Transcript

1. Aaron Parecki • October 2020
   OAuth 101
   Internet Identity Workshop XXXI


   View Slide

2. Specs are not good tutorials!


   View Slide

3. RFC6749
   RFC6750
   CLIENT TYPE
   AUTH METHOD
   GRANT TYPE
   RFC6819
   RFC7009
   RFC7592
   RFC7662
   RFC7636
   RFC7591
   RFC7519
   RFC8252
   OIDC
   RFC8414
   STATE PARAM
   TLS
   CSRF
   UMA 2
   FAPI
   RFC7515
   RFC7516
   RFC7517
   RFC7518
   TOKEN BINDING
   POP
   SECURITY BCP
   CIBA
   HTTP SIGNING
   MUTUAL TLS SPA BCP
   JARM
   JAR
   TOKEN EXCHANGE
   DPOP


   View Slide

4. The Password Anti-Pattern


   View Slide

5. The Password Anti-Pattern
   facebook.com ~2010


   View Slide

6. The Password Anti-Pattern
   • How do you revoke this app’s access?

   • Do you trust the app to not store your password?

   • Do you trust the app to access only the things it says
   it needs?

   • Do you trust the app to not do things like change
   your password or delete your account?


   View Slide

7. View Slide

8. how can I let an app

   access my data
   without giving it my password?


   View Slide

9. password
   password
   passw
   ord


   View Slide

10. Authorization Server Access Token Resource (API)


    View Slide

11. OAuth doesn't tell the app

    who
    logged in


    View Slide

12. Identification
    authentication
    Accessing APIs
    authorization


    View Slide

13. How OAuth Works


    View Slide

14. Authorization Code
    OAuth Flows
    Device Flow Client Credentials
    Implicit Password
    web mobile SPA browserless devices server-to-server
    CLI
    CLI
    >_
    >_


    View Slide

15. POST /resource/1/update HTTP/1.1
    Authorization: Bearer RsT5OjbzRn430zqMLgV3Ia
    Host: api.authorization-server.com
    description=Hello+World
    USING AN ACCESS TOKEN


    View Slide

16. ROLES IN OAUTH
    OAuth Server
    (Authorization Server)
    aka the token factory
    API
    (Resource Server)
    The Application
    (Client)
    The User
    (Resource Owner)
    Device
    (User Agent)


    View Slide

17. ROLES IN OAUTH
    OAuth Server
    (Authorization Server)
    aka the token factory
    API
    (Resource Server)
    The Application
    (Client)
    The User
    (Resource Owner)
    Device
    (User Agent)
    Travis-CI.org GitHub


    View Slide

18. ROLES IN OAUTH
    OAuth Server
    (Authorization Server)
    aka the token factory
    API
    (Resource Server)
    The Application
    (Client)
    The User
    (Resource Owner)
    Device
    (User Agent)
    iPhone App Okta Your API


    View Slide

19. Client Types
    Public

    Confidential



    View Slide

20. OAuth 2.1 Client Types
    Public

    Confidential

    Credentialed



    View Slide

21. Public
    Confidential
    Application running on
    a server
    Has the ability to keep
    strings secret since code
    is running in a trusted
    environment
    The application can't be
    deployed with a secret
    JavaScript/Single-Page
    apps: "view source"
    Native apps: decompile and
    extract strings
    Credentialed
    Obtains credentials
    on first launch
    A native app can use
    Dynamic Client Registration
    to obtain credentials which it
    can use in later exchanges


    View Slide

22. Authorization Code + PKCE


    View Slide

23. User: I’d like to use this great app
    App: Please go to the authorization server to grant me access, take this hash with you
    User: I’d like to log in to this app, here's the hash it gave me
    AS: Here is a temporary code the app can use
    App: Here's the code, and the plaintext secret, please give me a token
    User: Here is the temporary code, please use this to get a token
    AS: Let me verify the hash of that secret... ok here is an access token!
    App: Please let me access this user’s data with this access token!
    App: Hang on while I generate a new secret and hash it
    User
    Agent
    App OAuth Server
    API
    ?


    View Slide

24. Front Channel
    Back Channel
    https://accounts.google.com/?...
    Passing data via the browser's address bar
    The user, or malicious software,
    can modify the requests and responses
    Sent from client to server
    HTTPS request from client to server,
    so requests cannot be tampered with


    View Slide

25. OAuth Server OAuth Client
    Passing Data via the Back Channel


    View Slide

26. OAuth Server OAuth Client
    Passing Data via the Front Channel
    Delivery
    Service


    View Slide

27. Front Channel Benefits
    https://accounts.google.com/?...
    ‣ The user being involved
    enables them to give consent
    ‣ Enables easier two-factor
    authorization integration
    ‣ Doesn't require the receiver to
    have a publicly routable IP
    (e.g. can work on a phone)


    View Slide

28. Generate the Code Verifier
    4A6hBupTkAtgbaQs39RSELUEqtSWTDTcRzVh1PpxD5YVKllU
    Generate a random string 43-128 characters long
    ipSBt30y48l401NGbLjo026cqwsRQzR5KI40AuLAdZ8
    The challenge is the SHA256 hash of the verifier string
    base64url(sha256(code_verifier))
    Generate the Code Challenge


    View Slide

29. The app builds the auth link
    https://authorization-server.com/auth?
    response_type=code&
    client_id=CLIENT_ID&
    redirect_uri=REDIRECT_URI&
    scope=photos&
    state=1234zyx&
    code_challenge=XXXXXXXXXXXXX&
    code_challenge_method=S256
    Include the code challenge (the hashed value) in the request


    View Slide

30. View Slide

31. The user is redirected back to the application with an authorization code
    example://callback?error=access_denied&state=1234xyz
    The user is redirected back to the application with an error code
    If User Denies
    If User Allows
    example://callback?
    code=AUTH_CODE_HERE&
    state=1234zyx


    View Slide

32. Exchange the Code for an Access Token
    Verify state, then make a POST request:
    • grant_type=authorization_code - indicates that this request contains an
    authorization code
    • code=CODE_FROM_QUERY - Include the authorization code from the
    query string of this request
    • redirect_uri=REDIRECT_URI - This must match the redirect_uri used in
    the original request
    • client_id=CLIENT_ID - The client ID you received when you first created
    the application
    • code_verifier=VERIFIER_STRING - The plaintext code verifier initially
    created


    View Slide

33. Exchange the Code for an Access Token
    POST https://api.authorization-server.com/token
    grant_type=authorization_code&
    code=AUTH_CODE_HERE&
    redirect_uri=REDIRECT_URI&
    client_id=CLIENT_ID&
    code_verifier=VERIFIER_STRING


    View Slide

34. Exchange the Code for an Access Token
    {
    "access_token":"RsT5OjbzRn430zqMLgV3Ia",
    "expires_in":3600,
    "refresh_token":"64d049f8b2119a12522d5dd96d5641af5e8"
    }
    The server compares the code_verifier with the code_challenge
    that was in the request when it generated the authorization code, and
    responds with an access token.


    View Slide

35. PKCE
    Ensures the app that receives the authorization code

    is the same one that started the exchange


    View Slide

36. Refresh tokens


    View Slide

37. Refresh tokens
    keep the user logged in


    View Slide

38. Application
    Refresh
    Token
    API
    (Resource Server)
    Access Token
    Authorization Server
    A
    ccess Token


    View Slide

39. Exchange the Refresh Token for an Access Token
    POST https://authorization-server.com/token
    grant_type=refresh_token&
    refresh_token=REFRESH_TOKEN&
    client_id=CLIENT_ID&
    client_secret=CLIENT_SECRET


    View Slide

40. New Access Token in the Response
    {
    "access_token": "RsT5OjbzRn430zqMLgV3Ia",
    "expires_in": 3600,
    "refresh_token": "64d049f8b21191e12522d5d96d5641af5e8"
    }


    View Slide

41. SIGN IN
    user authenticates
    access token
    & refresh token
    authorization
    request
    store refresh token
    in secure storage


    View Slide

42. SIGN IN
    biometrics unlock
    refresh token
    new access token
    & refresh token
    already has
    refresh token
    use refresh token
    to get new access token


    View Slide

43. Scope


    View Slide

44. Scope lets an application request
    limited access to data


    View Slide

45. View Slide

46. View Slide

47. Scope is a request that is
    confirmed by the user and the
    authorization server


    View Slide

48. Access tokens


    View Slide

49. Access tokens are what the
    application uses to request data
    from the API


    View Slide

50. Types of Access Tokens
    MTQ0NjJkZmQ5OTM2NDE1ZTZjNGZmZjI3
    eyJ0eXAiOiJKV1QiLCJhbGciOiJIUzI1NiJ9.eyJzdWIiOjEwMDAsI
    mlzcyI6Imh0dHBzOi8vYXV0aG9yaXphdGlvbi1zZXJ2ZXIuY29tIiw
    iY2lkIjoiaHR0cHM6Ly9leGFtcGxlLWFwcC5jb20iLCJpYXQiOjE0N
    zAwMDI3MDMsImV4cCI6MTUyOTE3NDg1MSwic2NvcGUiOiJyZWFkIHd
    yaXRlIn0.QiIrnmaC4VrbAYAsu0YPeuJ992p20fSxrXWPLw-gkFA
    Reference
    Self-Encoded (e.g. JWT)


    View Slide

51. Reference Tokens
    MTQ0NjJkZmQ5OTM2NDE1ZTZjNGZmZjI3
    * user_id
    * expiration
    * permissions
    * ...


    View Slide

52. Self-Encoded Tokens
    eyJ0eXAiOiJKV1QiLCJhbGciOiJIUzI1NiJ9.eyJzdWIiOjEwMDAsI
    mlzcyI6Imh0dHBzOi8vYXV0aG9yaXphdGlvbi1zZXJ2ZXIuY29tIiw
    iY2lkIjoiaHR0cHM6Ly9leGFtcGxlLWFwcC5jb20iLCJpYXQiOjE0N
    zAwMDI3MDMsImV4cCI6MTUyOTE3NDg1MSwic2NvcGUiOiJyZWFkIHd
    yaXRlIn0.QiIrnmaC4VrbAYAsu0YPeuJ992p20fSxrXWPLw-gkFA
    {
    "sub": "{USER_ID}",
    "aud": "{CLIENT_ID}",
    "exp": 1524240821,
    "scope": "create"
    }


    View Slide

53. A JWT Access Token
    eyJraWQiOiJvQ1JjR3RxVDhRV2tJR0MyVXpmcEZUczVqSkdnM00zSTNOMHgtZDJhSFNNIiwiYWxn
    IjoiUlMyNTYifQ.eyJ2ZXIiOjEsImp0aSI6IkFULkp3eVRTcTlqNDU0bDNTNmRTM1VTV1hMVVpwe
    kdKdWNSd1ZEbFZCNWNIc3cuVVM1V1NGYVFiQllUMC9GM2tjMG8vK1ZUY3VZZzdwVnZqZXZTT3hkU
    HhCMD0iLCJpc3MiOiJodHRwczovL2Rldi0zOTYzNDMub2t0YXByZXZpZXcuY29tL29hdXRoMi9kZ
    WZhdWx0IiwiYXVkIjoiYXBpOi8vZGVmYXVsdCIsImlhdCI6MTU0MzgwMzAyNSwiZXhwIjoxNTQzO
    DA2NjI1LCJjaWQiOiIwb2FoenBwM3RjcEZyZmNXSTBoNyIsInVpZCI6IjAwdWkwZmpraWV5TDQ2b
    WEwMGg3Iiwic2NwIjpbIm9mZmxpbmVfYWNjZXNzIiwicGhvdG8iXSwic3ViIjoiaW5xdWlzaXRpd
    mUtYWxiYXRyb3NzQGV4YW1wbGUuY29tIn0.ncVkzcc6qrFJSXE3-5UsRu_kHvbwIMKYL3PFaMwRe
    YTquPAcOQ8t93xF0bxbS8wrP0udCDvk6eYq4VbjoFdD59Yy6ltz0OKQl3-
    g8uFg2RwqTBMOKR0mYtQH0RCr9ORhSsmKolaDDt4TcRX78ZOAyhZ_Qg_UcEoHM4uZikpzBJYpYKb
    CCfbx-6FzYyHuvevSFzURISYpSHv3nbzirkEzKbOv7eZlg1cCYBdUoGuVBskyHxfMxFpoKQU3mwI
    FdlQJR8LZ8hA_5ZdYjjMeSXfjnhlP2rppJiHy1NreGXXcUsUA74V2t_keY44deTrnPgoFOSe9Ich
    Wqcj6sDMDutC4ag


    View Slide

54. A JWT Access Token
    {
    "typ": "JWT",
    "alg": "RS256",
    "kid": "oCRcGtqT8QWkIGC2UzfpFTs5jJGg3M3I3N0x-d2aHSM"
    }
    {
    "ver": 1,
    "jti": "AT.JwyTSq9j454l3S6dS3USWXLUZpzGJucRwVDlVB5cHsw.US5WSFaQbBYT0/F3kc0o/+VTcuYg7pVvjevSOxdPxB0=",
    "iss": "https://dev-396343.oktapreview.com/oauth2/default",
    "aud": "api://default",
    "iat": 1543803025,
    "exp": 1543806625,
    "cid": "0oahzpp3tcpFrfcWI0h7",
    "uid": "00ui0fjkieyL46ma00h7",
    "scp": [
    "offline_access",
    "photo"
    ],
    "sub": "inquisitive-albatross@example.com"
    }
    header
    claims


    View Slide

55. are you an app?
    are you an API?
    Authorization: Bearer RsT5OjbzRn430zqMLgV3Ia
    just use the token
    parse/extract/introspect the token
    {
    "sub": "{USER_ID}",
    "aud": "{CLIENT_ID}",
    "exp": 1524240821,
    "scp": "create"
    }


    View Slide

56. Access Token Validation
    The Fast Way The Strong Way
    Local Validation Remote Introspection
    eyJ0eXAiOiJKV1QiLCJhbGciOiJIUzI1NiJ9.eyJzdWIiOiIxMjM0NTY3ODkwIiwibmFtZS
    I6IkpvaG4gRG9lIiwiYWRtaW4iOnRydWUsImp0aSI6ImI5ZDRhNzViLTA2MDMtNDgxYy1hM
    jgyLTY3YTk0NDJiNGRkNiIsImlhdCI6MTUzMjQwMDkyMiwiZXhwIjoxNTMyNDA0NTIyfQ.S
    jYROEt8lZpEOq1eKh3OxRmRk3xttOXZeD5yW8aW2k8
    {
    "sub": "1234567890",
    "name": "John Doe",
    "admin": true,
    "jti": "b9d4a75b-0603-481c-a282-67a9442b4dd6",
    "iat": 1532400922,
    "exp": 1532404522
    }
    POST https://authorization-server.com/introspect
    token=eyJ0eXAiOiJKV1QiLCJhbGciOiJIUzI1NiJ9.eyJzdWIiOiIxMjM0NTY3OD
    &client_id={CLIENT_ID}
    &client_secret={CLIENT_SECRET}


    View Slide

57. Rejecting Revoked Tokens
    1:00 2:00 3:00 4:00 5:00 6:00 7:00 expired
    0:00
    Local
    Validation
    Remote
    Introspection
    User revokes application


    View Slide

58. API Gateway Token Validation
    API Gateway
    CUSTOMER API
    BILLING API
    ORDER API LOCAL
    VALIDATION
    TOKEN
    INTROSPECTION
    attacker
    attacker
    valid token
    valid token
    expired
    expired
    revoked
    revoked
    malformed
    valid token
    valid token
    revoked
    revoked
    X
    X
    X
    X
    X
    valid token
    revoked
    valid
    token
    revoked
    X


    View Slide

59. New Extensions


    View Slide

60. JWT Profile for Access Tokens
    Describes a standard set of JWT claims to
    use in a JWT access token.

    This enables resource servers to be built
    with standard libraries to validate tokens.


    View Slide

61. JWT Authorization Request (JAR)
    Create a JWT describing the authorization
    request instead of building a URL

    Provides: integrity protection, request
    authentication, confidentiality


    View Slide

62. Current Work


    View Slide

63. OAuth 2.1
    Consolidate the OAuth 2.0 specs,

    adding best practices,

    removing deprecated features

    Capture current best practices in OAuth
    2.0 under a single name


    View Slide

64. OAuth 2.0
    RFC6749 OAuth Core
    Authorization Code
    Implicit
    Password
    Client Credentials
    RFC6750 Bearer Tokens
    Tokens in HTTP Header
    Tokens in POST Form Body
    Tokens in GET Query String
    RFC7636
    +PKCE
    RFC8252
    PKCE for mobile
    Browser App BCP
    PKCE for SPAs
    PKCE for
    confidential
    clients
    Security BCP


    View Slide

65. OAuth 2.1
    Authorization Code
    Client Credentials
    +PKCE
    Tokens in HTTP Header
    Tokens in POST Form Body


    View Slide

66. OAuth 2.1
    oauth.net/2.1
    tools.ietf.org/html/draft-ietf-oauth-v2-1


    View Slide

67. Rich Authorization Requests (RAR)
    oauth.net/2/rich-authorization-requests


    View Slide

68. Pushed Authorization Requests (PAR)
    • Currently, the authorization request is sent in the front-channel

    • Front-channel is susceptible to inspection and modification

    • PAR initiates the OAuth flow from the back-channel
    oauth.net/2/pushed-authorization-requests


    View Slide

69. Pushed Authorization Requests (PAR)
    GET /authorize?response_type=code
    &client_id=s6BhdRkqt3&state=af0ifjsldkj
    &redirect_uri=https%3A%2F%2Fclient.example.org%2Fcb HTTP/1.1
    Host: as.example.com
    POST /as/par HTTP/1.1
    Host: as.example.com
    Content-Type: application/x-www-form-urlencoded
    Authorization: Basic czZCaGRSa3F0Mzo3RmpmcDBaQnIxS3REUmJuZlZkbUl3
    response_type=code
    &client_id=s6BhdRkqt3&state=af0ifjsldkj
    &redirect_uri=https%3A%2F%2Fclient.example.org%2Fcb
    Instead of:
    Push the request to the AS:
    oauth.net/2/pushed-authorization-requests


    View Slide

70. Pushed Authorization Requests (PAR)
    {
    "request_uri": "urn:example:bwc4JK-ESC0w8acc191e-Y1LTC2",
    "expires_in": 90
    }
    GET /authorize?request_uri=
    urn%3Aexample%3Abwc4JK-ESC0w8acc191e-Y1LTC2 HTTP/1.1
    AS responds with a URL:
    User visits that URL, authorization request details are hidden!
    oauth.net/2/pushed-authorization-requests


    View Slide

71. DPoP
    oauth.net/2/dpop
    A technique to
    cryptographically bind
    access tokens to a
    particular client.


    View Slide

72. Specs Built on OAuth
    • OpenID Connect (openid.net)

    • FAPI (Financial-Grade API)

    • UMA (User-Managed Access)

    • IndieAuth (indieauth.net)


    View Slide

73. aaronpk.com

    oauth.wtf


    View Slide
