PROTOCOLS AND STRUCTS FOR EFFECTIVE DATA FLOW
THE DOMAIN CHECK-IN PROCESS NOTIFY
RECAP ABOUT PROTOCOLS AND STRUCTS
STRUCTS defmodule Checkin do defstruct id: nil, lat: 0.0, lng:
0.0 end
STRUCTS %Checkin{id: "123", lat: 51.50, lng: 0.12} struct(Checkin, id: "123",
lat: 51.50, lng: 0.12) struct(Checkin, %{id: "123", lat: 51.50, lng: 0.12}) struct(Checkin, id: "123", lat: 51.50, lng: 0.12, ignored: true)
PROTOCOLS defprotocol Persistence do def create(thing) end
IMPLEMENTATION defimpl Persistence, for: Checkin do def create(checkin) do %Doc{class:
"Checkin", fields: Map.from_struct(checkin)} |> Repo.create end end
FALLBACK defprotocol Persistence do @fallback_to_any true def create(thing) end
FALLBACK defimpl Persistence, for: Any do def create(thing) do class
= Map.get(thing, :__struct__) |> to_string %Doc{class: class, fields: Map.from_struct(thing)} |> Repo.create end end
USAGE %Checkin{id: "123", lat: 51.50, lng: 0.12} |> Persistence.create
FLOW MESSAGE IDENTIFY LOG PROCESS LOG NOTIFY
FLOW MESSAGE IDENTIFY LOG PROCESS LOG NOTIFY
IDENTIFY { "meta" : { "version" : 1, "topic" :
"checkins", "type" : "create", "request_id" : "15456d4e-782b-11e5-8bcf-feff819cdc9f" }, "data" : { "ref" : "123ASDS", "lat" : 51.50, "lng" : 0.12 } }
IDENTIFY defmodule V1.Checkin.Create do defstruct request_id: nil, ref: nil, lat:
0.0, lng: 0.0 end
IDENTIFY def identify(payload) do case payload["meta"] do %{"version" => 1,
"topic" => "checkins", "type" => "create"} -> V1.Checkins.Create _other -> {:error, :unsupported_payload} end end
POPULATE def populate(struct_name, payload) do request_id = get_in(payload, "meta", "request_id")
struct_attrs = Map.put(payload["data"], "request_id", request_id) Kernel.struct(struct_name, Utils.atomise_map(struct_attrs)) end
ALL TOGETHER NOW message |> identify |> populate(message)
WINS STABLE INTERFACE DEFINES A BOUNDARY EXTENSIBLE INTENTION REVEALING
FLOW MESSAGE IDENTIFY LOG PROCESS LOG NOTIFY
LOG defimpl String.Chars, for: V1.Checkins.Create do def to_string(create_struct) do "type=create
status=accepted request_id=#{create_struct.request_id} ref={create_struct.ref}" end end
LOG def log(item) do :ok = Logger.info item item end
ALL TOGETHER NOW message |> identify |> populate(message) |> log
FLOW MESSAGE IDENTIFY LOG PROCESS LOG NOTIFY
PROCESS defimpl Job, for: V1.Checkin.Create do def process(create_struct) do {:ok,
new_record} = Persistence.create(create_struct) %V1.Checkin.Created{request_id: create_struct.request_id, record: new_record} end end
ALL TOGETHER NOW message |> identify |> populate(message) |> log
|> Job.process
WINS STABLE INTERFACE DEFINES A BOUNDARY EXTENSIBLE INTENTION REVEALING
FLOW MESSAGE IDENTIFY LOG PROCESS LOG NOTIFY
LOG defimpl String.Chars, for: V1.Checkins.Created do def to_string(created_struct) do "type=create
status=processed request_id=#{create_struct.request_id} id={created_struct.record.id}" end end
ALL TOGETHER NOW message |> identify |> populate(message) |> log
|> Job.process |> log
NOTIFY MESSAGE IDENTIFY LOG PROCESS LOG NOTIFY
NOTIFY defimpl Notify, for: V1.Checkin.Created do def topics(created_struct), do: ["checkins",
"users"] def to_message(created_struct) do %Message{request_id: created_struct.request_id, type: :create, data: %{id: created_struct.record.id}} end end
NOTIFY def notify(item) do payload = Notify.to_message(item) topics = Notify.topics(item)
PubSub.broadcast(payload, topics) end
ALL TOGETHER NOW message |> identify |> populate(message) |> log
|> Job.process |> log |> notify
EXECUTION MESSAGE IDENTIFY LOG PROCESS LOG NOTIFY LISTENER PROCESS POOL
PUBSUB POOL
EXTENDING FURTHER ADD NEW STRUCTS IMPLEMENT PROTOCOLS
CORE IDEAS ASSIGN INTENT TO DATA DEFINE FUNCTIONALITY AS PROTOCOLS
DEFINE STRICT BOUNDARIES BETWEEN STEPS
THANK YOU! http://bit.ly/ff-protocols-structs
PLUG ELIXIR, JAVASCRIPT, ELM DEVELOPMENT ELIXIR, JAVASCRIPT, ELM TRAINING ASK
ME ABOUT IT!
