Smash your adapter monolith with the Connect pattern

Server-side code is regularly broken down into manageable chunks, based around endpoints. As a result it tends to be nicely factored. But over several projects we noticed that the same was not true of adapters that talk to 3rd party systems. These pieces of code tended to grow uncontrolled, and were not given the same level of attention.

In this talk, I'll be covering a pattern that we discovered to help break down your Adapter Monolith into modular, easily digestible and (most importantly) testable pieces.

This talk is based in Kotlin and takes advantage of language features such as Data Classes, Companion Objects, Operator Overloading and Extension Functions. However the pattern concepts themselves are applicable to any technology choice or programming model.

Transcript

1. SMASH YOUR


   ADAPTER


   MONOLITH


   WITH THE


   CONNECT


   PATTERN
   David


   Denton


   View Slide

2. HELLO, IT’S DAVID
   TRAINER
   GDE


   View Slide

3. what’s the plan?
   • identify a problem with adapters


   • can we modularise, customise, test?


   • leverage Kotlin language features


   View Slide

4. … but first, some http4k basics
   • server as a function


   • heavily TDD-driven


   • lightweight (core = 1mb)


   • run in-memory, or on 10 servers, 6 serverless platforms


   View Slide

5. http4k basics (ii)
   typealias HttpHandler = (Request) -> Response


   fun interface Filter : (HttpHandler) -> HttpHandler


   val http = { req: Request -> Response(OK).body("hello") }


   val filter = Filter { next ->


   { req -> next(req.header("foo", “bar")) }


   }


   val decoratedHttp: HttpHandler = filter.then(filter).then(http)


   val response: Response = decoratedHttp(Request(GET, "/uri"))




   View Slide

6. /endpoint2
   /endpoint1
   /endpoint3
   Business


   logic
   API


   Adapter
   API


   Adapter
   Data access


   /endpoint4
   API


   Adapter
   a typical http microservice
   /endpoint2
   /endpoint1
   /endpoint3
   /endpoint4


   View Slide

7. fun MySecureApp(): HttpHandler =


   BearerAuth("my-very-secure-and-secret-bearer-token")


   .then(


   routes(


   echo(),


   health()


   )


   )


   fun echo() = "/echo" bind


   POST to { req: Request -> Response(OK).body(req.bodyString()) }


   fun health() = "/health" bind


   GET to { req: Request -> Response(OK).body("alive!") }


   val server = MySecureApp().asServer(Netty(8080)).start()
   server-side


   View Slide

8. /endpoint2
   /endpoint1
   /endpoint3
   Business


   logic
   API


   Adapter
   API


   Adapter
   Data access


   /endpoint4
   API


   Adapter
   a typical http microservice
   API


   Adapter
   API


   Adapter
   API


   Adapter


   View Slide

9. class GitHubApi(client: HttpHandler) {


   private val http = SetBaseUriFrom(Uri.of("https://api.github.com"))


   .then(SetHeader("Accept", "application/vnd.github.v3+json"))


   .then(client)


   fun getUser(username: String): UserDetails {


   val response = http(Request(GET, "/users/$username"))


   return UserDetails(userNameFrom(response), userOrgsFrom(response))


   }


   fun getRepoLatestCommit(owner: String, repo: String) = ....


   }


   val gitHub: GitHubApi = GitHubApi(OkHttp())


   val user: UserDetails = gitHub.getUser("octocat")
   the adapter monolith…


   View Slide

10. a real world example: K8S API
    • OpenApi Spec


    • 833 endpoints


    • 87k lines JSON


    • Kotlin version**


    • 32k LOC -> 17mb JAR
    * https://toolbox.http4k.org ** http://github.com/daviddenton/http4k-k8s-api


    View Slide

11. introducing connect
    • modularise monolithic adapters


    • simple pattern


    • testable & composable


    View Slide

12. action
    Action
    HTTP Req
    HTTP Resp
    Domain Req
    Domain Resp
    Action


    View Slide

13. interface GitHubApiAction {


    fun toRequest(): Request


    fun fromResponse(response: Response): R


    }


    data class GetUser(val username: String) : GitHubApiAction {


    override fun toRequest() = Request(GET, “/users/$username")


    override fun fromResponse(response: Response) =


    UserDetails(userNameFrom(response), userOrgsFrom(response))


    }


    data class UserDetails(val name: String, val orgs: List)
    declaring actions


    View Slide

14. adapter
    Adapter
    Domain
    Response
    Action
    http client
    Adapter


    View Slide

15. interface GitHubApi {


    operator fun invoke(action: GitHubApiAction): R


    companion object


    }
    define the adapter


    View Slide

16. fun GitHubApi.Companion.Http(client: HttpHandler) = object : GitHubApi {


    private val http = SetBaseUriFrom(Uri.of(“https://api.github.com"))


    .then(SetHeader("Accept", "application/vnd.github.v3+json"))


    .then(client)


    override fun invoke(action: GitHubApiAction) =


    action.fromResponse(http(action.toRequest()))


    }


    val gitHub: GitHubApi = GitHubApi.Http(OkHttp())


    val user: UserDetails = gitHub(GetUser("octocat"))
    reimplementing the adapter


    View Slide

17. fun GitHubApi.getUser(username: String): UserDetails


    = invoke(GetUser(username))


    fun GitHubApi.getLatestRepoCommit(owner: String, repo: String): Commit


    = invoke(GetRepoLatestCommit(owner, repo))


    val user: UserDetails = gitHub.getUser(“octocat")
    recreating our api


    View Slide

18. fun GitHubApi.getLatestUser(org: String, repo: String): UserDetails {


    val commit = getLatestRepoCommit(org, repo)


    return getUser(commit.author)


    }


    val latestUser: UserDetails = gitHub.getLatestUser("http4k", "http4k-connect")
    custom composite actions


    View Slide

19. testing the


    connect pattern


    View Slide

20. @Test
    fun `translates request`() {
    assertThat(GetUser("foobar").toRequest(), equalTo(Request(GET, "/users/foobar")))
    }
    @Test
    fun `translates response`() {
    assertThat(GetUser("foobar").fromResponse(Response(OK).body("foobar/admin,mgmt")),
    equalTo(UserDetails("foobar", listOf("admin", "mgmt"))))
    }
    testing actions


    View Slide

21. @Test


    fun `get user details`() {


    val githubApi = mockk()


    val userDetails = UserDetails("bob", listOf("http4k"))


    every { githubApi(any()) } returns userDetails


    assertThat(githubApi.getUser("bob"), equalTo(userDetails))


    }


    mock the adapter


    View Slide

22. class StubGitHubApi(private val users: Map) : GitHubApi {


    override fun invoke(action: GitHubApiAction): R =


    when (action) {


    is GetUser -> getUser(action, users) as R


    is GetRepoLatestCommit -> getRepoLatestCommit(action) as R


    else -> throw UnsupportedOperationException()


    }


    }


    private fun getUser(action: GetUser, users: Map) = users[action.username]
    private fun getRepoLatestCommit(action: GetRepoLatestCommit) = Commit(action.owner)
    stub the adapter


    View Slide

23. class RecordingGitHubApi(private val delegate: GitHubApi) : GitHubApi {


    val recorded = mutableListOf>()


    override fun invoke(action: GitHubApiAction): R {


    recorded += action


    return delegate(action)


    }


    }
    decorate the adapter


    View Slide

24. vary your


    programming model


    View Slide

25. interface GitHubApiAction {


    fun toRequest(): Request


    fun fromResponse(response: Response): Result


    }


    data class GetUser(val username: String) : GitHubApiAction {


    override fun toRequest() = Request(GET, "/users/$username")


    override fun fromResponse(response: Response) =


    when {


    response.status.successful -> Success(UserDetails(


    userNameFrom(response),


    userOrgsFrom(response))


    )


    else -> Failure(RuntimeException("Status: " + response.status))


    }


    }
    result4k


    View Slide

26. summary
    • simple, modular adapters


    • testable and composable


    • flexible on model


    • works with any req/resp protocol


    View Slide

27. • featherweight Kotlin-API adapters


    • zero reflection —> serverless & graal


    • in-memory fakes / storage
    http4k/http4k-connect


    View Slide

28. THANKS!
    @daviddenton hello@dentondav.id
    https://dentondav.id
    http4k/http4k http4k/http4k-connect


    View Slide
