Optimizing APIs for Consumers with GraphQL

Optimizing APIs for Consumers with GraphQL

Presented at Goruco

359024e7132672aaeef4a3e792be4ae5?s=128

Brooks Swinnerton

June 24, 2017
Tweet

Transcript

  1. None
  2. Hi, I’m Brooks

  3. I work at !

  4. optimizing APIs for consumers…

  5. with GraphQL

  6. let’s start with APIs

  7. REST APIs

  8. http://nyc-restaurant-grades.com

  9. http://nyc-restaurant-grades.com/api/v1/restaurants GET

  10. !"""# verb http://nyc-restaurant-grades.com/api/v1/restaurants GET

  11. !"""""""""""""""""""""""""""""""""""""""""""""""""""# endpoint !"""# verb http://nyc-restaurant-grades.com/api/v1/restaurants GET

  12. http://nyc-restaurant-grades.com/api/v1/restaurants GET

  13. [ { "id": 1, "name": "Garden Of Eat In", "grade":

    "A", "camis": "40394054", "address": "1416 Avenue J, Brooklyn, New York 11230", "cuisine": "Jewish/Kosher", "url": "http://nyc-restaurant-grades.com/api/v1/restaurants/1", "inspections_url": "http://nyc-restaurant-grades.com/api/v1/restaurants/1/inspections" }, { "id": 2, "name": "Hunan Delight", "grade": "A", "camis": "41188631", "address": "752 Union Street, Brooklyn, New York 11215", "cuisine": "Chinese", "url": "http://nyc-restaurant-grades.com/api/v1/restaurants/2", "inspections_url": "http://nyc-restaurant-grades.com/api/v1/restaurants/2/inspections" }, ... ] http://nyc-restaurant-grades.com/api/v1/restaurants GET
  14. REST APIs return resources

  15. enhance… !

  16. [ { "id": 1, "name": "Garden Of Eat In", "grade":

    "A", "camis": "40394054", "address": "1416 Avenue J, Brooklyn, New York 11230", "cuisine": "Jewish/Kosher", "url": "http://nyc-restaurant-grades.com/api/v1/restaurants/1", "inspections_url": "http://nyc-restaurant-grades.com/api/v1/ restaurants/1/inspections" }, ... ] http://nyc-restaurant-grades.com/api/v1/restaurants GET
  17. [ { "id": 1, "name": "Garden Of Eat In", "grade":

    "A", "camis": "40394054", "address": "1416 Avenue J, Brooklyn, New York 11230", "cuisine": "Jewish/Kosher", "url": "http://nyc-restaurant-grades.com/api/v1/restaurants/1", "inspections_url": "http://nyc-restaurant-grades.com/api/v1/ restaurants/1/inspections" }, ... ] http://nyc-restaurant-grades.com/api/v1/restaurants GET
  18. [ { "id": 1, "name": "Garden Of Eat In", "grade":

    "A", "camis": "40394054", "address": "1416 Avenue J, Brooklyn, New York 11230", "cuisine": "Jewish/Kosher", "url": "http://nyc-restaurant-grades.com/api/v1/restaurants/1", "inspections_url": "http://nyc-restaurant-grades.com/api/v1/ restaurants/1/inspections" }, ... ] http://nyc-restaurant-grades.com/api/v1/restaurants GET
  19. http://nyc-restaurant-grades.com/api/v1/restaurants/1/inspections GET

  20. http://nyc-restaurant-grades.com/api/v1/restaurants/1/inspections GET

  21. [ { "id": 1, "type": "Trans Fat / Initial Inspection",

    "score": 9, "grade": "A", "inspected_at": "2016-01-27T00:00:00.000Z", "graded_at": "2016-01-27T00:00:00.000Z", "url": "http://nyc-restaurant-grades.com/api/v1/restaurants/1/ inspections/1", "restaurant_url": "http://nyc-restaurant-grades.com/api/v1/ restaurants/1", "violations_url": "http://nyc-restaurant-grades.com/api/v1/ restaurants/1/inspections/1/violations" } ] http://nyc-restaurant-grades.com/api/v1/restaurants/1/inspections GET
  22. [ { "id": 1, "type": "Trans Fat / Initial Inspection",

    "score": 9, "grade": "A", "inspected_at": "2016-01-27T00:00:00.000Z", "graded_at": "2016-01-27T00:00:00.000Z", "url": "http://nyc-restaurant-grades.com/api/v1/restaurants/1/ inspections/1", "restaurant_url": "http://nyc-restaurant-grades.com/api/v1/ restaurants/1", "violations_url": "http://nyc-restaurant-grades.com/api/v1/ restaurants/1/inspections/1/violations" } ] http://nyc-restaurant-grades.com/api/v1/restaurants/1/inspections GET
  23. http://nyc-restaurant-grades.com/api/v1/restaurants/1/inspections/1/violations GET

  24. http://nyc-restaurant-grades.com/api/v1/restaurants/1/inspections/1/violations GET

  25. http://nyc-restaurant-grades.com/api/v1/restaurants/1/inspections/1/violations GET [ { "id": 62855, "description": "Food not protected

    from potential source of contamination during storage, preparation, transportation, display or service.", "code": "06C", "url": "http://nyc-restaurant-grades.com/api/v1/ restaurants/1/inspections/29572/violations/62855", "inspection_url": "http://nyc-restaurant-grades.com/api/v1/ restaurants/1/inspections/29572", "restaurant_url": "http://nyc-restaurant-grades.com/api/v1/ restaurants/1" } ]
  26. API Server /restaurants /inspections /violations

  27. API Server /restaurants /inspections /violations

  28. API Server /restaurants /inspections /violations

  29. API Server /restaurants /inspections /violations

  30. API Server /restaurants /inspections /violations

  31. "RESTful APIs are optimized for servers, not clients." - Mark

    Twain (I think)
  32. what if we wanted to put clients first?

  33. backends for frontends

  34. API Server /desktop /mobile /fridge

  35. API Server /desktop /mobile /fridge

  36. but this only works if you’re in control of the

    client
  37. what about a public API?

  38. enter GraphQL

  39. a data query language

  40. think SQL

  41. not Neo4j

  42. GraphQL is a specification

  43. { me { firstName lastName email } }

  44. { me { firstName lastName email } }

  45. { me { firstName lastName email } }

  46. { me { firstName lastName email } } { "data":{

    "me":{ "firstName":"Brooks", "lastName":"Swinnerton", "email":"brooks@github.com" } } }
  47. https://nyc-restaurant-grades.com/graphql POST

  48. !"""# verb https://nyc-restaurant-grades.com/graphql POST

  49. !"""# verb !""""""""""""""""""""""""""""""""""""""""# endpoint https://nyc-restaurant-grades.com/graphql POST

  50. https://nyc-restaurant-grades.com/graphql POST

  51. { restaurant(name: "Cafe Ghia") { name cuisine } } https://nyc-restaurant-grades.com/graphql

    POST
  52. { restaurant(name: "Cafe Ghia") { name cuisine } } https://nyc-restaurant-grades.com/graphql

    POST
  53. { restaurant(name: "Cafe Ghia") { name cuisine } } {

    "data": { "restaurant": { "name": "Cafe Ghia", "cuisine": "American" } } } https://nyc-restaurant-grades.com/graphql POST
  54. features of the query language

  55. GraphQL is typed

  56. { me { firstName lastName email } } type RootQuery

    { me: User } type User { firstName: String lastName: String email: String }
  57. { me { firstName lastName email } } type RootQuery

    { me: User } type User { firstName: String lastName: String email: String }
  58. { me { firstName lastName email } } type RootQuery

    { me: User } type User { firstName: String lastName: String email: String }
  59. type RootQuery { restaurant(name: String): Restaurant } type Restaurant {

    name: String! cuisine: String } { restaurant(name: "Cafe Ghia") { name cuisine } }
  60. type RootQuery { restaurant(name: String): Restaurant } type Restaurant {

    name: String! cuisine: String } { restaurant(name: "Cafe Ghia") { name cuisine } }
  61. type RootQuery { restaurant(name: String): Restaurant } type Restaurant {

    name: String! cuisine: String } { restaurant(name: "Cafe Ghia") { name cuisine } }
  62. type RootQuery { restaurant(name: String): Restaurant } type Restaurant {

    name: String! cuisine: String } { restaurant(name: "Cafe Ghia") { name cuisine } }
  63. { restaurants(borough: BROOKLYN) { name cuisine } }

  64. { restaurants(borough: BROOKLYN) { name cuisine } }

  65. { restaurants(borough: BROOKLYN) { name cuisine } }

  66. type RootQuery { restaurants(borough: RestaurantBorough): [Restaurant]! } enum RestaurantBorough {

    BRONX BROOKLYN MANHATTAN STATEN_ISLAND QUEENS } type Restaurant { name: String! cuisine: String }
  67. type RootQuery { restaurants(borough: RestaurantBorough): [Restaurant]! } enum RestaurantBorough {

    BRONX BROOKLYN MANHATTAN STATEN_ISLAND QUEENS } type Restaurant { name: String! cuisine: String }
  68. type RootQuery { restaurants(borough: RestaurantBorough): [Restaurant]! } enum RestaurantBorough {

    BRONX BROOKLYN MANHATTAN STATEN_ISLAND QUEENS } type Restaurant { name: String! cuisine: String }
  69. { restaurant(name: "Mcdonalds") { name cuisine } restaurant(name: "Wendy's") {

    name cuisine } }
  70. { restaurant(name: "Mcdonalds") { name cuisine } restaurant(name: "Wendy's") {

    name cuisine } } { "data": { "restaurant": { "name": "Mcdonalds", "cuisine": "American" }, "restaurant": { "name": "Wendy's", "cuisine": "American" } } }
  71. { restaurant(name: "Mcdonalds") { name cuisine } restaurant(name: "Wendy's") {

    name cuisine } } { "data": { "restaurant": { "name": "Mcdonalds", "cuisine": "American" }, "restaurant": { "name": "Wendy's", "cuisine": "American" } } }
  72. { mcdonalds: restaurant(name: "McDonalds") { name cuisine } wendys: restaurant(name:

    "Wendy's") { name cuisine } }
  73. { "data": { "mcdonalds": { "name": "Mcdonalds", "cuisine": "American" },

    "wendys": { "name": "Wendy's", "cuisine": "American" } } }
  74. { mcdonalds: restaurant(name: "McDonalds") { name cuisine } wendys: restaurant(name:

    "Wendy's") { name cuisine } }
  75. { mcdonalds: restaurant(name: "McDonalds") { ...RestaurantInfo } wendys: restaurant(name: "Wendy's")

    { ...RestaurantInfo } } fragment RestaurantInfo on Restaurant { name cuisine }
  76. GraphQL is introspectable

  77. documentation and client generation, are free

  78. None
  79. multiple resources in one round trip

  80. API Server /restaurants /inspections /violations

  81. API Server /restaurants /inspections /violations

  82. API Server /restaurants /inspections /violations

  83. API Server /restaurants /inspections /violations

  84. API Server /desktop /mobile /fridge

  85. API Server /desktop /mobile /fridge

  86. API Server /graphql

  87. API Server /graphql

  88. Implementing a GraphQL server

  89. https://nyc-restaurant-grades.com/graphql POST

  90. class GraphqlController < ApplicationController def create result = Graph::Schema.execute(params[:query]) render

    json: result end end app/controllers/graphql_controller.rb
  91. class GraphqlController < ApplicationController def create result = Graph::Schema.execute(params[:query]) render

    json: result end end app/controllers/graphql_controller.rb
  92. class GraphqlController < ApplicationController def create result = Graph::Schema.execute(params[:query]) render

    json: result end end app/controllers/graphql_controller.rb
  93. like SQL, there are many implementations

  94. let’s talk about the Ruby implementation

  95. rmosolgo/graphql-ruby

  96. { restaurant(name: "Cafe Ghia") { name cuisine } }

  97. { restaurant(name: "Cafe Ghia") { name cuisine } } type

    RootQuery { restaurant(name: String): Restaurant } type Restaurant { name: String! cuisine: String }
  98. type RootQuery { restaurant(name: String): Restaurant } ?

  99. ? type RootQuery { restaurant(name: String): Restaurant }

  100. type RootQuery { restaurant(name: String): Restaurant } module Graph::Types RootQuery

    = GraphQL::ObjectType.define do name 'RootQuery' end end
  101. # The query root. type RootQuery { restaurant(name: String): Restaurant

    } module Graph::Types RootQuery = GraphQL::ObjectType.define do name 'RootQuery' description 'The query root.' end end
  102. type RootQuery { restaurant(name: String): Restaurant } ?

  103. module Graph::Types RootQuery = GraphQL::ObjectType.define do name 'RootQuery' field :restaurant

    do argument :name, types.String type Graph::Types::Restaurant resolve -> (object, arguments, context) do ::Restaurant.find_by(name: arguments['name']) end end end end type RootQuery { restaurant(name: String): Restaurant }
  104. module Graph::Types RootQuery = GraphQL::ObjectType.define do name 'RootQuery' field :restaurant

    do argument :name, types.String type Graph::Types::Restaurant resolve -> (object, arguments, context) do ::Restaurant.find_by(name: arguments['name']) end end end end type RootQuery { restaurant(name: String): Restaurant }
  105. module Graph::Types RootQuery = GraphQL::ObjectType.define do name 'RootQuery' field :restaurant

    do argument :name, types.String type Graph::Types::Restaurant resolve -> (object, arguments, context) do ::Restaurant.find_by(name: arguments['name']) end end end end type RootQuery { restaurant(name: String): Restaurant }
  106. module Graph::Types RootQuery = GraphQL::ObjectType.define do name 'RootQuery' field :restaurant

    do argument :name, types.String type Graph::Types::Restaurant resolve -> (object, arguments, context) do ::Restaurant.find_by(name: arguments['name']) end end end end type RootQuery { restaurant(name: String): Restaurant }
  107. type Restaurant { name: String! cuisine: String } ?

  108. type Restaurant { name: String! cuisine: String } module Graph::Types

    Restaurant = GraphQL::ObjectType.define do name 'Restaurant' end end
