Sweet Streams (Are made of this)

Spring Cloud Data Flow - A gentle introduction.

Transcript

1. Version 1.0 October 2022 Sweet Streams (Are made of this) Spring Cloud Data Flow - A gentle overview Copyright © 2022 VMware, Inc. or its affiliates.
2. Cover w/ Image Agenda • What is Spring Cloud Data Flow? • Spring Batch • Spring Task • Spring Cloud Functions • Spring Cloud Stream Applications • Interview with a User • Q+A
3. What is Spring Cloud Data Flow? • Microservice based Enterprise Application Integration. ◦ Batch Jobs ◦ Tasks ◦ Streams
4. What is Spring Cloud Data Flow? • Orchestration and Deployment ◦ Tanzu Application Service / Cloud Foundry ◦ Kubernetes ◦ Local
5. What is Spring Cloud Data Flow? • Observability ◦ Micrometer ◦ Prometheus ◦ WaveFront ◦ InfluxDB ◦ More…
6. Stream DSL file | splitter | csv-to-json: transform > :input-stream http > :input-stream :input-stream > filter | aggregator > :output-stream :output-stream > jdbc :output-stream > json-to-ws-notification: transform | websocket Legend Stream App Topic App Label
7. Stream DSL
8. Stream DSL
9. Stream Definitions
10. Stream Definitions
11. Stream Definitions
12. Batch/Task Workflows • DSL can define complex Batch and or Task application topologies in addition to a single Batch or Task application • Each box is a Spring Batch or Task application. • Application Flow can split and join, based on optional conditional expressions
13. How did we build Spring Cloud Data Flow? Spring Cloud Data Flow Spring Boot Spring Cloud Spring Batch Spring Integration Spring AMQP Spring Kafka Spring Security Spring Data
14. Spring Cloud Data Flow Architecture • Data Flow UI, REST Client or Shell • Data Flow Server • Skipper Server • Messaging Middleware
15. Observability Streams
16. Observability Tasks
17. Pre-packaged Stream Applications aggregator analytics bridge cassandra cdc-debezium dataflow-tasklauncher elasticsearch file filter ftp groovy header-enricher http http-request image-recognition jdbc jms load-generator log mail mongodb mqtt object-detection pgcopy rabbit redis router rsocket s3 script semantic-segmentation sftp splitter syslog tcp throughput time transform twitter-message twitter-search twitter-stream twitter-trend twitter-update wavefront websocket zeromq
18. Pre-packaged Stream Applications aggregator dataflow-tasklauncher filter http jdbc splitter transform your-application
19. Introducing: A user.
20. Data ingest Data comes in via file or web service Once in the DB the batch process can consume Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum
21. Batch process
22. Batch process
23. Technology
24. Technology
25. Design • How do you eat an elephant? • Enable more real-time processing • Improve the feedback loop for failures • Use Java • Functional programming paradigm • How do you eat an elephant?
26. Design Spring Cloud Data Flow
27. Stream processing System is built to be event driven Files are broken into individual events File and web service events are processed by streaming applications All streaming apps are custom. (Didn’t use any off the shelf applications) Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum
28. Stream processing Failures can be handled on individual events Streaming apps are designed to be idempotent Load can be spread out much better Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Error handler
29. Batch processing System is built to be event driven Files are broken into individual events Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Lorem ipsum Spring Batch
30. Idempotent processing • At some point you must write to the DB (sink) • Processes are designed to be idempotent • The sink that persists is designed to cater for items being replayed
31. Developer experience • Everything is a Spring Boot application (Our Devs love this) • Changes can be tested locally • Custom templates • Dependency management (Solution BOM) • Easy to understand applications that are small and do one thing • Unit and integration testing is easy • Containers Paving the road to production
32. Deploying Data Flow
33. Deployment Data Flow deployment • Deployed to Kubernetes (using Bitnami Helm Charts) • Message broker is Apache Kafka • Customized to use non-OSS database • JDK17 Stream and Batch applications • GitOps ◦ Applications are defined in git ◦ Stream definition (DSL) and deployment info is in git ◦ Deployments via Dataflow REST API
34. Management and Observability Monitoring • Application metrics (uptime, resource utilization) • Monitor topic lag • Logs exported via sidecar application Scaling • Make sure JVM properties are set (Heap memory, CPU count, GC, etc) • Single instance of most apps • No dynamic scaling yet
35. Questions?
36. © 2020 Spring. A VMware-backed project. Resources • dataflow.spring.io • github.com/spring-cloud/spring-cloud-dataflow • dataflow.spring.io/docs/applications/pre-packaged/ • via.vmw.com/sweet-streams
37. Thank you Contact me at pcorneil@vmware.com @corneil © 2020 Spring. A VMware-backed project.
