Managing Kubernetes and OpenShift with ManageIQ - CloudOpen Europe

Managing Kubernetes and OpenShift with ManageIQ - CloudOpen Europe

Managing Kubernetes and OpenShift with ManageIQ.
A talk on container management aspects.
Presented at CloudOpen (Linux Con) Dublin, 2015

4f477cfca5c1d10d09157c07cdfa3af4?s=128

Alissa Bonas

October 06, 2015
Tweet

Transcript

  1. Managing Kubernetes and OpenShift with ManageIQ Alissa Bonas, Dublin 2015

  2. The stages of containers world

  3. Containerizing an app Alissa Bonas @ Cloud Open Dublin 2015

  4. Run a container Alissa Bonas @ Cloud Open Dublin 2015

  5. Run multiple containers Alissa Bonas @ Cloud Open Dublin 2015

  6. • Orchestrate containers • Run many containers on multiple hosts

    • Manage a containers based environment Run multiple containers Alissa Bonas @ Cloud Open Dublin 2015
  7. Today we’ll focus on Kubernetes OpenShift ManageIQ Alissa Bonas @

    Cloud Open Dublin 2015
  8. Kubernetes • Deployment, scaling and orchestration of containers across clusters

    of hosts. • 1.0 release - July 2015 Developed in Go Alissa Bonas @ Cloud Open Dublin 2015
  9. Kubernetes concepts • Node - a machine that containers run

    on • Pod - a group of containers • Replication controller - ensures there are always X replicas of pods Alissa Bonas @ Cloud Open Dublin 2015
  10. Kubernetes concepts • Service - a base load balancer that

    provides traffic to pods • Namespace - partitioning resources created by users into logical groups Alissa Bonas @ Cloud Open Dublin 2015
  11. OpenShift • Platform as a service for building and running

    applications - for developers • Built on top of Kubernetes • 3.0 release - June 2015 Developed in Go Alissa Bonas @ Cloud Open Dublin 2015
  12. OpenShift concepts • Provides additional capabilities ◦ application lifecycle ◦

    routing - extends service ◦ projects - extension of namespaces Build Deploy Run Alissa Bonas @ Cloud Open Dublin 2015
  13. • How many containers exist in my environment? • Does

    a specific node have enough resources? • How many distinct images are used? • Which registries are used? Insight and control Alissa Bonas @ Cloud Open Dublin 2015
  14. ManageIQ • A cloud management platform ◦ supports multiple virtualization

    providers • Insight and control ◦ inventory overview and events ◦ smart state analysis ◦ workflow/orchestration a Ruby on Rails project Alissa Bonas @ Cloud Open Dublin 2015
  15. New in upstream ManageIQ • Providers for container management •

    Supported providers ◦ Kubernetes ◦ OpenShift Alissa Bonas @ Cloud Open Dublin 2015
  16. Container management providers Alissa Bonas @ Cloud Open Dublin 2015

  17. Working together ManageIQ Kubernetes / Openshift Master REST Node A

    Node B Alissa Bonas @ Cloud Open Dublin 2015
  18. Inventory • Entities • Relationships • Additional information Alissa Bonas

    @ Cloud Open Dublin 2015
  19. Creating more insights • Modelling additional entities as first class

    citizens • Deducing relationships Alissa Bonas @ Cloud Open Dublin 2015
  20. Kubernetes provider summary Alissa Bonas @ Cloud Open Dublin 2015

  21. Kubernetes provider relationships Alissa Bonas @ Cloud Open Dublin 2015

  22. OpenShift provider summary

  23. OpenShift provider relationships Alissa Bonas @ Cloud Open Dublin 2015

  24. Nodes • OS and Software versions • How many entities

    are on a node • Capacity and utilization • Which infrastructure is it running on Alissa Bonas @ Cloud Open Dublin 2015
  25. Node summary page Alissa Bonas @ Cloud Open Dublin 2015

  26. What do we know about nodes? Capacity Docker and Kubernetes

    info OS info Alissa Bonas @ Cloud Open Dublin 2015
  27. What do we know about nodes? Alissa Bonas @ Cloud

    Open Dublin 2015
  28. Cross providers insight • Connect all layers of infrastructure, cloud

    and containers • Currently supports cross linking with ◦ OpenStack ◦ oVirt / RHEV ◦ VMware vCenter Alissa Bonas @ Cloud Open Dublin 2015
  29. Cross linking demystified Virtual Machines Hosts Nodes Pods Containers Alissa

    Bonas @ Cloud Open Dublin 2015
  30. Cross linking zoom out Virtual Machines Hosts Nodes Pods Containers

    Images Storage Network Services Routes Alissa Bonas @ Cloud Open Dublin 2015
  31. Cross provider example - Node Alissa Bonas @ Cloud Open

    Dublin 2015
  32. Cross provider - VM side Alissa Bonas @ Cloud Open

    Dublin 2015
  33. Nodes capacity and utilization

  34. Alissa Bonas @ Cloud Open Dublin 2015

  35. Alissa Bonas @ Cloud Open Dublin 2015

  36. Resource quotas and limit ranges • Limit the number of

    pods, containers, etc. ◦ tracked per a project/namespace scope • Limit CPU and memory ◦ tracked per pod, container Alissa Bonas @ Cloud Open Dublin 2015
  37. Container • Traceability - node, container id, image Alissa Bonas

    @ Cloud Open Dublin 2015
  38. Image from a known registry Alissa Bonas @ Cloud Open

    Dublin 2015
  39. Image from an unknown source Alissa Bonas @ Cloud Open

    Dublin 2015
  40. Registries

  41. Pods • Which containers are part of it • Which

    services work with it • Which node does it run on • Is it controlled by a replicator? Alissa Bonas @ Cloud Open Dublin 2015
  42. Pod Alissa Bonas @ Cloud Open Dublin 2015

  43. Replicators Searches for pods with this label Alissa Bonas @

    Cloud Open Dublin 2015
  44. Services • A portal IP and source/target port pairs •

    Redirects traffic to relevant pods based on a labels selector Alissa Bonas @ Cloud Open Dublin 2015
  45. Service example Alissa Bonas @ Cloud Open Dublin 2015

  46. OpenShift Routes • Exposes a service by giving it an

    externally reachable hostname • Can be fine tuned by /path • Can be also secured Alissa Bonas @ Cloud Open Dublin 2015
  47. Events / Timeline • Node ◦ ready / not ready

    / rebooted • Pod ◦ scheduled • More to come... Alissa Bonas @ Cloud Open Dublin 2015
  48. Tagging • Leveraging ManageIQ tags Alissa Bonas @ Cloud Open

    Dublin 2015
  49. • “A picture is worth a thousand words” • Includes

    cross provider relationships • Status color indication Topology view Alissa Bonas @ Cloud Open Dublin 2015
  50. Topology live demo Alissa Bonas @ Cloud Open Dublin 2015

  51. A glimpse into the future

  52. Dashboard - providers overview

  53. Dashboard - a single provider view

  54. Dashboard of a project Alissa Bonas @ Cloud Open Dublin

    2015
  55. Smart State Analysis • Inspect the packages included in an

    image • Combined with vulnerabilities db, generate alerts for important security issues on running containers Alissa Bonas @ Cloud Open Dublin 2015
  56. Analysis of an image Alissa Bonas @ Cloud Open Dublin

    2015
  57. An image after analysis

  58. ManageIQ community • http://talk.manageiq.org • https://github.com/ManageIQ/manageiq ◦ Follow label #providers/containers

    • #manageiq IRC on freenode Alissa Bonas @ Cloud Open Dublin 2015
  59. Projects info • http://www.openshift.org/ • http://kubernetes.io/ • http://manageiq.org/ Alissa Bonas

    @ Cloud Open Dublin 2015
  60. Icons Credits • The Go gopher - Renee French •

    Diamond by MarkieAnn Packer, the Noun Project • Rails by Luis Martins, the Noun Project • Light Bulb by artworkbean, the Noun Project • Sherlock by James Keuning, the Noun Project • Twitter by Lubos Volkov, the Noun Project • Link by Vitor Fernandes, the Noun Project
  61. Thank you! @mikeyteva
