1. Leveraging Self-Supervised
   Contextual Language Models for
   Deep Neural Network Antibody
   CDR-H3 Loop Prediction
   David Jimenez & Nazim Medzhidov, Ph.D
   Elix Inc.
   27/10/2021


   View Slide

2. 2
   Introduction
   ● Antibodies are proteins of the immune system that can bind to a huge variety of antigens with high affinity and
   specificity.
   ● Antibody structure, particularly the structure of the Complementarity Determining Regions (CDRs), determines
   the strength of antigen recognition
   ● The knowledge of antibody 3D structure is important when designing/optimizing a therapeutic candidate
   Challenges:
   ● H3 CDR loop has crucial role in antigen binding, however its structure is observed in various conformations,
   making it the most challenging part of the antibody to model.
   ● Antibody realm has relatively scarce structure annotated data compared to general proteins, which makes difficult
   the training and generalization of models.


   View Slide

3. 3
   Recent progress
   ● DeepH3[1] is a neural network based on RaptorX
   (general protein structure prediction) used for antibody
   structure prediction.
   ● Predicts inter-residue distances and angles as 26
   discretized classes in the range:
   ○ Distance: [4Å, 16Å]
   ○ Omega and Theta: [-180°, 180°]
   ○ Phi: [0, 180°]
   ● Relatively shallow architecture to compensate for
   scarcity of structural annotated data.
   x3
   x21
   1D ResNet
   1D to 2D
   Transformation
   2D ResNet
   2D Conv 2D Conv 2D Conv 2D Conv
   Input
   Sequence
   d 𝜑 𝜃 𝜔
   N
   Cβ
   C
   Cɑ
   N
   Cβ
   C
   Cɑ
   N
   Cβ
   C
   Cɑ
   N
   Cβ
   C
   Cɑ
   ω
   d
   1
   2
   1
   2
   Θ
   12
   Θ
   21
   φ
   21
   φ
   12
   [1] Ruffolo J.A, et al., Bioinformatics (2020)


   View Slide

4. 4
   Can we improve an H3 loop predicting model’s
   performance by leveraging similar unlabeled datasets?


   View Slide

5. Antibody TRAnsformer Cdr - H3 (ATRACH3):
   ● Augment an antibody H3 loop structure prediction model with a language model, trained unsupervised
   on a large dataset of protein sequences.
   5
   Proposed Approach: ATRACH3
   Language Model
   (ESM-1B)
   H3 Loop
   Prediction Model
   (DeepH3)
   Input
   Protein
   Sequence
   Representation
   Space
   d
   𝜑
   𝜔
   𝜃
   Trained Unsupervised
   Trained Supervised
   Proxy Task


   View Slide

6. 6
   ATRACH3
   Antibody TRAnsformer Cdr - H3 (ATRACH3):
   ● Selected Language Model: ESM-1B[2]; Contextual language model trained unsupervised on large protein
   datasets to reconstruct sequences with masked amino acids.
   ○ While the model cannot observe protein structure directly, it observes patterns in the sequences which are
   determined by structure.
   ○ The model spans a representation space reflecting structural knowledge.
   ● Selected Antibody Structure Prediction Model: DeepH3; learns to predict the inter residue distance and
   angles.
   ○ It is “hooked” to the second-to-last layer of ESM-1B, which contains a richer representation, not only of the
   underlying amino acid sequence, but also encoded features relating to structural data.
   ● Datasets:
   ○ Unlabeled dataset: The UniProt Archive (UniParc)[3] with approximately 250 million sequences.
   ○ Labeled dataset: SAbDab[4] dataset containing all the structure-labeled antibody sequences in the Protein Data
   Bank. After pre-processing, 1433 sequences were selected.
   ○ Test Set: Rosetta antibody benchmark dataset[5] comprising of 49 curated antibody targets.
   [2] Rives A, et al., PNAS (2020) [3] Leinonen R, et al., Bioinformatics (2004) [4] Dunbar J, et al., Nucleic Acids Res. (2014) [5] Marze N.A, et al., Prot. Eng. Des. Selection (2016)


   View Slide

7. 7
   Label Imbalance and Focal Loss
   Distance Label Distribution
   4Å 10Å 16Å
   Omega Label Distribution
   -180 0 180
   Theta Label Distribution
   -180 0 180
   Phi Label Distribution
   0 90 180
   Label distribution
   histograms
   DeepH3 trained with Cross
   Entropy Loss VS Focal Loss
   *CCC; Circular Correlation Coefficient


   View Slide

8. 8
   Results with 95:5 (Training Set: Validation Set) Ratio
   DeepH3 trained with focal loss was compared with the
   results of ATRACH3 trained with focal loss
   ATRACH3 improved 1.16%, 10.9%, 3.66%, and 6.45% in
   Distance, Omega, Theta and Phi, respectively.
   On average it improved 4.9% over DeepH3 trained on the
   same conditions.
   *CCC; Circular Correlation Coefficient


   View Slide

9. 9
   Can the unsupervised training on a large protein data
   compensate on the H3 loop prediction task with fewer data?


   View Slide

10. 10
    ATRACH3 Performance with fewer data
    To test the efficacy of ATRACH3 in reduced data situations we further reduced the available training set size to:
    95%, 90%, 80%, 66%, 50% and 33% of the original training set as follows:
    Antibody Annotated Structure Dataset


    View Slide

11. 11
    Results on Test Set with reduced training data points


    View Slide

12. 12
    Summary and Future Directions
    Findings:
    ● Using Focal loss improved baseline performance (DeepH3)
    ● Focal loss was used in ATRACH3
    ● Extending DeepH3 to leverage a similar dataset using unsupervised learning improved inter-residue angles
    and distance predictions for antibody H3-loop
    ● When trained with datasets of a smaller size, ATRACH3 was able to outperform the baseline on all 4 tasks.
    Furthermore the performance of ATRACH3 seems to decrease less rapidly when the data is reduced,
    compared to DeepH3.
    Future Directions:
    ● Investigate ATRACH3 performance when trained unsupervised on a focused dataset of antibody sequences


    View Slide
