  1. Eric Holscher Django Under The Hood November 6, 2015 Understanding

    Documentation Systems
  2. Who am I • Co-Founder of Read the Docs •

    Co-Founder of Write the Docs
  3. Today • Learn about Docutils/RST internals • Learn how Sphinx

    builds on top & extends RST • Understand how Django uses these tools, and how you can too
  4. Documentation Systems

  5. Sphinx • Extends RST with additions for documenting so ware

    • Has powerful semantic constructs
  6. Semantic Meaning • The power of HTML, and RST •

    What something is, not what it looks like • Once you know what it is, you can display it properly • Separation of Concerns
  7. # HTML (Bad) <b>issue 72</b> # HTML (Good) <span class=“issue”>issue

    72</span> # CSS .issue { text-format: bold; } Classic HTML Example
  8. # Bad <font color=“red”>Warning: Don’t do this!</font> # Good <span

    class=“warning”>Don’t do this!</span> # Best .. warning:: Don’t do this Classic RST Example
  9. # Markdown Check out [PEP 8](https:// www.python.org/dev/peps/pep-0008/) # RST Check

    out :pep:`8` Markdown vs. RST
  10. Semantic Markup shows the intent of your words

  11. +----------------------------------------------------------+ | | | Read the Docs | | +----------------------------------------------+

    | | | | | | | Sphinx | | | | +-----------------------------------+ | | | | | | | | | | | Docutils | | | | | | +--------------------+ | | | | | | | | | | | | | | | reStructuredText | | | | | | | | | | | | | | | +--------------------+ | | | | | | | | | | | | | | | | | | | | | | | +-----------------------------------+ | | | | | | | | | | | | | | | +----------------------------------------------+ | | | | | +----------------------------------------------------------+ Tech Overview
  12. Docutils

  13. Parts • Reader • Parser • Transformer • Writer

  14. How it fits together

  15. Reader • Get input and read it into memory •

    Quite simple, generally don’t need to do much
  16. Title ===== Paragraph. Words that have **bold in them**. Reader

    Example
  17. [u'Title', u'=====', u'', u'Paragraph.', u'', u'Words that have **bold in

    them**.'] Reader Example
  18. Reader’s are useful for adding non-filesystem types of input (StringIO,

    Network)
  19. Parser • Takes the input and actually turns it into

    a Doctree • RST is the only parser implemented in Docutils • Handles directives, inline markup, etc. • Implemented with a lined-based recursive state machine
  20. Doctree • AST for Docutils • Source of Truth •

    Tree structure with a document at the root node • Made up of a series of Nodes
  21. [u'Title', u'=====', u'', u'Paragraph.', u'', u'Words that have **bold in

    them**.'] Parser Example
  22. <document ids="title" names="title" source="test.rst" title="Title"> <title> Title <paragraph> Paragraph. <paragraph>

    Words that have <strong> bold in them Parser Example
  23. Nodes • Structural Elements •document, section, sidebar • Body Elements

    • paragraph, image, note • Inline Elements •emphasis, strong, subscript
  24. Nodes • Most common types of nodes are Text Nodes

    •nodes.paragraph(rawsource, nodes_or_text)
  25. RST Directives • Allow block level extension of RST •..

    note:: Foo = [<Note> Node]
  26. RST Interpreted Text Roles • Allows paragraph level extension of

    RST •:pep:`8` = [<Reference> Node]
  27. RST Parser • Really neat language • Some directives are

    tied to RST because of internal, recursive parsing
  28. .. note:: Wootles *blog* <note> <paragraph> Wootles <emphasis> blog RST

    Parser
  29. RST Parser • Recursively parses RST inside nodes • Python

    objects not portable • Need to think about how to port this to other parsers in the future
  30. RST lets you create arbitrary markup that matches the semantics

    of your problem space
  31. Parsers are used for implementing new RST features or adding

    new markup languages
  32. Transformer • Take the doctree and modify it in place

    • Allows for “full knowledge” of the content • Table of Contents • Generally implemented by traversing nodes of a certain type
  33. <document ids="title" names="title" source="test.rst" title="Title"> <title> Title <paragraph> Paragraph. <paragraph>

    Words that have <strong> bold in them Transform Example
  34. <document ids="title" names="title" source="test.rst" title="Title"> <title> Title <paragraph> Words that

    have <strong> bold in them <paragraph> Paragraph. Transform Example
  35. Transformers are used for changing the document in a way

    that requires full knowledge
  36. Writer • Takes the Doctree and writes it to actual

    files • HTML, XML, PDF, etc. • Translator does most of the work • Implemented with the Visitor pattern
  37. Visitor • Allows you to have arbitrary types of node’s

    and build `visit_` methods a er the fact • Generally a Directive creates an arbitrary Node type, which is converted by the Translator
  38. class MyHTMLVisitor(nodes.GenericNodeVisitor): def visit_foo(self, node): self.body.append(‘<div class=“foo”>’) def depart_foo(self, node):

    self.body.append('</div>\n') Translator
  39. <document ids="title" names="title" source="test.rst" title="Title"> <title> Title <paragraph> Words that

    have <strong> bold in them <paragraph> Paragraph. Writer Example
  40. <div class="document" id="title"> <h1 class="title">Title</h1> <p>Words that have <em>bold in

    them</em>.</p> <p>Paragraph.</p> </div> Writer Example
  41. Writers are used to change or add new output formats

    from the Doctree
  42. How it fits together

  43. Implementation

  44. # docutils/core.py self.document = self.reader.read(self.source, self.parser, self.settings) self.apply_transforms() self.writer.write(self.document, self.destination)

    Publisher
  45. # docutils/core.py self.document = self.reader.read(self.source, self.parser, self.settings) self.apply_transforms() self.writer.write(self.document, self.destination)

    Publisher
  46. # docutils/readers/__init__.py def read(self, source, parser, settings): self.source = source

    if not self.parser: self.parser = parser self.settings = settings self.input = self.source.read() document = self.new_document() self.parse(self.input, document) return document Reader
  47. # docutils/readers/__init__.py def read(self, source, parser, settings): self.source = source

    if not self.parser: self.parser = parser self.settings = settings self.input = self.source.read() document = self.new_document() self.parse(self.input, document) return document Reader
  48. # docutils/readers/__init__.py def parse(self, inputstring, document): """Parse `inputstring` and populate

    `document`, a document tree.""" self.statemachine = states.RSTStateMachine( state_classes=self.state_classes, initial_state=self.initial_state) inputlines = docutils.statemachine.string2lines( inputstring) self.statemachine.run(inputlines, document) RST Parser
  49. # docutils/core.py self.document = self.reader.read(self.source, self.parser, self.settings) self.apply_transforms() self.writer.write(self.document, self.destination)

    Publisher
  50. # docutils/core.py def apply_transforms(self): self.document.transformer.populate_from_components( (self.source, self.reader, self.reader.parser, self.writer, self.destination))

    self.document.transformer.apply_transforms() Transforms
  51. # docutils/core.py def apply_transforms(self): self.document.transformer.populate_from_components( (self.source, self.reader, self.reader.parser, self.writer, self.destination))

    self.document.transformer.apply_transforms() Transforms
  52. # docutils/transforms/__init__.py def apply_transforms(self): """Apply all of the stored transforms,

    in priority order.""" while self.transforms: priority, transform_class, pending, kwargs = self.transforms.pop() transform = transform_class(self.document, startnode=pending) transform.apply(**kwargs) Transforms
  53. # docutils/core.py self.document = self.reader.read(self.source, self.parser, self.settings) self.apply_transforms() self.writer.write(self.document, self.destination)

    Publisher
  54. Writer # docutils/writers/__init__.py def write(self, document, destination): self.translate() output =

    self.destination.write(self.output) return output
  55. Writer # docutils/writers/__init__.py def write(self, document, destination): self.translate() output =

    self.destination.write(self.output) return output
  56. # docutils/writers/html4css1/__init__.py def translate(self): visitor = self.translator_class(self.document) self.document.walkabout(visitor) self.output =

    self.apply_template() Translator
  57. # docutils/core.py self.document = self.reader.read(self.source, self.parser, self.settings) self.apply_transforms() self.writer.write(self.document, self.destination)

    Publisher
  58. We now have an HTML (or whatever Writer) document on

    the disk
  59. Sphinx Implementation

  60. Sphinx • Builds on top of the standard docutils concepts

    • Add it’s own abstractions, but uses the same docutils machinery underneath
  61. Sphinx Architecture

  62. Major Sphinx Components • Application • Environment • Builder

  63. Sphinx Application • Main level of orchestration for Sphinx •

    Handles configuration & building • Sphinx()
  64. Sphinx Environment • Keeps state for all the files for

    a project • Serialized to disk in between runs • Works as a cache
  65. Sphinx Builder • Wrapper around Docutils Writer’s • Generates all

    types of outputs • Generates most HTML output through Jinja templates instead of Translators
  66. Sphinx Architecture

  67. Typical Sphinx Run

  68. make html

  69. sphinx-build -b html -d _build/environment . _build/html

  70. # sphinx/application.py app = Sphinx(srcdir, confdir, outdir, doctreedir, opts.builder, confoverrides,

    status, warning, opts.freshenv, opts.warningiserror, opts.tags, opts.verbosity, opts.jobs) app.build(opts.force_all, filenames) Sphinx
  71. # sphinx/application.py app = Sphinx(srcdir, confdir, outdir, doctreedir, opts.builder, confoverrides,

    status, warning, opts.freshenv, opts.warningiserror, opts.tags, opts.verbosity, opts.jobs) app.build(opts.force_all, filenames) Sphinx
  72. # sphinx/application.py def build(self, force_all=False, filenames=None): self.builder.compile_all_catalogs() self.builder.build_all() Sphinx Application

  73. # sphinx/application.py def build(self, force_all=False, filenames=None): self.builder.compile_all_catalogs() self.builder.build_all() Sphinx Application

  74. # sphinx/builders/__init__.py def build_all(self, docnames, summary=None, method='update'): # Read files

    from disk and put them in the env updated_docnames = set(self.env.update(self.config, self.srcdir, self.doctreedir, self.app)) # Write the actual output to disk self.write(docnames, list(updated_docnames), method) Sphinx Builder
  75. # sphinx/builders/__init__.py def build_all(self, docnames, summary=None, method='update'): # Read files

    from disk and put them in the env updated_docnames = set(self.env.update(self.config, self.srcdir, self.doctreedir, self.app)) # Write the actual output to disk self.write(docnames, list(updated_docnames), method) Sphinx Builder
  76. # sphinx/environment.py def update(self, config, srcdir, doctreedir, app): reader =

    SphinxStandaloneReader(parsers=self.config.source_parsers) pub = Publisher(reader=reader, writer=SphinxDummyWriter(), destination_class=NullOutput) source = SphinxFileInput(app, self, source=None, source_path=src_path, encoding=self.config.source_encoding) pub.publish() doctree = pub.document doctree_filename = self.doc2path(docname, self.doctreedir, '.doctree') dirname = path.dirname(doctree_filename) if not path.isdir(dirname): os.makedirs(dirname) f = open(doctree_filename, 'wb') pickle.dump(doctree, f, pickle.HIGHEST_PROTOCOL) Sphinx Environment
  77. # sphinx/builders/__init__.py def build_all(self, docnames, summary=None, method='update'): # Read files

    from disk and put them in the env updated_docnames = set(self.env.update(self.config, self.srcdir, self.doctreedir, self.app)) # Write the actual output to disk self.write(docnames, list(updated_docnames), method) Sphinx Builder
  78. # sphinx/builders/html.py def write(self, build_docnames, updated_docnames, method=‘update'): for docname in

    list(build_docnames + updated_docnames): self.docwriter.write(doctree, destination) self.docwriter.assemble_parts() body = self.docwriter.parts['fragment'] metatags = self.docwriter.clean_meta ctx = self.get_doc_context(docname, body, metatags) self.handle_page(docname, ctx, event_arg=doctree) Sphinx Builder
  79. # sphinx/builders/html.py def write(self, build_docnames, updated_docnames, method=‘update'): for docname in

    list(build_docnames + updated_docnames): self.docwriter.write(doctree, destination) self.docwriter.assemble_parts() body = self.docwriter.parts['fragment'] metatags = self.docwriter.clean_meta ctx = self.get_doc_context(docname, body, metatags) self.handle_page(docname, ctx, event_arg=doctree) Sphinx Builder
  80. # docutils/writers/__init__.py def write(self, document, destination): self.translate() output = self.destination.write(self.output)

    Docutils Writer
  81. # docutils/writers/__init__.py def write(self, document, destination): self.translate() output = self.destination.write(self.output)

    Docutils Writer
  82. # sphinx/writers/html.py def translate(self): visitor = self.builder.translator_class( self.builder, self.document) self.document.walkabout(visitor)

    self.output = visitor.astext() Sphinx Writer
  83. # sphinx/builders/html.py def write(self, build_docnames, updated_docnames, method=‘update'): for docname in

    list(build_docnames + updated_docnames): self.docwriter.write(doctree, destination) self.docwriter.assemble_parts() body = self.docwriter.parts['fragment'] metatags = self.docwriter.clean_meta ctx = self.get_doc_context(docname, body, metatags) self.handle_page(docname, ctx, event_arg=doctree) Sphinx Builder
  84. # sphinx/builders/html.py def write(self, build_docnames, updated_docnames, method=‘update'): for docname in

    list(build_docnames + updated_docnames): self.docwriter.write(doctree, destination) self.docwriter.assemble_parts() body = self.docwriter.parts['fragment'] metatags = self.docwriter.clean_meta ctx = self.get_doc_context(docname, body, metatags) self.handle_page(docname, ctx, event_arg=doctree) Sphinx Builder
  85. # sphinx/builders/html.py def handle_page(self, pagename, addctx, templatename='page.html'): ctx = self.globalcontext.copy()

    output = self.templates.render(templatename, ctx) f = codecs.open(outfilename, 'w', encoding, 'xmlcharrefreplace') f.write(output) Sphinx Builder
  86. We now have a fully templated HTML file on disk

  87. Sphinx Core Events allow you to hook into most parts

    of the build process
  88. Sphinx Core Events • builder-inited • source-read • doctree-read •

    doctree-resolved • env-updated • html-page-context • build-finished
  89. Sphinx Architecture

  90. Examples

  91. Markdown Parser • Uses recommonmark as a bridge • Translates

    Commonmark Node’s into Docutils Node’s
  92. ## Markdown Header Hey There Markdown Parser

  93. <document source="example.md" title="Markdown Header"> <title> Markdown Header <paragraph> Hey There

    Markdown Parser
  94. # recommonmark/parser.py def reference(block): # Commonmark Block ref_node = nodes.reference()

    # Docutils Node label = make_refname(block.label) ref_node['name'] = label ref_node['refuri'] = block.destination ref_node['title'] = block.title return ref_node Markdown Parser
  95. from recommonmark.parser import CommonMarkParser source_parsers = { '.md': CommonMarkParser, }

    source_suffix = ['.rst', '.md'] Enable Markdown
  96. :name[content]{key=val} :smallcaps[content] :ref[scatter plot]{target=myFigure} Proposed Markdown Inline Markup

  97. ::: name [inline-content] {key=val} contents, can contain further block elements

    ::: :::eval [label] {.python} x = 1+1 print x ::: Proposed Markdown Block level Markup
  98. Table of Contents • Enabled with `.. contents::` Directive •

    Adds a pending node during parsing • Transform turns pending into a list of references
  99. .. contents:: TOC Getting Started ——————————————— Table of Contents

  100. <topic classes="contents" ids="toc" names="toc"> <title> TOC <pending> .. internal attributes:

    .transform: docutils.transforms.parts.Contents .details: Table of Contents
  101. <topic classes="contents" ids="toc" names="toc"> <title> TOC <bullet_list> <list_item> <paragraph> <reference

    ids="id1" refid="getting-started"> Getting Started Table of Contents
  102. References • Allow you to define and point at arbitrary

    points in documents • Sphinx makes them work across an entire project
  103. .. page 1 .. _my-title: Title ----- Paragraph .. page

    2 Look at the :ref:`my-title`. References
  104. <reference internal="True" refname="my-title"> References

  105. <reference internal="True" refuri=“page-1#my-title”> References

  106. Intersphinx • Allows you to link across Sphinx projects, semantically

    •:ref:`django:template-loaders`
  107. intersphinx_mapping = { 'python': ('http://python.readthedocs.org/en/latest/', None), 'django17': ('http://django.readthedocs.org/en/1.7/', None), 'django18':

    (‘http://sphinx.readthedocs.org/en/1.8/', None), } Intersphinx
  108. Reference Resolution Order • References • Domains • Intersphinx References

    • Intersphinx Domains
  109. How Django uses Sphinx

  110. Django Deployment • All documentation is written in RST •

    HTML generated at JSON blobs • Rendered through Django templates on the website
  111. :ticket:`1325` :setting:`MEDIA_URL` Django specific additions

  112. .. snippet:: :filename: part1.py print “hello world” Django specific additions

  113. def ticket_role(name, rawtext, text, lineno, inliner): num = int(text.replace('#', ''))

    url_pattern = inliner.document.settings.env.app.config.ticket_url url = url_pattern % num node = nodes.reference(rawtext, '#' + utils.unescape(text), refuri=url) return [node], [] Ticket Role
  114. class snippet_with_filename(nodes.literal_block): pass Snippet Node

  115. class SnippetWithFilename(Directive): has_content = True optional_arguments = 1 option_spec =

    {'filename': directives.unchanged_required} def run(self): code = '\n'.join(self.content) literal = snippet_with_filename(code, code) if self.arguments: literal['language'] = self.arguments[0] literal['filename'] = self.options['filename'] set_source_info(self, literal) return [literal] Snippet Directive
  116. def visit_snippet(self, node): lang = self.highlightlang fname = node['filename'] highlighted

    = highlighter.highlight_block(node.rawsource) starttag = self.starttag(node, 'div', suffix='', CLASS='highlight-%s' % lang) self.body.append(starttag) self.body.append('<div class="snippet-filename">%s</div>\n' % (fname,)) self.body.append(highlighted) self.body.append('</div>\n') raise nodes.SkipNode Snippet visitor
  117. These are generally useful for Django users, and should probably

    be released as a third party app
  118. Take Aways

  119. Make sure to use semantic markup when writing docs

  120. Generally your job is to get the nodes to exist

    in the way that you want
  121. Feel empowered to extend RST & Sphinx, and make them

    your own
  122. Understand where you need to plug into the pipeline, and

    do as little as possible to make it happen
  123. Thanks • @ericholscher • eric@ericholscher.com • Come talk to me

    around the sprints
