  1. Challenges of Distributing
    Postgres:

    A Citus Story
    Ozgun Erdogan
    QCon San Francisco | November 2017

    View Slide

  2. Developers Love Postgres
    PostgreSQL
    MySQL
    MongoDB
    SQL Server +
    Oracle
    0%
    18%
    35%
    53%
    70%
    Mar-11 Sept-11 Mar-12 Sept-12 Mar-13 Sept-13 Mar-14 Sept-14 Mar-15 Sept-15 Mar-16
    RDBMS: PostgreSQL, MySQL, Microsoft SQL Server, Oracle
    Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  3. I love Postgres, too
    3 Ozgun Erdogan | QCon San Francisco 2017
    Ozgun Erdogan
    CTO of Citus Data
    Distributed Systems
    Distributed Databases
    Formerly of Amazon
    Love drinking margaritas

    View Slide

  4. 4

    View Slide

  5. Our mission at Citus Data
    5 Ozgun Erdogan | QCon San Francisco 2017
    Make it so SaaS businesses

    never have to worry about
    scaling their database again

    View Slide

  6. What is the Citus database?
    1.Scales out PostgreSQL
    2.Extension to PostgreSQL
    3.Available in 3 Ways
    Ozgun Erdogan | QCon San Francisco 2017
    • Using sharding & replication
    • Query engine parallelizes SQL queries across many nodes
    • Using PostgreSQL extension APIs

    View Slide

  7. Citus, Packaged Three Ways
    Ozgun Erdogan | QCon San Francisco 2017
    Open

    Source
    Enterprise

    Software
    Fully-Managed

    Database as a Service
    github.com/citusdata/citus

    View Slide

  8. Simplified Citus Architecture

    View Slide

  9. 3 Challenges Distributing Postgres
    1. PostgreSQL and High Availability
    2. PostgreSQL is huge. How to keep up with it
    3. Distributed transactions
    Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  10. PostgreSQL &

    High Availability (HA)
    Designing for a Cloud-native world
    1

    View Slide

  11. Why is High Availability hard?
    PostgreSQL replication uses one primary &
    multiple secondary nodes. Two challenges:
    1. Most Postgres clients aren’t smart. When the
    primary fails, they retry the same IP.
    2. Postgres replicates entire state. This makes it
    resource intensive to reconstruct new nodes from a
    primary.
    Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  12. Database Failures Should Be Transparent
    Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  13. Database Failures Shouldn’t Be a Big Deal
    1. PostgreSQL streaming replication to replicate from
    primary to secondary. Back up to S3.
    2. Volume level replication to replicate to secondary’s
    volume. Back up to S3.
    3. Incremental backups to S3. Reconstruct secondary
    nodes from S3.
    Ozgun Erdogan | QCon San Francisco 2017
    3 Methods for HA & Backups in Postgres

    View Slide

  14. Postgres - Streaming Replication (1)
    Write-ahead logs
    (streaming repl.)
    Table foo
    Primary –
    PostgreSQL
    streaming repl.
    Table bar
    WAL logs
    Table foo
    Table bar
    WAL logs
    Secondary –
    PostgreSQL
    streaming repl.
    Monitoring Agents -
    streaming repl.
    setup & auto failover
    S3 / Blob Storage
    (Encrypted)
    Backup
    Process
    Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  15. Postgres – AWS RDS & Azure (2)
    Postgres
    Primary
    Monitoring Agents
    (Auto node failover)
    Persistent Volume
    Postgres
    Standby
    S3 / Blob Storage
    (Encrypted)
    Table foo
    Table bar
    WAL logs
    Table foo
    Table bar
    WAL logs
    Backup process
    Backup
    Process
    Persistent Volume
    Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  16. Postgres – Reconstruct from WAL (3)
    Postgres
    Primary
    Monitoring Agents
    (Auto node failover)
    Persistent Volume
    Postgres
    Secondary
    Backup
    Process
    S3 / Blob Storage
    (Encrypted)
    Table foo
    Table bar
    WAL logs
    Persistent Volume
    Table foo
    Table bar
    WAL logs
    Backup process
    Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  17. WHO DOES THIS? PRIMARY BENEFITS
    Streaming Replication
    (local / ephemeral disk)
    On-prem

    Manual EC2
    Simple to set up
    Direct I/O: High I/O & large storage
    Disk Mirroring
    RDS

    Azure Preview
    Works for MySQL and PostgreSQL

    Data durability in cloud environments
    Reconstruct from WAL
    Heroku

    Citus Cloud
    Enables Fork and PITR
    Node reconstruction in background
    (Data durability in cloud environments)
    How do these approaches compare?
    17 Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  18. Summary
    • In PostgreSQL, a database node’s state gets
    replicated in its entirety. The replication can be set up
    in three ways.
    • Reconstructing a secondary node from S3 makes
    bringing up or shooting down nodes easy.
    • When you shard your database, the state you need to
    replicate per node becomes smaller.
    Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  19. PostgreSQL is huge
    How do you scale all features?
    2

    View Slide

  20. 3 ways to build a distributed database
    1. Build a distributed database from scratch
    2. Middleware sharding (mimic the parser)
    3. Fork your favorite database (like PostgreSQL)
    Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  21. Example Transaction Block
    Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  22. Postgres Features, Tools & Frameworks
    • PostgreSQL manual (US Letter)
    • Clients for diff programming
    languages
    • ORMs, libraries, GUIs
    • Tools (dump, restore, analyze)
    • New features
    Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  23. At First, Forked PostgreSQL with Style
    Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  24. Two Stage Query Optimization
    1. Plan to minimize network I/O
    2. Nodes talk to each other using SQL over libpq
    3. Learned to cooperate with planner / executor bit by bit
    (Volcano style executor)
    Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  25. Citus Architecture (Simplified)
    25
    SELECT avg(revenue)
    FROM sales
    Coordinator
    SELECT sum(revenue), count(revenue)
    FROM table_1001
    SELECT sum … FROM table_1003
    Worker node 1
    Table metadata
    Table_1001
    Table_1003
    SELECT sum … FROM table_1002
    SELECT sum … FROM table_1004
    Worker node 2
    Table_1002
    Table_1004
    Worker node N
    .
    .
    .
    .
    .
    .
    Each node PostgreSQL with Citus installed
    1 shard = 1 PostgreSQL table
    Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  26. Unfork Citus using Extension APIs
    CREATE EXTENSION citus;
    • System catalogs – Distributed metadata
    • Planner hook – Insert, Update, Delete, Select
    • Executor hook – Insert, Update, Delete, Select
    • Utility hook – Alter Table, Create Index, Vacuum, etc.
    • Transaction & resources handling – file descriptors, etc.
    • Background worker process – Maintenance processes
    (distributed deadlock detection, task tracker, etc.)
    • Logical decoding – Online data migrations
    Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  27. PostgreSQL has transactions.
    How to handle distributed transactions
    3

    View Slide

  28. BEGIN
    INSERT
    UPDATE
    SELECT
    COMMIT
    ROLLBA
    CK

    View Slide

  29. Consistency in Distributed Databases
    1. 2PC: All participating nodes need to be up
    2. Paxos: Achieves consensus with quorum
    3. Raft: More understandable alternative to
    Paxos
    Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  30. Concurrency in Distributed Databases
    Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  31. Locks

    View Slide

  32. What is a Lock?
    • Protects against concurrent modifications.
    • Locks are released at the end of a
    transaction.

    View Slide

  33. Transactions Block on 1st Conflicting Lock

    View Slide

  34. Transactions and Concurrency
    • Transactions that don’t modify the same
    row can run concurrently.

    View Slide

  35. Transactions and Concurrency
    • Transactions that don’t modify the same
    row can run concurrently.

    View Slide

  36. Transactions and Concurrency
    • Transactions that don’t modify the same
    row can run concurrently.

    View Slide

  37. Transactions and Concurrency
    • Transactions that don’t modify the same
    row can run concurrently.

    View Slide

  38. Transactions and Concurrency
    • Transactions that don’t modify the same
    row can run concurrently.

    View Slide

  39. Transactions and Concurrency
    • Transactions that don’t modify the same
    row can run concurrently.

    View Slide

  40. Transactions and Concurrency
    • Transactions that don’t modify the same
    row can run concurrently.

    View Slide

  41. Transactions and Concurrency
    • Transactions that don’t modify the same
    row can run concurrently.

    View Slide

  42. Transactions and Concurrency
    • Transactions that don’t modify the same
    row can run concurrently.

    View Slide

  43. Distributed transactions are a complex topic
    • Most articles on distributed transactions focus on data
    consistency.
    • Data consistency is only one side of the coin. If you’re
    using a relational database, your application benefits
    from another key feature: deadlock detection.
    • https://www.citusdata.com/blog/2017/08/31/
    databases-and-distributed-deadlocks-a-faq
    Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  44. So now what? We talked about 3
    challenges distributing Postgres
    1. PostgreSQL, Replication, High Availability
    2. Tradeoffs in building a distributed database—
    and how we chose PostgreSQL’s extension
    APIs
    3. Distributed deadlock detection & distributed
    transactions
    Ozgun Erdogan | QCon San Francisco 2017

    View Slide

  45. 45
    Solving a very complex problem

    View Slide

  46. 46
    “SQL is hard, not impossible, to scale”

    View Slide

  47. © 2017 Citus Data. All right reserved.
    [email protected]
    Questions?
    @citusdata
    Ozgun Erdogan
    www.citusdata.com
