Statically Identifying Class Dependencies in Legacy JavaScript Systems: First Results (SANER ERA 2017)

Statically Identifying Class Dependencies in Legacy JavaScript Systems: First Results (SANER ERA 2017)

Identifying dependencies between classes is an essential activity when maintaining and evolving software applications. It is also known that JavaScript developers often use classes to structure their projects. This happens even in legacy code, i.e., code implemented in JavaScript versions that do not provide syntactical support to classes. However, identifying associations and other dependencies between classes remain a challenge due to the lack of static type annotations. This paper investigates the use of type inference to identify relations between classes in legacy JavaScript code. To this purpose, we rely on Flow, a state-of-theart type checker and inferencer tool for JavaScript. We perform a study using code with and without annotating the class import statements in two modular applications. The results show that precision is 100% in both systems, and that the annotated version improves the recall, ranging from 37% to 51% for dependencies in general and from 54% to 85% for associations. Therefore, we hypothesize that these tools should also depend on dynamic analysis to cover all possible dependencies in JavaScript code.

ASERG, DCC, UFMG

February 24, 2017
Tweet

More Decks by ASERG, DCC, UFMG

Other Decks in Research

Transcript

  1. Statically Identifying Class
    Dependencies in Legacy
    JavaScript Systems: First Results
    Leonardo Silva (IFNMG, Brazil)
    Marco T. Valente (UFMG, Brazil)
    Alexandre Bergel (University of Chile)
    SANER ERA, 2017

    View Slide

  2. JavaScript dominates the web…
    2
    src: https://www.codementor.io/learn-programming

    View Slide

  3. The language is prototype-based
    3
    But it is possible to emulate classes in
    JavaScript
    JavaScript

    View Slide

  4. 4
    4
    // function -> class
    function Circle (radius) {
    // property -> attribute
    this.radius = radius;
    }
    // function -> method
    Circle.prototype.getArea = function () {
    return (3.14 * this.radius * this.radius)
    }
    // Circle instance -> object
    var myCircle = new Circle (10);
    Classes in legacy JavaScript
    ECMAScript 5

    ( ES5 )
    JS version

    View Slide

  5. 5
    Heuristics for Class
    Identification
    Previous Work
    • Does Javascript Software Embrace Classes? SANER, 2015
    • JSClassFinder: A Tool to Detect Class-like Structures in
    JavaScript. CBSoft Tools, 2015

    View Slide

  6. 6
    Goal: Use type inference to identify

    class-to-class dependencies

    View Slide

  7. Type Inferencer
    https://flowtype.org/
    7

    View Slide

  8. Proposed Approach
    8

    View Slide

  9. Evaluation Design
    1. Select two TypeScript systems
    2. Build an “oracle” with all dependencies
    3. Transpile TypeScript to JavaScript
    4. Apply the proposed approach
    5. Measure precision and recall
    9

    View Slide

  10. Research Questions
    • RQ1: What is the accuracy of the proposed
    approach in detecting class dependencies?
    • RQ2: Do module annotations improve the accuracy
    of the proposed approach?
    10
    var X: Class = require(“fileX.js");

    View Slide

  11. 11
    RQ1 - Accuracy of the Proposed Approach
    System
    All Dependencies Associations
    Precision Recall Precision Recall
    INVERSIFYJS 100% 6% 100% 19%
    SATELLIZER 100% 44% 100% 85%

    View Slide

  12. 12
    RQ2 - Accuracy Using Module Annotations
    System
    All Dependencies Associations
    Precision Recall Precision Recall
    INVERSIFYJS 100% 37% 100% 54%
    SATELLIZER 100% 51% 100% 85%

    View Slide

  13. Future Work
    We plan to…
    • Extend our study
    • Investigate the causes of false negatives
    • Combine static and dynamic analysis
    13

    View Slide

  14. 14
    Open Questions
    1. Why module annotations do not help to improve
    type inference accuracy in some systems?
    2. Should one invest in dynamic analysis to detect
    class-to-class dependencies in JavaScript?

    View Slide

  15. [email protected]
    Thank you!!!
