Just-Right Consistency - Closing the CAP Gap
J on the Beach 2017
Christopher Meiklejohn
May 18, 2017
Transcript
157 slides
-
Just-Right Consistency Closing the CAP Gap Christopher S. Meiklejohn (@cmeik)
J on the Beach 2017, Málaga, Spain -
Outline: Closing the CAP Gap • Just-Right Consistency Available as
possible, and consistent when necessary 2 -
Outline: Closing the CAP Gap • Just-Right Consistency Available as
possible, and consistent when necessary • AntidoteDB The first database that provides transactions with strong semantics, targeted at the JRC approach 2 -
Outline: Closing the CAP Gap • Just-Right Consistency Available as
possible, and consistent when necessary • AntidoteDB The first database that provides transactions with strong semantics, targeted at the JRC approach • Moving forward Antidote’s path forward from research to company and product 2 -
A Clients read and write against the primary copy. [Photo:
http://vignette3.wikia.nocookie.net/the-titans-rp-and-information/images/f/f5/Blank-World-map2.gif/revision/latest/scale-to-width-down/1280?cb=20141016203452] -
A B C Geo-replicated for both fault-tolerance and high-availability. [Photo:
http://vignette3.wikia.nocookie.net/the-titans-rp-and-information/images/f/f5/Blank-World-map2.gif/revision/latest/scale-to-width-down/1280?cb=20141016203452] -
A B C Clients read and write locally for low-latency.
[Photo: http://vignette3.wikia.nocookie.net/the-titans-rp-and-information/images/f/f5/Blank-World-map2.gif/revision/latest/scale-to-width-down/1280?cb=20141016203452] -
A B C What happens if C can’t communicate with
other replicas? [Photo: http://vignette3.wikia.nocookie.net/the-titans-rp-and-information/images/f/f5/Blank-World-map2.gif/revision/latest/scale-to-width-down/1280?cb=20141016203452] -
A B C Choice 1: Consistent-Under-Partition (CP) • Synchronize each
operation Maintains “single system image” [Photo: http://vignette3.wikia.nocookie.net/the-titans-rp-and-information/images/f/f5/Blank-World-map2.gif/revision/latest/scale-to-width-down/1280?cb=20141016203452] -
A B C Choice 1: Consistent-Under-Partition (CP) • Synchronize each
operation Maintains “single system image” • Spanner/F1, serializability model Coordination is expensive; Spanner typically has to wait 100ms to commit an update transaction [Photo: http://vignette3.wikia.nocookie.net/the-titans-rp-and-information/images/f/f5/Blank-World-map2.gif/revision/latest/scale-to-width-down/1280?cb=20141016203452] -
A B C Choice 1: Consistent-Under-Partition (CP) • Synchronize each
operation Maintains “single system image” • Spanner/F1, serializability model Coordination is expensive; Spanner typically has to wait 100ms to commit an update transaction Over-conservative, but easy to program! [Photo: http://vignette3.wikia.nocookie.net/the-titans-rp-and-information/images/f/f5/Blank-World-map2.gif/revision/latest/scale-to-width-down/1280?cb=20141016203452] -
A B C Choice 2: Available-Under-Partition (AP) • Riak, Cassandra,
Dynamo Operations issued against local copy, and across the cluster in parallel [Photo: http://vignette3.wikia.nocookie.net/the-titans-rp-and-information/images/f/f5/Blank-World-map2.gif/revision/latest/scale-to-width-down/1280?cb=20141016203452] -
A B C Choice 2: Available-Under-Partition (AP) • Riak, Cassandra,
Dynamo Operations issued against local copy, and across the cluster in parallel • Local operation only, asynchronous propagation Stale reads and write conflicts will occur without synchronization [Photo: http://vignette3.wikia.nocookie.net/the-titans-rp-and-information/images/f/f5/Blank-World-map2.gif/revision/latest/scale-to-width-down/1280?cb=20141016203452] -
A B C Choice 2: Available-Under-Partition (AP) • Riak, Cassandra,
Dynamo Operations issued against local copy, and across the cluster in parallel • Local operation only, asynchronous propagation Stale reads and write conflicts will occur without synchronization Available, but difficult to program! [Photo: http://vignette3.wikia.nocookie.net/the-titans-rp-and-information/images/f/f5/Blank-World-map2.gif/revision/latest/scale-to-width-down/1280?cb=20141016203452] -
A B C CAP Theorem High cost CP AP [Photo:
http://vignette3.wikia.nocookie.net/the-titans-rp-and-information/images/f/f5/Blank-World-map2.gif/revision/latest/scale-to-width-down/1280?cb=20141016203452] -
A B C CAP Theorem High cost Low availability CP
AP [Photo: http://vignette3.wikia.nocookie.net/the-titans-rp-and-information/images/f/f5/Blank-World-map2.gif/revision/latest/scale-to-width-down/1280?cb=20141016203452] -
A B C CAP Theorem High cost Low availability Synchronization
CP AP [Photo: http://vignette3.wikia.nocookie.net/the-titans-rp-and-information/images/f/f5/Blank-World-map2.gif/revision/latest/scale-to-width-down/1280?cb=20141016203452] -
A B C CAP Theorem High cost Low availability Synchronization
Low cost CP AP [Photo: http://vignette3.wikia.nocookie.net/the-titans-rp-and-information/images/f/f5/Blank-World-map2.gif/revision/latest/scale-to-width-down/1280?cb=20141016203452] -
A B C CAP Theorem High cost Low availability Synchronization
Low cost High availability CP AP [Photo: http://vignette3.wikia.nocookie.net/the-titans-rp-and-information/images/f/f5/Blank-World-map2.gif/revision/latest/scale-to-width-down/1280?cb=20141016203452] -
A B C CAP Theorem High cost Low availability Synchronization
Low cost High availability Anomalies CP AP [Photo: http://vignette3.wikia.nocookie.net/the-titans-rp-and-information/images/f/f5/Blank-World-map2.gif/revision/latest/scale-to-width-down/1280?cb=20141016203452] -
A B C CAP Theorem High cost Low availability Synchronization
Low cost High availability Anomalies CP AP False dichotomy! [Photo: http://vignette3.wikia.nocookie.net/the-titans-rp-and-information/images/f/f5/Blank-World-map2.gif/revision/latest/scale-to-width-down/1280?cb=20141016203452] -
A B C CAP Theorem High cost Low availability Synchronization
Low cost High availability Anomalies CP AP False dichotomy! [Photo: http://vignette3.wikia.nocookie.net/the-titans-rp-and-information/images/f/f5/Blank-World-map2.gif/revision/latest/scale-to-width-down/1280?cb=20141016203452] • No “one-size-fits-all” consistency model Choosing either model will either be over-conservative or risk anomalies -
A B C CAP Theorem High cost Low availability Synchronization
Low cost High availability Anomalies CP AP False dichotomy! [Photo: http://vignette3.wikia.nocookie.net/the-titans-rp-and-information/images/f/f5/Blank-World-map2.gif/revision/latest/scale-to-width-down/1280?cb=20141016203452] • No “one-size-fits-all” consistency model Choosing either model will either be over-conservative or risk anomalies • Application-level invariants Instead, tailor consistency choices based on application- level invariants for each operation -
Just Right Consistency • Preserve sequential patterns Applications written sequentially
that are correct should maintain correctness under concurrency 13 -
Just Right Consistency • Preserve sequential patterns Applications written sequentially
that are correct should maintain correctness under concurrency • AP-compatible invariants Strongest AP model; invariants that only require “one way” communications 13 -
Just Right Consistency • Preserve sequential patterns Applications written sequentially
that are correct should maintain correctness under concurrency • AP-compatible invariants Strongest AP model; invariants that only require “one way” communications • CAP-sensitive invariants Transactions that require coordination; “two way” communication invariants 13 -
Just Right Consistency • Preserve sequential patterns Applications written sequentially
that are correct should maintain correctness under concurrency • AP-compatible invariants Strongest AP model; invariants that only require “one way” communications • CAP-sensitive invariants Transactions that require coordination; “two way” communication invariants • Tools for analysis and verification Identify and verify application has sufficient synchronization to ensure application invariants 13 -
Fælles Medicinkort • FMK [production] / FMKe [synthetic workload] Danish
National Joint Medicine Card; operating 24x7 since 2013 for 6 million Danish citizens 15 -
Fælles Medicinkort • FMK [production] / FMKe [synthetic workload] Danish
National Joint Medicine Card; operating 24x7 since 2013 for 6 million Danish citizens • Lifecycle management for prescriptions Involves patient, pharmacy, and doctor management around active prescriptions in Denmark 15 -
Fælles Medicinkort • FMK [production] / FMKe [synthetic workload] Danish
National Joint Medicine Card; operating 24x7 since 2013 for 6 million Danish citizens • Lifecycle management for prescriptions Involves patient, pharmacy, and doctor management around active prescriptions in Denmark • Assumed correct in isolation “Correct-Individually”, C in ACID, each operation ensures application-level invariants 15 -
Fælles Medicinkort • FMK [production] / FMKe [synthetic workload] Danish
National Joint Medicine Card; operating 24x7 since 2013 for 6 million Danish citizens • Lifecycle management for prescriptions Involves patient, pharmacy, and doctor management around active prescriptions in Denmark • Assumed correct in isolation “Correct-Individually”, C in ACID, each operation ensures application-level invariants 15 • create-prescription Create prescription for patient, doctor, pharmacy • update-prescription-medication Add or increase medication to prescription • process-prescription Deliver a medication by a pharmacy • get-*-prescriptions Query functions to return information about prescriptions -
FMKe Invariants • Relative order [secondary indexes] Create a prescription
and reference it by a patient 16 -
FMKe Invariants • Relative order [secondary indexes] Create a prescription
and reference it by a patient • Joint update [atomicity] Create prescription, then update doctor, patient, and pharmacy 16 -
FMKe Invariants • Relative order [secondary indexes] Create a prescription
and reference it by a patient • Joint update [atomicity] Create prescription, then update doctor, patient, and pharmacy • Precondition check [if, then] Medication should not be over delivered 16 -
AP-compatible • No synchronization Updates occur locally without blocking, no
synchronization in the critical path 18 -
AP-compatible • No synchronization Updates occur locally without blocking, no
synchronization in the critical path • Asynchronous operation Updates are fast, available, and exploit concurrency 18 -
AP-compatible • No synchronization Updates occur locally without blocking, no
synchronization in the critical path • Asynchronous operation Updates are fast, available, and exploit concurrency • Compatible invariants Relative order and joint update invariants can be preserved 18 -
RA RB 1 set(1) 3 2 set(2) set(3) 2 3
Concurrent assignments don’t commute! -
RA RB 1 set(1) 3 2 set(2) set(3) 2 3
Concurrent assignments don’t commute! Assignment requires CP. -
Can we make non-commutative updates commutative? 24 Can we find
a suitable data model for AP systems? -
RA RB 1 set(1) 3 2 set(2) set(3) ? ?
How do we deterministically pick a value to keep? -
RA RB 1 set(1) 3 2 set(2) set(3) ? ?
How do we deterministically pick a value to keep? Do we use a timestamp? (like Cassandra, and drop a value?) -
RA RB 1 set(1) 3 2 set(2) set(3) ? ?
How do we deterministically pick a value to keep? Do we use a timestamp? (like Cassandra, and drop a value?) Timestamps make concurrent operations commute but fail to capture intent. -
RA RB 1 set(1) 3 2 set(2) set(3) 3 3
max(2,3) max(2,3) Deterministic conflict resolution function. -
RA RB 1 set(1) 3 2 set(2) set(3) 3 3
max(2,3) max(2,3) Deterministic conflict resolution function. CRDTs generalize this framework. -
Conflict-Free Replicated Data Types • Replicated abstract data types
Extension of sequential data type that encapsulates deterministic merge function 28 -
Conflict-Free Replicated Data Types • Replicated abstract data types
Extension of sequential data type that encapsulates deterministic merge function • Many existing designs Sets, counters, registers, flags, maps 28 -
RA RB Q true(Q) P true(P) Program order implies ordering
relationship. -
RA RB Q true(Q) P true(P) Ordering is respected at
other replicas. -
RA RB Q true(Q) P true(P) Out of order propagation
violates invariant! -
RA RB Q true(Q) P true(P) P is true, Q
is NOT true! -
RA RB Q true(Q) P true(P) Reordering allows default password
to be used to login! -
Causal Consistency • Respect causality Ensure updates are delivered in
the causal order 44 -
Causal Consistency • Respect causality Ensure updates are delivered in
the causal order • Strongest available AP model Always able to return some compatible version for an object 44 -
Causal Consistency • Respect causality Ensure updates are delivered in
the causal order • Strongest available AP model Always able to return some compatible version for an object • Secondary indexing Causal consistency is sufficient for providing secondary indexing in an AP database 44 -
RA RB C1 Rx create Rx Dr update Dr(Rx) Add
reference in doctor record. -
RA RB C1 Rx create Rx Dr update Dr(Rx) Pt
update Pt(Rx) Add reference in patient record. -
RA RB C1 Rx create Rx Dr update Dr(Rx) Pt
update Pt(Rx) Ph update Ph(Rx) Add reference in pharmacy record. -
RA RB C1 Rx create Rx Dr update Dr(Rx) Pt
update Pt(Rx) Ph update Ph(Rx) Updates are causally consistent. -
RA RB C1 Rx create Rx Dr update Dr(Rx) Pt
update Pt(Rx) Ph update Ph(Rx) Client can read inconsistent state. -
RA RB C1 Rx create Rx Dr update Dr(Rx) Pt
update Pt(Rx) Ph update Ph(Rx) Client is missing update to pharmacy. -
RA RB C1 T1 create Rx update Dr(Rx) update Pt(Rx)
update Ph(Rx) Group updates into an atomic transaction. -
RA RB C1 T1 create Rx update Dr(Rx) update Pt(Rx)
update Ph(Rx) Updates reflect “All-Or-Nothing” property through snapshots. -
RA RB C1 T1 create Rx update Dr(Rx) update Pt(Rx)
update Ph(Rx) T2 Transactions are delivered in causal order. -
RA RB C1 T1 create Rx update Dr(Rx) update Pt(Rx)
update Ph(Rx) T2 Therefore, snapshots are causally consistent. -
RA(2) RB(2) ? ? RC(2) ? Three replicas each with
two available medications. -
RA(2) RB(2) 1 1 1 pp(1) RC(2) 1 Replica A
checks precondition and delivers medication. -
RA(2) RB(2) 1 1 1 pp(1) RC(2) 1 Correct outcome
where one medication remains. -
RA(2) RB(2) ? ? RC(2) ? Three replicas each with
two available medications. -
RA(2) RB(2) 4 4 1 pp(1) RC(2) 4 4 add(3)
Replica A checks precondition and delivers medication. -
RA(2) RB(2) 4 4 1 pp(1) RC(2) 4 4 add(3)
Replica C adds three medications to the prescription. -
RA(2) RB(2) 4 4 1 pp(1) RC(2) 4 4 add(3)
Correct outcome with four remaining medications. -
RA(2) RB(2) 4 4 1 pp(1) RC(2) 4 4 add(3)
Correct outcome with four remaining medications. Precondition is stable under concurrent addition. -
RA(2) RB(2) ? ? RC(2) ? Three replicas each with
two available medications. -
RA(2) RB(2) -1 -1 1 pp(1) RC(2) -1 0 pp(2)
Replica A checks precondition and delivers medication. -
RA(2) RB(2) -1 -1 1 pp(1) RC(2) -1 0 pp(2)
Replica C concurrently checks precondition and delivers two medications. -
RA(2) RB(2) -1 -1 1 pp(1) RC(2) -1 0 pp(2)
Incorrect outcome violating non-negative invariant. -
RA(2) RB(2) -1 -1 1 pp(1) RC(2) -1 0 pp(2)
Incorrect outcome violating non-negative invariant. Precondition is NOT stable under concurrent fulfillment. -
RA(2) RB(2) -1 -1 1 pp(1) RC(2) -1 0 pp(2)
Incorrect outcome violating non-negative invariant. Precondition is NOT stable under concurrent fulfillment. • Forbid concurrency Prevent operations from proceeding without synchronization to enforce invariant • Allow concurrency and remove invariant Allow operation to proceed, knowing that the invariant may be violated under concurrent operations -
RA RB I? I? ? Upre? RC I? ? Vpre?
Analyze possible pairs of concurrent operations… -
RA RB I? I? ? Upre? RC I? ? Vpre?
…to identify operations where the invariant can be violated. -
CISE Analysis • Individually correct Individual operations never violate the
invariant • Convergence Concurrent effects commute 81 -
CISE Analysis • Individually correct Individual operations never violate the
invariant • Convergence Concurrent effects commute • Precondition stability Preconditions are stable under every pair of concurrent operations 81 -
CISE Analysis • Individually correct Individual operations never violate the
invariant • Convergence Concurrent effects commute • Precondition stability Preconditions are stable under every pair of concurrent operations 81 If satisfied, invariant is guaranteed with concurrency. -
AntidoteDB • Open-source Erlang database Developed in Erlang, on top
of the Riak Core distributed systems framework 83 -
AntidoteDB • Open-source Erlang database Developed in Erlang, on top
of the Riak Core distributed systems framework • Transactional Causal Consistency Only industrial-grade database providing both causal consistency and all-or-nothing transactions 83 -
AntidoteDB • Open-source Erlang database Developed in Erlang, on top
of the Riak Core distributed systems framework • Transactional Causal Consistency Only industrial-grade database providing both causal consistency and all-or-nothing transactions • Alpha release available Currently under development, but an alpha release of the product is available on GitHub 83 -
A B N1 N2 TxnMgr Materializer Log InterDC-Repl …each operating
a transaction manager, materializers, log. -
A B N1 N2 TxnMgr Materializer Log InterDC-Repl Strong consistency
inside of the data center… -
A B N1 N2 TxnMgr Materializer Log InterDC-Repl …with a
causal consistency protocol running in the wide area. -
Data Model 89 Register • Last-Writer Wins • Multi-Value Set
• Grow-Only • Add-Wins • Remove-Wins Map Counter • Unlimited • Restricted ≥ 0 Graph • Directed • Monotonic DAG • Edit graph Sequence -
Object API 90 User1 = {michel, antidote_crdt_mvreg, user_bucket}, {ok, Time2}
= antidote:update_objects(ignore, [], [{User1, assign, {["Michel", “[email protected]”], ClientIdentifier}}]), {ok, Result, Time2} = antidote:read_objects( ignore, [], [User1]). -
Object API 91 User1 = {michel, antidote_crdt_mvreg, user_bucket}, {ok, Time2}
= antidote:update_objects(ignore, [], [{User1, assign, {["Michel", “[email protected]”], ClientIdentifier}}]), {ok, Result, Time2} = antidote:read_objects( ignore, [], [User1]). Identify an object by object identifier. -
Object API 92 User1 = {michel, antidote_crdt_mvreg, user_bucket}, {ok, Time2}
= antidote:update_objects(ignore, [], [{User1, assign, {["Michel", “[email protected]”], ClientIdentifier}}]), {ok, Result, Time2} = antidote:read_objects( ignore, [], [User1]). Use the update API to assign a value to this register. -
Object API 93 User1 = {michel, antidote_crdt_mvreg, user_bucket}, {ok, Time2}
= antidote:update_objects(ignore, [], [{User1, assign, {["Michel", “[email protected]”], ClientIdentifier}}]), {ok, Result, Time2} = antidote:read_objects( ignore, [], [User1]). Read the object, providing a minimum snapshot time. -
Object API 93 User1 = {michel, antidote_crdt_mvreg, user_bucket}, {ok, Time2}
= antidote:update_objects(ignore, [], [{User1, assign, {["Michel", “[email protected]”], ClientIdentifier}}]), {ok, Result, Time2} = antidote:read_objects( ignore, [], [User1]). Read the object, providing a minimum snapshot time. Simple, operation-based API. (think Redis, Riak CRDTs) -
Object API 93 User1 = {michel, antidote_crdt_mvreg, user_bucket}, {ok, Time2}
= antidote:update_objects(ignore, [], [{User1, assign, {["Michel", “[email protected]”], ClientIdentifier}}]), {ok, Result, Time2} = antidote:read_objects( ignore, [], [User1]). Read the object, providing a minimum snapshot time. Simple, operation-based API. (think Redis, Riak CRDTs) Causal dependencies are automatically captured by execution order. -
Transaction API 94 {ok, TxId} = antidote:start_transaction(Timestamp, []), {ok, _}
= antidote:read_objects([Set], TxId), ok = antidote:update_objects([{Set, add, "Java"}], TxId), {ok, _} = antidote:commit_transaction(TxId). -
Transaction API 95 Start a transaction with the transaction API,
with a given snapshot time and return a transaction identifier. {ok, TxId} = antidote:start_transaction(Timestamp, []), {ok, _} = antidote:read_objects([Set], TxId), ok = antidote:update_objects([{Set, add, "Java"}], TxId), {ok, _} = antidote:commit_transaction(TxId). -
{ok, TxId} = antidote:start_transaction(Timestamp, []), {ok, _} = antidote:read_objects([Set], TxId),
ok = antidote:update_objects([{Set, add, "Java"}], TxId), {ok, _} = antidote:commit_transaction(TxId). Transaction API 96 Read objects using the interactive transaction API. -
{ok, TxId} = antidote:start_transaction(Timestamp, []), {ok, _} = antidote:read_objects([Set], TxId),
ok = antidote:update_objects([{Set, add, "Java"}], TxId), {ok, _} = antidote:commit_transaction(TxId). Transaction API 97 Update objects using the interactive transaction API. -
{ok, TxId} = antidote:start_transaction(Timestamp, []), {ok, _} = antidote:read_objects([Set], TxId),
ok = antidote:update_objects([{Set, add, "Java"}], TxId), {ok, _} = antidote:commit_transaction(TxId). Transaction API 98 Once finished updating, commit the transaction. -
{ok, TxId} = antidote:start_transaction(Timestamp, []), {ok, _} = antidote:read_objects([Set], TxId),
ok = antidote:update_objects([{Set, add, "Java"}], TxId), {ok, _} = antidote:commit_transaction(TxId). Transaction API 98 Once finished updating, commit the transaction. Transactions read causally consistent snapshots and updates are applied atomically. -
Scalability 99 Kops / s 100 200 300 400 500
600 700 800 1 x 5 1 x 10 1 x 25 2 x 25 3 x 25 1 x 5 1 x 10 1 x 25 2 x 25 3 x 25 1 x 5 1 x 10 1 x 25 2 x 25 3 x 25 1 x 5 1 x 10 1 x 25 2 x 25 3 x 25 99(1) 90(10) 75(25) 50(50) read(update) ratio DCs × Servers LWW registers 100k keys/partition power law distribution -
Cure vs. SOA 100 Kops / s 0 100 200
300 400 500 600 700 800 900 1000 1100 Eiger GR Cure EC Eiger GR Cure EC Eiger GR Cure EC Eiger GR Cure EC 99(1) 90(10) 75(25) 50(50) read(update) ratio 3 DCs × 25 Servers LWW registers -
Cure vs. EC 101 Kops / s 100 200 300
400 500 600 700 800 900 1000 1100 1200 Cure, 1KB EC, 1KB Cure, 10KB EC, 10KB Cure, 1KB EC, 1KB Cure, 10KB EC, 10KB Cure, 1KB EC, 1KB Cure, 10KB EC, 10KB Cure, 1KB EC, 1KB Cure, 10KB EC, 10KB 99(1) 90(10) 75(25) 50(50) read(update) ratio 3 DCs x 25 Servers CRDT sets -
Future Features • Intra-DC replication Antidote provides no replication within
the datacenter and assumes only geo- replication at the moment 102 -
Future Features • Intra-DC replication Antidote provides no replication within
the datacenter and assumes only geo- replication at the moment • ACID transactions For Antidote to provide all of JRC, it needs ACID transaction support: no research needed, only implementation 102 -
Moving Forward • Research prototype Originally a research prototype to
build a database requiring reduced synchronization (SyncFree FP7) with Basho, Rovio, and Trifork 103 -
Moving Forward • Research prototype Originally a research prototype to
build a database requiring reduced synchronization (SyncFree FP7) with Basho, Rovio, and Trifork • Research ahead LightKone (H2020) will investigate moving AntidoteDB close to the edge to provide DDN services 103 -
Moving Forward • Research prototype Originally a research prototype to
build a database requiring reduced synchronization (SyncFree FP7) with Basho, Rovio, and Trifork • Research ahead LightKone (H2020) will investigate moving AntidoteDB close to the edge to provide DDN services • Industrialization Obtaining seed funding to start a company to industrialize AntidoteDB 103 -
Resources • https://github.com/SyncFree/antidote AntidoteDB • http://syncfree.github.io/antidote/ Documentation for AntidoteDB •
www.antidotedb.com Website • docker pull antidotedb/antidote Try out Antidote! 104
