1. The Curious Case of Android Button Nicola Corti @cortinico nco@yelp.com
3. Yelp Mission Connecting people with great local businesses.
4. About me Nicola Corti Android @ BizCore @cortinico Community Lover !✈
5. CC-by hisgett
9. Consistency First
10. Quick Button’s History
13. Skeuomorphic UI • Android 2.3 - iOS 6 • Easy of use
14. Flat UI • Windows Phone 7 (2010) • iOS 7+ (2013) • Streamlined & lighter • Responsive UI
15. Almost Flat (aka Flat 2.0) • Google Material Design (2014) • Shadows and
 Subtle Gradients
16. How to craft your buttons?
18. Shape
19. Rectangular Shadows Corners More about rounded corners: http://bit.ly/roundedcorner
20. Credits: Material Design - Elevation & Shadows
22. Key + Ambient = Result
24. Brand Platform CC kevint3141
25. Time to deep dive!
26. What’s actually an Android Button?
27. What’s actually an Android Button? java.lang.Object ↳ android.view.View ↳ android.widget.TextView ↳ android.widget.Button ↳ android.support.v7.widget.AppCompatButton
28. What’s actually an Android Button? java.lang.Object ↳ android.view.View ↳ android.widget.TextView ↳ android.widget.Button ↳ android.support.v7.widget.AppCompatButton
29. What’s actually an Android Button? java.lang.Object ↳ android.view.View ↳ android.widget.TextView ↳ android.widget.Button ↳ android.support.v7.widget.AppCompatButton
30. What’s actually an Android Button? java.lang.Object ↳ android.view.View ↳ android.widget.TextView ↳ android.widget.Button ↳ android.support.v7.widget.AppCompatButton
31. What’s actually an Android Button? java.lang.Object ↳ android.view.View ↳ android.widget.TextView ↳ android.widget.Button ↳ android.support.v7.widget.AppCompatButton
32. What’s actually an Android Button? java.lang.Object (554) ↳ android.view.View (26488) ↳ android.widget.TextView (11969) ↳ android.widget.Button (182) ↳ android.support.v7.widget.AppCompatButton (187)
33. Just a Button
34. Just a Button <Button />
35. Just a Button <Button android:layout_width="wrap_content" android:layout_height="wrap_content" />
36. Just a Button <android.support.v7.widget.AppCompatButton android:layout_width="wrap_content" android:layout_height="wrap_content" />
37. Just a Button /** * * <p>This will automatically be used when you use {@link Button} in your layouts */ public class AppCompatButton extends Button implements TintableBackgroundView, AutoSizeableTextView {
38. Just a Button /** * * <p>This will automatically be used when you use {@link Button} in your layouts */ public class AppCompatButton extends Button implements TintableBackgroundView, AutoSizeableTextView {
39. Just a Button /** * … * * <p>This will automatically be used when you use {@link Button} in your layouts * … */ public class AppCompatButton extends Button implements TintableBackgroundView, AutoSizeableTextView {
40. 4 defaults styles for a Button
41. 4 defaults styles for a Button <style name=“Widget.AppCompat.Button"/> <style name="Widget.AppCompat.Button.Colored"/> <style name="Widget.AppCompat.Button.Borderless"/> <style name="Widget.AppCompat.Button.Borderless.Colored"/>
42. 4 defaults styles for a Button <style name=“Widget.AppCompat.Button"/> <style name="Widget.AppCompat.Button.Colored"/> <style name="Widget.AppCompat.Button.Borderless"/> <style name="Widget.AppCompat.Button.Borderless.Colored"/> API 21+
43. 4 defaults styles for a Button <style name=“Widget.AppCompat.Button” parent="Base.Widget.AppCompat.Button"/> <style name="Widget.AppCompat.Button.Borderless"/> <style name="Widget.AppCompat.Button.Borderless.Colored"/> <style name="Widget.AppCompat.Button.Colored"/> <style name="Base.Widget.AppCompat.Button" parent="android:Widget.Material.Button"/> API 21+
44. data/res/values/styles_material.xml
45. data/res/values/styles_material.xml <!-- Bordered ink button --> <style name="Widget.Material.Button"> </style>
46. data/res/values/styles_material.xml <!-- Bordered ink button --> <style name="Widget.Material.Button"> <item name="background">@drawable/btn_default_material</item> <item name="textAppearance">?attr/textAppearanceButton</item> <item name="minHeight">48dip</item> <item name="minWidth">88dip</item> <item name="stateListAnimator">@anim/ button_state_list_anim_material</item> <item name="focusable">true</item> <item name="clickable">true</item> <item name="gravity">center_vertical|center_horizontal</item> </style>
47. data/res/values/styles_material.xml <!-- Bordered ink button --> <style name="Widget.Material.Button"> <item name="background">@drawable/btn_default_material</item> <item name="textAppearance">?attr/textAppearanceButton</item> <item name="minHeight">48dip</item> <item name="minWidth">88dip</item> <item name="stateListAnimator">@anim/ button_state_list_anim_material</item> <item name="focusable">true</item> <item name="clickable">true</item> <item name="gravity">center_vertical|center_horizontal</item> </style>
48. data/res/values/styles_material.xml <!-- Bordered ink button --> <style name="Widget.Material.Button"> <item name="background">@drawable/btn_default_material</item> <item name="textAppearance">?attr/textAppearanceButton</item> <item name="minHeight">48dip</item> <item name="minWidth">88dip</item> <item name="stateListAnimator">@anim/ button_state_list_anim_material</item> <item name="focusable">true</item> <item name="clickable">true</item> <item name="gravity">center_vertical|center_horizontal</item> </style>
49. data/res/values/styles_material.xml <!-- Bordered ink button --> <style name="Widget.Material.Button"> <item name="background">@drawable/btn_default_material</item> <item name="textAppearance">?attr/textAppearanceButton</item> <item name="minHeight">48dip</item> <item name="minWidth">88dip</item> <item name="stateListAnimator">@anim/ button_state_list_anim_material</item> <item name="focusable">true</item> <item name="clickable">true</item> <item name="gravity">center_vertical|center_horizontal</item> </style>
50. data/res/drawable/btn_default_material.xml
51. data/res/drawable/btn_default_material.xml <ripple xmlns:android="http://schemas.android.com/apk/res/android" android:color="?attr/colorControlHighlight"> <item android:drawable="@drawable/btn_default_mtrl_shape" /> </ripple>
52. data/res/drawable/btn_default_material.xml <ripple xmlns:android="http://schemas.android.com/apk/res/android" android:color="?attr/colorControlHighlight"> <item android:drawable="@drawable/btn_default_mtrl_shape" /> </ripple>
53. data/res/drawable/btn_default_material.xml <ripple xmlns:android="http://schemas.android.com/apk/res/android" android:color="?attr/colorControlHighlight"> <item android:drawable="@drawable/btn_default_mtrl_shape" /> </ripple>
54. <ripple xmlns:android="http://schemas.android.com/apk/res/android" android:color="?attr/colorControlHighlight"> <inset android:insetLeft="4dp" android:insetTop="6dp" android:insetRight="4dp" android:insetBottom="6dp"> ... </inset> </ripple>
55. <ripple xmlns:android="http://schemas.android.com/apk/res/android" android:color="?attr/colorControlHighlight"> <inset android:insetLeft="4dp" android:insetTop="6dp" android:insetRight="4dp" android:insetBottom="6dp"> <shape android:shape="rectangle" android:tint="?attr/colorButtonNormal"> ... </shape> </inset> </ripple>
56. <ripple xmlns:android="http://schemas.android.com/apk/res/android" android:color="?attr/colorControlHighlight"> <inset android:insetLeft="4dp" android:insetTop="6dp" android:insetRight="4dp" android:insetBottom="6dp"> <shape android:shape="rectangle" android:tint="?attr/colorButtonNormal"> ... </shape> </inset> </ripple>
57. <ripple xmlns:android="http://schemas.android.com/apk/res/android" android:color="?attr/colorControlHighlight"> <inset android:insetLeft="4dp" android:insetTop="6dp" android:insetRight="4dp" android:insetBottom="6dp"> <shape android:shape="rectangle" android:tint="?attr/colorButtonNormal"> ... </shape> </inset> </ripple>
58. <ripple xmlns:android="http://schemas.android.com/apk/res/android" android:color="?attr/colorControlHighlight"> <inset android:insetLeft="4dp" android:insetTop="6dp" android:insetRight="4dp" android:insetBottom="6dp"> <shape android:shape="rectangle" android:tint="?attr/colorButtonNormal"> <corners android:radius="2dp" /> ... </shape> </inset> </ripple>
59. <ripple xmlns:android="http://schemas.android.com/apk/res/android" android:color="?attr/colorControlHighlight"> <inset android:insetLeft="4dp" android:insetTop="6dp" android:insetRight="4dp" android:insetBottom="6dp"> <shape android:shape="rectangle" android:tint="?attr/colorButtonNormal"> <corners android:radius="2dp" /> <solid android:color="@color/white" /> ... </shape> </inset> </ripple>
60. <ripple xmlns:android="http://schemas.android.com/apk/res/android" android:color="?attr/colorControlHighlight"> <inset android:insetLeft="4dp" android:insetTop="6dp" android:insetRight="4dp" android:insetBottom="6dp"> <shape android:shape="rectangle" android:tint="?attr/colorButtonNormal"> <corners android:radius="2dp" /> <solid android:color="@color/white" /> <padding android:left="8dp" android:top="4dp" android:right="8dp" android:bottom="4dp" /> </shape> </inset> </ripple>
61. <ripple xmlns:android="http://schemas.android.com/apk/res/android" android:color="?attr/colorControlHighlight"> <inset android:insetLeft="@dimen/button_inset_horizontal_material" android:insetTop="@dimen/button_inset_vertical_material" android:insetRight="@dimen/button_inset_horizontal_material" android:insetBottom="@dimen/button_inset_vertical_material"> <shape android:shape="rectangle" android:tint="?attr/colorButtonNormal"> <corners android:radius="@dimen/control_corner_material" /> <solid android:color="@color/white" /> <padding android:left="@dimen/button_padding_horizontal_material" android:top="@dimen/button_padding_vertical_material" android:right="@dimen/button_padding_horizontal_material" android:bottom=“@dimen/button_padding_vertical_material" /> </shape> </inset> </ripple>
62. Typography
63. Typography • Use a verb • On Android, buttons are ALL CAPS • Principle of Least astonishment
64. Typography
65. Typography <Button android:layout_width="wrap_content" android:layout_height="wrap_content"/>
66. Typography <Button android:layout_width="wrap_content" android:layout_height="wrap_content" android:text="Log In"/>
67. Typography <Button style="@style/Base.Widget.AppCompat.Button" android:layout_width="wrap_content" android:layout_height="wrap_content" android:text="Log In"/>
68. res/values/styles_material.xml
69. res/values/styles_material.xml <!-- Bordered ink button --> <style name="Widget.Material.Button"> <item name="background">@drawable/btn_default_material</item> <item name="textAppearance">?attr/textAppearanceButton</item> <item name="minHeight">48dip</item> <item name="minWidth">88dip</item> <item name="stateListAnimator">@anim/ button_state_list_anim_material</item> <item name="focusable">true</item> <item name="clickable">true</item> <item name="gravity">center_vertical|center_horizontal</item> </style> <style name="TextAppearance.Material.Button"> <item name="textSize">@dimen/text_size_button_material</item> <item name="fontFamily">@string/font_family_button_material</item>
70. res/values/styles_material.xml <!-- Bordered ink button --> <style name="Widget.Material.Button"> <item name="background">@drawable/btn_default_material</item> <item name="textAppearance">?attr/textAppearanceButton</item> <item name="minHeight">48dip</item> <item name="minWidth">88dip</item> <item name="stateListAnimator">@anim/ button_state_list_anim_material</item> <item name="focusable">true</item> <item name="clickable">true</item> <item name="gravity">center_vertical|center_horizontal</item> </style> <style name="TextAppearance.Material.Button"> <item name="textSize">@dimen/text_size_button_material</item> <item name="fontFamily">@string/font_family_button_material</item>
71. <style name="Widget.Material.Button"> <item name="background">@drawable/btn_default_material</item> <item name="textAppearance">?attr/textAppearanceButton</item> <item name="minHeight">48dip</item> <item name="minWidth">88dip</item> <item name="stateListAnimator">@anim/ button_state_list_anim_material</item> <item name="focusable">true</item> <item name="clickable">true</item> <item name="gravity">center_vertical|center_horizontal</item> </style> <style name="TextAppearance.Material.Button"> <item name="textSize">@dimen/text_size_button_material</item> <item name="fontFamily">@string/font_family_button_material</item> <item name="textAllCaps">true</item> <item name=“textColor">?attr/textColorPrimary</item> </style>
72. <style name="Widget.Material.Button"> <item name="background">@drawable/btn_default_material</item> <item name="textAppearance">?attr/textAppearanceButton</item> <item name="minHeight">48dip</item> <item name="minWidth">88dip</item> <item name="stateListAnimator">@anim/ button_state_list_anim_material</item> <item name="focusable">true</item> <item name="clickable">true</item> <item name="gravity">center_vertical|center_horizontal</item> </style> <style name="TextAppearance.Material.Button"> <item name="textSize">@dimen/text_size_button_material</item> <item name="fontFamily">@string/font_family_button_material</item> <item name="textAllCaps">true</item> <item name=“textColor">?attr/textColorPrimary</item> </style>
73. Hierarchy
74. Hierarchy • First, define your color palette • Use contrast to define hierarchy • Primary: high • Negative: medium • Secondary: low
77. Hierarchy
78. Hierarchy <style name=“Widget.AppCompat.Button"/> <style name="Widget.AppCompat.Button.Colored"/> <style name="Widget.AppCompat.Button.Borderless"/> <style name="Widget.AppCompat.Button.Borderless.Colored"/>
79. Hierarchy <style name=“Widget.AppCompat.Button"/> <style name="Widget.AppCompat.Button.Colored"/> <style name="Widget.AppCompat.Button.Borderless"/> <style name="Widget.AppCompat.Button.Borderless.Colored"/> API 23+
80. Hierarchy <style name=“Widget.AppCompat.Button"/> <style name=“Widget.AppCompat.Button.Colored” parent=“Base.Widget.AppCompat.Button.Colored”/> <style name="Widget.AppCompat.Button.Borderless"/> <style name=“Widget.AppCompat.Button.Borderless.Colored"/> <style name=“Base.Widget.AppCompat.Button.Colored" parent=“android:Widget.Material.Button.Colored”/> API 23+
81. data/res/values/styles_material.xml
82. data/res/values/styles_material.xml <!-- Bordered ink button --> <style name="Widget.Material.Button"> ... </style>
83. data/res/values/styles_material.xml <!-- Bordered ink button --> <style name="Widget.Material.Button"> </style> <!-- Colored bordered ink button --> <style name="Widget.Material.Button.Colored"> </style>
84. data/res/values/styles_material.xml <!-- Bordered ink button --> <style name="Widget.Material.Button"> </style> <!-- Colored bordered ink button --> <style name="Widget.Material.Button.Colored"> <item name="background">@drawable/btn_colored_material</item> <item name="textAppearance">@style/ TextAppearance.Material.Widget.Button.Colored</item> </style>
85. data/res/values/styles_material.xml <!-- Bordered ink button --> <style name="Widget.Material.Button"> </style> <!-- Colored bordered ink button --> <style name="Widget.Material.Button.Colored"> <item name="background">@drawable/btn_colored_material</item> <item name="textAppearance">@style/ TextAppearance.Material.Widget.Button.Colored</item> </style>
86. data/res/values/styles_material.xml <!-- Bordered ink button --> <style name="Widget.Material.Button"> </style> <!-- Colored bordered ink button --> <style name="Widget.Material.Button.Colored"> <item name="background">@drawable/btn_colored_material</item> <item name="textAppearance">@style/ TextAppearance.Material.Widget.Button.Colored</item> </style>
87. data/res/values/styles_material.xml <!-- Bordered ink button --> <style name="Widget.Material.Button"> </style> <!-- Colored bordered ink button --> <style name="Widget.Material.Button.Colored"> <item name="background">@drawable/btn_colored_material</item> <item name="textAppearance">@style/ TextAppearance.Material.Widget.Button.Colored</item> </style>
88. data/res/drawable/btn_colored_material.xml
89. <inset xmlns:android="http://schemas.android.com/apk/res/android" android:insetLeft="@dimen/button_inset_horizontal_material" android:insetTop="@dimen/button_inset_vertical_material" android:insetRight="@dimen/button_inset_horizontal_material" android:insetBottom="@dimen/button_inset_vertical_material"> <ripple android:color="?attr/colorControlHighlight"> <item> <shape android:shape="rectangle" android:tint="@color/btn_colored_background_material"> <corners android:radius="@dimen/control_corner_material" /> <solid android:color="@color/white" /> <padding android:left="@dimen/button_padding_horizontal_material" android:top="@dimen/button_padding_vertical_material" android:right="@dimen/button_padding_horizontal_material" android:bottom="@dimen/button_padding_vertical_material" /> </shape> </item> </ripple> </inset> data/res/drawable/btn_colored_material.xml
90. <inset xmlns:android="http://schemas.android.com/apk/res/android" android:insetLeft="@dimen/button_inset_horizontal_material" android:insetTop="@dimen/button_inset_vertical_material" android:insetRight="@dimen/button_inset_horizontal_material" android:insetBottom="@dimen/button_inset_vertical_material"> <ripple android:color="?attr/colorControlHighlight"> <item> <shape android:shape="rectangle" android:tint="@color/btn_colored_background_material"> <corners android:radius="@dimen/control_corner_material" /> <solid android:color="@color/white" /> <padding android:left="@dimen/button_padding_horizontal_material" android:top="@dimen/button_padding_vertical_material" android:right="@dimen/button_padding_horizontal_material" android:bottom="@dimen/button_padding_vertical_material" /> </shape> </item> </ripple> </inset> data/res/drawable/btn_colored_material.xml
91. data/res/color/btn_colored_background_material.xml
92. data/res/color/btn_colored_background_material.xml <selector xmlns:android="http://schemas.android.com/apk/res/ android"> </selector>
93. data/res/color/btn_colored_background_material.xml <selector xmlns:android="http://schemas.android.com/apk/res/ android"> <item /> <item /> </selector>
94. data/res/color/btn_colored_background_material.xml <selector xmlns:android="http://schemas.android.com/apk/res/ android"> <item android:state_enabled="false" /> <item /> </selector>
95. data/res/color/btn_colored_background_material.xml <selector xmlns:android="http://schemas.android.com/apk/res/ android"> <item android:state_enabled="false" android:color="?attr/colorButtonNormal" /> <item /> </selector>
96. data/res/color/btn_colored_background_material.xml <selector xmlns:android="http://schemas.android.com/apk/res/ android"> <item android:state_enabled="false" android:alpha="?attr/disabledAlpha" android:color="?attr/colorButtonNormal" /> <item /> </selector>
97. data/res/color/btn_colored_background_material.xml <selector xmlns:android="http://schemas.android.com/apk/res/ android"> <item android:state_enabled="false" android:alpha="?attr/disabledAlpha" android:color="?attr/colorButtonNormal" /> <item android:color="?attr/colorAccent" /> </selector>
98. data/res/color/btn_colored_background_material.xml <selector xmlns:android="http://schemas.android.com/apk/res/ android"> <item android:state_enabled="false" android:alpha="?attr/disabledAlpha" android:color="?attr/colorButtonNormal" /> <item android:color="?attr/colorAccent" /> </selector>
99. Secondary color? • Use a ThemeOverlay (XML only) • Use backgroundTint
100. Secondary Color
101. Secondary Color <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content"/> <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content"/>
102. Secondary Color <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content" android:theme=“@style/MyRedButton"/> <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content"/>
103. Secondary Color <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content" android:theme=“@style/MyRedButton"/> <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content" android:backgroundTint=“@color/red"/>
104. Secondary Color <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content" android:theme=“@style/MyRedButton"/> <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content" android:backgroundTint=“@color/red"/>
105. Secondary Color <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content" android:theme=“@style/MyRedButton"/> <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content" android:backgroundTint=“@color/red"/>
106. Secondary Color <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content" android:theme=“@style/MyRedButton"/> <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content" android:backgroundTint=“@color/red"/>
107. Secondary Color <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content" android:theme=“@style/MyRedButton"/> <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content" android:backgroundTint=“@color/red"/> <style name="MyRedButton" />
108. Secondary Color <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content" android:theme=“@style/MyRedButton"/> <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content" android:backgroundTint=“@color/red"/> <style name="MyRedButton" parent=“ThemeOverlay.AppCompat.Light"/>
109. Secondary Color <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content" android:theme=“@style/MyRedButton"/> <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content" android:backgroundTint=“@color/red"/> <style name="MyRedButton" parent="ThemeOverlay.AppCompat.Light"> <item name=“android:colorAccent">@color/red</item> </style>
110. Secondary Color <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content" android:theme=“@style/MyRedButton"/> <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content" android:backgroundTint=“@color/red"/> <style name="MyRedButton" parent="ThemeOverlay.AppCompat.Light"> <item name=“android:colorAccent">@color/red</item> </style>
111. All works fine but…? .isEnabled = false with ThemeOverlay with backgroundTint with ThemeOverlay with backgroundTint
112. Secondary Color <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content" android:theme=“@style/MyRedButton"/> <android.support.v7.widget.AppCompatButton style="@style/Base.Widget.AppCompat.Button.Colored" android:layout_width="wrap_content" android:layout_height="wrap_content" android:backgroundTint=“@color/red"/>
113. data/res/color/btn_colored_background_material.xml <selector xmlns:android="http://schemas.android.com/apk/res/ android"> <item android:state_enabled="false" android:alpha="?attr/disabledAlpha" android:color="?attr/colorButtonNormal" /> <item android:color="?attr/colorAccent" /> </selector>
114. data/res/color/btn_colored_background_material.xml <selector xmlns:android="http://schemas.android.com/apk/res/ android"> <item android:state_enabled="false" android:alpha="?attr/disabledAlpha" android:color="?attr/colorButtonNormal" /> <item android:color="@color/red" /> </selector>
115. All works fine but…? • You need a ColorStateList
 for the backgroundTint • Delegate creations of drawables/CSL
 to a UtilClass
116. Feedback
117. Feedback • Buttons are alive! • They have states (ColorStateList/StateListDrawable) • Use Ripples (they handle states) • Animate Shadows (StateListAnimator)
121. Credits: Vadim Gomov - Dribbble Z-Value = Elevation + TranslationZ
122. Shadow
123. Shadow <Button android:layout_width="wrap_content" android:layout_height="wrap_content" android:elevation="2dp"/>
124. Shadow <Button android:layout_width="wrap_content" android:layout_height="wrap_content" android:elevation="2dp"/>
125. Shadow <Button android:layout_width="wrap_content" android:layout_height="wrap_content" android:elevation="8dp"/>
126. Shadow <Button android:layout_width="wrap_content" android:layout_height="wrap_content" android:stateListAnimator="@null" android:elevation="8dp"/> Why?
127. res/values/styles_material.xml
128. res/values/styles_material.xml <!-- Bordered ink button --> <style name="Widget.Material.Button"> <item name="background">@drawable/btn_default_material</item> <item name="textAppearance">?attr/textAppearanceButton</item> <item name="minHeight">48dip</item> <item name="minWidth">88dip</item> <item name="stateListAnimator">@anim/ button_state_list_anim_material</item> <item name="focusable">true</item> <item name="clickable">true</item> <item name="gravity">center_vertical|center_horizontal</item> </style>
129. res/values/styles_material.xml <!-- Bordered ink button --> <style name="Widget.Material.Button"> <item name="background">@drawable/btn_default_material</item> <item name="textAppearance">?attr/textAppearanceButton</item> <item name="minHeight">48dip</item> <item name="minWidth">88dip</item> <item name="stateListAnimator">@anim/ button_state_list_anim_material</item> <item name="focusable">true</item> <item name="clickable">true</item> <item name="gravity">center_vertical|center_horizontal</item> </style>
130. data/res/anim/button_state_list_anim_material.xml
131. <selector xmlns:android="http://schemas.android.com/apk/res/android"> </selector> data/res/anim/button_state_list_anim_material.xml
132. <selector xmlns:android="http://schemas.android.com/apk/res/android"> <item android:state_pressed="true" android:state_enabled=“true” /> <!-- rest state --> <item android:state_enabled=“true” /> <item /> </selector> data/res/anim/button_state_list_anim_material.xml
133. <selector xmlns:android="http://schemas.android.com/apk/res/android"> <item android:state_pressed="true" android:state_enabled="true"> <set> <objectAnimator android:propertyName="translationZ" android:duration="@integer/button_pressed_animation_duration" android:valueTo="@dimen/button_pressed_z_material" android:valueType="floatType"/> <objectAnimator android:propertyName="elevation" android:duration="0" android:valueTo="@dimen/button_elevation_material" android:valueType="floatType"/> </set> </item> <!-- rest state --> <item android:state_enabled=“true” /> <item /> </selector> data/res/anim/button_state_list_anim_material.xml 2dp + 6dp
134. <selector xmlns:android="http://schemas.android.com/apk/res/android"> <item android:state_pressed="true" android:state_enabled="true"> <set> <objectAnimator android:propertyName="translationZ" android:duration="@integer/button_pressed_animation_duration" android:valueTo="@dimen/button_pressed_z_material" android:valueType="floatType"/> <objectAnimator android:propertyName="elevation" android:duration="0" android:valueTo="@dimen/button_elevation_material" android:valueType="floatType"/> </set> </item> <!-- rest state --> <item android:state_enabled=“true” /> <item /> </selector> data/res/anim/button_state_list_anim_material.xml 2dp + 6dp
135. <selector xmlns:android="http://schemas.android.com/apk/res/android"> <item android:state_pressed="true" android:state_enabled="true"> <set> <objectAnimator android:propertyName="translationZ" android:duration="@integer/button_pressed_animation_duration" android:valueTo="@dimen/button_pressed_z_material" android:valueType="floatType"/> <objectAnimator android:propertyName="elevation" android:duration="0" android:valueTo="@dimen/button_elevation_material" android:valueType="floatType"/> </set> </item> <!-- rest state --> <item android:state_enabled=“true” /> <item /> </selector> data/res/anim/button_state_list_anim_material.xml 2dp + 6dp
136. <selector xmlns:android="http://schemas.android.com/apk/res/android"> <item android:state_pressed="true" android:state_enabled=“true” /> <!-- rest state --> <item android:state_enabled="true" /> <item /> </selector> data/res/anim/button_state_list_anim_material.xml 2dp + 6dp
137. <selector xmlns:android="http://schemas.android.com/apk/res/android"> <item android:state_pressed="true" android:state_enabled=“true” /> <!-- rest state --> <item android:state_enabled="true"> <set> <objectAnimator android:propertyName="translationZ" android:duration="@integer/button_pressed_animation_duration" android:valueTo="0" android:startDelay="@integer/button_pressed_animation_delay" android:valueType="floatType"/> <objectAnimator android:propertyName="elevation" android:duration="0" android:valueTo="@dimen/button_elevation_material" android:valueType="floatType" /> </set> </item> <item /> </selector> data/res/anim/button_state_list_anim_material.xml 2dp + 6dp 2dp
138. <selector xmlns:android="http://schemas.android.com/apk/res/android"> <item android:state_pressed="true" android:state_enabled=“true” /> <!-- rest state --> <item android:state_enabled="true"> <set> <objectAnimator android:propertyName="translationZ" android:duration="@integer/button_pressed_animation_duration" android:valueTo="0" android:startDelay="@integer/button_pressed_animation_delay" android:valueType="floatType"/> <objectAnimator android:propertyName="elevation" android:duration="0" android:valueTo="@dimen/button_elevation_material" android:valueType="floatType" /> </set> </item> <item /> </selector> data/res/anim/button_state_list_anim_material.xml 2dp + 6dp 2dp
139. <selector xmlns:android="http://schemas.android.com/apk/res/android"> <item android:state_pressed="true" android:state_enabled=“true” /> <!-- rest state --> <item android:state_enabled="true"> <set> <objectAnimator android:propertyName="translationZ" android:duration="@integer/button_pressed_animation_duration" android:valueTo="0" android:startDelay="@integer/button_pressed_animation_delay" android:valueType="floatType"/> <objectAnimator android:propertyName="elevation" android:duration="0" android:valueTo="@dimen/button_elevation_material" android:valueType="floatType" /> </set> </item> <item /> </selector> data/res/anim/button_state_list_anim_material.xml 2dp + 6dp 2dp
140. <selector xmlns:android="http://schemas.android.com/apk/res/android"> <item android:state_pressed="true" android:state_enabled=“true” /> <!-- rest state --> <item android:state_enabled=“true” /> <item /> </selector> data/res/anim/button_state_list_anim_material.xml 2dp + 6dp 2dp
141. <selector xmlns:android="http://schemas.android.com/apk/res/android"> <item android:state_pressed="true" android:state_enabled=“true” /> <!-- rest state --> <item android:state_enabled=“true” /> <item> <set> <objectAnimator android:propertyName="translationZ" android:duration="0" android:valueTo="0" android:valueType="floatType"/> <objectAnimator android:propertyName="elevation" android:duration="0" android:valueTo="0" android:valueType="floatType"/> </set> </item> </selector> data/res/anim/button_state_list_anim_material.xml 2dp + 6dp 2dp 0dp
142. <selector xmlns:android="http://schemas.android.com/apk/res/android"> <item android:state_pressed="true" android:state_enabled=“true” /> <!-- rest state --> <item android:state_enabled=“true” /> <item> <set> <objectAnimator android:propertyName="translationZ" android:duration="0" android:valueTo="0" android:valueType="floatType"/> <objectAnimator android:propertyName="elevation" android:duration="0" android:valueTo="0" android:valueType="floatType"/> </set> </item> </selector> data/res/anim/button_state_list_anim_material.xml 2dp + 6dp 2dp 0dp
143. <selector xmlns:android="http://schemas.android.com/apk/res/android"> <item android:state_pressed="true" android:state_enabled=“true” /> <!-- rest state --> <item android:state_enabled=“true” /> <item> <set> <objectAnimator android:propertyName="translationZ" android:duration="0" android:valueTo="0" android:valueType="floatType"/> <objectAnimator android:propertyName="elevation" android:duration="0" android:valueTo="0" android:valueType="floatType"/> </set> </item> </selector> data/res/anim/button_state_list_anim_material.xml 2dp + 6dp 2dp 0dp
144. Takeaways
145. Consistency first!
146. Don’t be afraid to deep dive
147. Buttons are alive!
148. Thanks! CC-by hisgett
