  1. AWS A-B-C’s

    View Slide

  2. Page
    Disclaimer: not
    actually in
    alphabetical order
    / Copyright ©2014 by Readify Pty Ltd
    2

    View Slide

  3. Page
    A is for IAM
    › Identity and Access Management.
    › Allows you to define credentials with restricted
    capabilities that you can then use when working with
    the .net SDK / Powershell API.
    › Users are provisioned with a key pair that serves as
    your keys to your kingdom – you can only retrieve
    them once, so store in a safe place!
    / Copyright ©2014 by Readify Pty Ltd
    3

    View Slide

  4. Page
    Regions and Availability Zones
    › AWS resources can be deployed into Regions, which
    are hosted in geographically separate locations – for
    example us-west-2 is in Oregon, whereas ap-southeast-
    2 is in Sydney.
    › Each region has at least two Availability Zones, which
    are hosted in separate data-centres within the region,
    ensuring that we can provision our resources in a
    highly available fashion.
    / Copyright ©2014 by Readify Pty Ltd
    4

    View Slide

  5. Page
    VPC
    › Virtual Private Cloud.
    › Is defined for a single region.
    › Defines a set of available IP addresses, subnets and
    routes.
    › They are used to isolate our EC2 instances (and other
    bits and bobs) from the rest of our AWS infrastructure,
    and control access to the internet.
    / Copyright ©2014 by Readify Pty Ltd
    5

    View Slide

  6. Page
    VPC - Subnet
    › Defines a range of IP addresses that can be assigned to
    services.
    › Is defined for an availability zone within a region.
    › Instances a launched ‘into’ the subnet.
    › These IP addresses may be public or private, depending on the
    subnets preferences.
    › Subnets can talk to other subnets via Routing.
    › This controls ‘Who can I talk to?’
    / Copyright ©2014 by Readify Pty Ltd
    6

    View Slide

  7. Page
    VPC - Routing
    › Route tables are used to restrict or enable traffic to
    travel between subnets.
    › They also control access to the internet by allowing a
    subnet to be connected to an internet gateway or NAT
    box.
    › Instances in AWS are *not* connected to the internet
    by default – you need to ensure you have appropriate
    routing in place.
    / Copyright ©2014 by Readify Pty Ltd
    7

    View Slide

  8. Page
    EC2
    › Elastic Compute is virtual machines – IaaS.
    › EC2 instances are provisioned within a Subnet in a
    given VPC.
    › A range of ‘images’ are available that provide various
    Windows and Linux configurations out of the box.
    › EC2 instances are also associated with Security Groups
    that define what inbound and outbound connections
    are allowed.
    / Copyright ©2014 by Readify Pty Ltd
    8

    View Slide

  9. Page
    EC2 - Security Groups
    › Security Groups define a group-level firewall to protect
    instances within the group.
    › ‘What language can I talk?’.
    › For example, you may want to allow inbound TCP over
    3389 for remote desktop connectivity.
    › Don’t forget about your instance’s windows firewall
    though!
    / Copyright ©2014 by Readify Pty Ltd
    9

    View Slide

  10. Page
    EC2 – Load Balancers
    › Load balancers provide an auto-scaling public entry
    point to our EC2 instance.
    › They can redirect traffic from given ports, terminate
    SSL, and check the health of instances that are enrolled
    in them.
    / Copyright ©2014 by Readify Pty Ltd
    10

    View Slide

  11. Page
    EC2 – Auto scaling
    › Auto Scaling Groups allow us to automatically
    provision more instances on demand to meet load
    demand.
    › Instances are provisioned from a Launch Configuration
    which defines the ‘shape’ of the EC2 instance to launch
    into the ASG.
    / Copyright ©2014 by Readify Pty Ltd
    11

    View Slide

  12. Page
    S3
    › Simple Storage Solution.
    › Allows us to store files up in the clouds!
    › Files are stored in ‘buckets’, which is how S3 partitions
    content.
    › Can be used to host static websites.
    / Copyright ©2014 by Readify Pty Ltd
    12

    View Slide

  13. Page
    CloudFormation
    › Actually has a name that almost makes sense!
    › Orchestrates the creation of AWS resources for us.
    › Takes the pain of ‘resiliently’ standing up / tearing down
    this stuff out of the process.
    › Processes ‘templates’ defined in JSON.
    / Copyright ©2014 by Readify Pty Ltd
    13

    View Slide

  14. Page
    Honourable Mentions
    › RDS – Relational Database Service, Amazon’s PaaS SQL
    offering.
    › Route 53 – DNS services within AWS.
    › Elastic Beanstalk – PaaS compute, can be used to host
    IIS websites.
    › CloudWatch – monitoring service for your AWS
    resources.
    / Copyright ©2014 by Readify Pty Ltd
    14

    View Slide

  15. Page / Copyright ©2014 by Readify Pty Ltd
    15

    View Slide
