clusterでLOD対応したときの話 / cluster LOD

clusterでLOD対応したときの話 / cluster LOD

2021年3月31日(水) @第5回VRM勉強会 by xyx (@xanxys_)

LOD全体の裏話は↓にて
Cluster Tech Talk https://youtu.be/WyC76fzzzCA?t=7629

Avatar for Cluster, Inc.

Cluster, Inc.

March 31, 2021
Tweet

More Decks by Cluster, Inc.

Other Decks in Programming

Transcript

  1. Cluster, Inc. All Rights Reserved. VRM minifier 20,301 verts /

    23,387 tris / 9.8MB
 7 static mesh + 4 skinned mesh
 100 nodes
 1,998 verts / 1,526 tris / 0.2MB
 1 skinned mesh
 18 nodes

  2. Cluster, Inc. All Rights Reserved. VRM minifier 出力仕様 • bone:

    VRM必須ボーンのみ • mesh: Δ~2K, ~2K頂点 skinned mesh ひとつ • material: unlit (opaque or alphacut), ~256px ひとつ 実装 • go • qmuntal/gltf + 数千行の独自コード 設計思想 • 出力VRMの使用メモリの上限保証 • 小ささの限界追求: プロダクト設計のベースラインとして機能させる ◦ 非表示やプレースホルダのぎりぎり手前
  3. Cluster, Inc. All Rights Reserved. マテリアル変換 Standard/MToon/Unlit → Unlitに •

    base textureとemissive textureの統合 • transparent → alpha cut • 透明部分のmesh消去 VRoid Studioの服は 透明テクスチャ多用してるので 簡略化前に削らないと 見えないメッシュに貴重なポリゴン が吸われてしまう
  4. Cluster, Inc. All Rights Reserved. メッシュ変換 I ひとつの空間に正規化してから統合 skinningはjoint nodeとinverse

    bind matrixが大事 • node(skinとskeleton)のtransformは不要 glTF仕様では珍しく(?)skinは解釈が難しい書き方になってる https://github.com/KhronosGroup/glTF-Tutorials/blob/master/gltfTutori al/gltfTutorial_020_Skins.md 大変そうにしてる人たち https://github.com/KhronosGroup/glTF-Tutorials/issues/17 https://github.com/KhronosGroup/glTF/issues/1270 https://github.com/KhronosGroup/glTF/pull/1195
  5. Cluster, Inc. All Rights Reserved. メッシュ変換 II メッシュ簡略化: ↓の論文を実装するだけ 高速化にコツがいる

    • 部分的にpriorityが更新されるpriority queue ファンシーな簡略化アルゴリズムより、 実データ・要望に合わせたコスト関数の設計が肝 Surface Simplification Using Quadric Error Metrics (1997) doi.org/10.1145/258734.258849 https://www.cs.cmu.edu/~./garland/Papers/quadrics.pdf
  6. Cluster, Inc. All Rights Reserved. 学び 実データで地道に改善していくのが大事 存在する仕様はすべて使われる 例 skin

    meshのbone hierarchyのネスト構造・スケーリング • アバター改変勢のデータ構造の特徴 opaqueの場合alphaは無視しなければならない(MUST) • 透明なテクスチャをopaqueで使ってる人がいる UVのrepeat mode textureが存在しない(flat colorな)mesh などなど…
  7. Cluster, Inc. All Rights Reserved. me/v 元になってるのはme/v • Web VRM

    viewer • 編集もちょっとできる • glTFデバッグに便利 これは個人でやってて オープンソース https://xanxys.github.io/mev/
