Too trivial to test?
An inverse view on defect prediction to identify methods with low fault risk

5aecc230f8e833c3e2cf2945c704c533?s=47 Stefan Wagner
February 28, 2020

Too trivial to test?
An inverse view on defect prediction to identify methods with low fault risk

Presentation of the corresponding paper published in PeerJ Computer Science at the German-speaking Software Engineering Conference in Innsbruck, Austria.

5aecc230f8e833c3e2cf2945c704c533?s=128

Stefan Wagner

February 28, 2020
Tweet

Transcript

  1. SE 2020 Innsbruck, Austria Stefan Wagner Too trivial to test?

    An inverse view on defect prediction to identify methods with low fault risk
  2. You can copy, share and change, film and photograph, blog,

    live-blog and tweet this presentation given that you attribute it to its author and respect the rights and licences of its parts. based on slides by @SMEasterbrook und @ethanwhite
  3. 3 Get the paper here:

  4. • Test resources are limited ➞ Need for prioritising testing

    activities • Defect prediction overall with little practical usage • Cross-project defect prediction even less 4 Motivation
  5. Identify code regions with low fault risk 5 Idea: Inverse

    Defect Prediction (IDP) FAULTY NON-FAULTY (Traditional) Defect Prediction OTHER LOW FAULT RISK Inverse Defect Prediction
  6. Approach

  7. 7 Compute Metrics Method Fixes

  8. 8

  9. 9 Faulty Methods Compute Metrics Merge Multiple Occurrences Method Fixes

  10. 10 All Methods Compute Metrics Remove Faulty Methods Faulty Methods

    Non-Faulty Methods Compute Metrics Merge Multiple Occurrences Method Fixes
  11. 11 All Methods Compute Metrics Remove Faulty Methods Faulty Methods

    Non-Faulty Methods Compute Metrics Merge Multiple Occurrences Method Fixes
  12. 12 All Methods Compute Metrics Remove Faulty Methods Faulty Methods

    Non-Faulty Methods Compute Metrics Merge Multiple Occurrences Method Fixes Address Data Imbalance
  13. 13 All Methods Compute Metrics Remove Faulty Methods Faulty Methods

    Non-Faulty Methods Compute Metrics Merge Multiple Occurrences Method Fixes Compute Association Rules Address Data Imbalance
  14. • Identify rules in a large dataset of transactions •

    Rules describe implications between items { antecedent } ! { consequent } • Properties of rules • support (significance) • confidence (precision) 14 Association Rule Mining
  15. 15 Method Properties (Items) Status setX(…) { IsSetter, NoNullChecks, NoLoops,

    NoConditions, … } Not faulty toString() { IsToString, NoNullChecks, NoLoops, … } Not faulty computeResult() { NoStringLiterals, NoSynchronizedBlocks, … } Faulty convert(…) { NoLoops, NoAssignments, NoArrayAccesses, … } Faulty getX() { IsGetter, NoLoops, NoConditions, NoAssignments, … } Not faulty getY() { IsGetter, NoLoops, NoConditions, NoAssignments, … } Not faulty checkArgs(…) { NoAssignments, NoSynchronizedBlocks, … } Not faulty Transactions
  16. 16 Rule { NoLoops } ! { Not faulty} {

    NoLoops, NoConditions, NoAssignments } ! { Not faulty } { IsSetter, NoConditions, NoAssignments, NoStringLiterals } ! { Not faulty } { LessThan3Sloc, NoConditions } ! { Not faulty } … Rules
  17. 17 Method Properties (Items) Status setX(…) { IsSetter, NoNullChecks, NoLoops,

    NoConditions, … } Not faulty toString() { IsToString, NoNullChecks, NoLoops, … } Not faulty computeResult() { NoStringLiterals, NoSynchronizedBlocks, … } Faulty convert(…) { NoLoops, NoAssignments, NoArrayAccesses, … } Faulty getX() { IsGetter, NoLoops, NoConditions, NoAssignments, … } Not faulty getY() { IsGetter, NoLoops, NoConditions, NoAssignments, … } Not faulty checkArgs(…) { NoAssignments, NoSynchronizedBlocks, … } Not faulty … Rule: { NoLoops } ! { Not faulty } Support: 4/7 = 57.1 % Confidence: 4/5 = 80.0 %
  18. 18 All Methods Compute Metrics Remove Faulty Methods Faulty Methods

    Non-Faulty Methods Compute Metrics Merge Multiple Occurrences Method Fixes IDP Classifier Select top n rules Compute Association Rules Address Data Imbalance
  19. Empirical Study

  20. 20 Fault Data from Defects4J

  21. RQ 1 RQ 2 RQ 3 21 Research Questions How

    many faults do methods classified as «low fault risk» contain? How large is the fraction of the code base consisting of methods classified as «low fault risk»? Is a trained classifier for methods with low fault risk generalizable to other projects?
  22. RQ 1 RQ 2 RQ 3 22 Research Questions How

    many faults do methods classified as «low fault risk» contain? How large is the fraction of the code base consisting of methods classified as «low fault risk»? Is a trained classifier for methods with low fault risk generalizable to other projects?
  23. 23 Evaluation using 10-fold Cross Validation Within-Project Predictions:

  24. 24 Top-3 Association Rules Commons Lang, Within-Project:

  25. 25 Proportion of Low-Fault-Risk Methods Within-Project Predictions: Chart Closure Lang

    Math Mockito Time 80% 34% 17% 29% 29% 44% Method- based Chart Closure Lang Math Mockito Time 78% 25% 5% 14% 11% 16% SLOC
  26. RQ 1 RQ 2 RQ 3 26 Research Questions How

    many faults do methods classified as «low fault risk» contain? How large is the fraction of the code base consisting of methods classified as «low fault risk»? Is a trained classifier for methods with low fault risk generalizable to other projects?
  27. 27 Faulty Methods in Low-Fault-Risk Methods Within-Project Predictions: Chart Closure

    Lang Math Mockito Time 0.1% 0.6% 1.1% 0.5% 0.2% 0.1%
  28. 28 Fault-Density Reduction Factor Within-Project Predictions: proportion of low-fault-risk methods

    out of all methods proportion of faulty low-fault-risk methods out of all faulty methods Example: 40% of all methods are classified as «low fault risk» and 10% of all methods are faulty low-fault-risk methods ! factor = 4
  29. 29 Fault-Density Reduction Factor Within-Project Predictions: 0 5 10 15

    20 Chart Closure Lang Math Mockito Time 1.5 2.6 3.4 3.1 3.2 4.4 4.3 7.1 7 10.9 4.4 4.5 Methods SLOC Threshold
  30. RQ 1 RQ 2 RQ 3 30 Research Questions How

    many faults do methods classified as «low fault risk» contain? How large is the fraction of the code base consisting of methods classified as «low fault risk»? Is a trained classifier for methods with low fault risk generalizable to other projects?
  31. 31 Evaluation Cross-Project Predictions:

  32. 32 Proportion of Low-Fault-Risk Methods Cross-Project Predictions: Chart Closure Lang

    Math Mockito Time 18% 22% 27% 23% 25% 32% Chart Closure Lang Math Mockito Time 7% 7% 9% 8% 8% 11% Methods SLOC
  33. 33 Fault-Density Reduction Factor Cross-Project Predictions: 0 5 10 15

    20 Chart Closure Lang Math Mockito Time 1.4 5.8 6.1 1.6 4.4 3.3 4.2 18.3 16.3 4 13.6 8.3 Methods SLOC Threshold
  34. 34 Fault-Density Reduction Factor Cross-Project Predictions: 0 5 10 15

    20 Chart Closure Lang Math Mockito Time 1.4 5.8 6.1 1.6 4.4 3.3 4.2 18.3 16.3 4 13.6 8.3 Methods (cross) SLOC (cross) Methods (within) SLOC (within) Threshold
  35. • Inverse Defect Prediction can successfully predict low-fault-risk methods •

    ~20–40% of the methods (5–20% of SLOC) classified as «low fault risk» • Applicable for cross-project predictions 35 Conclusion
  36. # Rule Support Confidence # 1 { NoMethodInvocations, SlocLessThan4, NoArithmeticOperations,

    NoNullLiterals } ) { NotFaulty } 10.43% 96.76% 2 { NoMethodInvocations, SlocLessThan4, NoArithmeticOperations } ) { NotFaulty } 11.03% 96.09% 3 { NoMethodInvocations, SlocLessThan4, NoCastExpressions, NoNullLiterals } ) { NotFaulty } 10.43% 95.43% 4 { NoMethodInvocations, SlocLessThan4, NoCastExpressions, NoInstantiations } ) { NotFaulty } 10.13% 95.31% 5 { NoMethodInvocations, SlocLessThan4, NoCastExpressions } ) { NotFaulty } 11.03% 94.85%
  37. Prof. Dr. Stefan Wagner e-mail stefan.wagner@informatik.uni-stuttgart.de phone +49 (0) 711

    685-88455 WWW www.iste.uni-stuttgart.de/se Twitter prof_wagnerst ORCID 0000-0002-5256-8429 Institute of Software Technology Slides are available at www.stefan-wagner.biz. Joint work with Rainer Niedermayr and Tobias Röhm
  38. Pictures used in this slide deck Trivial Pursuit by Bram

    Cymet published under CC BY-NC 2.0 (https://flic.kr/p/ 67AFso)
