Building Distributed System with Akka

Transcript

1. Building Distributed System with Akka
   Anil Wadghule

   @anildigital


   View Slide

2. !✈#


   View Slide

3. View Slide

4. View Slide

5. View Slide

6. Current scene in internet


   View Slide

7. Size of the internet


   View Slide

8. Market forces leading to change
   Concurrent connections
   •“Internet of Things”, mobile devices
   Big data
   •Size of data is overwhelming our ability to manage it
   Response times
   •Real-time results (e.g. analytics) with sub-second
   latencies


   View Slide

9. Physical factors leading to change
   •Expensive hardware → cheap hardware
   •A single machine → cluster of machines
   •A single core → multiple cores
   •Slow networks → fast networks
   •Small data snapshots → big data, streams of data


   View Slide

10. Modern Application Requirements
    High
    Availability
    Fault
    Tolerance
    Scalability


    View Slide

11. Google going down? Accepted?


    View Slide

12. Google going down? Accepted?
    Highly
    Available


    View Slide

13. Millions people visit Google


    View Slide

14. Millions people visit Google
    Highly
    Scalable


    View Slide

15. Facebook doesn’t crash in afternoon


    View Slide

16. Fault
    Tolerant
    Facebook doesn’t crash in afternoon


    View Slide

17. Reactive Principles


    View Slide

18. What is a Distributed System?


    View Slide

19. Your computer?


    View Slide

20. Your computer?


    View Slide

21. Your computer? NO.


    View Slide

22. No global clock
    Distributed Systems


    View Slide

23. You have a distributed system,
    when the crash of a computer
    you’ve never heard of, stops you
    from getting any work done.
    Leslie Lamport: A Guide to Building Dependable Distributed Systems.


    View Slide

24. A collection of independent
    computers that appear to its
    users as one computer.
    Tanenbaum and Steen: Distributed Systems, Principles and
    Paradigms


    View Slide

25. Collection of interconnected
    nodes


    View Slide

26. Distributed Architecture


    View Slide

27. 8 Fallacies of Distributed System
    •The network is reliable.
    •Latency is zero.
    •Bandwidth is infinite.
    •The network is secure.
    •Topology doesn't change.
    •There is one administrator.
    •Transport cost is zero.
    •The network is homogeneous.


    View Slide

28. Distributed System Examples
    •amazon.com
    •Cassandara database
    (unlike local Sqlite db)


    View Slide

29. How do we scale?


    View Slide

30. Coffeeshop Example


    View Slide

31. Regular small app
    o o
    One
    Americano
    Please!
    Akira


    View Slide

32. Regular small app
    o o
    Akira - Americano
    Head

    Barista
    Assistant

    Baristas


    View Slide

33. Starbucks goes popular
    •Starbucks needs to serve
    more customers now


    View Slide

34. Scaling Strategies
    •Read Replication
    •Sharding
    •Consistent Hashing


    View Slide

35. Read Replication


    View Slide

36. o o
    Akira - Americano
    Akira - Americano
    Akira - Americano
    Akira - Americano
    Akira - Americano
    Read Replication
    Akira - Americano
    Head

    Barista
    Assistant

    Baristas


    View Slide

37. Issues for Read Replication
    •Complexity
    •Consistency


    View Slide

38. Sharding


    View Slide

39. Sharding
    •Add more writers (i.e. Head
    Baristas)
    •Split orders with some key
    (i.e. Customers name )


    View Slide

40. Sharding
    o o
    Akira - Americano
    Akira - Americano
    Akira - Americano
    Akira - Americano
    o o
    Akira - Americano
    Koichi - Cappuccino
    Akira to Chang

    Barista 1
    Jim to Lorenzo

    Barista 2
    A-C
    J-L
    Akira - Americano
    Akira - Americano
    Koichi - Cappuccino
    Koichi - Cappuccino
    Koichi - Cappuccino
    Koichi - Cappuccino
    Koichi - Cappuccino
    Koichi - Cappuccino


    View Slide

41. Issues with Sharding
    •Limited data model
    •More complexity
    •Limited data access patterns
    •Only good for certain kind of
    applications e.g. SAAS apps


    View Slide

42. Consistent Hashing


    View Slide

43. Consistent Hashing and Random Trees
    Karger et al. at MIT, 1997


    View Slide

44. 0000
    2000
    4000
    6000
    8000
    10000
    12000
    14000
    Akira-Americano


    View Slide

45. 0000
    2000
    4000
    6000
    8000
    10000
    12000
    14000
    9F72-Americano


    View Slide

46. 0000
    2000
    4000
    6000
    8000
    10000
    12000
    14000
    9F72-Americano
    9F72 > 8000


    View Slide

47. What if node crashes?


    View Slide

48. 0000
    2000
    4000
    6000
    8000
    10000
    12000
    14000
    Node crashes
    9F72-Americano


    View Slide

49. 0000
    2000
    4000
    6000
    8000
    10000
    12000
    14000
    9F72-Americano
    9F72-Americano
    9F72-Americano
    N = 3

    Replication Factor


    View Slide

50. Consistency formula
    R + W > N
    • N = Total number of replicas (e.g. 3)
    • W = Number of replicas acknowledge my update
    • R = Number of replicas that agree on read


    View Slide

51. When to use consistent hashing?
    •Scale
    •Transactional data (Business
    transactions .. not ACID) Data
    which changes a lot
    •Always available


    View Slide

52. CAP Theorem


    View Slide

53. Consistency
    Availability Partition Tolerance


    View Slide

54. Consistency


    View Slide

55. Availability


    View Slide

56. Partition Tolerance


    View Slide

57. CAP Theorem
    •Partitioning can’t be
    negotiated. It’s reality.
    •You have to compromise
    Availability or Consistency


    View Slide

58. Distributed Transactions


    View Slide

59. ACID?
    Distributed Transactions


    View Slide

60. Ordering Coffee
    •Receive Order
    •Process Payment
    •Enqueue order (mark the cup)
    •Make Coffee
    •Deliver Drink


    View Slide

61. Why split the work?
    •Parallelization
    •Uneven workloads


    View Slide

62. What could go wrong?
    •Payment failure
    •Insufficient resources
    •Equipment failure
    •Worker failure
    •Consumer failure


    View Slide

63. Response to failure?
    •Write-off (throw it out)
    •Retry (Typical)
    •Compensating action


    View Slide

64. Distributed Transactions
    •How can we design a coffeeshop
    with atomic transaction?


    View Slide

65. Distributed Computation


    View Slide

66. Distributed Computation Strategies
    •Scatter-Gather
    •Map Reduce


    View Slide

67. Fault Tolerance


    View Slide

68. Fault Tolerant System
    •Embraces the notion of failure


    View Slide

69. Ideal world system has
    •Two paths
    •Components that can never fail
    •Accounting for every possible
    fault by providing a recovery
    action


    View Slide

70. Most regular applications
    •Catch-all mechanism
    •Terminate as soon as
    uncaught failure arises


    View Slide

71. FileWatcher LogFile
    LogProcessor
    Row
    Log Processor
    Log Processor
    DbWriter
    Database
    Connection
    The database connection might break
    Java Concurrent Logs Processor


    View Slide

72. runnable.run()
    runnable.run()
    runnable.run()
    dbWriter.write(row5)
    runnable.run()
    DBBrokenConnectionException
    DBBrokenConnectionException
    DBBrokenConnectionException
    con.write(row5)
    Exception moves up
    the stack on the
    thread.
    We don’t have the
    connection details
    here to re-create
    dbWriter
    and retro
    dbWriter
    logProcessor
    FileWatcher
    thread
    logProcessor.process
    (file)
    Runnable
    dbWriter Writes using db Connection
    Exception can happen from different threads
    Many log processors are called to process files from several threads.
    Java Concurrent Logs Processor


    View Slide

73. Difficult to recover
    •Exception moves up in stack
    •Making processed lines and connection
    info available
    •Breaks simple design
    •Violates best practices (Encapsulation,
    DI, SRP)


    View Slide

74. What we need is
    •Faulty component replaced
    in a threadsafe manner


    View Slide

75. Fault tolerant requirements
    •Fault Isolation
    •Structure
    •Redundancy
    •Replacement
    •Reboot
    •Suspend
    •Separation of concerns


    View Slide

76. Resilience


    View Slide

77. Capacity to recover from
    difficulties


    View Slide

78. Why care about resiliency?
    •Financial losses
    •Losing customers
    •Affecting customers


    View Slide

79. Actor Model


    View Slide

80. Actor Model
    Carl Hewitt, 1973


    View Slide

81. Actors
    •Higher level abstraction to write
    concurrent and distributed programs
    •To concurrently manageable state
    •Communication with Actor is by
    sending messages


    View Slide

82. Akka


    View Slide

83. Akka
    •Created July 2009 by Jonas
    Bonér
    •https://github.com/akka/akka
    •Written in Scala


    View Slide

84. Akka
    •Open-source toolkit
    •Simplifies
    •Concurrency
    •Distribution


    View Slide

85. Akka
    •Actor Model on JVM
    •Emphasizes actor-based
    concurrency (inspiration drawn from
    Erlang)


    View Slide

86. Why Akka?


    View Slide

87. Let it crash
    • Akka provides two separate
    flows:
    • Normal flow
    • Fault recovery flow


    View Slide

88. Let it crash
    •The normal flow consists
    • Actors that handle normal messages
    •The recovery flow consists
    • Actors that monitor the actors in the
    normal flow.


    View Slide

89. FileWatcher
    Disk Error Stop Corrupt
    FileException
    Resume Restart
    DbBrokeConnection
    Exception
    LogProcessor DbWriter
    LogProcessingSupervisor
    Escalate
    Actors in the log-processing application
    do not concern themselves with fault
    recovery
    Supervisors can decide to
    escalate problem to higher level
    The LogProcessingSupervisor
    create all the actors at startup
    and supervises them all
    Akka Concurrent Logs Processor


    View Slide

90. LogProcessingSupervisor
    FileWatcher
    LogProcessor
    DbWriter
    DiskError Stop
    CorruptFileException Resume
    Db Broken
    Connection
    Exception
    Restart
    DbNodeDownException
    logProcessor
    Stop
    The LogProcessor also watches
    the dbWriter and replaces it once
    it is terminated due to a
    DbNodeDownException
    Akka Concurrent Logs Processor


    View Slide

91. Benefits of Let it Crash
    •Fault isolation
    •Structure 
    •Redundancy 
    •Replacement 
    •Reboot 
    •Component lifecylcle
    •Suspend 
    •Separation of
    concerns 


    View Slide

92. Akka - What’s in it?


    View Slide

93. Akka Layers
    Akka Core
    Akka IO
    Akka Remote (Implements Distribution)
    Akka Cluster (Mobility)
    Akka Cluster Extensions (Pattern
    Singleton, Sharding, PubSub)


    View Slide

94. Akka provides
    •Local actor
    •Remote actor
    •Scheduling
    •Routing
    •Cluster
    •Cluster Singleton
    •Sharding
    •Persistence
    •Distributed Data


    View Slide

95. Local Actor on
    JVM1
    Local Actor on JVM


    View Slide

96. Local Actor on JVM
    Local Actor on
    JVM1
    Coordinator Actor


    View Slide

97. Local Actor on JVM
    Coordinator Actor
    println(“Hello World”)


    View Slide

98. class Worker extends Actor {
    def receive = {
    case x =>
    println(x)
    }
    }
    val system = ActorSystem("ExampleActorSystem")
    val workerActorRef = system.actorOf(Props[Worker])
    workerActorRef | "Hello World"


    View Slide

99. Akka Remoting


    View Slide

100. Actor on JVM 1 Actor on JVM 2
     Akka Remoting


     View Slide

101. val workerActorRef = system.actorOf(Props[Worker])
     workerActorRef ! "Hello Conference"
     val workerActorRef =
     context.actorSelection("akka:tcp://
     ExampleActorSystem@127.0.0.1:9005/usr/WorkerActor")
     workerActorRef ! "Hello World"


     View Slide

102. akka {
     actor {
     provider = "akka.remote.RemoteActorRefProvider"
     }
     remote {
     enabled-transports = ["akka.remote.netty.tcp"]
     netty.tcp {
     hostname = "127.0.0.1"
     port = 2552
     }
     }
     }


     View Slide

103. Akka Cluster


     View Slide

104. Akka Cluster
     •Fault Tolerant Membership service for
     Akka nodes built on top of Akka Remoting
     •No Single point of failure or bottleneck
     •Provides support of load balancing or fail
     over


     View Slide

105. Akka Cluster
     •Allows dynamically grow or
     shrink number of nodes
     •Actor could reside anywhere in
     the cluster.. local or remote.


     View Slide

106. Akka Cluster Node Types
     Node
     Cluster
     Leader
     Seed
     Node
     Node
     Node


     View Slide

107. Cluster
     (node 1, node 2, node 3, node 4)
     Node 1
     Node 2
     Node 3
     Node 4
     User
     a b
     c d e
     User
     a b
     c d e
     User
     a b
     c d e
     User
     a b
     c d e
     This cluster is ring of Nodes
     Every node contains an actor system.
     The actor system needs to have the
     same name to be part of
     the same cluster.
     A list of member nodes
     Is maintained in a
     current cluster state. The actor
     systems gossip to each
     other about this state
     Akka Cluster


     View Slide

108. Akka Cluster features
     •Cluster membership
     •Load balancing
     •Node partitioning
     •Partition Points
     •Gossip & Convergence
     •Failure Detection


     View Slide

109. Akka Gossip Protocol
     •Decentralised, probabilistic, viral
     communication protocol with
     convergence
     •Each node hold the state of the
     cluster and tell neighbours about it


     View Slide

110. Gossip (Communication Between Nodes)
     7
     7
     7
     Convergence


     View Slide

111. Gossip (Communication Between Nodes)
     7
     7
     7
     Convergence
     7
     7


     View Slide

112. How do we detect when
     node fails?


     View Slide

113. Failure Detector


     View Slide

114. Failure Detector
     7
     !
     7
     Failure Detection
     7
     7


     View Slide

115. Failure Detector
     7 7
     7
     7
     7 7
     7
     7


     View Slide

116. Cluster
     Seed nodes (1, 2, 3)
     Master nodes (4, 5)
     Worker nodes (6, 7, 8)
     Node 1:
     Seed Role
     Node 3:
     Seed Role
     Node 2:
     Seed Role
     Node 4:
     Master Role
     Node 7:
     Worker Role
     Node 8:
     Worker Role
     Node 5:
     Master Role
     Node 6:
     Worker Role
     Minimal setup cluster.
     3 seeds
     2 master
     3 workers


     View Slide

117. Cluster
     Seed Nodes: 1
     Node 1:
     Seed Role


     View Slide

118. Cluster
     Seed Nodes: (1, 2)
     Joining: (3)
     Node 1:
     Seed Role
     Node 2:
     Seed Role
     Node 3:
     Seed Role
     Join


     View Slide

119. Cluster
     Seed Nodes: (1, 2, 3)
     Joining nodes: (4, 5)
     Node 1:
     Seed Role
     Node 2:
     Seed Role
     Node 4: Worker Role
     seed list (1, 2, 3)
     Join
     Node 3:
     Seed Role
     Node 5: Master Role
     seed list (1, 2, 3)
     Node 3
     responds fastest
     and handles
     join of node 5
     Node 2
     responds fastest
     and handles
     join of node 4


     View Slide

120. Cluster
     Seed nodes: (2)
     Master nodes: (5)
     Worker nodes: (4)
     Joining nodes: (6, 7)
     Node 1:
     Seed Role
     Node 2:
     Seed Role
     Node 7: Worker Role
     seed list (1, 2, 3)
     Join
     Node 3:
     Seed Role
     Node 5: Master Role
     seed list (1, 2, 3)
     Node 2
     responds fastest
     and handles
     join of node 4
     Leave
     Leave
     Node 4:
     Worker Role
     Node 5:
     Master Role
     Node 6: Worker
     Role
     seed list (1, 2, 3)
     Join


     View Slide

121. Cluster
     Seed nodes (1, 2, 3)
     Master nodes (4, 5)
     Worker nodes (6, 7, 8)
     Node 1:
     Seed Role
     Node 3:
     Seed Role
     Node 2:
     Seed Role
     Node 4:
     Master Role
     Node 7:
     Worker Role
     Node 8:
     Worker Role
     Node 5:
     Master Role
     Node 6:
     Worker Role
     Minimal setup cluster.
     3 seeds
     2 master
     3 workers


     View Slide

122. Cluster
     Leader: Node 1
     Node 1: Leaving
     Node 2: Up
     Node 3: Up
     Seed node 1
     Seed node 2 Seed node 3
     Leave


     View Slide

123. Cluster
     Leader: Node 1
     Node 1: Exiting
     unreachable
     Node 2: Up
     Node 3: Up
     Seed node 1
     cluster node
     Is shutdown
     Seed node 2 Seed node 3
     Leave


     View Slide

124. Cluster
     Leader: Node 2
     Node 1: Removed
     Node 2: Up
     Node 3: Up
     Seed node 2 Seed node 3


     View Slide

125. Joining Up Leaving
     Unreachable
     Down
     Initial state
     Final state
     State in transition
     Key
     Join Leader action Leader
     Exiting
     Leader action
     Leader action
     Down
     Removed


     View Slide

126. Akka Cluster Patterns
     •Singleton
     •Sharding
     •Routing
     •Distributed Pub Sub


     View Slide

127. Cluster Singleton


     View Slide

128. Cluster Singleton
     b
     a
     e
     d
     c
     S


     View Slide

129. Cluster Singleton
     b
     a
     e
     d
     c
     S


     View Slide

130. Cluster Singleton
     b e
     d
     c
     S


     View Slide

131. Akka Cluster Sharding


     View Slide

132. Cluster Sharding
     •To distribute actors across several
     nodes
     •Interact with them with logical
     identifier (without knowing physical
     location)


     View Slide

133. Node
     Shard
     E E
     E E
     E
     Shard Region
     Shard
     Coordinator
     Akka Cluster Sharding


     View Slide

134. Akka Persistence


     View Slide

135. Akka Persistence
     •Stateful actors to persist their
     internal state.
     •State can be recovered when actor is
     started, restarted


     View Slide

136. Akka Persistence
     •Implemented using Event Sourcing
     •Only Changes to actor’s internal state
     are stored
     •Current state is never stored directly.


     View Slide

137. Akka Distributed Data


     View Slide

138. Distributed Data
     •A set of merge-friendly data types
     to maintain state across cluster


     View Slide

139. Distributed Data
     •Useful to share data between nodes
     in Akka Cluster
     •Based on Conflict Free Replicated
     Data Types (CRDTs).


     View Slide

140. Akka makes distributed systems
     less difficult


     View Slide

141. References
     • Akka in Action - Raymond Roestenburg,
     • https://speakerd.s3.amazonaws.com/presentations/
     9a6b0f62b9ee4dc8980e5ff590f1a6cf/sheridan_college.pdf
     • Distributed Systems in One Lesson http://shop.oreilly.com/product/0636920039518.do
     by Tim Berglund
     • Learning Akka - Salma Khater
     • Hands on Introduction to Distributed Systems Concepts with Akka Clustering - by David
     Russell
     • A tour of the (advanced) Akka features in 60 minutes by Johan Janssen
     • Go distributed (and scale out) with Actors and Akka Clustering


     View Slide

142. Thank you!


     View Slide

143. Questions?
     @anildigital


     View Slide
