Keep Calm, it's Reverse Engineering Time - PyTN2016

4f477cfca5c1d10d09157c07cdfa3af4?s=47 Alissa Bonas
February 07, 2016

Keep Calm, it's Reverse Engineering Time - PyTN2016

As developers, sometimes we have to investigate a bug, or add a new feature in a codebase that is completely new to us. Sometimes it can be even developed in technology that we are unfamiliar with, often with no one available to ask anything about that code. How can we do this?
In this talk I would like to share some ideas, tips and tools related to reverse engineering of various code components (server side, frontend, etc) – that can help developers to successfully overcome this challenge.


Alissa Bonas

February 07, 2016


  1. Alissa Bonas mikeyteva

  2. “Run Forrest, Run”

  3. When is it needed? • Add a new feature •

    Fix a bug • Investigate a problem • Maintain legacy code • Integration with another system or component
  4. “My momma always said, life was like a box of

    chocolates. You never know what you’re gonna get”
  5. How can we succeed?

  6. Ask the person who developed it

  7. None
  8. However...

  9. Is it an open source project? • Check the docs

    / wiki • Ask in the community ◦ mailing list ◦ forum ◦ irc ◦ open an issue / ticket with a question
  10. None
  11. Back to basics

  12. Back to basics • Technology / Programming language • Source

    control • Running tests • Build / Run / Deploy
  13. Detecting languages on Github

  14. Detecting languages on Github

  15. Not 100% accurate

  16. Look for hints • File extensions • .gitignore • README.md

  17. Look for more hints • Requirements.txt / setup.py • pom.xml

    / build.xml • Gemfile / gemspec • bower.json
  18. Scope the task

  19. Minor changes • Fix typos • Add more info to

    a log statement • Persist a field that already exists in an object
  20. In search we trust • Search for strings in the

    code repository • Search existing logs for object names
  21. Medium size changes • Add a new field to an

    object / model ◦ process and persist ◦ use it in all code layers • Upgrade the version of a third party library ◦ regression is your nemesis ◦ minor version upgrade != major version upgrade
  22. Follow the trail • Follow existing fields ◦ understand the

    flow • Follow the tests ◦ learn how to add new tests ◦ check if tests pass after code changes
  23. Major changes • Refactor a module / component • Add

    a new functionality which requires a deep understanding of the system • Performance is key and must not be harmed
  24. Understand • The architecture of the system • Relevant flows

    and use cases • The main path • Fallback, retries, etc.
  25. Number 1 factor is...

  26. Time

  27. None
  28. Goal: Identify entry points • UI / REST / Backend

    • Class hierarchy • Identify and learn frameworks
  29. Get to know the code better • Is there a

    dependency injection mechanism? • How do the components communicate • Configuration keys to enable more info in the logs
  30. Get to know the system better • Identify persistency ◦

    data store type ◦ how the data is stored • Know your container ◦ web server ◦ application server
  31. Product configuration files • Static files location • Check how

    they are used and changed ◦ directly ◦ loaded into the database
  32. Multi process system • Identify the processes • How do

    they communicate with each other • High availability / symmetric
  33. Multithreaded considerations • Sync or async code flow • Usage

    of thread pools
  34. After several iterations • Create a sequence diagram • UML

    draw.io Free online Visio alternative
  35. Iterating over the code is like solving a puzzle

  36. None
  37. Creating anchors “In climbing, a piton (/ˈpiːtɒn/; also called a

    pin or peg) is a metal spike (usually steel) that is driven into a crack or seam in the rock with a hammer, and which acts as an anchor to protect the climber against the consequences of a fall, or to assist progress in aid climbing” (wikipedia)
  38. Creating anchors • Read the code • If we can

    debug - put breakpoints • Read existing logs • Understand through unitests
  39. Creating anchors continued • Change the log level • Add

    more logging statements • Check history in source control - commits and comments
  40. Creating anchors - IDE Bookmarks

  41. Creating anchors - the analog way • Works too!

  42. Backend

  43. Example - utilities to explore the JVM • JConsole •

    VisualVM • (more tools exist)
  44. Getting more hints • Explore threads names • Thread dump

    - check thread source • Take a heap dump - explore classes • Check which objects a map contains
  45. Hint on the database Hint on the scheduler

  46. Network analyzer / packet sniffer • Software that intercepts and

    logs traffic ◦ decodes data ◦ shows packet fields • For example - Wireshark • Define filters for efficiency
  47. Example

  48. Goal • Send a SOA envelope to a service •

    Sender - Ruby code • Target - Java SOA service
  49. Reports Engine 1 Reports Engine 2 Reports Engine 3 UI

    Reports Engine 4 http /engine1 http /engine2 http /engine3 http /engine4 SOA Tomcat SOA SOA SOA SOA
  50. Steps • Basic understanding what SOA is • Intercept traffic

    of the existing Java code • Learn how a SOA envelope should look like • Write Ruby code to create a SOA envelope
  51. Frontend

  52. Frontend • Which libraries are used • Search for strings

    / translation files • Search for icon files location and usage • Learn how UI calls backend
  53. Browser developer tools • FireBug • Chrome developer tools

  54. Following the code • Which css and js are downloaded

    • Add watches in the script tab • Set a breakpoint ◦ Use ‘debugger;’ keyword in code ◦ Set a breakpoint • Inspect elements
  55. Inspect the logo 160px * 159px File type and location

    Press here to switch to element selection mode Inspecting elements
  56. Inspect the logo 160px * 159px Inspecting elements

  57. Useful options • Network tab • Copy as curl •

    Copy response • Copy link address
  58. Following network requests Alissa Bonas @ PyTN 2016

  59. Analyzing response Alissa Bonas @ PyTN 2016

  60. Analyzing response - zoom in JSON response

  61. REST Client • Learn how REST API is designed

  62. In short...

  63. None
  64. Thank you! mikeyteva
