Modern Enterprise Application Configuration with Spring

Transcript

1. None

2. modern enterprise app config

3. chris beams

4. you

5. github.com/cbeams/modern-config

6. modern enterprise app config

7. enterprise think big (big enough to hire own devs) typically

   not tech companies finance, media, insurance, gov't, ...

8. enterprise application typically long-lived teams change over time tech and

   requirements do too

9. enterprise application often large ... in size of codebase ...

   in no. of devs

10. enterprise application legacy and diversity are the rule

11. enterprise app configuration what components are involved? how are they

    parameterized? what dependencies exist? how are they satisfied?

12. modern enterprise app config concise comprehensive clear and communicative flexible

    and extensible code-based and typesafe
13. None

14. the Spring mission to provide comprehensive infrastructural support for building

    enterprise applications

15. ok... but what exactly is Spring?

16. Spring Framework 1.x

17. (2004)

18. 2004 spring ~= spring-framework

19. Spring Framework 3.x

20. (2012)

21. 2012 spring != spring-framework

22. 2012 spring >> spring-framework

23. spring == spring-framework spring-security spring-integration spring-batch spring-data-* spring-social

24. spring == spring-roo spring-amqp spring-webflow spring-ws spring-net ...

25. spring == spring-*

26. None
27. None

28. spring == comprehensive infrastructural support ...and there's a lot of

    infrastructure out there! configuration is just one (important) concern

29. which brings us back to...

30. modern enterprise app config

31. the approach · ·

32. the approach POJOs + 3rd party components ·

33. the approach POJOs + 3rd party components configuration instructions ·

34. the approach POJOs + 3rd party components ↓ configuration ┌─────────────────────┐

    instructions → │ the Spring container│ └─────────────────────┘ ·

35. the approach POJOs + 3rd party components ↓ configuration ┌─────────────────────┐

    instructions → │ (ApplicationContext)│ └─────────────────────┘ ·

36. the approach POJOs + 3rd party components ↓ configuration ┌─────────────────────┐

    instructions → │ the Spring container│ └─────────────────────┘ ·

37. the approach POJOs + 3rd party components ↓ configuration ┌─────────────────────┐

    instructions → │ the Spring container│ └─────────────────────┘ ┌─────────────────────────┐ │ fully configured system │ │ ready for use │ └─────────────────────────┘

38. you get one consistent mechanism for config fail-fast behavior at

    startup dependency injection vs dependency lookup ... leading to simple, testable POJO components ability to enhance behavior through AOP

39. config style POJOs + 3rd party components ↓ configuration ┌─────────────────────┐

    instructions → │ the Spring container│ └─────────────────────┘ ┌─────────────────────────┐ │ fully configured system │ │ ready for use │ └─────────────────────────┘

40. config style POJOs + 3rd party components ↓ <beans> ┌─────────────────────┐

    XML → │ the Spring container│ └─────────────────────┘ ┌─────────────────────────┐ │ fully configured system │ │ ready for use │ └─────────────────────────┘

41. <beans/>

42. <beans> </beans>

43. <beans> <bean id="foo" class="com.foo.Foo"/> </beans>

44. <beans> <bean id="foo" class="com.foo.Foo"/> <bean id="bar" class="com.foo.Bar"> <property name="foo" ref="foo"/>

    </bean> </beans>
45. None

46. <beans> <bean id="foo" class="com.foo.Foo"/> <bean id="bar" class="com.foo.Bar"> <property name="foo" ref="foo"/>

    </bean> <bean .../> </beans>
47. None

48. <beans> <bean id="foo" class="com.foo.Foo"/> <bean id="bar" class="com.foo.Bar"> <property name="foo" ref="foo"/>

    </bean> <bean .../> <bean .../> </beans>
49. None

50. <beans> <bean id="foo" class="com.foo.Foo"/> <bean id="bar" class="com.foo.Bar"> <property name="foo" ref="foo"/>

    </bean> <bean .../> <bean .../>

51. <bean .../> </beans>

52. <beans> <bean id="foo" class="com.foo.Foo"/> <bean id="bar" class="com.foo.Bar"> <property name="foo" ref="foo"/>

    </bean> <bean .../> <bean .../>

53. <bean .../> <import resource="more-beans.xml"/> </beans>

54. <beans> xml simple general purpose flexible

55. but...

56. <beans> xml verbose not typesafe wants special tooling

57. <namespace:*> xml helps

58. e.g. <tx:annotation-driven/> <aop:aspectj-autoproxy/> <jee:jndi-lookup/> <util:list/>

59. <namespace:*> xml concise powerful easier to use

60. but...

61. <namespace:*> xml opaque non-extensible difficult to write your own

62. config style POJOs + 3rd party components ↓ <beans> ┌─────────────────────┐

    XML → │ the Spring container│ └─────────────────────┘ ┌─────────────────────────┐ │ fully configured system │ │ ready for use │ └─────────────────────────┘

63. config style POJOs + 3rd party components ↓ <beans> +

    ┌─────────────────────┐ <namespace:*> → │ the Spring container│ XML └─────────────────────┘ ┌─────────────────────────┐ │ fully configured system │ │ ready for use │ └─────────────────────────┘

64. config style POJOs + 3rd party components ↓ @Component- ┌─────────────────────┐

    scanning → │ the Spring container│ + @Autowired └─────────────────────┘ ┌─────────────────────────┐ │ fully configured system │ │ ready for use │ └─────────────────────────┘

65. @Component public class Foo { // ... } @Component public

    class Bar { private Foo foo;

66. @Autowired public void setFoo(Foo foo) { this.foo = foo; }

    }

67. @Component-scanning + @Autowired eliminates a lot of xml really concise,

    convenient now widely used especially for MVC @Controllers

68. but...

69. @Component-scanning + @Autowired can't wire up third-party code ambiguities can

    arise (enter @Qualifier) still requires xml to bootstrap

70. I mean, if you've got this package com.foo; @Component public

    class Bar { @Autowired public void setFoo(Foo foo) { ... } }

71. I mean, if you've got this package com.foo; @Component public

    class Bar { @Autowired public void setFoo(Foo foo) { ... } } ... then this is kind of ironic, right? <context:component-scan base-package="com.foo"/>

72. config style POJOs + 3rd party components ↓ @Component- ┌─────────────────────┐

    scanning → │ the Spring container│ + @Autowired └─────────────────────┘ ┌─────────────────────────┐ │ fully configured system │ │ ready for use │ └─────────────────────────┘

73. config style POJOs + 3rd party components ↓ @Configuration ┌─────────────────────┐

    + @Bean → │ the Spring container│ └─────────────────────┘ ┌─────────────────────────┐ │ fully configured system │ │ ready for use │ └─────────────────────────┘

74. bean definition @Configuration public class AppConfig { @Bean public QuoteService

    quoteService() { RealTimeQuoteService quoteService = ...; return quoteService; } }

75. bean definition // @Configuration classes =~ <beans/> documents @Configuration public

    class AppConfig { @Bean public QuoteService quoteService() { RealTimeQuoteService quoteService = ...; return quoteService; } }

76. bean definition @Configuration public class AppConfig { // @Bean methods

    ~= <bean/> elements @Bean public QuoteService quoteService() { RealTimeQuoteService quoteService = ...; return quoteService; } }

77. bean definition @Configuration public class AppConfig { @Bean public QuoteService

    quoteService() { RealTimeQuoteService quoteService = // instantiate return quoteService; } }

78. bean definition @Configuration public class AppConfig { @Bean public QuoteService

    quoteService() { RealTimeQuoteService quoteService = ...; // configure return quoteService; } }

79. bean definition @Configuration public class AppConfig { @Bean public QuoteService

    quoteService() { RealTimeQuoteService quoteService = ...; return quoteService; // object managed by Spring } }

80. bean definition @Import(OtherConfig.class) // =~ <import/> @Configuration public class AppConfig

    { @Bean public QuoteService quoteService() { RealTimeQuoteService quoteService = ...; return quoteService; } }

81. bean definition @Import(OtherConfig.class) @Configuration public class AppConfig { @Autowired QuoteSource

    quoteSource; // from OtherConfig @Bean public QuoteService quoteService() { RealTimeQuoteService quoteService = ...; return quoteService; } }

82. bean definition @Import(OtherConfig.class) @Configuration public class AppConfig { @Autowired QuoteSource

    quoteSource; @Bean public QuoteService quoteService() { RealTimeQuoteService quoteService = ...; quoteService.setQuoteSource(quoteSource); // inject return quoteService; } }

83. bootstrap and use public class Main { public static void

    main(String... args) { } }

84. bootstrap and use public class Main { public static void

    main(String... args) { ApplicationContext ctx = new AnnotationConfigApplicationContext(AppConfig.class); QuoteService quoteService = ctx.getBean(QuoteService.class); System.out.println(quoteService.currentValue("AAPL")); } }

85. bootstrap and use public class Main { public static void

    main(String... args) { // bootstrap the Spring container ApplicationContext ctx = new AnnotationConfigApplicationContext(AppConfig.class); QuoteService quoteService = ctx.getBean(QuoteService.class); System.out.println(quoteService.currentValue("AAPL")); } }

86. bootstrap and use public class Main { public static void

    main(String... args) { ApplicationContext ctx = new AnnotationConfigApplicationContext(AppConfig.class); // retrieve the bean we want to use in typesafe fashion QuoteService quoteService = ctx.getBean(QuoteService.class); System.out.println(quoteService.currentValue("AAPL")); } }

87. bootstrap and use public class Main { public static void

    main(String... args) { ApplicationContext ctx = new AnnotationConfigApplicationContext(AppConfig.class); QuoteService quoteService = ctx.getBean(QuoteService.class); // use the bean however desired System.out.println(quoteService.currentValue("AAPL")); } }

88. @Configuration typesafe, object-oriented can configure any component complete programmatic control

    no special tooling required centralized, blueprint-style

89. but...

90. @Configuration no equivalent to <namespace:*/> xml still required for tx

    mgmt, aop, etc

91. @Enable*

92. @Enable* (and friends)

93. e.g. @EnableTransactionManagement @EnableAspectJAutoProxy @EnableLoadTimeWeaving @EnableScheduling @EnableAsync @EnableWebMvc @ComponentScan

94. simple.

95. if you've got this package com.foo; @Component public class Bar

    { @Autowired public void setFoo(Foo foo) { ... } }

96. if you've got this package com.foo; @Component public class Bar

    { @Autowired public void setFoo(Foo foo) { ... } } ... then this is kind of ironic ... <context:component-scan base-package="com.foo"/>

97. I mean, if you've got this package com.foo; @Component public

    class Bar { @Autowired public void setFoo(Foo foo) { ... } } ... but this makes a lot more sense. @ComponentScan("com.foo")

98. and if you've got this package com.foo; @Repository public class

    WidgetRepo { @Transactional public void add(Widget widget) { ... } }

99. and if you've got this package com.foo; @Repository public class

    WidgetRepo { @Transactional public void add(Widget widget) { ... } } ... then why do this ... <tx:annotation-driven/>

100. and if you've got this package com.foo; @Repository public class

     WidgetRepo { @Transactional public void add(Widget widget) { ... } } ... when you could do this? @EnableTransactionManagement

101. example

102. example @EnableScheduling

103. some component package com.foo; public class ChatterBox { public void

     saySomething() { System.out.println(randomWord()); } }

104. some component package com.foo; public class ChatterBox { @Scheduled(fixedRate=1000) public

     void saySomething() { System.out.println(randomWord()); } }

105. some component package com.foo; public class ChatterBox { // (@Scheduled

     has been @Scheduled(fixedRate=1000) // around since Spring 3.0) public void saySomething() { System.out.println(randomWord()); } }

106. some component package com.foo; public class ChatterBox { // "hey

     Spring, call this @Scheduled(fixedRate=1000) // method every second" public void saySomething() { System.out.println(randomWord()); } }

107. configuration package com.foo.config; @Configuration public class Config { @Bean public

     ChatterBox chatterBox() { return new ChatterBox(); } }

108. configuration package com.foo.config; @Configuration @EnableScheduling public class Config { @Bean

     public ChatterBox chatterBox() { return new ChatterBox(); } }

109. configuration package com.foo.config; @Configuration @EnableScheduling // look for and process

     @Scheduled public class Config { @Bean public ChatterBox chatterBox() { return new ChatterBox(); } }

110. configuration package com.foo.config; @Configuration @EnableScheduling public class Config { @Bean

     public ChatterBox chatterBox() { // Spring ensures return new ChatterBox(); // saySomething() method is } // called once per second }

111. @Enable* benefits easy to see what's going on easy to

     write your own adapts smoothly from simple to sophisticated supported beyond core spring-framework e.g. spring-data's @EnableMongoRepositories

112. code-based configuration is complete as of Spring Framework 3.1 can

     configure all major container features mix and match styles as desired

113. but...

114. but... ?

115. no buts.

116. no buts. code-based configuration: can be adopted incrementally but can

     go all the way which means...
117. None
118. None

119. XML IS OVER!

120. XML IS OVER! for dependency injection

121. XML IS OVER! for enabling features of the Spring container

122. XML IS OVER! for Hibernate integration, too

123. Hibernate 4 support Spring 3.1 builds against Hibernate 4 new

     orm.hibernate4 packaging

124. familiar? <bean id="sessionFactory" class="org.sfwk.orm.hib3.AnnotationSessionFactoryBean"> <property name="dataSource" ref="myDataSource"/> <property name="annotatedClasses"> <list>

     <value>com.foo.Person</value> <value>com.foo.Account</value> </list> </property> <property name="hibernateProperties"> <value> hibernate.dialect=org.hibernate.dialect.HSQLDialect </value> </property> </bean>

125. we can do better than that.

126. @Bean public SessionFactory sessionFactory() { return new LocalSessionFactoryBuilder(dataSource()) .addAnnotatedClasses(Person.class, Account.class)

     .buildSessionFactory(); }

127. XML IS OVER!

128. XML IS OVER! and not just Spring XML

129. JPA

130. persistence.xml <persistence xmlns="http://java.sun.com/xml/ns/persistence" xmlns:xsi="..." xsi:schemaLocation="..." version="2.0"> <persistence-unit name="sample"> <jta-data-source>java:/DefaultDS</jta-data-source> <properties>

     <property name="hibernate.dialect" value="org.hibernate.dialect.HSQLDialect"/> </properties> </persistence-unit> </persistence>

131. say goodbye.

132. @Bean public LocalContainerEntityManagerFactoryBean emf() { LocalContainerEntityManagerFactoryBean emf = new LocalContainerEntityManagerFactoryBean();

     emf.setDataSource(dataSource()); emf.setPersistenceXmlLocation( "classpath:META-INF/persistence.xml"); return emf; }

133. @Bean public LocalContainerEntityManagerFactoryBean emf() { LocalContainerEntityManagerFactoryBean emf = new LocalContainerEntityManagerFactoryBean();

     emf.setDataSource(dataSource()); emf.setPersistenceXmlLocation( "classpath:META-INF/persistence.xml"); // no more! return emf; }

134. @Bean public LocalContainerEntityManagerFactoryBean emf() { LocalContainerEntityManagerFactoryBean emf = new LocalContainerEntityManagerFactoryBean();

     emf.setDataSource(dataSource()); emf.setPackagesToScan("com.foo.domain"); return emf; }

135. @Bean public LocalContainerEntityManagerFactoryBean emf() { LocalContainerEntityManagerFactoryBean emf = new LocalContainerEntityManagerFactoryBean();

     emf.setDataSource(dataSource()); // scan classpath for JPA @Entity types emf.setPackagesToScan("com.foo.domain"); return emf; }

136. XML IS OVER! and not just Spring XML

137. web.xml

138. <web-app> <servlet> <servlet-name>dispatcher</servlet-name> <servlet-class> org.springframework.web.servlet.DispatcherServlet </servlet-class> <init-param> <param-name>contextConfigLocation</param-name> <param-value> /WEB-INF/spring/dispatcher-config.xml

     </param-value> </init-param> <load-on-startup>1</load-on-startup> </servlet> <servlet-mapping> <servlet-name>dispatcher</servlet-name> <url-pattern>/</url-pattern> </servlet-mapping> <web-app>

139. gone. (if you've got Servlet 3)

140. public class WebInit implements WebApplicationInitializer { @Override public void onStartup(ServletContext

     container) { AnnotationConfigWebApplicationContext ctx = new AnnotationConfigWebApplicationContext() ctx.register(DispatcherConfig.class); ServletRegistration.Dynamic dispatcher = container.addServlet( "dispatcher", new DispatcherServlet(ctx)); dispatcher.setLoadOnStartup(1); dispatcher.addMapping("/"); } }
141. None

142. WebApplicationInitializer allows code-based config of servlet container builds on Servlet

     3's ServletContainerInitializer auto-detected on Servlet container startup

143. application-context.xml persistence.xml web.xml

144. XML IS OVER.

145. None
146. None
147. None

148. XML IS OVER, if you want it*

149. *which means that you really shouldn't worry, because XML support

     is definitely not going anywhere. This is a concern that commonly comes up when we talk about annotations and such, but we've said it before and we'll say it again: XML was, is, and ever will be a first class citizen in Spring. These new features just mean that if you don't want XML, you don't have to use it. That's all. kthx, bye.

150. config style POJOs + 3rd party components ↓ @Configuration ┌─────────────────────┐

     + @Bean → │ the Spring container│ └─────────────────────┘ ┌─────────────────────────┐ │ fully configured system │ │ ready for use │ └─────────────────────────┘

151. config style POJOs + 3rd party components ↓ @Configuration ┌─────────────────────┐

     + @Bean → │ the Spring container│ + @Enable* └─────────────────────┘ ┌─────────────────────────┐ │ fully configured system │ │ ready for use │ └─────────────────────────┘

152. config style POJOs + 3rd party components (hybrid) ↓ <bean>

     + ┌─────────────────────┐ @Component + → │ the Spring container│ @Configuration └─────────────────────┘ ┌─────────────────────────┐ │ fully configured system │ │ ready for use │ └─────────────────────────┘

153. recommendations

154. recommendations go for 100% code-based config @Component + @Autowired for

     "your" components @Bean for third-party components @Enable to control framework features

155. modern enterprise app config concise comprehensive clear and communicative flexible

     and extensible code-based and typesafe

156. much more Environment and PropertySource APIs bean definition profiles testing

     support for @Configuration classes brand-new spring-scala project spring-integration Scala & Groovy DSLs

157. check it out everything in this talk available in 3.1

     spring-framework 3.2 RC1 is now out a great time for feedback RC2 in a few weeks GA by year end

158. get involved everything's on GitHub see CONTRIBUTING.md new Gradle build

     in 3.2 makes it easy

159. questions?

160. thanks! @cbeams | cbeams.github.com/modern-config @springframework | github.com/springsource example code: github.com/cbeams/distyles
