Federated Queries with HAWQ - SQL on Hadoop and Beyond

Spring One 2015 presentation: http://bit.ly/1LQlTrL
InfoQ video: http://bit.ly/2wpzwgs

In the space of Big Data, Pivotal offers two powerful data processing tools namely HAWQ and GemFire. HAWQ is a scalable OLAP SQL-on-Hadoop system, while GemFire is OLTP like, in-memory data grid and event processing system. This presentation will show different integration approaches that allow integration and data exchange between HAWQ and GemFire. The practical experience in applying Spring Boot and Spring XD for some of the use cases will be shared while walking you through the implementation of the different Integration strategies. Amongst other we will show an integration path that leverages SpringXD to ingest GemFire data and store it in HDFS as well as the benefits of using Spring Boot to implement REStful proxy for the HAWQ Web Table integration scenario.

Transcript

1. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   SPRINGONE2GX
   WASHINGTON, DC
   Federated Queries with HAWQ
   SQL on Hadoop and Beyond
   By Christian Tzolov
   @christzolov


   View Slide

2. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

   Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   Safe Harbor Statement
   The following is intended to outline the general direction of Pivotal's offerings. It is
   intended for information purposes only and may not be incorporated into any
   contract. Any information regarding pre-release of Pivotal offerings, future updates
   or other planned modifications is subject to ongoing evaluation by Pivotal and is
   subject to change. This information is provided without warranty or any kind,
   express or implied, and is not a commitment to deliver any material, code, or
   functionality, and should not be relied upon in making purchasing decisions
   regarding Pivotal's offerings. These purchasing decisions should only be based on
   features currently available. The development, release, and timing of any features
   or functionality described for Pivotal's offerings in this presentation remain at the
   sole discretion of Pivotal. Pivotal has no obligation to update forward looking
   information in this presentation.
   2


   View Slide

3. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

   Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   3
   Bio
   Christian Tzolov
   Pivotal Technical Architect,
   BigData, Hadoop, SpringXD
   Apache Committer, Crunch PMC member
   ctzolov@pivotal.io
   @christzolov
   blog.tzolov.net


   View Slide

4. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

   Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   Contents
   • Data System Concepts
   • Data System Reference Architectures.
   • Real Life Use Case: OLTP and OLAP Data Systems Integration
   • Passive Data Synchronization (Demo)
   • Federated Queries With HAWQ
   • HAWQ Web Tables
   • HAWQ PXF Architecture
   • Geode PXF (Demo)
   4


   View Slide

5. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

   Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   How Compute
   Arbitrary Functions
   on Arbitrary Data

   Query = Function (All Data)
   5


   View Slide

6. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

   Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   Data System Concepts
   6


   View Slide

7. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

   Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   Data
   What is Data?
   • Data is Information
   • Derived vs. Fact Information
   • Not derived information will be called Data
   • Data hold to be true simply because it exists
   • All other information is derived from the Data
   7


   View Slide

8. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

   Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   Data System
   System that computes arbitrary functions on arbitrary data.
   • Low Latency
   • High Throughput
   • Scalability
   • Ad hoc queries
   • Provenance
   8


   View Slide

9. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

   Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
   Data System Principles
   The 6-elements Application = Data-Native System
   • Fact Data
   • Immutable Data
   • Deterministic Functions
   • Data-Lineage
   • Data Locality - space or temporal
   • All Data vs. Working Set
   9


   View Slide

10. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Data System – Key Properties
    10


    View Slide

11. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Data System Architectures
    11


    View Slide

12. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Data System Architectural Patterns
    How to build Data Systems?
    • Data Lake
    • Lambda
    • Kappa / Samza
    • Tachyon
    12


    View Slide

13. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Data Lake (From ETL to ELT)
    Single Store For All Data
    • Store Raw Data
    • No Data Schema Limitations
    • No Data Volume Limitations
    • Late evaluation
    • Extract-Transform-Load (ETL) vs. Extract-Load-Transform (ELT)
    • Data Lineage
    13


    View Slide

14. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    • Batch Layer
    • Serving Layer
    • Speed Layer
    14
    Lambda Architecture


    View Slide

15. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    • Durable Queues (Kafka)
    • Replaying History
    • Versioned Outputs
    • Dynamic Output Switch
    15
    Kappa Architecture


    View Slide

16. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Tachyon
    No write speed constrains
    • Data-Lineage Based Fault Tolerance
    • Asynchronous Checkpoints
    • Unbounded Writes
    16


    View Slide

17. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Real Life Use Case
    17


    View Slide

18. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Real Life Use Case
    • Integrate an In-Memory Data Grid - Geode (e.g. GemFire) with SQL-On-Hadoop
    OLAP system - HAWQ
    • Provide an unified data view across both systems
    • Use Geode as Slowly Changing Dimensions (SCDs) store for HAWQ
    • Keep the Operational and Historical data in Sync
    18


    View Slide

19. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    • Cache - Performance / Consistency / Resiliency
    • Region
    • Distributed j.u.Map on steroids
    • Highly available, redundant
    • Distributed
    • Locator, Server, Client
    Apache Geode & GemFire (OLTP)
    19


    View Slide

20. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Geode use cases…
    20
    China Railway

    Corporation
    5,700 train stations
    4.5 million tickets per day
    20 million daily users
    1.4 billion page views per day
    40,000 visits per second
    * http://pivotal.io/big-data/pivotal-gemfire
    Indian Railways
    7,000 stations
    72,000 miles of track
    23 million passengers daily
    120,000 concurrent users
    10,000 transactions per minute


    View Slide

21. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    HAWQ (SQL-on-HADOOP)
    • Enterprise SQL on Hadoop analytic engine built around a high-performance
    Greenplum MPP Database
    • HAWQ runs natively on Apache Hadoop, HDFS and YARN.
    • Supports multiple Hadoop file formats: Parquet, HDFS and Avro
    • 100% ANSI SQL compliant (ANSI SQL-92, SQL-99, and SQL-2003…)
    • ODBC and JDBC connectivity
    • Implemented in C and C++
    21


    View Slide

22. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    HAWQ (SQL-on-HADOOP)
    • Runs TPC-DS benchmark in half the wall clock time that Impala
    • Beats Impala by overall 454% in performance
    • Compared to Hive, HAWQ provides an additional of 344% of performance
    improvement on complex queries
    • Impala and Apache Hive™ do not support all standard TPC-DS queries
    • HAWQ runs 100% of them natively.
    22


    View Slide

23. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Test Environment
    • HDFS – Distributed file system. PHD or HDP Hadoop distributions.
    • HAWQ - SQL-on-Hadoop.
    • Geode/GemFire - In-memory data grid.
    • SpringXD – runtime integration and streaming platform.
    • Apache Ambari – Manages all Clusters.
    • Apache Zeppelin – Web interface for interacting with different Data Systems.
    23
    GEODE
    Locator,
    Servers
    HAWQ
    Master,
    Segments
    HDFS
    NameNode, DataNodes
    SPRING
    XD
    Admin,
    Containers
    Zeppelin Notebook
    Ambari


    View Slide

24. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Test Environment - Ambari Management
    24


    View Slide

25. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Passive Data Synchronization
    25


    View Slide

26. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Passive Synchronization (Case 1)
    26


    View Slide

27. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Passive Synchronization (Case 1) - Demo
    27


    View Slide

28. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Passive Synchronization (Case 2) - gpfdist
    28


    View Slide

29. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Passive Synchronization (Case 2): Demo
    29


    View Slide

30. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Federated Queries With HAWQ
    30


    View Slide

31. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Access dynamic data sources on a web server or by executing OS scripts.
    31
    HAWQ Web Table – Architecture


    View Slide

32. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    HAWQ Web Table
    • HAWQ Web Table - access dynamic data sources on a web server or by
    executing OS scripts.
    • Leverage Geode REST API and OQL.
    • RESTful SpringBoot app to convert JSON into TSV.
    32
    CREATE EXTERNAL WEB TABLE EMPLOYEE_WEB_TABLE (...)
    EXECUTE E'curl http:///gemfire-api/v1/
    queries/adhoc?q='
    ON MASTER FORMAT 'text' (delimiter '|' null 'null' escape E'\\');


    View Slide

33. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    HAWQ Web Table – Limitations
    • Not Scalable
    • No “Filter Push Down”
    • Inflexibility
    • No Compression
    • Requires Additional Components
    33


    View Slide

34. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    HAWQ PXF/Geode External Table
    34


    View Slide

35. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Pivotal eXtension Framework (PXF)
    • Java-Based
    • Parallel, High Throughput Data Access
    • Heterogeneous Data Sources.
    • ANSI-compliant SQL On Any Dataset
    • Wide variety of PXF plugins
    35


    View Slide

36. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    PXF Architecture
    36


    View Slide

37. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    PXF Data Model
    • Data Source is modeled as a collection of one or more Fragments.
    • Each Fragment consists of many Rows that in turn are split into typed Fields.
    • Analyzer (optional) provides PXF statistical data for the HAWQ query optimizer
    • Metadata about the data source locations, access attributes, table schemas
    formats, SQL queries filters, etc
    37


    View Slide

38. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    PXF Processors
    38


    View Slide

39. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    PXF Runtime Model
    39


    View Slide

40. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    CREATE EXTERNAL TABLE ext_table_name

    LOCATION('pxf://:/path/to/data?
    FRAGMENTER=package.name.FragmenterForX&
    ACCESSOR=package.name.AccessorForX&
    RESOLVER=package.name.ResolverForX&
    =')
    FORMAT ‘custom'(formatter='pxfwritable_import');
    40
    PXF External Tables Definition


    View Slide

41. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Available PXF Plugins
    • HdfsTextSimple
    • HdfsTextMulti
    • Hive
    • HiveRC
    • HiveText
    • Hbase
    • Avro
    41
    • Accumulo
    • Casandra
    • JSON
    • Redis
    • Geode/Gemfire
    • Pipes


    View Slide

42. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Build Geode PXF Plugin
    42


    View Slide

43. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/

    GEMFIRE
    A profile for reading Gemfire data

    io.pivotal.pxf.plugins.gemfire.GemfireFragmenter
    fragmenter>
    io.pivotal.pxf.plugins.gemfire.GemfireAccessor
    io.pivotal.pxf.plugins.gemfire.GemfireResolver


    43
    PXF Geode Profile


    View Slide

44. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Geode External Table Definition
    CREATE EXTERNAL TABLE (...)
    LOCATION('pxf:///?
    PROFILE=GEMFIRE &
    LOCATORS= &
    REGION=')
    FORMAT 'CUSTOM' (FORMATTER='pxfwritable_import');
    44


    View Slide

45. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    public class GemfireFragmenter extends Fragmenter {
    public GemfireFragmenter(InputData inputData) throws Exception {
    super(inputData);
    }
    public List getFragments() throws Exception {
    return Arrays.asList (new Fragment(
    inputData.getDataSource(),
    new String[] { inputData.getUserProperty("URL-HOST") },
    new byte[0]));
    }
    }
    45
    Geode Fragmenter


    View Slide

46. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    public class GemfireAccessor extends Plugin implements ReadAccessor {
    public GemfireAccessor(InputData input) throws Exception {
    super(input);
    }
    public boolean openForRead() throws Exception { … }
    public OneRow readNextObject() throws Exception {…}
    public void closeForRead() throws Exception {…}
    }
    46
    Geode Accessor


    View Slide

47. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    public class GemfireResolver extends Plugin implements ReadResolver {
    public GemfireResolver(InputData input) {
    super(input);
    }
    public List getFields(OneRow paramOneRow) throws Exception {
    }
    }
    47
    Geode Resolver


    View Slide

48. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Demo 3: Federated queries with PXF/Geode
    48


    View Slide

49. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    Demo 3: Federated queries with PXF/Geode
    49


    View Slide

50. Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a

    Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
    50
    By Christian Tzolov
    @christzolov
    HADOOP WORKFLOWS AND DISTRIBUTED YARN APPS USING SPRING
    TECHNOLOGIES
    Learn More. Stay Connected.
    @springcentral Spring.io/video


    View Slide
