Proteus硬件仿真
130323-gz-珠三角技术沙龙-#来点儿硬的#
10分钟介绍”零成本”玩玩arduino
Zoom.Quiet
March 24, 2013
Transcript
15 slides
10分钟介绍”零成本”玩玩arduino Proteus硬件仿真
主要内容 proteus仿真软件介绍(ISIS.exe部分, ARES不介绍) 针对arduino进行仿真实验
20年历史的仿真软件 可视化电路设计、单片机仿真(ARM,PIC,AVR,8051) 软件调试(查看寄存器、断点、单独调试、和Keil等工具联合调 试) 结果显示(LED,LCD,RS232 ,虚拟探针,示波器) 与真实硬件交互的能力 (收费软件) Proteus的特点
Proteus界面
对象选择器里面选择所需原件 常用 RES(电阻)、CAP(电容)、 LED-GREEN(绿色发光二极管)、 CRYSTAL(晶振)、AT89C51(微控制 器) 绘图栏选择绘制电路 双击MCU设置程序文件、频率等 进程控制栏点击运行 Proteus基本用法
Arduino uno官方原理图: http://arduino.cc/en/Main/ ArduinoBoardUno 核心 微控制器 ATMega328 Proteus仿真arduino-原理
Arduino的微控制单元-Atmega168/328: Proteus仿真arduino-针脚映射
ATMega328p 晶振、电源等 Pin13外接LED Proteus仿真arduino-连接电路
在arduino内编译 BlinkWithoutDe lay程序 找到 BlinkWithoutDe lay.cpp.hex文 件 Proteus仿真arduino-编译程序
选择Program file为刚才编 译的hex 设置外部晶振 等参数 Proteus仿真arduino-设置MCU
点击运行,观察针脚电平、LED状态 Proteus仿真arduino-运行
Google一下“Debug Arduino with Proteus” Proteus仿真arduino-调试
通过COMPIM/EPIM,RS232连接硬件, 以太网访问网络 VSM SDK编写模块 更多设计图(SPICE社区): http:// www.youspice.com/ys/en/ microcontroller-circuits.3sp? p=true&nr=10&s=id %3Dd&cts=microcontroller
Proteus仿真-其他
参考资料 基于Proteus的ARM(LPC2124)学习 http://wenku.baidu.com/ view/a0a96973f242336c1eb95e84.html Proteus VSM 总体介绍 http://opt.zju.edu.cn/zjuopt3/ redir.php?catalog_id=97 Proteus仿真平台介绍
http://www.fayinmei.com/html/docs/xingyeziliao/ zikongdianqi/2012/0411/4066.html Getting Started with Proteus – Arduino http://www.youspice.com/ys/gettingstartedwithproteus. 3sp?pageNum=1 Debug Arduino with Proteus http://www.thinkcreate.org/ index.php/debug-arduino-with-proteus/
谢谢观赏 sharing is fun @heyfluke
