  1. Android Testing Support Library The Nitty Gritty © Zan Markan

    2016 - @zmarkan
  2. Android Testing Support Library The Nitty Gritty © Zan Markan

    2016 - @zmarkan
  3. Testing 101 • on JVM vs on device • unit

    / integration / functional / end to end • Robolectric, Calabash, Instrumentation, Robotium, Appium © Zan Markan 2016 - @zmarkan
  4. "Support" • Android framework vs Support libraries • Trend to

    unbundle • support-v4, appcompat-v7, recyclerview, ... © Zan Markan 2016 - @zmarkan
  5. Android Testing Support Library © Zan Markan 2016 - @zmarkan

  6. Good Old Times... • jUnit3 syntax • Remember ActivityInstrumentationTestCase2? public

    class OldSchoolTest extends ActivityInstrumentationTestCase2<ResourceListActivity> { public OldSchoolTest() { super(ResourceListActivity.class); } //... } © Zan Markan 2016 - @zmarkan
  7. More jUnit3 goodness • overriding setUp() and tearDown() • testPrefixedMethods()

    & test_prefixedMethods() • Ignorance Inheritance is bliss © Zan Markan 2016 - @zmarkan
  8. public class OldSchoolTest extends ActivityInstrumentationTestCase2<ResourceListActivity> { public OldSchoolTest() { super(ResourceListActivity.class);

    } @Override protected void setUp() throws Exception { super.setUp(); //Omg. } @Override protected void tearDown() throws Exception { super.tearDown(); //Srsly?? } @SmallTest public void testMustHaveTheTestPrefix(){ fail("No."); } @SmallTest public void test_canHaveUnderscoreInPrefixAsWell(){ fail("Just no."); } } © Zan Markan 2016 - @zmarkan
  9. Welcome to the present • jUnit4 syntax • No more

    extending • @Test, @Before, @After, @AfterClass,... • ActivityTestRule, InstrumentationRegistry © Zan Markan 2016 - @zmarkan
  10. @RunWith(AndroidJUnitRunner.java) public class ModernTest{ @Rule ActivityTestRule<ResourceListActivity> activityRule = new ActivityTestRule<>(ResourceListActivity.class);

    @Before public void setupMocks{ } @After public void clearMocks(){ } @Test public void anyNameYouWish(){ //Yay } } © Zan Markan 2016 - @zmarkan
  11. What else? • Espresso • More Espresso (there's a lot

    to it) • UIAutomator • ... © Zan Markan 2016 - @zmarkan
  12. But First... The setup (note: AS does that on it's

    own if you create a new project - these instructions will mostly apply for legacy projects) © Zan Markan 2016 - @zmarkan
  13. Gradle • Set your test runner to be AndroidJUnitRunner ©

    Zan Markan 2016 - @zmarkan
  14. Gradle • Set your test runner to be AndroidJUnitRunner testInstrumentationRunner

    "android.support.test.runner.AndroidJUnitRunner" © Zan Markan 2016 - @zmarkan
  15. defaultConfig { applicationId "com.zmarkan.testingresources" minSdkVersion 23 targetSdkVersion 23 versionCode 1

    versionName "1.0" testInstrumentationRunner "android.support.test.runner.AndroidJUnitRunner" } buildTypes { release { minifyEnabled false proguardFiles getDefaultProguardFile('proguard-android.txt'), 'proguard-rules.pro' } } © Zan Markan 2016 - @zmarkan
  16. Gradle • Set your test runner to be AndroidJUnitRunner •

    Add dependencies © Zan Markan 2016 - @zmarkan
  17. Gradle • Set your test runner to be AndroidJUnitRunner •

    Add dependencies // JUnit4 Rules androidTestCompile 'com.android.support.test:rules:0.5' // Android JUnit Runner androidTestCompile 'com.android.support.test:runner:0.5' // Espresso core androidTestCompile 'com.android.support.test.espresso:espresso-core:2.2.1' // Espresso-contrib for DatePicker, RecyclerView, Drawer actions, Accessibility checks, CountingIdlingResource androidTestCompile 'com.android.support.test.espresso:espresso-contrib:2.2.1' © Zan Markan 2016 - @zmarkan
  18. dependencies { compile 'com.android.support:appcompat-v7:23.2.1' compile 'com.android.support:design:23.2.1' //Unit testing testCompile 'junit:junit:4.12'

    // JUnit4 Rules androidTestCompile 'com.android.support.test:rules:0.5' // Android JUnit Runner androidTestCompile 'com.android.support.test:runner:0.5' // Espresso core androidTestCompile 'com.android.support.test.espresso:espresso-core:2.2.1' // Espresso-contrib for DatePicker, RecyclerView, Drawer actions, Accessibility checks, CountingIdlingResource androidTestCompile 'com.android.support.test.espresso:espresso-contrib:2.2.1' © Zan Markan 2016 - @zmarkan
  19. Gradle • Set your test runner to be AndroidJUnitRunner •

    Add dependencies • Voila! © Zan Markan 2016 - @zmarkan
  20. Error:Conflict with dependency 'com.android.support:support-annotations'. Resolved versions for app (23.2.1) and

    test app (23.1.1) differ. See http://g.co/androidstudio/app-test-app-conflict for details. © Zan Markan 2016 - @zmarkan
  21. Gradle • Set your test runner to be AndroidJUnitRunner •

    Add dependencies • Voila! • Resolve dependencies © Zan Markan 2016 - @zmarkan
  22. Dependency resolutions • App and Test app depend on different

    lib versions • Run ./gradlew :app:dependencies © Zan Markan 2016 - @zmarkan
  23. compile - Classpath for compiling the main sources. +--- com.android.support:appcompat-v7:24.2.1

    | +--- com.android.support:support-v4:24.2.1 | | +--- com.android.support:support-compat:24.2.1 | | | \--- com.android.support:support-annotations:24.2.1 | | +--- com.android.support:support-media-compat:24.2.1 | | | \--- com.android.support:support-compat:24.2.1 (*) | | +--- com.android.support:support-core-utils:24.2.1 | | | \--- com.android.support:support-compat:24.2.1 (*) | | +--- com.android.support:support-core-ui:24.2.1 | | | \--- com.android.support:support-compat:24.2.1 (*) | | \--- com.android.support:support-fragment:24.2.1 | | +--- com.android.support:support-compat:24.2.1 (*) | | +--- com.android.support:support-media-compat:24.2.1 (*) | | +--- com.android.support:support-core-ui:24.2.1 (*) | | \--- com.android.support:support-core-utils:24.2.1 (*) | +--- com.android.support:support-vector-drawable:24.2.1 | | \--- com.android.support:support-compat:24.2.1 (*) | \--- com.android.support:animated-vector-drawable:24.2.1 | \--- com.android.support:support-vector-drawable:24.2.1 (*) \--- com.android.support:design:24.2.1 +--- com.android.support:support-v4:24.2.1 (*) +--- com.android.support:appcompat-v7:24.2.1 (*) \--- com.android.support:recyclerview-v7:24.2.1 +--- com.android.support:support-annotations:24.2.1 +--- com.android.support:support-compat:24.2.1 (*) \--- com.android.support:support-core-ui:24.2.1 (*) © Zan Markan 2016 - @zmarkan
  24. androidTestCompile - Classpath for compiling the androidTest sources. +--- com.android.support.test.espresso:espresso-core:2.2.2

    | +--- com.squareup:javawriter:2.1.1 | +--- com.android.support.test:rules:0.5 | | \--- com.android.support.test:runner:0.5 | | +--- com.android.support:support-annotations:23.1.1 | | +--- junit:junit:4.12 | | | \--- org.hamcrest:hamcrest-core:1.3 | | \--- com.android.support.test:exposed-instrumentation-api-publish:0.5 | +--- com.android.support.test:runner:0.5 (*) | +--- javax.inject:javax.inject:1 | +--- org.hamcrest:hamcrest-library:1.3 | | \--- org.hamcrest:hamcrest-core:1.3 | +--- com.android.support.test.espresso:espresso-idling-resource:2.2.2 | +--- org.hamcrest:hamcrest-integration:1.3 | | \--- org.hamcrest:hamcrest-library:1.3 (*) | +--- com.google.code.findbugs:jsr305:2.0.1 | \--- javax.annotation:javax.annotation-api:1.2 \--- com.android.support.test.espresso:espresso-contrib:2.2.2 +--- com.android.support:design:23.1.1 | +--- com.android.support:appcompat-v7:23.1.1 | | \--- com.android.support:support-v4:23.1.1 | | \--- com.android.support:support-annotations:23.1.1 | +--- com.android.support:recyclerview-v7:23.1.1 | | +--- com.android.support:support-annotations:23.1.1 | | \--- com.android.support:support-v4:23.1.1 (*) | \--- com.android.support:support-v4:23.1.1 (*) +--- com.google.android.apps.common.testing.accessibility.framework:accessibility-test-framework:2.0 | \--- org.hamcrest:hamcrest-core:1.3 +--- com.android.support:recyclerview-v7:23.1.1 (*) +--- com.android.support.test.espresso:espresso-core:2.2.2 (*) \--- com.android.support:support-v4:23.1.1 (*) © Zan Markan 2016 - @zmarkan
  25. Compile task \--- com.android.support:design:24.2.1 +--- com.android.support:support-v4:24.2.1 (*) +--- com.android.support:appcompat-v7:24.2.1 (*)

    \--- com.android.support:recyclerview-v7:24.2.1 +--- com.android.support:support-annotations:24.2.1 +--- com.android.support:support-compat:24.2.1 (*) \--- com.android.support:support-core-ui:24.2.1 (*) © Zan Markan 2016 - @zmarkan
  26. androidTestCompile \--- com.android.support.test.espresso:espresso-contrib:2.2.2 +--- com.android.support:design:23.1.1 | +--- com.android.support:appcompat-v7:23.1.1 | |

    \--- com.android.support:support-v4:23.1.1 | | \--- com.android.support:support-annotations:23.1.1 | +--- com.android.support:recyclerview-v7:23.1.1 | | +--- com.android.support:support-annotations:23.1.1 ... © Zan Markan 2016 - @zmarkan
  27. Dependency resolutions • App and Test app depend on different

    lib versions • Run ./gradlew :app:dependencies • Resolve with: • Force dependency versions in the test APK • exclude dependecy (everywhere applicable) • use ResolutionStrategy © Zan Markan 2016 - @zmarkan
  28. Force versions in test APK // Resolve conflicts between main

    and test APK: androidTestCompile "com.android.support:support-annotations:$rootProject.supportLibraryVersion" androidTestCompile "com.android.support:support-v4:$rootProject.supportLibraryVersion" androidTestCompile "com.android.support:recyclerview-v7:$rootProject.supportLibraryVersion" androidTestCompile "com.android.support:appcompat-v7:$rootProject.supportLibraryVersion" androidTestCompile "com.android.support:design:$rootProject.supportLibraryVersion" Source: github.com/googlesamples/android-architecture/blob/todo- mvp/todoapp/app/build.gradle © Zan Markan 2016 - @zmarkan
  29. Exclude Dependency androidTestCompile('com.android.support.test.espresso:espresso-core:2.2.1'){ exclude module: 'support-annotations' } © Zan Markan

    2016 - @zmarkan
  30. Set ResolutionStrategy configurations.all() { resolutionStrategy.force 'com.android.support:support-annotations:22.1.0' } © Zan Markan

    2016 - @zmarkan
  31. Gradle • Set your test runner to be AndroidJUnitRunner •

    Add dependencies • Resolve dependencies • Voila! © Zan Markan 2016 - @zmarkan
  32. Espresso © Zan Markan 2016 - @zmarkan

  33. Espresso - components • View interactions & assertions • Hamcrest

    syntax • No (unnecessary) waits © Zan Markan 2016 - @zmarkan
  34. Espresso - API Cheat sheet: google.github.io/android-testing-support-library/docs/espresso/ cheatsheet © Zan Markan

    2016 - @zmarkan
  35. Poking the screen onView(withId(R.id.button)).perform(click()); © Zan Markan 2016 - @zmarkan

  36. Poking the screen onView(withId(R.id.button)).perform(click()); onView( allOf( withParent(withId(R.id.container)), withText("Hello World!") )

    ).check(matches(isDisplayed())); © Zan Markan 2016 - @zmarkan
  37. Espresso - contrib • RecyclerView • Drawers • Pickers •

    Accessibility © Zan Markan 2016 - @zmarkan
  38. Espresso++ • Custom matchers • Custom ViewActions • Idling resources

    • Page objects • Intent mocking © Zan Markan 2016 - @zmarkan
  39. Custom matchers • Find a view in the hierarchy •

    Good for custom views & components • Override: • describeTo • matchesSafely © Zan Markan 2016 - @zmarkan
  40. Custom matchers interface MyView{ boolean hasCustomProperty(); } static BoundedMatcher withCustomPropery()

    { return new BoundedMatcher<Object, MyView>(MyView.class){ @Override public void describeTo(Description description) { description.appendText("Custom property is enabled"); } @Override protected boolean matchesSafely(MyView item) { return item.hasCustomProperty(); } }; } © Zan Markan 2016 - @zmarkan
  41. Custom ViewActions • Same story as matchers, just a bit

    more extensive • example allows us to scroll in NestedScrollView • github.com/zmarkan/Android-Espresso-ScrollableScroll © Zan Markan 2016 - @zmarkan
  42. Custom ViewActions - API public class ScrollableUtils { public static

    ViewAction scrollableScrollTo() { return actionWithAssertions(new ScrollableScrollToAction()); } } © Zan Markan 2016 - @zmarkan
  43. Implementation... public class ScrollableScrollToAction implements ViewAction{ private static final String

    TAG = com.zmarkan.nestedscroll.action.ScrollableScrollToAction.class.getSimpleName(); @SuppressWarnings("unchecked") @Override public Matcher<View> getConstraints() { return allOf(withEffectiveVisibility(ViewMatchers.Visibility.VISIBLE), isDescendantOfA(anyOf( isAssignableFromClassOrInterface(ScrollingView.class)))); } @Override public void perform(UiController uiController, View view) { if (isDisplayingAtLeast(90).matches(view)) { Log.i(TAG, "View is already displayed. Returning."); return; } Rect rect = new Rect(); view.getDrawingRect(rect); if (!view.requestRectangleOnScreen(rect, true /* immediate */)) { Log.w(TAG, "Scrolling to view was requested, but none of the parents scrolled."); } uiController.loopMainThreadUntilIdle(); if (!isDisplayingAtLeast(90).matches(view)) { throw new PerformException.Builder() .withActionDescription(this.getDescription()) .withViewDescription(HumanReadables.describe(view)) .withCause(new RuntimeException( "Scrolling to view was attempted, but the view is not displayed")) .build(); } } @Override public String getDescription() { return "scroll to"; } } © Zan Markan 2016 - @zmarkan
  44. Implementation... @Override public Matcher<View> getConstraints() { return allOf(withEffectiveVisibility(ViewMatchers.Visibility.VISIBLE), isDescendantOfA(anyOf( isAssignableFromClassOrInterface(ScrollingView.class))));

    } © Zan Markan 2016 - @zmarkan
  45. Implementation... @Override public void perform(UiController uiController, View view) { if

    (isDisplayingAtLeast(90).matches(view)) { Log.i(TAG, "View is already displayed. Returning."); return; } Rect rect = new Rect(); view.getDrawingRect(rect); if (!view.requestRectangleOnScreen(rect, true /* immediate */)) { Log.w(TAG, "Scrolling to view was requested, but none of the parents scrolled."); } uiController.loopMainThreadUntilIdle(); if (!isDisplayingAtLeast(90).matches(view)) { throw new PerformException.Builder() .withActionDescription(this.getDescription()) .withViewDescription(HumanReadables.describe(view)) .withCause(new RuntimeException( "Scrolling to view was attempted, but the view is not displayed")) .build(); } } © Zan Markan 2016 - @zmarkan
  46. Don't panic. • Take something that works • ...like scrollTo()

    in regular Espresso for ScrollView • modify it • profit © Zan Markan 2016 - @zmarkan
  47. Custom IdlingResource • A better way to wait • Use

    when you have background stuff going on • Override: • getName • isIdleNow • registerIdleTransitionCallback © Zan Markan 2016 - @zmarkan
  48. Custom IdlingResource public class CustomIdlingResource implements IdlingResource{ private ResourceCallback resourceCallback;

    private EventBus bus; private boolean loadingCompleted = false; public CustomIdlingResource(EventBus bus){ bus.register(this); } public void onEvent(LoadingCompletedEvent event){ loadingCompleted = true; isIdleNow(); } } © Zan Markan 2016 - @zmarkan
  49. Custom IdlingResource @Override public String getName() { return CustomIdlingResource.class.getName(); }

    @Override public void registerIdleTransitionCallback( ResourceCallback resourceCallback) { this.resourceCallback = resourceCallback; } @Override public boolean isIdleNow() { boolean idle = loadingCompleted; if (idle && resourceCallback != null) { resourceCallback.onTransitionToIdle(); bus.unregister(this); } return idle; } } © Zan Markan 2016 - @zmarkan
  50. Page Object Pattern • Build your own DSL • Every

    screen is a Page • Page-specific actions and verifications • (as seen in Calabash, etc...) © Zan Markan 2016 - @zmarkan
  51. Page Class public class MainViewTestUtils { public void enterUserName(String text){

    /* espresso goes here */ } public void enterPassword(String text){ /* ... */ } public void pressContinue(){ /* ... */ } public void assertErrorShown(boolean shown){ /* ... */ } } © Zan Markan 2016 - @zmarkan
  52. Page Class in test @Test public void errorShownWhenPasswordIncorrect(){ MainViewTestUtils view

    = new MainViewTestUtils(); view.enterUsername(username); view.enterPassword(incorrectPassword); view.pressContinue(); view.assertErrorShown(true); } © Zan Markan 2016 - @zmarkan
  53. To boldly go... © Zan Markan 2016 - @zmarkan

  54. UI Automator • Interact with any installed app • Use

    to create full end-to-end tests • Can coexist with Espresso in the same app • Use uiautomatorviewer command to find items in the hierarchy © Zan Markan 2016 - @zmarkan
  55. UI Automator viewer © Zan Markan 2016 - @zmarkan

  56. UI Automator syntax UiDevice device = UiDevice.getInstance(InstrumentationRegistry.getInstrumentation(); device.pressHome(); device.findObject(new UiSelector().descriptionContains("Google

    search")).clickAndWaitForNewWindow(); © Zan Markan 2016 - @zmarkan
  57. Test Runner © Zan Markan 2016 - @zmarkan

  58. Test Runner • Spins up tests... • and runs them

    • Customise to prepare mocks • Easier run/debug via command line © Zan Markan 2016 - @zmarkan
  59. Extending the Runner • Use custom Application class • Provide

    mocked dependencies • Specify this new runner in build.gradle © Zan Markan 2016 - @zmarkan
  60. Extending the Runner public class CustomRunner extends AndroidJUnitRunner{ @Override public

    Application newApplication(ClassLoader cl, String className, Context context) throws InstantiationException, IllegalAccessException, ClassNotFoundException { return Instrumentation.newApplication(TestApplication.class, context); } } © Zan Markan 2016 - @zmarkan
  61. Running on the Command line • Run module/package/class/method • Run

    Large/Medium/Small test only • Shard to run in parallel • Debug without reinstalling © Zan Markan 2016 - @zmarkan
  62. Simple API • send commands to runner via ADB (adb

    shell [commands]) • am instrument -w -e class your.full.classname#methodName your.test.package.name/your.test.Runner.class • d.android.com/tools/testing/testing_otheride.html © Zan Markan 2016 - @zmarkan
  63. Test Rules © Zan Markan 2016 - @zmarkan

  64. Test Rules • Set starting activity / Service • Replace

    ActivityInstrumentationTestCase2 • (in most cases) • Add / Extend to create more components © Zan Markan 2016 - @zmarkan
  65. Test Rules - examples • MockWebServerRule - sets up MockWebServer

    when required • Source: github.com/artem-zinnatullin/qualitymatters © Zan Markan 2016 - @zmarkan
  66. Firebase test lab • Simple setup • CI support (via

    gcloud) • Support for VMs • firebase.google.com/docs/test-lab • Robo test for automated testing © Zan Markan 2016 - @zmarkan
  67. Espresso Test Recorder • Since AS 2.2 preview 3 •

    Generates test code after clicking on screen • (Not necessarily nice code) • tools.android.com/tech-docs/test-recorder © Zan Markan 2016 - @zmarkan
  68. Above & Beyond? • Espresso Web for WebViews • JankTestHelper

    • Stuff is being added. © Zan Markan 2016 - @zmarkan
  69. Best of all? © Zan Markan 2016 - @zmarkan

  70. It's all open source! © Zan Markan 2016 - @zmarkan

  71. fin • ! www.spacecowboyrocketcompany.com • " @zmarkan • # zan

    at markan dot me • $ androidchat.co (zmarkan) • %& @zmarkan © Zan Markan 2016 - @zmarkan
  72. • google.github.io/android-testing-support-library/contribute • Quality Matters - Artem Zinnatulin • d.android.com/tools/testing-support-library

    • github.com/googlesamples/android-testing • chiuki.github.io/advanced-android-espresso © Zan Markan 2016 - @zmarkan
