1. Rails Engines from the bottom up Akira Matsuda
2. self.name Akira Matsuda (দా ໌)
3. From Japan
4. self.inspect GitHub: amatsuda Twitter: @a_matsuda a committer of: Ruby, Rails, Haml the founder of: Asakusa.rb an organizer of: RubyKaigi
5. Unknown Ruby 2.1 "new feature" # before 2.1: ActiveRecord::Base.send :include, MyPagination # since 2.1: ActiveRecord::Base.include MyPagination
6. My least favorite Ruby 2.1 new feature # freezing String 'Kiev'.frozen # 'frozen String' literal (the f suffix) 'Kiev'f # "f" is not for "Float" '1.0'f # "to_f" to get a "Float" '1.0'f.to_f
7. f to every String!ɹ # Then this is how our code would look like... source 'https://rubygems.org'f gem 'rails'f, '4.0.0'f gem 'sqlite3'f gem 'sass-rails'f, '~> 4.0.0'f gem 'uglifier'f, '>= 1.3.0'f gem 'coffee-rails'f, '~> 4.0.0'f gem 'jquery-rails'f gem 'turbolinks'f gem 'jbuilder'f, '~> 1.2'f group :doc do gem 'sdoc'f, require: false end
8. amatsuda creator of: kaminari, active_decorator, action_args, gem-src, html5_validators, everywhere, kawaii_validation, i18n_generators, ... recently created: database_rewinder, ljax_rails
9. Rails Engineer?
10. https://twitter.com/kosaki55tea/ status/147525384546689024 Boeing 787 engine engineer strongly objects to software engineers calling them selves engineers.
11. Ruby on Rails has Engines!
12. What are Rails Engines? "Engines can be considered miniature applications that provide functionality to their host applications" (Rails Guides)
13. Engine.is_a? Engine.is_a Rails application Engine.is_a Rails plugin Engine.is_a Gem
14. From the bottom up % cd RAILS_ROOT % mkdir hello hello/hello.gemspec
15. Creating a gem
16. We need a gemspec # hello/hello.gemspec Gem::Specification.new do |g| g.name = 'hello'f g.version = '0'f end
17. Bundling via bundler # RAILS_ROOT/Gemfile gem 'hello'f, path: 'hello'f
18. Bundler (RubyGems) adds PLUGIN_ROOT/lib into $LOAD_PATH % rails r 'puts $:'
19. Now let's implement some features
20. Say hello from our plugin # hello/lib/hello.rb puts 'Hello, Kiev!'f
21. What happens when bundling hello gem? RubyGems adds the lib directory into $LOAD_PATH Then someone calls hello/lib/ hello.rb le somehow
22. Let's see who called hello.rb # hello/lib/hello.rb puts caller puts 'Hello, Kiev!'f
23. the callers were require require require require... .../gems/bundler-1.3.5/lib/bundler/runtime.rb:72:in `require' .../gems/bundler-1.3.5/lib/bundler/runtime.rb:72:in `block (2 levels) in require' .../gems/bundler-1.3.5/lib/bundler/runtime.rb:70:in `each' .../gems/bundler-1.3.5/lib/bundler/runtime.rb:70:in `block in require' .../gems/bundler-1.3.5/lib/bundler/runtime.rb:59:in `each' .../gems/bundler-1.3.5/lib/bundler/runtime.rb:59:in `require' .../gems/bundler-1.3.5/lib/bundler.rb:132:in `require' ./config/application.rb:7:in `<top (required)>' .../gems/railties-4.0.0/lib/rails/commands/runner.rb:42:in `require' .../gems/railties-4.0.0/lib/rails/commands/runner.rb:42:in `<top (required)>' .../gems/railties-4.0.0/lib/rails/commands.rb:86:in `require' .../gems/railties-4.0.0/lib/rails/commands.rb:86:in `<top (required)>' ./bin/rails:4:in `require' ./bin/rails:4:in `<main>'
24. How Bundler requires a gem # gems/bundler-1.3.5/lib/bundler/runtime.rb module Bundler class Runtime < Environment def require(*groups) ... @definition.dependencies.each do |dep| ... Array(dep.autorequire || dep.name).each do |file| required_file = file Kernel.require file end ... ennnnnd
25. Kernel.require(autorequire || name) I didn't set anything to "autorequire" attribute, so it just requires the "name" equivalent to `require 'hello'` hello/lib/ is included in $LOAD_PATH, so nally ruby nds hello/lib/hello.rb and loads it
26. Creating a Rails plugin gem Tie your gem with the main app Just declare a class inheriting ::Rails::Railties class
27. Adding Railtie class and an initializer # hello/lib/hello.rb module Hello class Railtle < ::Rails::Railtie initializer 'hello.init'f do puts 'initializing hello...'f end end end
28. What happens when Raitie.inherited? # railties/lib/rails/railtie.rb module Rails class Railtie class << self def inherited(base) unless base.abstract_railtie? subclasses << base end end ... ennnd
29. YOUR_APP::Application. initialize! YOUR_APP/con g/environment.rb => railties/lib/rails/application.rb: initialize! => railties/lib/rails/initalizable.rb: run_initializers => raities/lib/rails/application.rb: initializer ... => Railties.new
30. Railtie.subclasses # railties/lib/rails/engine/railties.rb module Rails class Engine < Railtie class Railties include Enumerable attr_reader :_all def initialize @_all || = ::Rails::Railtie.subclasses.map(&:instance) + ::Rails::Engine.subclasses.map(&:instance) end ... ennnd
31. The points so far You can bundle a directory as a gem if it has a .gemspec le bundler automatically calls "gem/lib/#{gemname}.rb" You can create a Rails hook by inheriting ::Rails::Railtie class inside the plugin
32. Rails Engine A Rails plugin is a gem A Rails plugin is a Railtie A Rails Engine is also a Railtie
33. Anatomy of Rails Engine my_engine !"" app # !"" assets # # !"" images # # !"" javascripts # # $"" stylesheets # !"" controllers # !"" helpers # !"" mailers # !"" models # $"" views !"" bin !"" config !"" lib # !"" my_engine # # !"" engine.rb # # $"" version.rb # !"" my_engine.rb # $"" tasks $"" test
34. Difference between Engines and non-Engine plugins An Engine can contain models, controllers, views, routes, etc An Engine should contain a subclass of ::Rails::Engine
35. Enginize hello gem by subclassing Rails::Engine # hello/lib/hello.rb module Hello class Engine < ::Rails::Engine end end
36. If a class.is_a? Engine, it should be a Railtie as well % rails r "p Rails::Engine.ancestors" [ Rails::Engine, Rails::Railtie, Rails::Initializable, Object, ActiveSupport::Dependencies::Loadable, JSON::Ext::Generator::GeneratorMethods::Object, Kernel, BasicObject ]
37. What happens when subclassed? # railties/lib/rails/engine.rb class Engine < Railtie class << self attr_accessor :called_from, :isolated ... def inherited(base) ... base.called_from = begin call_stack = caller.map { |p| p.sub(/:\d+.*/, '') } File.dirname(call_stack.detect { |p| p !~ %r[railties[\w.-]*/lib/rails|rack[\w.-]*/lib/rack] }) end ...
38. Doesn't have to be a named class # hello/lib/hello.rb module Hello Class.new ::Rails::Engine end
39. Doesn't have to be wrapped inside the Hello module # hello/lib/hello.rb Class.new ::Rails::Engine
40. Engine can contain models # hello/app/models/foo.rb class Foo def foo p 'foooo'f end end
41. How could Rails nd Foo? hello/app/models was added in $LOAD_PATH hello/app/models was added in the Engine's eager_load_paths
42. $LOAD_PATH % rails r 'puts $:'
43. eager_load_paths? # hello/lib/hello.rb p Class.new(::Rails::Engine).config.eager_load_paths
44. Make it a webapp # hello/config/routes.rb Rails.application.routes.draw do resources :foos end # hello/app/controllers/foos_controller.rb class FoosController < ApplicationController def index render text: Foo.new.foo end end
45. Rails Engine is_a plugin is_a Gem is_a tiny application that can contain models, controllers, routes, etc.
46. What can Engines do?
47. My First Rails Engine
48. amatsuda/kaminari A pagination plugin Created for Rails 3.0.0 AFAIK the 2nd Rails Engine in the world
49. Why Engine? Rails Engine can contain app/ {controllers,models,views,helpers,etc} A pagination library consists of model extension, helpers, and views It was quite natural to implement as an Engine (Just wanted to try the new feature of Rails 3.0)
50. Anatomy of Kaminari kaminari !"" app # !"" helpers # $"" views # $"" kaminari !"" config # $"" locales !"" lib # !"" generators # # $"" kaminari # # $"" templates # $"" kaminari # !"" helpers # $"" models $"" spec
51. Initial version https://github.com/amatsuda/ kaminari/tree/v0.1.0 There exist some bugs, but the code is pretty straightforward Only 4 les in kaminari/lib/ directory!
52. v0.1.0 (railtie.rb for the Raitie class) (engine.rb for the Engine class) active_record.rb for AR extension (helper.rb for the helpers) (views are in app/views)
53. active_record.rb (edited) # kaminari/lib/kaminari/active_record.rb (edited) module Kaminari::ActiveRecord extend ActiveSupport::Concern included do def self.inherited(kls) kls.class_eval do scope :page, lambda {|num| offset(PER_PAGE * ([num.to_i, 1].max - 1)).limit(10) } do def per(num) offset(offset_value / limit_value * num).limit(num) end ... ennnnnd
54. How this code works? How does Kaminari paginate? (Pat Shaughnessy) http://patshaughnessy.net/2011/9/10/ how-does-kaminari-paginate Active Record scopes vs class methods (Carlos Antônio) http://blog.plataformatec.com.br/ 2013/02/active-record-scopes-vs- class-methods/
55. "Kaminari" Naming a gem is so hard There was no available /.*page.*/ name @hsbt named it "kaminari" probably inspired by "nokogiri"
56. "Kaminari" ཕ == thunder I know it's hard to memorize, hard to spell, and hard to pronounce for you, non-Japanese In fact, everybody pronounces it incorrectly (I don't mind though)
57. New version? The next version will be 0.15.0 We're working on that...
58. Mountable Engines
59. The Problem constants, routes, helpers often con ict between main_app and Engines
60. The con ict main_app !"" app # $"" controllers # $"" users_controller.rb $"" my_engine $"" app $"" controllers $"" users_controller.rb
61. The Solution Since Rails 3.1 "Isolated Engine" or "Mountable Engine"
62. Mountable Engine % rails plugin new my_engine -- mountable
63. Anatomy of a Moutable Engine MyEngine !"" app # !"" assets # # !"" images # # # $"" my_engine # # !"" javascripts # # # $"" my_engine # # # $"" application.js # # $"" stylesheets # # $"" my_engine # # $"" application.css # !"" controllers # # $"" my_engine # # $"" application_controller.rb # !"" helpers # # $"" my_engine # # $"" application_helper.rb # !"" mailers # # $"" my_engine # !"" models # # $"" my_engine # $"" views # $"" layouts # $"" my_engine # $"" application.html.erb !"" config # $"" routes.rb !"" lib # !"" my_engine # # !"" engine.rb # # $"" version.rb # $"" my_engine.rb !"" my_engine.gemspec $"" test
64. Mountable Engine's Engine # my_engine/lib/my_engine/engine.rb module MyEngine class Engine < ::Rails::Engine isolate_namespace MyEngine end end
65. What can a Mountable Engine do? It can provide safely namespaced models, controllers, views, etc. It can be "mounted" onto the parent Rails application's certain URL It can refer to the parent application from controllers / views via `main_app` method
66. Real world examples Documentations in Rails ER diagram Page transition diagram
67. ER Diagram
68. amatsuda/erd
69. ERD A mountable Engine that loads the main_app's models and draws the ER diagram on the browser You can create new model, add / rename / alter column, etc.
70. (DEMO) rails g some model
71. A tiny tip erd mounts itself onto the main_app's routes on the :after_initialize hook, so users don't have to con gure anything
72. Self-mounting Engine # erd/lib/erd/railtie.rb module Erd class Railtie < ::Rails::Railtie #:nodoc: initializer 'erd' do |app| ActiveSupport.on_load(:after_initialize) do if Rails.env.development? Rails.application.routes.append do mount Erd::Engine, :at => '/erd' ennnnnnd
73. amatsuda/roundabout
74. I'll be the Roundabout Visualizes page (action) transitions No need for any extra programming or document writing. Just run `rake spec` Records all page transitions in `rake spec`
75. (DEMO) % rails g scaffold user name age:integer % rake db:migrate require 'roundabout/rspec'f add spec/feature/???_spec.rb
76. What roundabout does Generates documents Tells us missing `visit`s Shows us "page visit coverage" Motivates users to complete feature specs
77. amatsuda/hocus_pocus
78. hocus_pocus Released before 3.1.0 stable AFAIK this was the rst released mountable Engine in the world
79. HocusPocus Records your browser action You can copy & paste the generated text into your spec/ features. No need to handwrite anymore!
80. (DEMO)
81. HocusPocus (reprise) A Wiki-wiki way Rails app development platform Users can edit current page like a Wiki page Catches URL missing in the browser for example, just visit http://localhost:3000/books Catches link_to missing in the browser for example, add `link_to 'authors', authors_path`
82. (DEMO)
83. Anatomy of HocusPocus hocus_pocus !"" engines # !"" command_line # # !"" app # # # !"" controllers # # # $"" views # # !"" config # # $"" lib # !"" editor # # !"" app # # # !"" assets # # # !"" controllers # # # $"" views # # !"" config # # $"" lib # !"" generator # # !"" app # # # !"" assets # # # !"" controllers # # # !"" helpers # # # $"" views # # !"" config # # $"" lib # $"" recorder # !"" app # # !"" assets # # !"" controllers # # $"" views # !"" config # $"" lib !"" lib # !"" generators # # $"" hocus_pocus # $"" hocus_pocus $"" spec
84. Engines in an Engine! AFAIK the only Rails Engine that contains other Rails Engines inside Adds each Engine's lib, app/* into $LOAD_PATH require_paths does the trick
85. Gem::Speci cation #require_path # hocus_pocus/hocus_pocus.gemspec Gem::Specification.new do |s| s.name = 'hocus_pocus' s.version = HocusPocus::VERSION s.authors = ['Akira Matsuda'] s.homepage = 'https://github.com/amatsuda/hocus_pocus' ... s.require_paths = ['lib', 'engines/generator/lib', 'engines/ editor/lib', 'engines/recorder/lib', 'engines/command_line/lib'] ... end
86. amatsuda/ljax_rails
87. ljax_rails "Lazy-load" partial views in Ajax Created last week Not an "isolated" engine but loads a JS le from app/assets
88. Anatomy of ljax_rails ljax_rails !"" app # $"" assets # $"" javascripts # $"" ljax_rails.js.coffee !"" lib # !"" ljax_rails # # !"" action_controller_monkey.rb # # !"" action_dispatch_monkey.rb # # $"" action_view_monkey.rb # $"" ljax_rails.rb !"" ljax_rails.gemspec $"" spec
89. render :partial <%# app/views/users/index.html.erb %> <%= render 'users'f %>
90. remote: true <%# app/views/users/index.html.erb %> <%= render 'users'f, remote: true %>
91. What if the query is very very slow? class UsersController < ApplicationController ... def index if request.ljax? @users = User.all sleep 3 end ennd
92. Have fun with Rails Engines, and be a great Rails Engineer!
