H:|[_checkboxView]-(checkboxToLabelSpacing)-[_labelView]-|" options:0 metrics:@{@"checkboxToLabelSpacing": @(kHSCheckboxToLabelHorizontalSpacing)} views:views]; [self addConstraints: _horizontalSpacingConstraints]; _checkboxVerticalCenteringConstraint = [NSLayoutConstraint constraintWithItem:_checkboxView attribute:NSLayoutAttributeCenterY relatedBy:NSLayoutRelationEqual toItem:self attribute:NSLayoutAttributeCenterY multiplier:1.0 constant:0]; [self addConstraint: _checkboxVerticalCenteringConstraint]; _labelVerticalCenteringConstraint = [NSLayoutConstraint constraintWithItem:_labelView attribute:NSLayoutAttributeCenterY relatedBy:NSLayoutRelationEqual toItem:self attribute:NSLayoutAttributeCenterY multiplier:1.0 constant:0]; [self addConstraint: _labelVerticalCenteringConstraint]; ! _checkboxWidthConstraint = [NSLayoutConstraint constraintWithItem:_checkboxView attribute:NSLayoutAttributeWidth relatedBy:NSLayoutRelationEqual toItem:nil attribute:0 multiplier:1.0 constant:kHSCheckboxSize.width]; _checkboxWidthConstraint.priority = UILayoutPriorityRequired; [_checkboxView addConstraint: _checkboxWidthConstraint]; _checkboxHeightConstraint = [NSLayoutConstraint constraintWithItem:_checkboxView attribute:NSLayoutAttributeHeight relatedBy:NSLayoutRelationEqual toItem:nil attribute:0 multiplier:1.0 constant:kHSCheckboxSize.height]; _checkboxHeightConstraint.priority = UILayoutPriorityRequired; [_checkboxView addConstraint: _checkboxHeightConstraint]; _checkboxHeightToContentHeightConstraints = [NSLayoutConstraint constraintsWithVisualFormat:@"V:|-(verticalPadding)-[_checkboxView]-(verticalPadding)-|" options:0 metrics:@{@"verticalPadding": @(kHSCheckboxVerticalPadding)}
23. Xcode 4
24. Xcode 5
26. A Constraint Defines a relation between two view attributes
27. A Constraint view.left = superview.left + 100.0 100 Defines a relation between two view attributes
28. A Constraint view.trailing <= superview.trailing - 200 <= -200 Defines a relation between two view attributes
29. A Constraint Defines a relation between two view attributes view.trailing <= superview.trailing - 200 <= -200
30. view.centerY = superview.centerY * 0.5 A Constraint centerY 0.5* centerY centerY Defines a relation between two view attributes
31. view.width = superview.width * 0.5 A Constraint 1:2 Defines a relation between two view attributes
32. A Constraint view1.attribute1 = view2.attribute2 * multiplier + constant
33. view1.attribute1 = view2.attribute2 * multiplier + constant A Constraint
34. view1.attribute1 = view2.attribute2 * multiplier + constant A Constraint typedef NS_ENUM(NSInteger, NSLayoutAttribute) { NSLayoutAttributeLeft = 1, NSLayoutAttributeRight, NSLayoutAttributeTop, NSLayoutAttributeBottom, NSLayoutAttributeLeading, NSLayoutAttributeTrailing, NSLayoutAttributeWidth, NSLayoutAttributeHeight, NSLayoutAttributeCenterX, NSLayoutAttributeCenterY, NSLayoutAttributeBaseline, NSLayoutAttributeNotAnAttribute = 0 };
35. A Constraint typedef NS_ENUM(NSInteger, NSLayoutRelation) { NSLayoutRelationLessThanOrEqual = -1, NSLayoutRelationEqual = 0, NSLayoutRelationGreaterThanOrEqual = 1, }; view1.attribute1 = view2.attribute2 * multiplier + constant
36. A Constraint enum { UILayoutPriorityRequired = 1000, UILayoutPriorityDefaultHigh = 750, UILayoutPriorityDefaultLow = 250, UILayoutPriorityFittingSizeLevel = 50, }; typedef float UILayoutPriority; @ priority view1.attribute1 = view2.attribute2 * multiplier + constant
37. A Constraint goes both ways @ priority view1.attribute1 = view2.attribute2 * multiplier + constant
38. A Constraint @ priority view1.attribute1 = view2.attribute2 * multiplier + constant view.width = superview.width * 0.5 + 0.0 1:2 goes both ways
39. view.width = superview.width * 0.5 + 0.0 A Constraint @ priority view1.attribute1 = view2.attribute2 * multiplier + constant goes both ways
40. view.width = superview.width * 0.5 + 0.0 A Constraint superview.width = (view.width - 0.0)/0.5 @ priority view1.attribute1 = view2.attribute2 * multiplier + constant goes both ways
41. Intrinsic Content Size
42. Intrinsic Content Size Content hugging priority < external width constraint
43. Intrinsic Content Size Content compression resistance priority < external width constraint
44. Layout Engine • Constraints • Intrinsic Content Sizes Meet as many constraints and intrinsic content sizes as possible, keeping constraint priority, content hugging and compression resistance into account Inputs Process
46. Meet as many constraints and intrinsic content sizes as possible, keeping constraint priority, content hugging and compression resistance into account Layout Engine • Constraints • Intrinsic Content Sizes Inputs Process
47. Layout Engine • Constraints • Intrinsic Content Sizes Linear Algebra Inputs Process
48. Layout Engine Inputs • Constraints • Intrinsic Content Sizes Process Linear Algebra Output • No layout
 or • Multiple Layouts
 or • A Single Layout
49. Layout Engine Unsatisfiable constraints Ambiguous layout • Constraints • Intrinsic Content Sizes Linear Algebra ✔ Inputs Process Output • No layout
 or • Multiple Layouts
 or • A Single Layout
50. A Fully Specified Layout • At least two constraints or content size specification per axis ! • No contradicting constraints ! • Result: Every view has a valid frame
53. _horizontalSpacingConstraints = [NSLayoutConstraint constraintsWithVisualFormat:@"H:|[_checkboxView]-(checkboxToLabelSpacing)-[_labelView]-|" options:0 metrics:@{ @"checkboxToLabelSpacing": @(kHSCheckboxToLabelHorizontalSpacing) } views:views]; [self addConstraints: _horizontalSpacingConstraints]; H:|[_checkboxView]-(checkboxToLabelSpacing)-[_labelView]-|
54. H:|[_checkboxView]-(checkboxToLabelSpacing)-[_labelView]-|
55. _horizontalSpacingConstraints = [NSLayoutConstraint constraintsWithVisualFormat:@"H:|[_checkboxView]-(checkboxToLabelSpacing)-[_labelView]-|" options:0 metrics:@{ @"checkboxToLabelSpacing": @(kHSCheckboxToLabelHorizontalSpacing) } views:views]; [self addConstraints: _horizontalSpacingConstraints]; H:|[_checkboxView]-(checkboxToLabelSpacing)-[_labelView]-|
56. _labelVerticalCenteringConstraint = [NSLayoutConstraint constraintWithItem:_labelView attribute:NSLayoutAttributeCenterY relatedBy:NSLayoutRelationEqual toItem:self attribute:NSLayoutAttributeCenterY multiplier:1.0 constant:0]; [self addConstraint: _labelVerticalCenteringConstraint];
57. Interface Builder Visual Format constraintWithItem: Ease of Use +++ ++ + Expressiveness + + +++
58. Animations • Frame changes can be animated. • Frames change by changing constraints. • Constraint changes can be animated.
59. Animations • Frame changes can be animated. • Frames change by changing constraints. • Constraint changes can be animated. UIView
60. [UIView animateWithDuration:0.3 animations:^{ _leftView.frame = CGRectMake(10, 10, 20, 20); }];
61. constraint.constant = 65; ! [UIView animateWithDuration:0.3 animations:^{ [_leftView layoutIfNeeded]; } completion:nil];
63. constraint.constant = 65; ! [UIView animateWithDuration:0.3 animations:^{ [_leftView layoutIfNeeded]; } completion:nil];
65. - (void)pan:(UIPanGestureRecognizer*)sender { if (sender.state == UIGestureRecognizerStateBegan) { ! _grabbedView = [self.view hitTest:[sender locationInView:self.view] withEvent:nil]; ! } else if (sender.state == UIGestureRecognizerStateChanged) { ! CGPoint trans = [sender translationInView: self.view]; _grabbedView.center = CGPointMake(_grabbedView.center.x+trans.x, _grabbedView.center.y+trans.y); [sender setTranslation:CGPointZero inView:self.view]; } else if (sender.state == UIGestureRecognizerStateEnded) { ! [_grabbedView setNeedsLayout]; [UIView animateWithDuration:1.0 animations:^{ [_grabbedView layoutIfNeeded]; }]; ! } }
67. Animation Caveats • Scope of [view layoutIfNeeded] is fuzzy • Anchor point determined by Auto Layout (CGAffineTransformScale )
68. Animation Caveats • “Auto Layout is animating changes that I don’t want to animate!?” • “Auto Layout is not animating changes that I do want to animate!?”
69. Animation Caveats >= 20 >= 20
70. Animation Caveats >= 20 >= 20
73. >= 0 @ 1000 >= 0 @ 1000
74. >= 0 @ 1000 >= 0 @ 1000 >= 0 @ 1000
75. >= 0 @ 1000 >= 0 @ 1000 >= 0 @ 1000 ! ! @ 500 @ 500
77. Final Notes
78. UIScrollView & Auto Layout is tricky
 http://developer.apple.com/library/ios/technotes/tn2154/_index.html
79. UIScrollView & Auto Layout is tricky
 http://developer.apple.com/library/ios/technotes/tn2154/_index.html
80. http://oleb.net/blog/2014/03/how-i-learned-to-stop-worrying-and-love-auto-layout/ Auto Layout is not all or nothing and that’s a good thing
81. Auto Layout is not free (as in no-op)
 [self.window addConstraints: allMyConstraints]; ❌
82. [self.deepestPossibleView addConstraints: allMyConstraints]; ✔ Auto Layout is not free (as in no-op)

83. !
 http://floriankugler.com/blog/2013/4/21/auto-layout-performance-on-ios Auto Layout is not free (as in no-op)

84. Debugging Auto Layout problems is overwhelming at first
85. Unable to simultaneously satisfy constraints. Probably at least one of the constraints in the following list is one you don't want. Try this: (1) look at each constraint and try to figure out which you don't expect; (2) find the code that added the unwanted constraint or constraints and fix it. (Note: If you're seeing NSAutoresizingMaskLayoutConstraints that you don't understand, refer to the documentation for the UIView property translatesAutoresizingMaskIntoConstraints) ( "<NSLayoutConstraint:0x10927a090 H:[UIView:0x10927be30(75)]>", "<NSLayoutConstraint:0x10922bd40 H:|-(NSSpace(20))-[UIView:0x10927be30] (Names: '|':UIView:0x109269cf0 )>", "<NSLayoutConstraint:0x109275f50 H:[UIView:0x10927be30]-(200)-[UIView:0x10927c970]>", "<NSLayoutConstraint:0x10927b6a0 H:[UIView:0x10927c970]-(20)-| (Names: '|':UIView:0x109269cf0 )>", "<NSLayoutConstraint:0x10927eb00 H:|-(NSSpace(20))-[UIView:0x109269cf0] (Names: '|':UIView:0x109267470 )>", "<NSLayoutConstraint:0x10927eb50 H:[UIView:0x109269cf0]-(NSSpace(20))-| (Names: '|':UIView:0x109267470 )>", "<NSAutoresizingMaskLayoutConstraint:0x10930ef10 h=-&- v=-&- UIView:0x109267470.width == UIWindow:0x10930a3e0.width>", "<NSAutoresizingMaskLayoutConstraint:0x10930fe60 h=--- v=--- H:[UIWindow:0x10930a3e0(320)]>" ) ! Will attempt to recover by breaking constraint <NSLayoutConstraint:0x10927a090 H:[UIView:0x10927be30(75)]> ! Break on objc_exception_throw to catch this in the debugger. The methods in the UIConstraintBasedLayoutDebugging category on UIView listed in <UIKit/UIView.h> may also be helpful.
86. // Debugging ! /* Everything in this section should be used in debugging only, never in shipping code. These methods may not exist in the future - no promises. */ @interface UIView (UIConstraintBasedLayoutDebugging) ! /* This returns a list of all the constraints that are affecting the current location of the receiver. The constraints do not necessarily involve the receiver, they may affect the frame indirectly. Pass UILayoutConstraintAxisHorizontal for the constraints affecting [self center].x and CGRectGetWidth([self bounds]), and UILayoutConstraintAxisVertical for the constraints affecting[self center].y and CGRectGetHeight([self bounds]). */ - (NSArray *)constraintsAffectingLayoutForAxis:(UILayoutConstraintAxis)axis NS_AVAILABLE_IOS(6_0); ! /* If there aren't enough constraints in the system to uniquely determine layout, we say the layout is ambiguous. For example, if the only constraint in the system was x = y + 100, then there are lots of different possible values for x and y. This situation is not automatically detected by UIKit, due to performance considerations and details of the algorithm used for layout. The symptom of ambiguity is that views sometimes jump from place to place, or possibly are just in the wrong place. -hasAmbiguousLayout runs a check for whether there is another center and bounds the receiver could have that could also satisfy the constraints. -exerciseAmbiguousLayout does more. It randomly changes the view layout to a different valid layout. Making the UI jump back and forth can be helpful for figuring out where you're missing a constraint. */ - (BOOL)hasAmbiguousLayout NS_AVAILABLE_IOS(6_0); - (void)exerciseAmbiguityInLayout NS_AVAILABLE_IOS(6_0); @end
87. • http://www.objc.io/issue-3/advanced-auto-layout-toolbox.html • https://developer.apple.com/library/ios/documentation/ UserExperience/Conceptual/AutolayoutPG/Introduction/ Introduction.html# Literature
88. Thanks Thomas Visser, @thomvis88 (We’re hiring @touchwonders) www.touchwonders.com
