Managing Kubernetes and OpenShift with ManageIQ - ContainerCon Seattle

Managing Kubernetes and OpenShift with ManageIQ - ContainerCon Seattle

Managing Kubernetes and OpenShift with ManageIQ.
A talk on container management aspects.
Presented at Container Con (Linux Con) Seattle, 2015

4f477cfca5c1d10d09157c07cdfa3af4?s=128

Alissa Bonas

August 17, 2015
Tweet

Transcript

  1. Managing Kubernetes and OpenShift with ManageIQ Alissa Bonas @ Container

    Con Seattle 2015
  2. • Containerizing an app The stages of containers world Alissa

    Bonas @ Container Con Seattle 2015
  3. The stages of containers world • Run a container Alissa

    Bonas @ Container Con Seattle 2015
  4. The stages of containers world • Run multiple containers Alissa

    Bonas @ Container Con Seattle 2015
  5. • Orchestrate containers • Run many containers on multiple hosts

    • Manage a containers environment The stages of containers world Alissa Bonas @ Container Con Seattle 2015
  6. Today we’ll focus on Kubernetes OpenShift ManageIQ Alissa Bonas @

    Container Con Seattle 2015
  7. Kubernetes • Deployment, scaling and orchestration of containers across clusters

    of hosts. • http://kubernetes.io/ • 1.0 release - July 2015 Developed in Go Alissa Bonas @ Container Con Seattle 2015
  8. Kubernetes main concepts • Node - a machine that containers

    run on • Namespace - partitioning resources created by users into logical groups • Pod - a group of containers Alissa Bonas @ Container Con Seattle 2015
  9. Kubernetes main concepts • Replication controller - ensures there are

    always X replicas of pods • Service - a base load balancer that provides traffic to pods Alissa Bonas @ Container Con Seattle 2015
  10. OpenShift • Platform as a service for building and running

    applications - for developers • http://www.openshift.org/ • 3.0 release - June 2015 Developed in Go Alissa Bonas @ Container Con Seattle 2015
  11. OpenShift main concepts • Built on top of Kubernetes •

    Provides additional capabilities ◦ application lifecycle ◦ routing - extends service ◦ projects - extension of namespaces Build Deploy Run Alissa Bonas @ Container Con Seattle 2015
  12. • How many containers exist in my environment? • Does

    a specific node have enough resources? • How many distinct images are used? • Which registries are used? Insight and control Alissa Bonas @ Container Con Seattle 2015
  13. ManageIQ • A cloud management platform • http://manageiq.org/ • Botvinnik

    release - June 2015 a Ruby on Rails project Alissa Bonas @ Container Con Seattle 2015
  14. ManageIQ concepts • “A manager of managers” ◦ supports multiple

    virtualization providers • Insight and control ◦ inventory overview and events ◦ smart state analysis ◦ workflow/orchestration Alissa Bonas @ Container Con Seattle 2015
  15. New in upstream ManageIQ • Providers for container management •

    Support added for ◦ Kubernetes ◦ OpenShift Alissa Bonas @ Container Con Seattle 2015
  16. Working together ManageIQ Kubernetes / Openshift Master Node A Node

    B Alissa Bonas @ Container Con Seattle 2015
  17. Container management providers Alissa Bonas @ Container Con Seattle 2015

  18. Creating a provider • Kubernetes/OpenShift master host/port • SSL •

    Token based Alissa Bonas @ Container Con Seattle 2015
  19. Inventory • Entities • Relationships • Additional information Alissa Bonas

    @ Container Con Seattle 2015
  20. Creating more insights • Modelling additional entities as first class

    citizens • Deducing relationships Alissa Bonas @ Container Con Seattle 2015
  21. Kubernetes provider summary page Alissa Bonas @ Container Con Seattle

    2015
  22. Kubernetes provider relationships Alissa Bonas @ Container Con Seattle 2015

  23. OpenShift provider summary page Alissa Bonas @ Container Con Seattle

    2015
  24. OpenShift provider relationships Alissa Bonas @ Container Con Seattle 2015

  25. Projects Alissa Bonas @ Container Con Seattle 2015

  26. Nodes • OS and Software versions • How many entities

    are on a node • Capacity and utilization • Which infrastructure is it running on Alissa Bonas @ Container Con Seattle 2015
  27. Node Summary page Alissa Bonas @ Container Con Seattle 2015

  28. What do we know about nodes? Capacity Docker and Kubernetes

    info Alissa Bonas @ Container Con Seattle 2015
  29. Nodes • Quick overview on main nodes properties Alissa Bonas

    @ Container Con Seattle 2015
  30. Cross providers insight • Connect all layers of infrastructure, cloud

    and containers • Currently support cross linking with ◦ OpenStack ◦ oVirt / RHEV Alissa Bonas @ Container Con Seattle 2015
  31. Cross linking demystified Virtual Machines Hosts Nodes Pods Containers Storage

    Network Alissa Bonas @ Container Con Seattle 2015
  32. Cross linking demystified Virtual Machines Hosts Nodes Pods Containers Images

    Storage Network Services Routes Alissa Bonas @ Container Con Seattle 2015
  33. Cross provider example - Node Alissa Bonas @ Container Con

    Seattle 2015
  34. Cross provider VM example Alissa Bonas @ Container Con Seattle

    2015
  35. Nodes capacity and utilization

  36. None
  37. None
  38. Resource quotas and limit ranges • Limit the number of

    pods, containers, etc. ◦ tracked per a project/namespace scope • Limit CPU and memory ◦ tracked per pod, container Alissa Bonas @ Container Con Seattle 2015
  39. Container • Traceability - container id, image • Restart count

    - potential issues? Alissa Bonas @ Container Con Seattle 2015
  40. Registries Alissa Bonas @ Container Con Seattle 2015

  41. Image from a known registry Alissa Bonas @ Container Con

    Seattle 2015
  42. Image from an unknown source Alissa Bonas @ Container Con

    Seattle 2015
  43. Pods • Which containers are part of it • Which

    services work with it • Which node does it run on • Is it controlled by a replicator? Alissa Bonas @ Container Con Seattle 2015
  44. Pods Alissa Bonas @ Container Con Seattle 2015

  45. Pod Alissa Bonas @ Container Con Seattle 2015

  46. Replicators Searches for pods with this label Alissa Bonas @

    Container Con Seattle 2015
  47. Services • A portal IP and source/target port pairs •

    Redirects traffic to relevant pods based on a labels selector Alissa Bonas @ Container Con Seattle 2015
  48. Service example Alissa Bonas @ Container Con Seattle 2015

  49. OpenShift Routes • Exposes a service by giving it an

    externally reachable hostname • Can be fine tuned by /path • Can be also secured Alissa Bonas @ Container Con Seattle 2015
  50. Events / Timeline • Node ◦ ready / not ready

    / rebooted • Pod ◦ scheduled • More to come... Alissa Bonas @ Container Con Seattle 2015
  51. Tagging • Leveraging ManageIQ tags Alissa Bonas @ Container Con

    Seattle 2015
  52. A glimpse into the future

  53. Dashboard - providers overview

  54. Dashboard - a single provider view

  55. Dashboard of a project

  56. • “A picture is worth a thousand words” • Includes

    cross provider relationships • Statuses Topology Alissa Bonas @ Container Con Seattle 2015
  57. Topology demo

  58. Topology demo

  59. Open source • Rapidly changing projects before their release •

    Hard to track • A chance to influence early Alissa Bonas @ Container Con Seattle 2015
  60. ManageIQ community • http://talk.manageiq.org • https://github.com/ManageIQ/manageiq ◦ Follow label #providers/containers

    • #manageiq IRC on freenode Alissa Bonas @ Container Con Seattle 2015
  61. Icons Credits • The Go gopher - Renee French •

    Diamond by MarkieAnn Packer from the Noun Project • Rails by Luis Martins from the Noun Project • Light Bulb by artworkbean from the Noun Project • Sherlock by James Keuning
  62. Thank you! @mikeyteva
