AWS VPC 101

AWS UG BLR talk - Introduction to AWS VPC

Transcript

1. Ashwin | Jun 11, 2020 AWS VPC 101 AWS UG BLR
2. $ whoami • Old school linux / sysadmin • <3 Shell / Unix • Cloud • IoT • Mail • DNS • Engineering @ Verloop
3. Agenda • VPC intro • History of the VPC • Regions / Subnets - Availability Zones • Route Table • NACLs • Security Groups • Peering
4. What is a VPC ?
5. Your VPC is a Data Center…
6. • Virtual Network dedicated to your AWS Account • Logically Isolated • RFC compliant • Container for your AWS Resources - EC2, RDS, EKS, Fargate • Resources talk to the internet via the VPC • Regular network constructs - IP ranges, subnets, route tables, etc… • Security - NACL, Security Groups
7. Quick History Lesson…
8. AWS EC2 Classic • Flat network - Distributed over AWS infrastructure • Shared with multiple customers • Discontinued with introduction of AWS VPC • All instances received a public IP address • DNS hostnames were fixed + enabled by default • Shared hardware tenancy only
9. Regions, AZs and Subnets
10. Regions • Physical location • Cluster of data centres • Multiple isolated, physically separate AZs
11. Availability Zone • Isolated logical cluster of data centres • Separation of risk domains - power, internet, cooling, security • Interconnected by low latency redundant networks
12. Now the fun part…
13. 172.31.0.0/16
14. • Every region has a default VPC • RFC 1918 compatible private range. • No conflict with internet ranges • Ipv4 default • Ipv6 overlay network with dual stack n/w config • Default VPC lets you have 65535 Ipv4 addresses
15. Subnets
17. • Belong to a VPC • Resides completely within an AZ • Subsetof VPC CIDR block • Resource in subnet can be public OR private based on route tables
18. Route Tables
19. • Rules to move network packets around • Every VPC has a default route table • Can also assign different route tables to different subnets
20. Traffic for my VPC stays inside my VPC
21. Route Tables continued…
23. Destination Target 172.31.0.0/16 local 0.0.0.0/0 igw_id IP: 35.10.245.123 IP: 35.10.211.231 Destination Target 172.31.0.0/16 local 0.0.0.0/0 nat_gw_id
24. Security Groups
25. • Distributed Firewall • Instance level • Grant access to resources on the network • Can be grouped by IP, CIDR range or even security group • STATEFUL - One rule, both directions! • All rules evaluated before allowing traffic • Applies only on assignment
27. DO NOT TOUCH THE NACLs!!!
28. • Subnet level access control • Rules have priority and are evaluated in order • STATELESS - One rule, one direction! • Automatically applies to all resources in associated subnet
29. Peering
30. • Network connection between 2 VPCs • Handle traffic using private IPv4 address • Seamless handover between networks • Mandatory for both networks to be on separate CIDR blocks
32. Questions ???
33. Thank you! mail@cruisemaniac.com https://cruisemaniac.com
