Building and Integrating A Data Platform

Last year, Benoit and others were busy integrating and customising Barrel, a modern and opensource data platform with master-master replication written in Erlang.

This talk will describe the different challenge we faced in building a P2P middle-tier platform in Erlang to persist the data and “actors” states from micro-services in different levels of storage and replicate them between different locations. This talk will also describe the different patterns used for Reads and Writes concurrency but also continuous automated indexation of the data and “actors”.

Transcript

1. BUILDING AND INTEGRATING
   A DATA PLATFORM
   CodeBeam SF - 2018


   View Slide

2. benoît chesneau
   craftsman working on P2P and custom data
   endpoints solution
   enki multimedia: the corporate interface
   member of the Erlang Industrial User Group
   about me


   View Slide

3. micromobile
   services


   View Slide

4. 1. Does my service do only one thing?
   2. Is my service autonomous?
   3. Does this service own its own data?
   a good micro-service?


   View Slide

5. isolated
   own its own data
   resilient
   communicate with other by asynchronous
   messages
   micro-servcice


   View Slide

6. sharing data in the mobile age between and across
   micro-services make applications more scalable
   and resilient
   Ex: messaging systems,
   sharing data


   View Slide

7. sharing data
   update

   and query
   microservice
   standard solution: client
   call a webservices to query
   and update the data
   problem: if connection is
   slow or absent the micro-
   service stops
   cloud

   storage


   View Slide

8. sharing data
   microservice
   local storage replicated
   always available
   eventually consistent
   cloud

   storage
   update

   and query
   synchronize
   local

   storage


   View Slide

9. barrel
   Bring and keep a
   view of your data
   near your application


   View Slide

10. a database focusing on simplicity
    document oriented
    Automatic indexing
    Focusing on simplicity


    View Slide

11. Docs are maps
    { “id” : “someid”,
    “Key” : “value” }


    View Slide

12. automatic indexing
    Access by path: /locations/country/Germany


    View Slide

13. Local first
    local first: bring and keep a view of your data near your
    application
    data is synchronised with other storages
    Replication to and from any sources


    View Slide

14. partial view
    query
    node
    Title Text


    View Slide

15. library embedded in your Erlang application(*)
    available as a micro-service via HTTP(1,2) or via
    the Erlang distribution
    Peer to peer: a barrel is the unit
    Semantic to allow distributed transactions
    P2p
    (*) including elixir or lfe, or ….


    View Slide

16. every peers fork the master, updates are offline
    peers pull and merge from the main server
    works well for back pressure (writes can be
    delayed)
    CRDT semantic for conflict-free data structures


    View Slide

17. causality
    no vector clock
    revision tree


    View Slide

18. a a a
    b c
    commit
    Alice Iko Bob
    state
    t0
    pull
    operations
    manual
    automatic
    rejected


    View Slide

19. a a a
    b b
    Alice Iko Bob
    state
    t0
    rejected
    pull
    pull
    t1
    c
    b
    d
    merge
    operations


    View Slide

20. a a a
    b b
    Alice Iko Bob
    state
    t2
    pull
    t3
    c
    b
    d
    pull
    operations


    View Slide

21. ?
    ??
    Erlang


    View Slide

22. Erlang is slow
    Erlang is only for communications protocols
    I should do it rust…
    No access to low level memory and file systems
    APIS
    Why not Erlang


    View Slide

23. Barrel is more a data orchestration service than a
    database
    Basic indexing
    Focus on replicating the data
    Nifs to help
    Why Erlang


    View Slide

24. Doc: Revision + Metadata data:
    Read-Modify-Write: concurrency issue
    Incremental changes log: append only
    Indexes: when a new winning version is found the
    doc is indexed.
    Blobs (attachments)
    What we write


    View Slide

25. Provides connectors for other storages
    RocksdDB for local persistent storage

    https://gitlab.com/barrel-db/erlang-rocksdb.git
    Dirty-nifs
    ETS?
    Use the right tool for …


    View Slide

26. Goal: anticipate the resource usage at the node
    level
    Return early to the client
    Control applied to all resources in the nodes
    Back-pressure
    let it bend: be resilient


    View Slide

27. worker_pool

    https://github.com/inaka/worker_pool
    Hard to debug your program
    Little control on the pending requests
    Ecpocxy but handle back-pressure the reverse way
    Simple pooling


    View Slide

28. Clients and Jobs should be handled independently
    Active and passive regularion
    Request unit: to set the number of requests we
    want to serve / seconds
    Flow-Based programming?
    sbroker, partially fit the bill:

    https://github.com/fishcakez/sbroker
    Dynamic regulation


    View Slide

29. Started with a simple “Single Writer Multiple
    Readers” pattern
    bottleneck: A process to handle the final write to the
    database
    We do and // most of the work out of the write
    process
    Indexes are processed asynchronously (but a
    session can read its own writes if needed)
    Concurrency challenge


    View Slide

30. Read access is shared via ETS
    On request a monitor to the db is created
    ets: to share the state
    between readers


    View Slide

31. When using the erlang distribution, events are
    dispatched by nodes, processes always subscribe
    locally
    Events


    View Slide

32. Erlang distribution is not used to share the data
    Erlang distribution can be switched
    HTTP transports
    Transport the data


    View Slide

33. Roadmap


    View Slide

34. 1.0: 24 march 2018
    1.1: 24 april 2018
    …
    Milestones


    View Slide

35. 1.0: Websockets support (with new hackney)
    1.1: Experimental: GRPC
    Coming features


    View Slide

36. ?


    View Slide

37. barrel is released in march 2018
    https://barrel-db.org
    contact me @benoitc
