  1. Designing
    Audio Plugin Framework
    for Android
    atsushieno @ github, speakerdeck, google, facebook, twitter(ja)

    View full-size slide

  2. How do we compose music?

    View full-size slide

  3. How do we compose music on PC?
    DAW
    audio plugins
    MIDI devices

    View full-size slide

  4. What is Audio Plugin?
    Instrument (Synth) Effector

    View full-size slide

  5. What is Audio Plugin "Framework" ?
    A common interface
    makes them interoperable
    Audio Plugin Fx
    Hosts (DAWs)
    Plugins

    View full-size slide

  6. Existing Audio Plugin Frameworks
    Linux
    Windows
    Mac
    iOS
    Android
    VST
    Audio
    Unit
    LADSPA /
    LV2
    !?

    View full-size slide

  7. Linux
    Windows
    Mac
    iOS
    VST
    Filling the Gap
    Audio
    Unit
    LADSPA /
    LV2
    Android !!
    AAP

    View full-size slide

  8. Demo (recorded)
    (Audio plugin devs don't
    develop and test with
    DAWs. Instead, we use
    simple "host" for testing.)

    View full-size slide

  9. Keys to successful audio plugin framework?
    bigger ecosystem
    API/ABI stability and extensibility
    Meet audio plugin requirements

    View full-size slide

  10. Keys to successful audio plugin framework?
    bigger ecosystem
    API/ABI stability and extensibility
    Meet realtime audio equirements

    View full-size slide

  11. Know how plugins are developed
    01
    02
    Audio processing (DSP)
    Design Plugin
    03
    04
    Plugin UI
    Package Plugin Bundles
    How the plugin works ?
    (especially regarding user inputs)

    View full-size slide

  12. Know how plugins are developed
    it is mostly about byte (float) array processing
    01
    02
    Audio processing (DSP)
    Design Plugin
    03
    04
    Plugin UI
    Package Plugin Bundles
    void applyPlugin(
    vector midiMessages,
    vector audioInputs,
    vector audioOutputs)
    {
    switch(current_program) {
    case PIANO:
    piano(midiMessages, audioOutputs);
    break;
    case GUITAR: ...
    }
    }

    View full-size slide

  13. Know how plugins are developed
    01
    02
    Design Plugin
    Audio processing (DSP)
    03
    04
    Plugin UI
    Package Plugin Bundles
    cross-platform? per platform?
    Only for Win/Mac?

    View full-size slide

  14. Know how plugins are developed
    01
    02
    Design Plugin
    Audio processing (DSP)
    03
    04
    Plugin UI
    Package Plugin Bundles
    VST? AU? LV2?

    View full-size slide

  15. Easily import existing plugins
    VST3
    AU
    LV2
    AAP
    they often use cross-platform,
    cross-plugin frameworks... JUCE
    ...or, they can often "wrap" foreign plugins. LV2

    View full-size slide

  16. Keys to successful audio plugin framework?
    bigger ecosystem
    API/ABI stability and extensibility
    Meet realtime audio requirements

    View full-size slide

  17. What if we lose compatibility...
    incompatible versions =
    smaller ecosystem :(
    Audio Plugin Fx
    Hosts (DAWs)
    Plugins

    View full-size slide

  18. Keys to successful audio plugin framework?
    bigger ecosystem
    API/ABI stability and extensibility
    Meet realtime audio requirements

    View full-size slide

  19. Realtime Audio Requirements
    Audio processing has to be done in "realtime", in 10ms-ish
    Realtime != high performance processing. WCET (worst case exec. time) matters.
    Realtime blockers: GC, JIT, I/O, thread blocking, many system calls...
    non-RT? audio glitches, out-of-sync performance, dropouts = noise

    View full-size slide

  20. Realtime Audio Requirements
    blocking syscalls for example...
    seealso: Real-time 101 videos @Audio Developers Conference 2019

    View full-size slide

  21. Android-specific issues?
    DAWs cannot load
    plugins in-process
    Plugins (kinda) have to be
    distributed via Google Play
    either only DAW or only
    plugin app can show the UI
    NO dlopen()
    App Distribution Single Activity

    View full-size slide

  22. Process isolation
    Process
    Process
    Desktop in general
    Process
    Host (DAW)
    Plugin Plugin

    Android
    Process
    Host (DAW)
    Plugin Plugin

    View full-size slide

  23. IPC-based plugin chains
    need to use ASharedMemory (ashmem)
    NdkBinder: native Binder API - minSdkVersion 29
    "Android IPC mechanism" by jserv
    Though it's still full of mutex...

    View full-size slide

  24. UI architecture (draft stage)
    It's nicer if plugin UI can be loaded on the working DAW
    But UI code (Java or native) from the plugin app cannot be loaded on DAW
    Otherwise application/Activity has to switch around too often
    Will popup via WINDOW_MANAGER service work? (needs investigation)
    What if the plugin UI is in HTML so that WebView can load it??

    View full-size slide

  25. UI architecture - web UI (idea only)
    my desktop PoC (LV2) >>>
    Web-tech based UI is also in...
    ● iPlug2 WebUI
    ● mod-ui
    ● blueprint (JUCE/React)
    ● juce_emscripten
    ongoing work anyways, issue #34

    View full-size slide

  26. Further thoughts / discussions...
    Should we ever invent another plugin framework?
    Are existing code really useful on mobile?
    because mobile is too different...
    Maybe UIs aren't. Audio parts are.

    View full-size slide

  27. Thanks!
    Repos
    ● android-audio-plugin-framework
    ● aap-lv2
    ● aap-juce

    View full-size slide
