OAuth by Example - Workshop

Authentication and authorization has come a long way in the last ten years. Are you still rolling your own identity? Don't know the differences between the authorization code grant from and the client credentials grant? Do you want to accept social authentication to your service but you're not sure how?

Join Andy March as we review OAuth and OIDC, their history, the problems they solve and how you can apply them to your services. This workshop will guide you through configuring Okta as an identity provider, deploying a simple web app enforcing authentication and authorization.

Transcript

1. by example


   View Slide

2. 10+ years working in secure systems
   Hi!
   Platform Specialist at Okta
   Software Developer (.NET / Java / JS)
   @andymarch


   View Slide

3. Heroku.com/signup
   Get Hands On


   View Slide

4. View Slide

5. View Slide

6. View Slide

7. View Slide

8. Digital Identity
   Circa 2007
   Simple Login – forms and cookies
   Single Sign-on – SAML
   Delegated Access – passwords


   View Slide

9. Yelp ~ 2007


   View Slide

10. Facebook ~ 2010


    View Slide

11. View Slide

12. Specs are not tutorials


    View Slide

13. Delegated authorization with OAuth 2.0


    View Slide

14. Who’s who of OAuth 2.0
    Resource Owner Client Authorization Server Resource Server
    Guest Hotel Room
    Reception Desk
    Hotel


    View Slide

15. Register: redirect address
    ClientID, Client secret


    View Slide

16. ClientId
    (a unique identifier of an application)


    View Slide

17. ClientSecret
    (an authenticator for an application)


    View Slide

18. View Slide

19. Authorization Code Grant
    (the most common and most secure grant for users)


    View Slide

20. Redirect: AuthorizationServer, ClientID, Scope
    Login
    ClientID, Scope


    View Slide

21. Scope
    (a requested permission)


    View Slide

22. View Slide

23. View Slide

24. Consent
    (the user explicitly granting access)


    View Slide

25. AuthorizationCode
    Redirect: AuthorizationCode


    View Slide

26. Front Channel
    (server to server communication through a user’s browser)


    View Slide

27. AuthorizationCode
    client id, client secret
    Access Token
    Access Token


    View Slide

28. Back Channel
    (direct server to server communication)


    View Slide

29. Client Credentials Grant
    (the machine to machine grant)


    View Slide

30. client id, client secret, scopes
    Access Token
    Access Token


    View Slide

31. What is an access token anyway
    Sent by a client in calls to a service.
    Demonstrates a user has consented access to resources.
    Two varieties:
    - Reference tokens
    - Self encoded tokens


    View Slide

32. Access Token
    eyJraWQiOiJ5T1k4Y0dTdldRWHNheDRBWmpZV3JhZzhWU2ktYnJRaVVoM19wV0NmTF9ZIiwiYWx
    nIjoiUlMyNTYifQ.eyJ2ZXIiOjEsImp0aSI6IkFULjJHTGZUQ0puSG0yUDR1ZTl2aU81dEhMSE5
    xV2dUcWI3ZXhMY1lIbk11OVkiLCJpc3MiOiJodHRwczovL2V4YW1wbHkub2t0YS1lbWVhLmNvbS
    9vYXV0aDIvZGVmYXVsdCIsImF1ZCI6ImFwaTovL2RlZmF1bHQiLCJpYXQiOjE1NjU5NDcyODYsI
    mV4cCI6MTU2NTk1NDQ4NiwiY2lkIjoiMG9hMmhmc2hybWdyY2tlbXYwaTciLCJ1aWQiOiIwMHUy
    dzZmdzN4cXZnTHYyUDBpNyIsInNjcCI6WyJvcGVuaWQiXSwic3ViIjoidGVzdEB0ZXN0LmNvbSJ
    9.TgXMcCNGIpDvqa8EY75lbns_kcyVa6t7Qx5F97YxGd1Ci_iGYPtzBx8Qf2avQPWVcYJmA6mcx
    sBBeqzWMTcqWaGoSbt8N9MG1ma_JITIkEX2kZB2Vw66_X1vAwiKJ8_6ytoAVqcAkc2ulXdKp-
    XVGsCv1R011O70Hdp2tIzKNWH-wGV1uZDq5_dBGB4Pk6hkp7lQb-
    ix3WVBEEjyHUzMYFDki9vx_dvGuj2kaay_TPXVqc-
    OqClMd4O3vpwW3DZMCGB5vndAX49h61fbJUTShYGral-NC1XdI1dY1aTROGfetVC-
    k95zBTFVjwI_TsJe8qmVG9GLlO2fpkY4JdMhaA


    View Slide

33. Access Token
    eyJraWQiOiJ5T1k4Y0dTdldRWHNheDRBWmpZV3JhZzhWU2ktYnJRaVVoM19wV0NmTF9ZIiwiYWx
    nIjoiUlMyNTYifQ.eyJ2ZXIiOjEsImp0aSI6IkFULjJHTGZUQ0puSG0yUDR1ZTl2aU81dEhMSE5
    xV2dUcWI3ZXhMY1lIbk11OVkiLCJpc3MiOiJodHRwczovL2V4YW1wbHkub2t0YS1lbWVhLmNvbS
    9vYXV0aDIvZGVmYXVsdCIsImF1ZCI6ImFwaTovL2RlZmF1bHQiLCJpYXQiOjE1NjU5NDcyODYsI
    mV4cCI6MTU2NTk1NDQ4NiwiY2lkIjoiMG9hMmhmc2hybWdyY2tlbXYwaTciLCJ1aWQiOiIwMHUy
    dzZmdzN4cXZnTHYyUDBpNyIsInNjcCI6WyJvcGVuaWQiXSwic3ViIjoidGVzdEB0ZXN0LmNvbSJ
    9.TgXMcCNGIpDvqa8EY75lbns_kcyVa6t7Qx5F97YxGd1Ci_iGYPtzBx8Qf2avQPWVcYJmA6mcx
    sBBeqzWMTcqWaGoSbt8N9MG1ma_JITIkEX2kZB2Vw66_X1vAwiKJ8_6ytoAVqcAkc2ulXdKp-
    XVGsCv1R011O70Hdp2tIzKNWH-wGV1uZDq5_dBGB4Pk6hkp7lQb-
    ix3WVBEEjyHUzMYFDki9vx_dvGuj2kaay_TPXVqc-
    OqClMd4O3vpwW3DZMCGB5vndAX49h61fbJUTShYGral-NC1XdI1dY1aTROGfetVC-
    k95zBTFVjwI_TsJe8qmVG9GLlO2fpkY4JdMhaA


    View Slide

34. Access Token
    eyJraWQiOiJ5T1k4Y0dTdldRWHNheDRBWmpZV3JhZzhWU2ktYnJRaVVoM19wV0NmTF9ZIiwiYWx
    nIjoiUlMyNTYifQ
    eyJ2ZXIiOjEsImp0aSI6IkFULjJHTGZUQ0puSG0yUDR1ZTl2aU81dEhMSE5xV2dUcWI3ZXhMY1l
    Ibk11OVkiLCJpc3MiOiJodHRwczovL2V4YW1wbHkub2t0YS1lbWVhLmNvbS9vYXV0aDIvZGVmYX
    VsdCIsImF1ZCI6ImFwaTovL2RlZmF1bHQiLCJpYXQiOjE1NjU5NDcyODYsImV4cCI6MTU2NTk1N
    DQ4NiwiY2lkIjoiMG9hMmhmc2hybWdyY2tlbXYwaTciLCJ1aWQiOiIwMHUydzZmdzN4cXZnTHYy
    UDBpNyIsInNjcCI6WyJvcGVuaWQiXSwic3ViIjoidGVzdEB0ZXN0LmNvbSJ9
    TgXMcCNGIpDvqa8EY75lbns_kcyVa6t7Qx5F97YxGd1Ci_iGYPtzBx8Qf2avQPWVcYJmA6mcxsB
    BeqzWMTcqWaGoSbt8N9MG1ma_JITIkEX2kZB2Vw66_X1vAwiKJ8_6ytoAVqcAkc2ulXdKp-
    XVGsCv1R011O70Hdp2tIzKNWH-wGV1uZDq5_dBGB4Pk6hkp7lQb-
    ix3WVBEEjyHUzMYFDki9vx_dvGuj2kaay_TPXVqc-
    OqClMd4O3vpwW3DZMCGB5vndAX49h61fbJUTShYGral-NC1XdI1dY1aTROGfetVC-
    k95zBTFVjwI_TsJe8qmVG9GLlO2fpkY4JdMhaA


    View Slide

35. JWT Header
    {
    "typ": "JWT",
    "alg": "HS256"
    }


    View Slide

36. {
    "ver": 1,
    "jti": "AT.2GLfTCJnHm2P4ue9viO5tHLHNqWgTqb7exLcYHnMu9Y",
    "iss": "https://examply.okta-emea.com/oauth2/default",
    "aud": "api://default",
    "iat": 1565947286,
    "exp": 1565953668,
    "cid": "0oa2hfshrmgrckemv0i7",
    "uid": "00u2w6fw3xqvgLv2P0i7",
    "scp": [
    ”profile"
    ],
    "sub": "test@test.com"
    }
    JWT Payload


    View Slide

37. TgXMcCNGIpDvqa8EY75lbns_kcyVa6t7Qx5F97YxGd1Ci_iGYPtzBx8Qf2avQPWVcYJmA6mcxsB
    BeqzWMTcqWaGoSbt8N9MG1ma_JITIkEX2kZB2Vw66_X1vAwiKJ8_6ytoAVqcAkc2ulXdKp-
    XVGsCv1R011O70Hdp2tIzKNWH-wGV1uZDq5_dBGB4Pk6hkp7lQb-
    ix3WVBEEjyHUzMYFDki9vx_dvGuj2kaay_TPXVqc-
    OqClMd4O3vpwW3DZMCGB5vndAX49h61fbJUTShYGral-NC1XdI1dY1aTROGfetVC-
    k95zBTFVjwI_TsJe8qmVG9GLlO2fpkY4JdMhaA
    JWT Signature


    View Slide

38. View Slide

39. Local Token Validation
    Check the signature
    Check the audience
    Check the issuance timestamp
    Check the expiry timestamp


    View Slide

40. View Slide

41. View Slide

42. View Slide

43. Remote Token Validation: Introspection
    http://examply.okta-emea.com/oauth2/default/v1/introspect
    Authorization Basic ${Base64(:)}
    token=“bdfFGEW3g[…]sdChg7a4n8”
    token_type_hint=access_token
    {
    "active": true
    }
    Request
    Response


    View Slide

44. View Slide

45. Simple Login – OAuth 2.0
    Single Sign-on – OAuth 2.0
    Mobile app login – OAuth 2.0
    Delegated Access – OAuth 2.0
    Digital Identity
    Circa 2012
    Authentication
    Authentication
    Authentication
    Authorization


    View Slide

46. OpenID


    View Slide

47. OpenID Connect Default Scopes
    Openid
    Indicates an OpenId request
    Profile
    Access to the user’s profile
    Email
    Access to the user’s email address
    Address
    Access to the user’s physical address
    Phone
    Access to the user’s telephone number
    Offline_access
    Request refresh token for continued access


    View Slide

48. eyJraWQiOiJ5T1k4Y0dTdldRWHNheDRBWmpZV3JhZzhWU2ktYnJRaVVoM19wV0NmTF9ZIiwiYWx
    nIjoiUlMyNTYifQ.eyJzdWIiOiIwMHUydzZmdzN4cXZnTHYyUDBpNyIsInZlciI6MSwiaXNzIjo
    iaHR0cHM6Ly9leGFtcGx5Lm9rdGEtZW1lYS5jb20vb2F1dGgyL2RlZmF1bHQiLCJhdWQiOiIwb2
    EyaGZzaHJtZ3Jja2VtdjBpNyIsImlhdCI6MTU2NTk2MTYzNCwiZXhwIjoxNTY1OTY1MjM0LCJqd
    GkiOiJJRC54b3dfc21BM3I5Y19uRVN1N2VBZ2JQMElWREV1cVpkRkg1NmlpN0NnZnB3IiwiYW1y
    IjpbInB3ZCJdLCJpZHAiOiIwMG8yYXoyaWVycUt1T1QwRDBpNyIsIm5vbmNlIjoieHc5czJiZXM
    zdCIsImF1dGhfdGltZSI6MTU2NTk2MTYxMCwiYXRfaGFzaCI6IjZzdGd1WU9fV3A2Q1Y0NXAxSF
    NsQ1EiLCJ0ZXN0Y2xhaW0iOlsiRXZlcnlvbmUiXX0.Il6htgtZeH9vhN1xXB05DWvNG9V-
    xiVAki3qEaj8jxI2jkHshq-2lhy_wmaZpjeDUGQNCIwv-
    1K3JkckW4cFzmDn0Dw6hCykN5EEFLGfkBeO-
    25nV64UZUHFDAGH_jhI5v5ARGKZcQQIwf3saeakA2rVkXDAYW8SWwbt96hwFkH15JolTK0YVf1h
    nRX9hzrkKPJY9JgIhmDsMciLvMOPs93ViAR4ufUp_hVYLSsR6Uq-
    PDR33eoX9XqktylviG9K9BoRzqu8muM1nqrwZAFUk61CeTRNhR5nI30-NH0bcZhAY2Ts8Q-
    Pj41m8t_7LIVYbUqxvC0JhcdKbmCNN3FRVw
    ID Tokens


    View Slide

49. eyJraWQiOiJ5T1k4Y0dTdldRWHNheDRBWmpZV3JhZzhWU2ktYnJRaVVoM19wV0NmTF9ZIiwiYWx
    nIjoiUlMyNTYifQ.eyJzdWIiOiIwMHUydzZmdzN4cXZnTHYyUDBpNyIsInZlciI6MSwiaXNzIjo
    iaHR0cHM6Ly9leGFtcGx5Lm9rdGEtZW1lYS5jb20vb2F1dGgyL2RlZmF1bHQiLCJhdWQiOiIwb2
    EyaGZzaHJtZ3Jja2VtdjBpNyIsImlhdCI6MTU2NTk2MTYzNCwiZXhwIjoxNTY1OTY1MjM0LCJqd
    GkiOiJJRC54b3dfc21BM3I5Y19uRVN1N2VBZ2JQMElWREV1cVpkRkg1NmlpN0NnZnB3IiwiYW1y
    IjpbInB3ZCJdLCJpZHAiOiIwMG8yYXoyaWVycUt1T1QwRDBpNyIsIm5vbmNlIjoieHc5czJiZXM
    zdCIsImF1dGhfdGltZSI6MTU2NTk2MTYxMCwiYXRfaGFzaCI6IjZzdGd1WU9fV3A2Q1Y0NXAxSF
    NsQ1EiLCJ0ZXN0Y2xhaW0iOlsiRXZlcnlvbmUiXX0.Il6htgtZeH9vhN1xXB05DWvNG9V-
    xiVAki3qEaj8jxI2jkHshq-2lhy_wmaZpjeDUGQNCIwv-
    1K3JkckW4cFzmDn0Dw6hCykN5EEFLGfkBeO-
    25nV64UZUHFDAGH_jhI5v5ARGKZcQQIwf3saeakA2rVkXDAYW8SWwbt96hwFkH15JolTK0YVf1h
    nRX9hzrkKPJY9JgIhmDsMciLvMOPs93ViAR4ufUp_hVYLSsR6Uq-
    PDR33eoX9XqktylviG9K9BoRzqu8muM1nqrwZAFUk61CeTRNhR5nI30-NH0bcZhAY2Ts8Q-
    Pj41m8t_7LIVYbUqxvC0JhcdKbmCNN3FRVw
    ID Tokens


    View Slide

50. eyJraWQiOiJ5T1k4Y0dTdldRWHNheDRBWmpZV3JhZzhWU2ktYnJRaVVoM19wV0NmTF9ZIiwiYWx
    nIjoiUlMyNTYifQ
    eyJzdWIiOiIwMHUydzZmdzN4cXZnTHYyUDBpNyIsInZlciI6MSwiaXNzIjoiaHR0cHM6Ly9leGF
    tcGx5Lm9rdGEtZW1lYS5jb20vb2F1dGgyL2RlZmF1bHQiLCJhdWQiOiIwb2EyaGZzaHJtZ3Jja2
    VtdjBpNyIsImlhdCI6MTU2NTk2MTYzNCwiZXhwIjoxNTY1OTY1MjM0LCJqdGkiOiJJRC54b3dfc
    21BM3I5Y19uRVN1N2VBZ2JQMElWREV1cVpkRkg1NmlpN0NnZnB3IiwiYW1yIjpbInB3ZCJdLCJp
    ZHAiOiIwMG8yYXoyaWVycUt1T1QwRDBpNyIsIm5vbmNlIjoieHc5czJiZXMzdCIsImF1dGhfdGl
    tZSI6MTU2NTk2MTYxMCwiYXRfaGFzaCI6IjZzdGd1WU9fV3A2Q1Y0NXAxSFNsQ1EiLCJ0ZXN0Y2
    xhaW0iOlsiRXZlcnlvbmUiXX0
    Il6htgtZeH9vhN1xXB05DWvNG9V-xiVAki3qEaj8jxI2jkHshq-2lhy_wmaZpjeDUGQNCIwv-
    1K3JkckW4cFzmDn0Dw6hCykN5EEFLGfkBeO-
    25nV64UZUHFDAGH_jhI5v5ARGKZcQQIwf3saeakA2rVkXDAYW8SWwbt96hwFkH15JolTK0YVf1h
    nRX9hzrkKPJY9JgIhmDsMciLvMOPs93ViAR4ufUp_hVYLSsR6Uq-
    PDR33eoX9XqktylviG9K9BoRzqu8muM1nqrwZAFUk61CeTRNhR5nI30-NH0bcZhAY2Ts8Q-
    Pj41m8t_7LIVYbUqxvC0JhcdKbmCNN3FRVw
    ID Tokens


    View Slide

51. {
    "typ": "JWT",
    "alg": "RS256",
    "kid": "yOY8cGSvWQXsax4AZjYWrag8VSi-brQiUh3_pWCfL_Y"
    }
    ID Token Header


    View Slide

52. {
    "sub": "00u2w6fw3xqvgLv2P0i7",
    "ver": 1,
    "iss": "https://examply.okta-emea.com/oauth2/default",
    "aud": "0oa2hfshrmgrckemv0i7",
    "iat": 1565961634,
    "exp": 1565965234,
    "jti": "ID.xow_smA3r9c_nESu7eAgbP0IVDEuqZdFH56ii7Cgfpw",
    "amr": [
    "pwd"
    ],
    "idp": "00o2az2ierqKuOT0D0i7",
    "nonce": ”number_only_once",
    "auth_time": 1565961610,
    "at_hash": "6stguYO_Wp6CV45p1HSlCQ",
    }
    ID Token Payload


    View Slide

53. Access Token vs ID Token
    OAuth specification
    Audience is the resource server
    Describes the granted access by the user
    OpenId Specification
    Audience is the client
    Describes the authentication of the user


    View Slide

54. Simple Login – OpenID Connect
    Single Sign-on – OpenID Connect
    Mobile App Login – OpenID Connect
    Delegated Access – OAuth 2.0
    Digital Identity
    Today


    View Slide

55. andymarch.co.uk/oauthbyexample
    Get Hands On


    View Slide

56. Resources


    View Slide

57. OAuth 2.0 Playground


    View Slide

58. OAuth 2.0 Simplified
    Written by Aaron Parecki, Senior Security Architect @ Okta
    Member of the OAuth working group
    Maintainer of OAuth.net


    View Slide

59. OAuth.net


    View Slide

60. OIDCDebugger.com


    View Slide

61. Developer.okta.com
    andy.march@okta.com
    @andymarch


    View Slide
