Profiling PHP applications

It's nothing new that speed is important for the success of any web application. Only a few hundred milliseconds may lie between a user leaving your site or staying. Unfortunately performance problems are oftentimes hard to fix and even harder to pinpoint.

In this talk I will show you how we at ResearchGate measure web application performance, which means not only timing how long the PHP backend took to deliver a page, but also tracking the speed the users actually perceives in the browser. After that you will see how you can track down and analyze any problems you found through measuring with the help of tools like Xdebug, XHProf and the Symfony Debug Toolbar. And if you still need to get faster after optimizing and fixing all these issues, I'll introduce you to some tricks, techniques and patterns to even further decrease load times.

Transcript

1. My site is slow,
   what can I do?
   @BastianHofmann
   Profiling PHP applications


   View Slide

2. This talk is all
   about...
   ...


   View Slide

3. Speed. And with that I mean, not the drug, the movie or any game, but


   View Slide

4. Speed of your web
   application
   the ..


   View Slide

5. We'll talk about...


   View Slide

6. Why it matters
   and why you should care about it


   View Slide

7. How to measure it
   what actually is pagespeed and ...


   View Slide

8. How to find out
   where the problems
   are
   and ..


   View Slide

9. Before we start
   ...


   View Slide

10. A few words
    about me
    ...


    View Slide

11. I work at ResearchGate, the professional network for scientists and researchers


    View Slide

12. ResearchGate gives
    science back to the
    people who make it
    happen.
    We help researchers
    build reputation and
    accelerate scientific
    progress.
    On their terms.
    ‟
    the goal is to give...


    View Slide

13. over 3 million users


    View Slide

14. here some impressions of the page


    View Slide

15. you may have read about us in the news recently


    View Slide

16. http://gigaom.com/2013/06/05/heres-how-bill-gatess-
    researchgate-investment-might-change-the-world-for-the-
    better
    http://venturevillage.eu/researchgate


    View Slide

17. have this, and also work on some cool stuff


    View Slide

18. we are hiring


    View Slide

19. Questions? Ask
    by the way, if you have any questions throughout this talk, if you don't understand
    something, just raise your hand and ask.


    View Slide

20. http://speakerdeck.com/u/bastianhofmann
    the slides will be available on speakerdeck


    View Slide

21. Why should you
    care?
    so, pagespeed...


    View Slide

22. It is really important
    of course because ...


    View Slide

23. View Slide

24. but seriously, in the last years multiple studies were made on the importance of speed for a
    web application. how does it affect usage and conversion? how long are people waiting for
    content? how does it affect sales? if people left because the site is slow, are they coming
    back?


    View Slide

25. Every ms counts
    in short, the result of every study was the same: ...


    View Slide

26. in detail


    View Slide

27. in detail


    View Slide

28. ..


    View Slide

29. So what is
    pagespeed?


    View Slide

30. Server
    the first thing the contributes to pagespeed is what happens on the server. this is also the
    easiest part, because it is completely under our control


    View Slide

31. Your PHP application
    Request
    Response
    so what your server and your application is doing between incoming request and outgoing
    response


    View Slide

32. Your PHP application
    Request
    Response
    Load balancer
    though this does not mean only your application, but also the rest of your setup, like a
    loadbalancer


    View Slide

33. Your PHP application
    Request
    Response
    Load balancer
    and also your application is probably not a single small php script, but a big application with
    multiple components that each can affect speed differently. so getting a more detailed view
    on these components might be interesting as well. more to that later


    View Slide

34. web server db
    http service
    http service
    cache
    user request
    additionally most bigger applications have some kind of a service oriented architecture, same
    things apply here. knowing about the speed of the different services is important.


    View Slide

35. what is your web application like?


    View Slide

36. But there is more
    ... your application does not stop at your server. somehow it needs to get to your user


    View Slide

37. so internet connectivity is also a big part, contributing to pagespeed, that means everything
    from dns lookup, over ssl handshake to actually transporting the content over the wire


    View Slide

38. when your user received the content, he needs to display it. and some browsers are way
    slower than others in doing it


    View Slide

39. so the dom needs to be rendered, css fetched and applied, images loaded


    View Slide

40. and of course nearly no web application comes without javascript. this needs to be loaded
    and executed as well


    View Slide

41. http://www.stevesouders.com/blog/2012/02/10/the-performance-golden-rule/


    View Slide

42. So what happens
    on your server is
    really iportant


    View Slide

43. But the rest as well
    my point is: what is important is the pagespeed your user perceives. this contains everything
    from server to his browser. in the end it's your fault if the site is slow, even if the user's
    computer and browser is crappy.


    View Slide

44. Step 1
    how to deal with this...


    View Slide

45. Measuring
    measuring your actual pagespeed


    View Slide

46. who is doing it?


    View Slide

47. if you start: it's going to hurt


    View Slide

48. because although everything seems to be fine on your fast, 2 month old machine, with lot's
    of ram, cpu power, latest chrome, from your 50mbit vdsl connection with a very low ping to
    your data center.


    View Slide

49. reality is: Old computers


    View Slide

50. Old feature phones, slower smart phones, mobile networks in general (edge anyone?)


    View Slide

51. old browsers


    View Slide

52. people in countries with big latencies to your datacenter and/or slow internet connections
    (rember dial up)


    View Slide

53. So you need to
    measure at your
    users side


    View Slide

54. Navigation Timing
    API
    https://developer.mozilla.org/en-US/docs/
    Navigation_timing
    there is actually a great javascript up that is supported by a lot of modern browsers


    View Slide

55. you get timestamps for all important events of a pageload


    View Slide

56. DEMO


    View Slide

57. For older browsers
    you have to do it
    yourself
    though ...
    e.g. by manually measuring the time with javascript and on the server. this is actually kind of
    hard (clock offsets, etc)


    View Slide

58. Or


    View Slide

59. https://github.com/lognormal/boomerang
    use something of people who already did this for you


    View Slide

60. Getting it back to
    the server
    so now you have all the timestamps in your javascript, you need to ...


    View Slide

61. logstash
    http://logstash.net/
    enter the next tool, logstash is a very powerful tool to handle log processing


    View Slide

62. input filter output
    basic workflow is that you have some input where logstash gets log messages in, on this
    input you can execute multiple filters that modify the message and then you can output the
    filtered message somewhere


    View Slide

63. Very rich plugin
    system
    to do this it offers a very large and rich plugin system for all kinds of inputs, filters and
    outputs, and you can also write your own


    View Slide

64. browser
    JS: boomerang
    logstash
    trackingServer
    access log
    requests
    tracking image
    with timing
    information as
    query
    parameters
    for our purpose we can just have boomerang in the browser collect the timestamps and then
    send a small tracking request (inserting an image) to a tracking server. the timestamps are
    added as query parameters to this request. the server only returns an empty image and logs
    the request to his access log which logstash can parse.


    View Slide

65. Graphing it
    we want to...


    View Slide

66. Graphite
    http://graphite.wikidot.com/
    again there are many tools available to collect and display these metrics: one i want to
    highlight is graphite


    View Slide

67. graphite comes with a powerful interface where you can plot and aggregate this data into
    graphs and perform different mathematical functions on it to get it exactly the way you want
    to display your data


    View Slide

68. browser
    JS: boomerang
    logstash
    trackingServer
    access log
    requests
    tracking image
    with timing
    information as
    query
    parameters
    graphite
    statsd
    and statsd is a small load balancing daemon for it. so this is your setup logstash sends these
    timestamps to statsd who aggregates the information and sends them to graphite


    View Slide

69. input {
    file {
    type => "pagespeed-access"
    path => [ "/var/log/nginx/
    access_log/monitoring-access.log" ]
    }
    }
    in logstash this is how to get the date from the log into logstash


    View Slide

70. filter{
    grok {
    type => "pagespeed-access"
    pattern => "^.*\s\"[A-Z]+\s[^\?\s]+
    \?page=%{DATA:page}\&connectTime=%
    {NUMBER:connectTime}...)?\sHTTP\/\d\.\d\".*
    $"
    }
    grok {
    type => "pagespeed-access"
    match => ["page", "^(profile|
    home|...)\.logged(In|Out)$"]
    exclude_tags =>
    ["_grokparsefailure"]
    }
    }
    you can apply filters to put it into a structured form and validate it


    View Slide

71. output {
    statsd {
    type => "pagespeed-access"
    exclude_tags =>
    ["_grokparsefailure"]
    host => "localhost"
    port => 8126
    namespace => "pagespeed"
    sender => ""
    timing => [
    "%{page}.connect", "%
    {connectTime}", ...
    ]
    }
    }
    and the put the data somehwere else. here we are sending it to statsd.
    what's that


    View Slide

72. and thats what such graphes then may look like


    View Slide

73. Can we measure
    more?
    I said earlier we may need information about services etc


    View Slide

74. Load balancer
    in a soa architecture we can do something similar with the access logs of our services, which
    also have timing information. or if we have a load balancer in between as well. we can get
    useful information from there


    View Slide

75. Example: HAProxy
    you can get the time of the request, time spent in haproxy queues etc.


    View Slide

76. input {
    file {
    type => "haproxy-http-log"
    path => [ "/var/log/
    haproxy-http.log*" ]
    }
    }
    example config


    View Slide

77. filter {
    grok {
    type => "haproxy-http-log"
    pattern => "%{HAPROXYHTTP}"
    }
    mutate {
    type => "haproxy-http-log"
    gsub => [
    "server_name", "\.", "_",
    "client_ip", "\.", "_"
    ]
    }
    }
    example config


    View Slide

78. output {
    statsd {
    type => "haproxy-http-log"
    exclude_tags => ["_grokparsefailure"]
    host => "localhost"
    port => 8125
    namespace => "lb"
    sender => ""
    increment => [
    ! ! "haproxy.%{backend_name}.%{server_name}.%
    {client_ip}.hits",
    ! ! "haproxy.%{backend_name}.%{server_name}.%
    {client_ip}.responses.%{http_status_code}"
    ! ! ]
    timing => [
    "haproxy.%{backend_name}.%{server_name}.%
    {client_ip}.time_request", "%{time_request}",
    "haproxy.%{backend_name}.%{server_name}.%
    {client_ip}.time_backend_connect", "%{time_backend_connect}",
    "haproxy.%{backend_name}.%{server_name}.%
    {client_ip}.time_backend_response", "%{time_backend_response}",
    "haproxy.%{backend_name}.%{server_name}.%
    {client_ip}.time_queue", "%{time_queue}",
    "haproxy.%{backend_name}.%{server_name}.%
    {client_ip}.time_duration", "%{time_duration}"
    ]
    }
    }
    example config


    View Slide

79. browser
    JS: boomerang
    logstash
    trackingServer
    access log
    requests
    tracking image
    with timing
    information as
    query
    parameters
    graphite
    statsd
    logstash
    load balancer
    access log
    logstash
    service
    access log
    logstash can analyse these logs and send them to statsd as well


    View Slide

80. From within your
    PHP app
    What is also useful is to measure certain things from within your php app, e.g. rendering
    time. time database requests took. time spent of certain business logic etc. you can either
    just log this to a file and use the same logstash mechanism, or if you just need to have it for
    debugging, do it differently. more to that later.


    View Slide

81. Only overall?


    View Slide

82. By pages
    but you should not only measure all your request, you should differentiate by...


    View Slide

83. By browser


    View Slide

84. By country


    View Slide

85. Logged in / out


    View Slide

86. Heavy users
    .. or just everything that makes sense for you


    View Slide

87. Define goals
    and after measuring everything and you see that you are slow somehwere, you should define
    goals, what performance you want to reach


    View Slide

88. Step 2
    but before you can start fixing stuff, ...


    View Slide

89. How to find out
    where the problems
    are
    finding out ...


    View Slide

90. Profiling
    you can do this through ...


    View Slide

91. first tool usefull for this is ...
    xdebug has quite a few functionalities like offering the ability to make breakpoints in your
    code, nicer error displays and so on. but one is also profiling of your app


    View Slide

92. xdebug.profiler_enable_trigger = 1
    http://url?XDEBUG_PROFILE
    you can either activate profiling for every request or selectively for all requests that have a
    GET, POST or COOKIE parameter called XDEBUG_PROFILE


    View Slide

93. Webgrind
    https://github.com/jokkedk/webgrind
    this write so called cachegrind files. in order to view this you can use tools like kcachegrind
    or the easiest one ...


    View Slide

94. you can see everything that happend in this request, every function that was invoked, how
    often this was and how long it took.


    View Slide

95. DEMO


    View Slide

96. Use it locally on
    your dev machine
    one thing with xdebug, it slows down php, so .. but not in production


    View Slide

97. XHProf
    https://github.com/facebook/xhprof
    for production there is xhprof, developed by facebook


    View Slide

98. Use it in production
    for a subset of
    requests
    you can safely use it in production, it comes with a performance overhead but only when
    used, so you can activate it, but only use for a small percentage of requests or when manually
    activated (e.g. by a cookie).


    View Slide

99. XHGUI
    https://github.com/preinheimer/xhgui
    to display the xhprof profiles, there is a nice tool called xhgui


    View Slide

100. in addition to the normal thinkgs like seeing


     View Slide

101. the whole callstack


     View Slide

102. you can also visualize this in a graph


     View Slide

103. and can do analysis over multiple requests and compare them to each other


     View Slide

104. DEMO


     View Slide

105. Symfony Debug
     Toolbar
     i said earlier, that there is another good way to get information about your applications
     internals, especially if you only need it for debugging and not in a graph. this is with the..


     View Slide

106. it comes with standard symfony and you probably all have seen it already


     View Slide

107. you can click on it and it gives you nice detailed information about the request. stuff like
     doctrine queries, a nice timeline, exceptions, routing, events etc.


     View Slide

108. DEMO


     View Slide

109. Extend it
     http://symfony.com/doc/current/cookbook/profiler/
     data_collector.html
     but did you know that you can extend it? there are some good ready made extensions
     available, e.g. for caching, http calls, versioning etc. just check packagist, but you can also
     write your own easily.


     View Slide

110. here are some examples how we at researchgate extended it (disclaimer: we are not even
     using full symfony, but only some components).


     View Slide

111. View Slide

112. View Slide

113. View Slide

114. View Slide

115. View Slide

116. DEMO


     View Slide

117. Step 3
     now that you have all this debugging information to pinpoint your bottlenecks, let's get to ...


     View Slide

118. Fix it


     View Slide

119. That's someting you
     have to do
     unfortunately ... since it is very dependent on your application and your setup


     View Slide

120. View Slide

121. Remember
     but


     View Slide

122. Speed matters


     View Slide

123. http://twitter.com/BastianHofmann
     http://lanyrd.com/people/BastianHofmann
     http://speakerdeck.com/u/bastianhofmann
     mail@bastianhofmann.de
     thanks, you can contact me on any of these platforms or via mail.


     View Slide
