Kong Ingress Controllerで実現multiple rate limiting

【第2回開催！】Kong Community, Japanミートアップ

Transcript

1. 【第2回開催！】
   Kong Community, Japan
   ミートアップ


   View Slide

2. THE CLOUD CONNECTIVITY COMPANY
   2
   © Kong Inc.
   THE CLOUD
   CONNECTIVITY COMPANY
   Kong Ingress Controllerで実現
   multiple rate limiting
   Wenhan Shi
   Solutions Engineer
   wenhan.shi@konghq.com


   View Slide

3. THE CLOUD CONNECTIVITY COMPANY
   3
   © Kong Inc. 3
   Who am I
   施 文翰(シ ブンカン) Wenhan Shi
   • 日立製作所 - Linux kernel module development/Support
   • Red Hat K.K. - GlusterFS/OpenShift Support
   • Canonical Japan K.K. - Ubuntu/OpenStack/Kubernetes Support
   • Rancher Lab/SUSE - Rancher Support
   • Kong Inc. - Solutions Engineer
   @shi_wenhan
   wenhan.shi@konghq.com


   View Slide

4. THE CLOUD CONNECTIVITY COMPANY
   4
   © Kong Inc. 4
   Agenda ● Kong Ingress Controller(KIC)
   ● KIC + Rate Limiting
   ● KIC + multiple Rate Limiting


   View Slide

5. THE CLOUD CONNECTIVITY COMPANY
   5
   © Kong Inc. 5
   Kong Ingress Controller(KIC)


   View Slide

6. THE CLOUD CONNECTIVITY COMPANY
   6
   © Kong Inc. 6
   Kubernetes Ingress Controllerとは


   View Slide

7. THE CLOUD CONNECTIVITY COMPANY
   7
   © Kong Inc. 7
   Kubernetes Ingress Controllerとは
   ■ Kubernetesクラスタで利用できるもう一つの
   Ingress Controllers
   ■ KubernetesのAPI serverをNativelyサポート
   ○ YAMLでKongのリソースを設定


   View Slide

8. THE CLOUD CONNECTIVITY COMPANY
   8
   © Kong Inc. 8
   Kubernetes Ingress Controllerとは
   ■ Kubernetesクラスタで利用できるもう一つの
   Ingress Controllers
   ■ KubernetesのAPI serverをNativelyサポート
   ○ YAMLでKongのリソースを設定


   View Slide

9. THE CLOUD CONNECTIVITY COMPANY
   9
   © Kong Inc. 9
   KICをインストール
   • Yamlファイル
   • Helm
   kubectl create -f \
   https://raw.githubusercontent.com/Kong/kubernetes-ingress-controller/v2.8.0/deploy/single/all-in-one-dbless.yaml
   helm upgrade -i my-kong kong/kong -n kong \
   --set ingressController.installCRDs=false --wait


   View Slide

10. THE CLOUD CONNECTIVITY COMPANY
    10
    © Kong Inc. 10
    KICをインストール
    • PodとSvcが作成
    ❯ kubectl get pod -n kong
    NAME READY STATUS RESTARTS AGE
    my-kong-kong-6db76664df-6vjlg 2/2 Running 0 4m58s
    ❯ kubectl get svc -n kong
    NAME TYPE CLUSTER-IP EXTERNAL-IP
    PORT(S) AGE
    my-kong-kong-proxy LoadBalancer 10.100.140.184 xx-xx.ap-southeast-1.elb.amazonaws.com
    80:30966/TCP,443:31707/TCP 5m3s
    my-kong-kong-validation-webhook ClusterIP 10.100.149.74
    443/TCP 5m3s
    ❯ http proxy.kic.aws.kongtest.net
    HTTP/1.1 404 Not Found
    …
    {
    "message": "no Route matched with those values"
    }


    View Slide

11. THE CLOUD CONNECTIVITY COMPANY
    11
    © Kong Inc. 11
    Route(Ingress)の作成
    • Ingressを作成してsvcを公開
    ❯ kubectl get svc
    NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
    echo ClusterIP 10.100.83.81 8080/TCP,80/TCP 23d
    ❯ kubectl apply -f - << EOF
    apiVersion: networking.k8s.io/v1
    kind: Ingress
    metadata:
    name: kong-demo-ingress
    spec:
    ingressClassName: kong
    rules:
    - http:
    paths:
    - path: /demo
    pathType: Exact
    backend:
    service:
    name: echo
    port:
    number: 80
    EOF


    View Slide

12. THE CLOUD CONNECTIVITY COMPANY
    12
    © Kong Inc. 12
    Route(Ingress)の作成
    • Ingressを作成してsvcを公開
    ❯ http proxy.kic.aws.kongtest.net/demo
    HTTP/1.1 200 OK
    …
    Hostname: echo-744d654d7b-mdb99
    Pod Information:
    node name: ip-192-168-8-117.ap-southeast-1.compute.internal
    pod name: echo-744d654d7b-mdb99
    pod namespace: default
    pod IP: 192.168.7.142
    …


    View Slide

13. THE CLOUD CONNECTIVITY COMPANY
    13
    © Kong Inc. 13
    Route(Ingress)の設定
    • もう少しRouteの設定をしたいなら、KongIngressを作成し、Ingress RuleとBindする
    kubectl apply -f - <apiVersion: configuration.konghq.com/v1
    kind: KongIngress
    metadata:
    name: update-kong-demo-ingress
    route:
    headers:
    foo:
    - bar
    ---
    apiVersion: networking.k8s.io/v1
    kind: Ingress
    metadata:
    name: kong-demo-ingress
    annotations:
    kubernetes.io/ingress.class: kong
    konghq.com/override : update-kong-demo-ingress
    spec:


    View Slide

14. THE CLOUD CONNECTIVITY COMPANY
    14
    © Kong Inc. 14
    Route(Ingress)の作成
    • Ingressを作成してsvcを公開
    ❯ http proxy.kic.aws.kongtest.net/demo
    HTTP/1.1 404 Not Found
    …
    {
    "message": "no Route matched with those values"
    }
    ❯ http proxy.kic.aws.kongtest.net/demo foo:bar
    HTTP/1.1 200 OK
    …
    Hostname: echo-744d654d7b-mdb99
    Pod Information:
    node name: ip-192-168-8-117.ap-southeast-1.compute.internal
    pod name: echo-744d654d7b-mdb99
    pod namespace: default
    pod IP: 192.168.7.142
    …


    View Slide

15. THE CLOUD CONNECTIVITY COMPANY
    15
    © Kong Inc. 15
    KIC + Rate Limiting


    View Slide

16. THE CLOUD CONNECTIVITY COMPANY
    16
    © Kong Inc. 16
    KICでPluginの実装
    1. CRDを使ってPluginリソースを作成
    2. Ingress リソースのannotationに設定
    kong-demo-ingress
    echo


    View Slide

17. THE CLOUD CONNECTIVITY COMPANY
    17
    © Kong Inc. 17
    Pluginの作成
    • Kongのプラグインは以下のCRDで実装
    • KongPlugin: Namespaceレベル
    • KongClusterPlugin: Clusterレベル
    kubectl apply -f - <apiVersion: configuration.konghq.com/v1
    kind: KongPlugin
    metadata:
    name: rate-limiting
    config:
    minute: 5
    policy: local
    plugin: rate-limiting
    disabled: false
    EOF
    kubectl apply -f - <apiVersion: configuration.konghq.com/v1
    kind: KongClusterPlugin
    metadata:
    name: jwt-auth
    annotations:
    kubernetes.io/ingress.class: kong
    labels:
    global: "true"
    plugin: jwt
    EOF


    View Slide

18. THE CLOUD CONNECTIVITY COMPANY
    18
    © Kong Inc. 18
    PluginをIngressに適用
    • Ingressのannotationsに利用するプラグインを宣言
    • rate limitingの適用状況を確認
    ❯ kubectl annotate ingress kong-demo-ingress konghq.com/plugins=rate-limiting
    ingress.networking.k8s.io/kong-demo-ingress annotated
    annotations:
    konghq.com/plugins: rate-limiting
    ❯ http --header proxy.kic.aws.kongtest.net/demo
    ❯ http --header proxy.kic.aws.kongtest.net/demo
    ❯ http --header proxy.kic.aws.kongtest.net/demo
    ❯ http --header proxy.kic.aws.kongtest.net/demo
    ❯ http --header proxy.kic.aws.kongtest.net/demo
    ❯ http --header proxy.kic.aws.kongtest.net/demo
    HTTP/1.1 429 Too Many Requests
    …
    RateLimit-Limit: 5
    RateLimit-Remaining: 0
    RateLimit-Reset: 28


    View Slide

19. THE CLOUD CONNECTIVITY COMPANY
    19
    © Kong Inc. 19
    KIC + multiple Rate Limiting


    View Slide

20. THE CLOUD CONNECTIVITY COMPANY
    20
    © Kong Inc. 20
    Multiple rate limiting?
    1. 各クライアントからは同じパスから、同一の
    APIをアクセス
    2. リクエストにあるヘッダーを見て別々の
    Rate Limitingを適用


    View Slide

21. THE CLOUD CONNECTIVITY COMPANY
    21
    © Kong Inc. 21
    Multiple rate limiting?
    1. 各クライアントからは同じパスから、同一の
    APIをアクセス
    2. リクエストにあるヘッダーを見て別々の
    Rate Limitingを適用


    View Slide

22. THE CLOUD CONNECTIVITY COMPANY
    22
    © Kong Inc. 22
    Multiple rate limiting?
    Demo


    View Slide

23. THE CLOUD CONNECTIVITY COMPANY
    23
    © Kong Inc. 23
    Thank you
