What for, Where and How to Adopt MIDI 2.0

What for, Where and How to Adopt MIDI 2.0

Slides for https://coscup.org/2022/ (Jul. 30th.)

Atsushi Eno

July 28, 2022
Tweet

More Decks by Atsushi Eno

Other Decks in Technology

Transcript

  1. What for, Where and
    How to Adopt MIDI 2.0
    @COSCUP 2022
    atsushieno

    View Slide

  2. @atsushieno and MIDI...
    /me had been playing with MIDI since 199x.
    using MML (Music Macro Language) to MIDI compiler to create *.mid files
    atsushieno/managed-midi: "the truly cross-platform .NET MIDI API", and co.
    atsushieno/ktmidi: switched to Kotlin, supports MIDI 2.0
    atsushieno/augene-ng: MML to MIDI 2.0 to DAW (tracktion) compiler
    wrote a Japanese indie tech book about MIDI 2.0, IIRC world's first.

    View Slide

  3. What is MIDI?
    MIDI = Musical Instrument Digital Interface ( = commonly used)
    MIDI 1.0 was standardized in 1983, then MIDI 2.0 in 2020

    View Slide

  4. MIDI 1.0 was about...
    General MIDI: collection of instruments
    indexed by program number
    source

    View Slide

  5. MIDI 1.0 was about...
    MIDI messages: instructions such as note-on, note-off, control change and pitchbend
    source

    View Slide

  6. MIDI devices and cables
    later: USB, BLE
    MIDI 1.0 was about...

    View Slide

  7. MIDI 1.0 was about...
    Standard MIDI: format of MIDI music file (SMF)
    It was a popular format to distribute music
    before MP3 became popular.
    They were even ded on WWW.
    (source)

    View Slide

  8. How do we compose music on PC in 2022?
    In 2020s we mostly use DAWs, and they don't save songs in .mid file!
    We use audio plugins (VST / AU / LV2 / ...) for instruments
    and effect plugins

    View Slide

  9. Why audio plugins?
    We need unlimited kind of instruments and effect controllers beyond MIDI
    We need same (identical) audio outputs across computers
    We need finer parameters than 7-bit data ranges
    We want to pass raw audio samples (or whatever) to those instruments.

    View Slide

  10. Is MIDI 1.0 gone?
    YES and NO...
    The basic song structures
    in DAWs remain similar to SMF:
    - We have tracks
    Also, meta event tracks
    - We have MIDI-like events
    (optionally with loops)

    View Slide

  11. Is MIDI 1.0 gone?
    Some music composers distribute
    SMF as additional contents.

    View Slide

  12. Is MIDI 1.0 gone?
    DAWs can import and export SMF too.

    View Slide

  13. DAW and MIDI
    We use pianorolls and/or (rhythm) step sequencers.
    We also use MIDI keyboard to add notes onto the bound track.
    BUT, those audio plugins do not (necessarily) receive MIDI events directly.
    Every plugin format has their own "events" e.g. VST3 Note On/Off
    MIDI
    VST3

    View Slide

  14. DAWs usually support multiple audio plugin formats in consistent manner.
    DAWs store some abstract sequence, and convert them to the target event.
    DAW and MIDI
    VST3
    LV2
    audio audio
    audio

    View Slide

  15. Audio Plugins: the World is Divided
    Audio plugin products are often built and released for multiple targets
    (Win/Mac/..., VST/AU/...)
    Event inputs for multiple targets: needs abstraction too
    VST3 events
    AU events
    LV2 events
    audio
    audio
    audio

    View Slide

  16. In the wake of MIDI 2.0...
    Is MIDI 1.0 good for the abstract sequence? It's not expressive enough...
    But MIDI 2.0 is here!
    - Specification finalized in early 2020
    - Has 32-bit fine parameters, per-note expressions and controllers, etc...
    The specification can be downloaded at AMEI https://tinyurl.com/midi-2-spec
    (or at MMA, but they require user registration)

    View Slide

  17. What are the MIDI 2.0 specification components?
    MIDI-CI, MIDI 2.0 Property Exchange, Profile Configuration
    CI: bi-directional messaging. (Pairing one-way MIDI conns. like UDP in HTTP/3.)
    PE: based on MIDI-CI, manage MIDI device properties: "get", "set", "query" etc.
    PC: MIDI devices may have profiles such as "Organ profile", "E.Piano profile" etc.
    MIDI 2.0 UMP (Universal MIDI Packet)
    Some other specifications e.g. USB MIDI 2.0 protocol

    View Slide

  18. MIDI 2.0 UMP: brand new message format
    "programmer friendly" fixed size: 4 bytes, 8 bytes, or 16 bytes
    Timestamps are there too (i.e. SMF event delta time equivalents)
    00h 4 bytes Utility messages (timestamps) -
    10h 4 bytes System Realtime or System Common messages F1h-FFh in MIDI 1.0
    20h 4 bytes MIDI 1.0 Channel Voice messages 80h-E0h in MIDI 1.0
    30h 8 bytes Sysex7 messages F0h in MIDI 1.0
    40h 8 bytes MIDI 2.0 channel voice messages -
    50h 16 bytes Sysex8 and Mixed Data Set messages -

    View Slide

  19. MIDI 2.0 channel voice messages
    00h Per-Note RPN (Registered Controller) 80h Note Off
    10h Per-Note NRPN (Assignable Controller) 90h Note On
    20h RPN (Registered Controller) A0h Polyphonic Pressure
    30h NRPN (Assignable Controller) B0h Control Change
    40h Relative RPN (Registered Controller) C0h Program Change
    50h Relative NRPN (Assignable Controller) D0h Channel Pressure
    60h Per-Note Pitch Bend E0h Pitch Bend
    70h (unused) F0h Per-Note Management

    View Slide

  20. MIDI 2.0 channel voice messages
    note on (90h) / off (80h): has 16-bits velocity, extra attribute (16 bits)
    MIDI 2.0 supports 256 channels, 16 channels * 16 groups
    The attribute can be anything.
    "pitch 7.9" can be specified for microtonal note (7-bit semitones, 9-bit microtone)

    View Slide

  21. MIDI 2.0 channel voice messages
    control change (B0h): has 32-bit data
    ... and it can be per-note controller (00h)

    View Slide

  22. Note: they are not new features in audio world
    VST3 and AU supported per-note expressions and controllers.
    MIDI 1.0 was capable of partially supporting:
    - microtonal tunings (i.e. beyond 12-tones equal temperament) => MTS
    - pitch bend that does not apply to ALL notes on the channel => MPE
    MIDI 2.0 made them "standard".

    View Slide

  23. Are We MIDI 2.0 Yet?
    Platform support: Only on Mac, iOS, and Android (USB-MIDI 2.0 only)
    "Where can I buy MIDI 2.0 ?" (devices)
    Roland A-88MkII ?
    Erae Touch ?
    If there is no MIDI 2.0 device yet, can we even use it? → still YES in theory
    (source)

    View Slide

  24. MIDI 2.0 on MIDI 1.0: Promote to UMPs using MIDI-CI
    (1) You can use MIDI-CI to promote the protocol to MIDI 2.0 UMPs.
    MIDI-CI: universal system exclusive messages (MIDI 1.0 compatible)
    (MIDI-CI v1.1 spec. P.23)

    View Slide

  25. MIDI 2.0 on MIDI 1.0: Promote to UMPs using MIDI-CI
    (2) Remember earlier discussion on audio plugins?
    DAW events can be represented using MIDI 2.0 UMPs!
    MIDI
    AU
    MIDI

    View Slide

  26. MIDI 2.0 on MIDI 1.0: Promote to UMPs using MIDI-CI
    (2) Remember earlier discussion on audio plugins?
    DAW events can be represented using MIDI 2.0 UMPs!
    MIDI 2.0
    AU
    Set New
    Protocol
    MIDI 2.0

    View Slide

  27. Audio Plugins and MIDI 2.0
    AudioUnit: we'll still have to map UMPs to AU-specific events. But CoreMIDI
    supports MIDI-CI and UMP, so native UMP support may be matter of time.
    vst3sdk is reportedly capable of map most of MIDI 2.0 UMPs to VST3 events.
    CLAP plugin (very new) can deal with MIDI 2.0 natively.
    JUCE framework: supports UMP processing. vNext will support MIDI 2.0 devices.
    The plugin base (AudioProcessor) receives raw MIDI buffer so UMPs could fit there.
    Developers are going to explore MIDI 2.0 applicability here.

    View Slide

  28. MIDI 2.0 software synthesizers?
    Maybe? It should be possible too

    View Slide

  29. Summary
    MIDI 2.0 is modern upgrade from MIDI 1.0, paying attention to backward compat.
    Limited platform support, no instrument devices, but that doesn't matter.
    Audio plugins APIs are similarly featureful, but MIDI 2.0 made them standard.
    Audio plugins are (getting) ready to deal with UMPs, so it's worth to learn!

    View Slide

  30. Thanks!
    Questions?
