Scala + Caliban で作るGraphQL バックエンド / Making GraphQL Backend with Scala + Caliban

Transcript

1. 阿川 耕司
   Scala + Caliban で作る
   GraphQL バックエンド


   View Slide

2. 小売向けサイネージのプロダクト「ミライネージ」
   でテックリードを担当している。
   阿川 耕司 / Koji AGAWA
   2013年度 中途入社
   AI事業本部 DX本部 ミライネージ
   @atty303
   @atty303


   View Slide

3. Scala + Caliban で作る
   GraphQL バックエンド


   View Slide

4. 1.What's GraphQL ?
   2.Caliban
   3.Authentication
   4.Node Interface
   5.Relay-based Pagination
   6.Summary


   View Slide

5. What’s GraphQL ?


   View Slide

6. GraphQL
   •APIのクエリ言語
   •サーバーは型付きスキーマを公開
   •クライアントは欲しいデータだけをリクエスト
   •クライアントとサーバーは任意の言語を使える
   •サポートツールが充実


   View Slide

7. GraphQL in Scala
   Sangria Caliban
   Since 2015 2019
   Effect System Future ZIO
   Boilerplate 多い 少ない
   Resolver 密結合 疎結合


   View Slide

8. Caliban


   View Slide

9. Caliban の特徴
   •最小限のボイラープレート
   •Purely Functional
   •強い型付け
   •明示的なエラー
   •スキーマとリゾルバーの分離


   View Slide

10. case class User(
    id: UUID,
    name: String,
    age: Option[Int]
    )
    スキーマ定義
    type User {
    id: ID!
    name: String!
    age: Int
    }


    View Slide

11. case class UserArgs(id: UUID)
    case class Query(
    user: UserArgs => Option[User],
    users: Seq[User]
    )
    スキーマ定義
    type Query {
    user(id: ID): User
    users: [User!]!
    }


    View Slide

12. trait UserResolver {
    def getUser(id: UUID): Option[User]
    def getAllUsers(): Seq[User]
    }
    val query = Query(
    args => userResolver.getUser(args.id),
    userResolver.getAllUsers
    )
    val api = graphQL(RootResolver(query))
    リゾルバ定義


    View Slide

13. query {
    user(id: 123) {
    name
    groups {
    name
    }
    }
    }
    N+1 問題


    View Slide

14. for {
    user <- getUser(id)
    groups <- ZIO.foreachPar(user.groupIds)(getGroup)
    } yield User(user.name, groups)
    素朴な実装
    N+1 Query


    View Slide

15. for {
    user <- getUser(id)
    groups <- ZQuery.foreachPar(user.groupIds)(getGroup)
    } yield User(user.name, groups)
    ZQuery
    1+1 Query


    View Slide

16. case class GetGroup(id: Int) extends Request[Throwable, Group]
    val GroupDataSource =
    DataSource.fromFunctionBatchedM("GroupDataSource")(
    requests => dao.getGroups(requests.map(_.id))
    )
    def getGroup(id: Int): ZQuery[Any, Throwable, Group] =
    ZQuery.fromRequest(GetGroup(id))(GroupDataSource)
    ZQuery


    View Slide

17. ZQuery のメリット
    •並列クエリ
    •同一クエリのキャッシュ(重複排除)
    •バッチ化
    DataLoader の FP アプローチ


    View Slide

18. Authentication


    View Slide

19. val routesM: IO[HttpRoutes[RIO[AppEnv, *]]] =
    for {
    a = Http4sAdapter.makeHttpService
    [AppEnv with Has[Auth.Service], CalibanError](interpreter)
    route = new Auth[AppEnv].apply(a)
    } yield Router[RIO[AppEnv, *]](
    "/graphql" -> route
    )
    http4s router


    View Slide

20. class Auth[R <: Has[_] with Database]() {
    def apply(route: HttpRoutes[RIO[R with Has[Auth.Service, *]]): HttpRoutes[RIO[R, *]] =
    Http4sAdapter.provideSomeLayerFromRequest[R with Database, Has[Auth.Service]](
    route,
    req => makeService(req).toLayer
    )
    def makeService(req: Request[RIO[R, *]]): RIO[Database, Auth.Service] = ???
    }
    object Auth {
    trait Service {
    def authUser: Option[AuthUser]
    }
    }
    Authentication service


    View Slide

21. case class Query(
    getAllUsers: ZIO[Has[Auth.Service], Throwable, User]
    )
    val resolver = Query(
    ZIO.access[Has[Auth.Service]] {
    _.get.authUser match {
    case Some(authUser) => ???
    case None => ???
    }
    )
    Usage


    View Slide

22. Authentication
    •ZLayerの理解が必須
    •サンプルが解読できずDiscordで作者に聞いた
    •ZIO コミュニティDiscordは活発


    View Slide

23. Node Interface


    View Slide

24. # An object with a Globally Unique ID
    interface Node {
    # The ID of the object.
    id: ID!
    }
    type User implements Node {
    id: ID!
    # Full name
    name: String!
    }
    Node Interface


    View Slide

25. sealed trait Node {
    def id: String
    }
    case class User(id: String, name: String) extends Node
    Node Interface in Caliban (?)


    View Slide

26. sealed trait Node {
    def id: String
    }
    case class User(id: String, name: String) extends Node
    Not scalable ...


    View Slide

27. def lookupUser(id: String): UQuery[Option[User]] =
    ZQuery.some(User(id))
    def lookupGroup(id: String): UQuery[Option[Group]] =
    ZQuery.some(Group(id))
    val node = Node.instance
    .withType(lookupUser)
    .withType(lookupGroup)
    implicit val nodeSchema: Schema[Any, Node] = node.build
    case class Query(
    node: NodeArg => IO[CalibanError, Node]
    )
    Solution


    View Slide

28. Solution
    https://gist.github.com/paulpdaniels/d8e932b9faee19812d2de8f56dd77a51


    View Slide

29. Node Interface
    •Caliban標準のサポート無し
    •サンプル実装をベースに独自実装


    View Slide

30. Relay-based Pagination


    View Slide

31. object PaginatedQuery {
    def apply[A: Get](
    fullTableQuery: Fragment
    )(
    cursor: Cursor,
    orderBy: Fragment = Fragment.empty
    ): TranzactIO[PageInfoDto[A]] = ???
    }
    Relay-based Pagination の一般化


    View Slide

32. case class Cursor(
    first: Option[Int],
    after: Option[String],
    last: Option[Int],
    before: Option[String]
    )
    Cursor / PageInfo
    case class PageInfoDto[A](
    totalCount: Long,
    hasPreviousPage: Boolean,
    hasNextPage: Boolean,
    value: Vector[A]
    )


    View Slide

33. WITH _SOURCE AS ($table),
    _T AS (
    SELECT ROW_NUMBER() OVER (ORDER BY ${orderBy}) AS n, ${idColumn} AS id
    FROM _SOURCE
    ORDER BY ${orderBy}
    ),
    _afterN AS (SELECT n FROM _T WHERE _T.id = ${after}),
    _beforeN AS (SELECT n FROM _T WHERE _T.id = ${before}),
    _totalN AS (SELECT COUNT(1) AS total FROM _T),
    _page AS (
    SELECT n, _T.id
    FROM _T
    WHERE (${cursor.after} IS NULL OR n > COALESCE((TABLE _afterN), 0))
    AND (${cursor.first} IS NULL OR n <= COALESCE((TABLE _afterN), 0) + ${cursor.first})
    AND (${cursor.before} IS NULL OR n < COALESCE((TABLE _beforeN), (TABLE _totalN) + 1))
    AND (${cursor.last} IS NULL OR n >= COALESCE((TABLE _beforeN), (TABLE _totalN) + 1) - ${cursor.last})
    ),
    _minN AS (SELECT MIN(n) FROM _page),
    _maxN AS (SELECT MAX(n) FROM _page)
    SELECT
    _totalN.total,
    CASE WHEN (TABLE _minN) > 1 THEN true ELSE false END AS has_previous_page,
    CASE WHEN (TABLE _maxN) < (TABLE _totalN) THEN true ELSE false END AS has_next_page,
    _page.id
    FROM _page, _totalN
    Pagination SQL (!)


    View Slide

34. WITH _SOURCE AS ($table),
    …
    [$table]
    SELECT id FROM signages ORDER BY name
    Pagination SQL


    View Slide

35. val nodes = ZQuery.foreachPar(
    pageInfo.value.map(id => GetSignageRequest(GRI(id.asString)))
    )(
    ZQuery.fromRequest(_)(getSignageDataSource.dataSource)
    )
    SignageConnection(
    edges = nodes.map(_.map(n => SignageEdge(n.databaseId.asString, n))),
    nodes = nodes,
    pageInfo = PageInfo(
    hasNextPage = pageInfo.hasNextPage,
    hasPreviousPage = pageInfo.hasPreviousPage,
    startCursor = pageInfo.value.headOption.map(_.asString),
    endCursor = pageInfo.value.lastOption.map(_.asString)
    ),
    totalCount = pageInfo.totalCount
    )
    Resolver


    View Slide

36. ミライネージの Pagination
    •Pagination の一般化
    •ページングしない、IDだけを返すSQLだけ書く
    •ZQueryによりIDを肉付けする


    View Slide

37. Summary


    View Slide

38. GraphQLで得られたもの
    •フロントエンドに依存しすぎないバックエンド
    (CQRSではフロントエンドにあわせて都度Queryを実装)
    •Vue Apollo でフロントエンドの爆速実装
    •graphql-code-generator で型安全なクエリ
    •安定したモデル (≠ ドメインモデル)


    View Slide

39. Summary
    •型安全&ボイラープレート無しの GraphQL バックエンド
    •純粋関数による構成からのテスト容易性
    •標準仕様への準拠からの言語間の相互運用性
    •責務の分離による記述の容易性


    View Slide

40. ご視聴ありがとうございました。


    View Slide
