Distributed Log Search Based on Time Series Access and Service Relations

AINA-2022 / @Online / April 15, 2022

https://link.springer.com/chapter/10.1007/978-3-030-99587-4_10

Transcript

1. Distributed Log Search based on
   Time Series Access and
   Service Relations
   Tomoyuki Koyama, Takayuki Kushida
   Tokyo University of Technology
   AINA-2022 / April 15, 2022
   1


   View Slide

2. Server
   Introduction
   • Log is a message that is recorded events within the software.
   • Supports analysis of processing procedures in past
   • Helps administrators to find errors in software
   • Log Management
   • The total volume of logs increases as the number of logs increases.
   • Millions of logs need to be retrieved in a short time.
   2
   Software
   March 27, 2022 10:24:13 Started app
   March 27, 2022 10:25:40 Communicated node1
   March 27, 2022 10:25:40 Stored file1
   March 27, 2022 10:35:00 Stopped app Logs Administrator
   Search


   View Slide

3. Introduction
   • Distributed Tracing is realized by logs.
   • It improves transactions traceability on microservices.
   • Each transaction is assigned a request identifier ’Request ID’.
   • Microservices store log messages with the identifier on log files.
   • Administrator finds the messages for root cause analysis.
   3
   [2021-10-22T00:27:09.383Z] "GET /paper/0416f705-df88-4d5f-82e8-095d4bd89e37/download HTTP/1.1" 200 -
   via_upstream - "-" 0 736954 134 133 "-" "Python/3.9 aiohttp/3.7.4.post0" "11c0553b-e1cd-9044-b4ce-
   49576dcbae6c" "paper-app.paper:4000" "10.42.2.65:8000" inbound|8000|| 127.0.0.6:37351 10.42.2.65:8000
   10.42.2.64:44452 outbound_.4000_._.paper-app.paper.svc.cluster.local default
   EXAMPLE: Log message
   Users
   Microservice A Microservice B
   Request ID=11c0553…
   Log files
   Log messages
   with Request ID
   Administrator
   Find log messages
   with Request ID
   Request ID=11c0553…
   HTTP Request (transaction)
   Request ID
   (1)
   (2)
   (3)
   (4)


   View Slide

4. Introduction
   • Scatter-Gather Pattern enables horizontal scalability.
   • A method for large scale data processing
   • Scatter: The root node splits a task into several sub-tasks, and
   scatters sub-tasks to leaf nodes.
   • Gather: Leaf nodes return a result of the sub-task
   to the root node.
   • Prerequisite
   • Applies Scatter-Gather Pattern to log search
   for distributed tracing
   4
   Leaf nodes
   Root node
   Scatter
   Gather
   Admin


   View Slide

5. Issue – Log Search
   ◆ A simple search method accesses all logs in parallel.
   5
   Search response time
   The volume of accessed logs
   corresponding
   As the volume of accessed logs on search increases, Search response time increases.
   As the total volume of logs increases, Search response time increases.
   ◆ Reduction of search response time is useful for trouble-shoot.
   Short response time reduces the total time for repairing troubles.
   Needs: The method for reduction the volume of logs on search


   View Slide

6. Proposed Method
   • Proposes a fast log search method for distributed tracing
   • Reduces the number of accessed log data on Search.
   • Focuses on time-series access patterns of log data
   and service relations
   6
   B
   Microservices
   A C
   B
   Service Relations
   A
   C
   Logs
   Service
   Discovery
   Blocks
   Placement Rule
   Leaf nodes
   Root
   node
   Moving blocks by
   placement rule
   Istio
   Admin
   Search Query
   Store Phase
   Search Phase
   Clustering by
   datetime &
   microservice
   Block List


   View Slide

7. Proposed Method – Reduction of search target logs
   Service relations correspond to Chronological order among logs.
   7
   Search target period
   Accessed Blocks
   in search targets
   Unaccessed Blocks
   in search targets
   Datetime
   Blocks: Microservice A
   Blocks: Microservice B
   Service A sends a request to Service B.
   =Time-series access patterns
   Service B writes a log message after
   Servce A writes a log message.
   A B
   Microservices
   Example)
   (1)Request
   (2)Response
   A B
   Service Relations
   Clustering by datetime
   & microservice
   Log:
   sent
   Reduces the number of accessed blocks on Search Phase
   Log:
   received


   View Slide

8. Experimental Method
   • Measures search response time from
   search requests sent till the search
   responses recived
   • Creates 14 VMs on Hypervisor
   • CPU: 1[Core], RAM: 1[GB], Storage: 30[GB]
   • 1 root node, 13 leaf nodes
   • Stores production logs (paper search website) to leaf nodes
   • Enhances the volume of logs: 1,600 → 8,065,000 [messages]
   8
   Collected from production microservices
   request_id=xxx bs=8, s_dt_begin="2021-12-13T10:21:50", s_dt_end="2023-02-13T10:21:50"
   Search Query


   View Slide

9. Experimental Results
   • Compares search response time between proposed method and
   all parallel method while the search target period expands
   • The proposed method is 52% shorter than all parallel method in
   response time maximally.
   9
   better
   Proposed method
   0
   0.5
   1
   1.5
   2
   2.5
   3
   3 6 9 12 15 18 21 24
   Response time [Sec]
   Date/time range in search query [Month]
   proposal-04
   proposal-08
   proposal-16
   proposal-32
   0
   0.5
   1
   1.5
   2
   2.5
   3
   3 6
   Response time [Sec]
   Dat
   all-p
   all-p
   Response time[sec]
   Search target period [month]
   All parallel method
   Search target period [month]
   21 24
   onth]
   al-16
   al-32
   0
   0.5
   1
   1.5
   2
   2.5
   3
   3 6 9 12 15 18 21 24
   Response time [Sec]
   Date/time range in search query [Month]
   all-parallel-04
   all-parallel-08
   all-parallel-16
   all-parallel-32
   Response time[sec]
   better
   Block Size=4[MB]
   Block Size=8[MB]
   Block Size=16[MB]
   Block Size=32[MB]
   Block Size=4[MB]
   Block Size=8[MB]
   Block Size=16[MB]
   Block Size=32[MB]


   View Slide

10. Discussion
    ◆Block size
    • The proposed method sets fixed block size.
    • The number of log messages per block is homogeneous.
    • The file size which can be read and written simultaneously
    depends on Disk I/O performance per leaf node.
    • Block size has to be calculated from Disk I/O performance.
    • One of the methods is using iostat command which returns
    I/O performance.
    10


    View Slide

11. Thank you for listening
    11
